DTP port
The DTP input port is compatible with Extron XTP DTP 24 SF/UTP cables.
ATTENTION:
• Do not connect this port to a computer data or telecommunications network.
• Ne connectez pas ces port à des données informatiques ou à un réseau de
télécommunications.
•
Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201
cable to link the encoder to Extron DTP products.
• N'utilisez pas le câble AV Skew-Free UTP version améliorée UTP23SF d'Extron
ou le câble STP201 pour relier la grille de commutation avec des produits DTP
d'Extron.
• To ensure FCC Class A and CE compliance, STP cables and STP connectors are
required.
• Afin de s'assurer de la compatibilité entre FCC Classe A et CE, les câbles STP et
les connecteurs STP sont nécessaires.
Extron recommends using the following practices to achieve full transmission distances up
to 330 feet (100 m) and reduce transmission errors.
• Use the following Extron XTP DTP 24 cables and connectors for the best performance:
• XTP DTP 24/1000
XTP DTP 24P/1000 Plenum 1000' (305 m) spool
•
• XTP DTP 24 Plug
• If you are not using XTP DTP 24 cable, Extron recommends, at a minimum, using
24 AWG, solid conductor, STP cable with a minimum bandwidth of 400 MHz.
• Terminate cables with shielded connectors to the TIA/EIA-T568B standard as straight-
through (patch) cables only (see
• Limit the use of more than two pass-through points, which may include patch points,
punch down connectors, couplers, and power injectors. If these pass-through points
are required, use CAT 6 or 6a shielded couplers and punch down connectors.
NOTE: When using cable in bundles or conduits, consider the following:
• Do not exceed 40% fill capacity in conduits.
• Do not comb the cable for the first 65 feet (20 meters), where cables are
straightened, aligned, and secured in tight bundles.
• Loosely place cables and limit the use of tie wraps or hook and loop fasteners.
• Separate twisted pair cables from AC power cables.
Non-Plenum 1000' (305 meter) spool
Package of 10
figure 3 on page 7).
NAV E 101 DTP Encoder • Installation and Basic Operation
22-236-03
22-235-03
101-005-02
