Emerson Centellis 2000 Shelf Release 3.0 Manual page 137

socket_type = dgram
wait = yes user = root
log_on_success += USERID
log_on_failure += USERID
server_args = -vvv /tftpboot
disable = no
protocol = udp
}
2. Enter the following command to have xinetd reread its configuration file:
/etc/rc.d/init.d/xinetd restart
3. If there are any TFTP daemons that have not timed out, you must stop them. To do
so, enter the following command:
killall in.tftpd
Your TFTP server is now configured.
Providing Linux Kernel and initial ramdisk
To provide Linux kernel and initial ramdisk, proceed as follows:
1. Copy the pxelinux bootloader to the /tftpboot directory.
2. Create a blade specific directory, e.g. /tftpboot/<board-dir>, and copy the
Linux kernel and the initial ramdisk for the boards to this directory.
3. Create a directory /tftpboot/pxelinux.cfg. Change to this directory and
create a file named default.<boardname> which will contain the board specific
boot line parameters, for example,
/tftpboot/pxelinux.cfg/default.ATCA7150 DEFAULT <board-
dir>/kernel ramdisk_size=... console=ttyS0,<baudrate>
initrd=<board-dir>/ramdisk.image.gz root=/dev/ram0 ip=none
rw ...
4. In the /tftpboot/pxelinux.cfg directory, create a softlink for the blade's
MAC address to the default.<boardname> file:
ln –s default.<boardname> <MAC address with leading 01 and
"–" as delimiter>
Centellis 2000 Shelf Release 3.0 Installation and Use (6806800L99F)
DHCP Configuration and Network Boot
137
