MICRO-EPSILON surfaceCONTROL SC2500 Operating Instructions Manual page 40

Appendix | GenICam surfaceCONTROL Parameters | Version 1.5
Name
EventErrorCode
EventErrorMessage
User Set Control
UserSetSelector
UserSetLoad[UserSetSelector]
UserSetSave[UserSetSelector]
UserSetDefault
DigitalIO Control
LineSelector
LineMode[LineSelector]
LineInverter[LineSelector]
LineStatus[LineSelector]
LineStatusAll
LineSource[LineSelector]
surfaceCONTROL 3D SC2500 / SC2510
Description
Returns an error code for
the error(s) that hap-
pened.
Returns a detailed mes-
sage for the error.
Selects the feature User
Set to load, save or config-
ure. Default = factory
settings
Loads the User Set speci-
fied by UserSetSelector to
the device and makes it
active.
Save the User Set speci-
fied by UserSetSelector to
the non-volatile memory of
the device.
Selects the feature User
Set to load and make
active by default when the
device is reset.
Default = factory settings
Selects the physical line
(or pin) of the external
device connector or the
virtual line of the Transport
Layer to configure.
Controls if the physical
Line is used to Input or
Output a signal.
Controls the inversion of
the signal of the selected
input or output Line.
Returns the current status
of the selected input or
output Line.
Returns the current status
of all available Line signals
at time of polling in a sin-
gle bitfield.
Selects which internal
acquisition or I/O source
signal to output on the
selected Line.
Documentation Text
This parameter returns the defect type for a measuring error. The
following error codes are possible:
- 1: Error Sensor Hardware: An error occurred in a hardware compo-
nent in the sensor. Contact Micro-Epsilon.
- 2: Error Sensor Acquisition: An error occurred during data acquisition
in the sensor. Contact Micro-Epsilon.
- 3: Error 3D Reconstruction: The 3D reconstruction could not be
calculated.
- 9: Error Critical Temperature: As temperatures are too high, further
measurements are prevented.
In addition to the error type, an additional description of the measuring
error is returned if necessary.
Selects the user settings function for loading, saving or configuring.
Here, Default means default settings.
Loads the user setting specified by ""UserSetSelector"" into the sen-
sor and enables it.
Saves the user setting specified by ""UserSetSelector"" to the
sensor.
Selects the user setting that is loaded and enabled by default
when the sensor is reset. Here, Default means factory settings.
Selection of the GPIO port to be configured.
Defines whether the selected GPIO port is an input or output.
Enables inverting of the input or output signal for the selected
GPIO port.
Queries the status of the selected GPIO port.
Outputs the current status of all digital in-/outputs.
Selects the internal source for the output signal of the selected GPIO
port.
Page 40
