Removing The Bluetooth Module - EUROCOM TN120T Service Manual

Disassembly

Removing the Bluetooth Module

Figure 12
Bluetooth Removal
1. Turn off the computer, remove the battery
2. The Bluetooth module will be visible at point
a. Remove the cover and
3. Remove screw
locate the Bluetooth
4. Carefully disconnect the cable
module.
5. Lift the Bluetooth module
b. Remove the screw.
c. Disconnect the cable
and seperate the con-
a.
nector.
d. Lift the Bluetooth module
out.
b.
5. Bluetooth Module
• 1 Screw
2 - 16 Removing the Bluetooth Module
