A DTP IN input (see figure 2
between a compatible Extron DTP transmitting device and this RJ-45
connector (see TP connectors
and for detailed NOTES).
Signal LED indicator — Lights green when the encoder is receiving a
video signal.
Link LED indicator — Lights yellow when a device is connected and communication
is established.
NOTE: The encoder can supply power to the connected DTP transmitter via power
over DTP.
B HDMI Output port — Connect a display to this female HDMI
connector for local loop-through monitoring of the source signal (see
HDMI connector on page 9 to use the LockIt HDMI Cable Lacing
Bracket to secure the connector to the encoder).
C NAV 1G port— Connect to an Ethernet LAN on which one or more
decoders also reside for streaming, and control( see
page 7 to properly wire the connector and for detailed NOTES).
Act (amber) LED — Indicates transmission of data packets on the
RJ-45 connector. This LED blinks as the encoder communicates.
Link (green) LED — Indicates that the encoder is properly connected
to an Ethernet LAN. This LED lights steadily.
D
RESET button and LED
encoder reset. For the different reset levels, press and hold the button while the
encoder is running or while you power up the encoder (see
on page 12 for details).
E Power connector — Plug a standard IEC power cord into this
connector to connect the encoder to a 100 VAC to 240 VAC,
50 or 60 Hz power source.
on page 5) — Connect an STP cable
on page 7 to properly wire the connector
— The RESET button initiates three modes of
