EUROCOM 1800N Road Warrior User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1800N Road Warrior and is the answer not in the manual?

Questions and answers

Related Manuals for EUROCOM 1800N Road Warrior

Summary of Contents for EUROCOM 1800N Road Warrior

  • Page 2 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no re- sponsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 3: Trademarks

    Preface Trademarks This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intel- lectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home or other limited viewing uses only unless otherwise authorized by Mac- rovision Corporation.

  • Page 4: Federal Communications Commission (Fcc) Statement

    Preface Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits Warning for a Class B digital device, pursuant to Part 15 of the FCC Rules. Use only shielded ca- These limits are designed to provide reasonable protection against bles to connect I/O de- harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swim- ming pool.
  • Page 6 Preface IMPORTANTES MESURES DE SÉCURITÉ Certaines mesures de sécurité doivent être prises pendant l’utilisa- tion de matérial téléphonique afin de réduire les risques d’incendie, de choc électrique et de blessures. En voici quelquesunes: Ne pas utiliser l’appareil près de l’eau,, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à...

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To ensure that does not happen, follow these suggestions: 1. Don’t drop it. Make sure it’s on a stable surface. If the compu- ter falls, the case and other components could be damaged.
  • Page 8 Preface 5. Follow the proper working procedures for computer. Do not turn off the computer until you properly shutdown all pro- grams. Do not turn off any peripheral devices when the compu- ter is on. Do not disassemble the computer by yourself. Remember to periodically save your data as data may be lost if the battery is depleted.

  • Page 9: Power Safety

    Preface Power Safety. The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company.

  • Page 10: Battery Precautions

    Preface Battery Precautions Only use batteries designed for this computer • . The wrong battery Battery Disposal type may explode, leak or damage the computer. The product that you • Recharge the batteries using the notebook’s system. Incorrect recharg- have purchased con- ing may make the battery explode.

  • Page 11: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may vio- late your warranty and expose you and the computer to electric shock.

  • Page 12: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: 1. Check that the battery pack and any spares are fully charged. 2. Power off the computer and peripherals. 3.
  • Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 7: Troubleshooting, keep these points in mind: Hand-carry the notebook. For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 14 Preface Fly safely. Most airlines have regulations about the use of computers and other electronic devices in flight. These restrictions are for your safety, fol- low them. If you stow the notebook in an overhead compartment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
  • Page 15 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 16 Preface Remember to: • Alter your posture frequently. • Stretch and exercise your body several times a day. • Take periodic breaks when you work at the computer for long periods of time. Frequent and short breaks are better than fewer and longer breaks.
  • Page 17 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead light- ing or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly.

