Initial Operation - MICRO-EPSILON surfaceCONTROL SC2500 Operating Instructions Manual

Installation and Assembly
5.6

Initial Operation

The sensor and the controller may only be connected to peripherals when they do not carry power,
that is, only when the supply voltage has been switched off.
Mount the sensor according to the assembly instructions, see
Mount the controller as per the assembly instructions, see
Connect the sensor and the controller to the cable harness included in the delivery, see
Connect the controller to the PC. To do so, use a common Ethernet cable of category CAT5e or higher.
Connect the sensor to the power supply, see
Connect the controller to the power supply, see
surfaceCONTROL 3D SC2500 / SC2510
Chap. 5.1.
Chap. 5.3.
Chap. 5.4.2.2.
Chap. 5.4.3.2.
Chap. 5.4.1.
Page 22
