3. When the screws are loosened sufficiently, carefully lift up the heat sink
4. Turn the release latch
towards the unlock symbol
5
5. Carefully (it may be hot) lift the CPU
6. When re-inserting the CPU, pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!).
c.
e.
All manuals and user guides at all-guides.com
, to release the CPU
6
up out of the socket
(Figure
d.
4
Unlock
The heat sink, and CPU area in
6
general, contains parts which are
subject to high temperatures. Allow
the area time to cool before remov-
ing these parts.
(Figure
c) off the computer.
4
(Figure
d).
e).
5
Lock
7
Caution
Disassembly
Figure 9
Processor Removal
Sequence
c. Remove the heat sink.
d. Turn the release latch to
unlock the CPU.
e. Lift the CPU out of the
socket.
5
4. Heat Sink
6. CPU
Removing the Processor 2 - 13