  • Page 18: Table Of Contents

    Preface Contents Notice ....................I Trademarks ..................II Federal Communications Commission (FCC) Statement .....III Instructions for Care and Operation ..........VI Power Safety................VIII Battery Precautions ...............IX Cleaning ..................X Servicing ..................X Travel Considerations ..............XI Introduction ........... 1-1 Overview ..................1-1 The Manual ..................1-2 System Software ................1-2 Advanced Users ................1-3 Beginners and Not-So-Advanced Users ........1-3...
  • Page 19 Preface Getting To Know Your Computer ..........1-6 Top View With LCD Display Closed .......... 1-7 Front With LCD Panel Open ............1-8 LCD Panel ................... 1-9 Close Cover Switch ..............1-9 LED Status Indicators ..............1-9 Power Button ................1-10 Built-In Microphone ..............
  • Page 20 Preface External IDE Port ...............1-16 Mini - IEEE 1394 Port ...............1-16 PC Card Slot ................1-16 Right Side View .................1-17 Hard Disk Drive .................1-18 Dual USB Ports ................1-18 RJ-11 Phone Jack ...............1-19 RJ-45 LAN Jack .................1-19 Vent ....................1-19 Rear View ...................1-20 Security Lock ................1-20 Bottom View ................1-21 Peripheral Devices ..............1-22...
  • Page 21 Preface LED Indicators ................2-6 LED Status Indicators ..............2-7 LED Power Indicators ..............2-8 LED Communication Indicators ..........2-8 The Hard Disk Drive (HDD) ............2-9 The External IDE Device ............2-10 Bay Manager ................2-11 The Floppy Disk Drive (FDD) ..........2-12 Inserting/Removing Floppy Disks ..........
  • Page 22 Preface Configuring The TouchPad and Buttons ........2-25 Mouse ..................2-26 Adding a Printer .................2-27 USB Printer ................2-27 Install Instructions: ..............2-27 Parallel Printer ................2-28 Install Instructions: ..............2-28 Advanced Controls ........ 3-1 Overview ..................3-1 Advanced Video Controls ............3-2 Opening the LCD .................3-2 Making Adjustments For The LCD: Resolution & Color ....3-3 Legacy VGA/SVGA Memory ............3-5 Dynamic Video Memory Technology ..........3-6 Attaching a Monitor (CRT) ............3-7...
  • Page 23 Preface Power Management Features ............. 3-14 Advanced Configuration and Power Interface (ACPI) ....3-14 Advanced Power Management (APM 1.2) ........ 3-14 Enabling Power Management/Options ........3-15 Conserving Power Through Individual Components ....3-16 Monitor Standby ................ 3-16 Hard Disk Standby ..............3-16 Conserving Power Throughout The Whole System ....
  • Page 24 Preface Drivers & Utilities ......... 4-1 Overview ..................4-1 What To Install ................4-2 Authorized Driver Message ............4-3 Version Conflict Message ............4-3 Windows 98 Second Edition ............4-5 Save To Disk - Hibernate .............4-5 Chipset (Win98SE) ..............4-7 Audio (Win98SE) .................4-8 Video (Win98SE) .................4-8 LAN (Win98SE) ................4-9 Modem (Win98SE) ..............4-10 TouchPad (Win98SE) ..............4-11...
  • Page 25 Preface Audio (WinME) ................. 4-15 Video (WinME) ................. 4-16 LAN (WinME) ................4-16 Modem (WinME) ..............4-17 TouchPad (WinME) ..............4-18 Hotkey (WinME) ............... 4-18 Bay Manager (WinME) ............. 4-18 Windows 2000 Professional ............4-19 Chipset (Win2000) ..............4-19 Audio (Win2000) ............... 4-19 Video (Win2000) ...............
  • Page 26 Preface TouchPad (WinXP) ..............4-26 Hotkey (WinXP) ................4-26 Bay Manager (WinXP) ...............4-26 BIOS Utilities ......... 5-1 Overview ..................5-1 The Power-On Self Test (POST) ..........5-3 POST Screen ................5-4 Failing the POST ................5-5 Fatal Errors ...................5-5 Non-Fatal Errors ................5-5 The System Configuration Utility ..........5-6 Entering Setup ................5-6 SCU Menu ..................5-7 Working with the Menu Bar ............5-8...
  • Page 27 Preface Memory ..................5-14 Disks Menu ................5-15 Components Menu ..............5-16 Power Menu ................5-17 Exit Menu ...................5-18 Upgrading The Computer ....6-1 Overview ..................6-1 When Not to Upgrade ..............6-2 Upgrading the Hard Disk Drive ...........6-3 Removing The Hard Disk ............6-3 Some Things To Watch Out For ..........6-5 Software ..................6-5 Setting Up A New HDD ...............6-5 Upgrading The System Memory ..........6-6...
  • Page 28 Preface Viruses ..................7-5 Upgrading and Adding New Hardware/Software ......7-6 Power ....................7-8 Display ..................7-14 Hard Disk Drive (HDD) .............7-19 Boot Password ................7-19 Floppy Disk Drive (FDD) ............7-20 Audio ..................7-21 CD Device ..................7-22 PC Card ..................7-25 The PC Card Problem in Windows 98 ........7-26 Keyboard and Mouse ..............7-27 Printer ..................7-28 Operation ..................7-30...
  • Page 29 Preface Storage ..................A-3 Audio ...................A-4 Instant Keys .................A-4 PC Card Sockets ................A-4 Interface ..................A-5 Communication ................A-6 Power Management ..............A-6 Power ...................A-6 Indicator ..................A-7 H/W Certificate ................A-7 S/W Certificate ................A-7 Environmental Spec ..............A-7 Physical ..................A-7 Weight ..................A-7 Optional ..................A-8 Glossary ..........G-1 XXVIII...

  • Page 30: Introduction

    Introduction Chapter 1: Introduction Overview What this chapter covers: • The Manual — how to use it • Quick Start Guide — the minimum you need to know • System Map — navigate around your computer Overview 1 - 1...

  • Page 31: The Manual

    Introduction The Manual This manual refers to the hardware and essential software required to run your computer. Depending on how your system is configured, some or all of the features described may already be set up. System Software Your computer may already come with system software pre-in- stalled.

  • Page 32: Advanced Users

    Introduction Advanced Users If you are an advanced user you may skip over most of this manual. However you may find it useful to refer to “What To Install” on Advanced Notes page 4 - 2, “BIOS Utilities” on page 5 - 1 and “Upgrading The Computer”...

  • Page 33: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safety information indicated by the symbol. Also please Warning Notes note the safety and handling instructions as indicated in the Preface. Not Included Operating Systems (e.g. Windows 98 Second Edition, Window Me, Windows 2000 Professional, Windows XP etc.) have their own man- uals, as do applications (e.g.

