Removing the Optical (CD/DVD) Device

1. Turn off the computer, remove the battery
2. Remove the screw at point
3. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The
screw holes should line up.
4. Insert the new device and replace the optical device screw
5. Reconnect the fan cable before replacing the bay cover (
6. Replace the bay cover and screws.
7. Restart the computer to allow it to automatically detect the new device.
a.
1
All manuals and user guides at all-guides.com
(page 2 -
5), and the CPU/RAM bay cover
, and use a screwdriver to carefully push out the optical device at point
1
1
(page 2 -
.
in
Figure 6 on page 2 -
10).
5
b.
3
Removing the Optical (CD/DVD) Device 2 - 17
Disassembly
Figure 13
Optical Device
.
10)
Removal
.
2
a. Remove the cover and
locate the screw.
b. Remove the screw and
push the optical device
out off the computer at
point 2 and remove the
optical device.
2
3. Optical Device
• 1 Screw
