Operation
2. Remove both securing bolts (6.1).
3. Place the suction plate (6) on the main body (7). If
the suction plates are heavy, use a suitable lifting aid.
4. Fasten the suction plate (6) to the main body (7) with
the two securing bolts (6.1).
5. Turn both securing bolts (6) in the direction of the ar-
rows so that the overhang is secured behind the
mounting bracket.
6. Make sure that both securing bolts cannot be pulled
out.