  • Page 34: Quick Start Guide

    Introduction Quick Start Guide This guide assumes that you are already familiar with notebook PC’s Peripheral Devices and can tell at a glance what and where all the key components are. If you are not that comfortable with this type of device, then please Please note that pe- refer to the following pages, which give an overview of the system.

  • Page 35: System Map

    Introduction System Map Your notebook PC has a lot of built-in features. Most of these are en- abled by your operating system. Further explanations of the various subsystems are covered in the chapter or pages indicated. Getting To Know Your Computer The following will help you to become familiar with the basic func- tions, and to learn the location of the various ports and components of your computer.

  • Page 36: Top View With Lcd Display Closed

    Introduction Top View With LCD Display Closed To open the LCD display: Figure 1 - 1 1. Place the computer on a stable surface. 2. Move the cover latch “1” to the right to release the top cover. Top View With LCD 3.

  • Page 37: Front With Lcd Panel Open

    Introduction Front With LCD Panel Open 1. LCD Panel 2. LED Status Indi- cators 3. Close Cover Switch 4. Power Button 5. Built-In Micro- phone 6. Keyboard 7. Speakers 8. Hot-Key Buttons 9. Touch Pad and Buttons 10.LED Power & Communication Indicators 11.

  • Page 38: Lcd Panel

    Introduction LCD Panel The notebook PC comes with a 12.1" XGA TFT flat panel screen. Close Cover Switch This switch acts as a sensor to tell when the LCD Panel is closed. When this LCD cover sensor is activated the default setting of your operating system’s power scheme sends the computer into a power saving state (See “Advanced Power Menu”...

  • Page 39: Power Button

    Introduction Power Button Press this button to turn your computer on or off (See “Turning On The Computer” on page 2-5). This button may also be used as a suspend/resume key, once configured as such, in the power manage- ment control panel of your operating system (“Configuring the Power Button”...

  • Page 40: Keyboard

    Introduction Keyboard The computer has an B5-Size “WinKEY” keyboard with an embed- ded numeric keypad. It has the same features as a full-sized desktop keyboard and can easily be replaced with a different language key- board should you desire. Speakers Two built-in speakers provide rich, stereo sound.

  • Page 41: Touchpad & Buttons

    Introduction TouchPad & Buttons The pointing device features a sensitive glide pad for precise move- ments. It functions the same way as a two-button mouse. The right TouchPad button is the same as the right mouse button; the left TouchPad button is the same as the left mouse button. The central buttons may be used to scroll up and down, or they may be config- ured to perform a variety of functions.

  • Page 42: Headphone-In Jack

    Introduction Headphone-In Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Infrared Transceiver This transceiver allows wireless communications with an infrared- compatible device. The infrared transceiver is 115.2k SIR, 4M bps Infrared FIR, IrDA 1.1 compliant.

  • Page 43: Left Side View

    Introduction Left Side View Figure 1 - 3 Left Side View 1. Antenna (raised) 2. External Monitor (CRT) Port 3. DC-In Jack 4. PS/2 Type Port 5. Telephone Headset Jack 6. External IDE Device Port 7. Mini IEEE 1394 Port 8.

  • Page 44: External Monitor (Crt) Port

    Introduction External Monitor (CRT) Port Connect an external CRT monitor to this port to allow dual video or simultaneous display on the LCD and external CRT monitor (“At- taching a Monitor (CRT)” on page 3-7). DC-In Jack Plug the supplied AC adapter into this jack to power your notebook. PS/2 Type Port Connect an external PS/2 type mouse or keyboard to this port.

  • Page 45: External Ide Port

    Introduction External IDE Port Plug the external IDE device into this port (See “The External IDE Device” on page 2-10, and “Bay Manager Driver” in the sidebar). Mini - IEEE 1394 Port This allows high speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below).

  • Page 46: Right Side View

    Introduction Right Side View Figure 1 - 4 Right Side View 1. Hard Disk Bay 2. Dual USB Ports 3. Vent 4. Phone & LAN Jacks Overheating To prevent your compu- ter from overheating make sure nothing blocks the vent while the computer is in use.

  • Page 47: Hard Disk Drive

    Introduction Hard Disk Drive Please see “Upgrading the Hard Disk Drive” on page 6-3 for in- formation on upgrading/replacing your hard disk drive. Drive Warning Don’t try to remove the hard disk (HDD) while the system is on. This could cause data loss or damage.

  • Page 48: Rj-11 Phone Jack

    Introduction RJ-11 Phone Jack This port connects to the built-in modem (Not the optional GPRS module which is wireless). You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port.

  • Page 49: Rear View

    Introduction Rear View Figure 1 - 5 Rear View 1. Security Lock Security Lock To prevent possible theft a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. 1 - 20 System Map...

