Product description

3.6 Optional accessories

Optional accessories: Wheelset and handle extension

3.6.1 Wheelset SH-2500-RS

The wheelset SH-2500-RS makes it possible to expand the operating range of the lifting device.
The wheelset is comprised of two attachable wheels (Ø 300 mm) and a hinged support with swivel castors.
The wheelset can be easily retrofitted onto the base device SH.

3.6.2 Handle extension SH-2500-HGV

The handle extension is recommended when the positioning units are wider than 1 meter. This keeps the employees feet
at a safe distance from the load.

3.6.3 Beam for multiple suction plates

The beam makes it possible to install 2 or 3 suction plates.
52400046 / 52400048
19 / 58
