Removing the 3G Module

1. Turn off the computer, remove the battery
2. The 3G module will be visible at point
3. Carefully disconnect cable
2
4. The 3G module
will pop-up.
4
(
5. Lift the 3G module
Figure d
a.
b.
2
3
All manuals and user guides at all-guides.com
(page 2 -
5) and the hard disk
under the hard disk.
1
, then remove the screw
from the module socket.
3
)
up and off the computer.
c.
1
d.
(page 2 -
6).
4
4
Removing the 3G Module 2 - 9
Disassembly
Figure 5
3G Removal
a. Remove the hard disk
b. Disconnect the cable
and remove the screw.
c. The 3G module will pop
up.
d. Remove the 3G mod-
ule.
Note: Make sure you
reconnect the antenna
cable to the "Main"
socket
(Figure
b).
4. 3G Module
• 2 Screws