  • Page 50: Bottom View

    Introduction Bottom View Figure 1 - 6 Bottom View 1. Battery 2. Battery Release Latches 3. Hard Disk Release Latch 4. FAN Outlet 5. RAM Cover 6. SIM Card Cover Overheating To prevent your com- puter from overheating make sure nothing blocks the fan outlet while the computer is...

  • Page 51: Peripheral Devices

    Introduction Peripheral Devices Peripheral devices can be added to the notebook through the ports, jacks and slots on the sides and front of the computer. Peripheral devices include: • Audio input - microphone. • Audio output - S/PDIF, Speakers, Headphones. •...
  • Page 52 Introduction System Map 1 - 23...
  • Page 53 Introduction 1 - 24 System Map...

  • Page 54: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview Your notebook computer can be used almost anywhere, in the home, office, or on the road. To learn more about your computer, please read this chapter. This chapter includes: • The Power Sources •...

  • Page 55: The Power Sources

    Using The Computer The Power Sources Either an AC adapter or a battery pack can power the computer. Power Button as Standby or Hibernate AC Adapter Button Only use the AC adapter that comes with your computer. The wrong If you are using an type of AC adapter will damage the computer and its components.

  • Page 56: Battery

    Using The Computer Battery The battery allows you to use your notebook computer while you are on the road, or an electrical outlet is unavailable. Battery life varies depending on the applications and the configuration you're using. To increase battery life, let the battery discharge completely before re- charging.

  • Page 57: Recharging Battery With The Ac Adapter

    Using The Computer Recharging Battery with the AC Adapter The battery pack automatically recharges when the AC adapter is at- tached and plugged into an electrical outlet. If the computer is pow- ered on, and in use, it will take several hours to fully recharge the battery.

  • Page 58: Turning On The Computer

    Using The Computer Turning On The Computer Now you are ready to begin using your notebook computer. To turn Forced Off it on simply press the power button on the top right of the front panel. When the computer is turned on, the Power Button can also be used If the Ctrl + Alt + Del combination as a Standby/Hibernate/Shutdown hot-key button if pressed for less...

  • Page 59: Led Indicators

    Using The Computer LED Indicators There are two sets of LED indicators (LED Status Indicators and LED Power & Communication Indicators) on your computer. These display helpful information about the current status of the computer. Figure 2 - 4 LED Indicator Location 1.

  • Page 60: Led Status Indicators

    Using The Computer LED Status Indicators Icon Color Description Num Lock The external IDE device (floppy, CD, CD- For more information Green RW, DVD etc.) is being accessed. on the number lock feature see “The Nu- meric Keypad” Green The Hard Drive is being accessed. page 2 - 22.

  • Page 61: Led Power Indicators

    Using The Computer LED Power Indicators Table 2 - 2 LED Power Indicators Icon Color Description Green The battery full The battery is being charged. Blinking Low battery warning. Green Green The system power is on. The system is in suspend mode (“Con- Blinking figuring the Power Button”...

  • Page 62: The Hard Disk Drive (Hdd)

    Using The Computer The Hard Disk Drive (HDD) The hard disk drive is used to store your data in the notebook com- Power Safety puter. It is mounted in a removable case and can be taken out to ac- commodate other 2.5” (9.5mm) height IDE hard disk drives. The Before attempting to system supports PIO mode 4 /ATA-33/66/100.

  • Page 63: The External Ide Device

    Using The Computer The External IDE Device The computer may come with an optional external IDE drive bay. , Bay Manager Driver It may contain one of the following combinations, depending on your purchase: Please make you have installed the Bay Man- ager driver (See...

  • Page 64: Bay Manager

    Using The Computer Bay Manager Once you have installed the Bay Manager software you will have the following icon in your taskbar Warning Right-click on the icon and select Insert or Remove/Swap Connecting or discon- necting the IDE drive Bay Device. without following the The system will then provide instructions (Figure 2 - 7) to Bay Manger instruc-...

  • Page 65: The Floppy Disk Drive (Fdd)

    Using The Computer The Floppy Disk Drive (FDD) A 1.44 MB, 3.5” floppy disk drive module may be part of your com- Media Warning bination. By default it is drive "A:" and can be used as a boot device if properly set in the BIOS. For more information refer to “Boot De- Don’t try to remove a vice (Startup Menu)”...

  • Page 66: The Cd Device

    Using The Computer The CD Device Depending on the configuration purchased, your system may have Sound Volume one or more CD devices. If present in a standard configuration, one Adjustment will appear as drive "D:". If there is a second drive it will be drive "E:".

  • Page 67: Handling Cd's Or Dvd's

    Using The Computer Handling CD’s or DVD’s Proper handling of your CDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on Media Warning your CD-ROM / DVD-ROM discs can be accessed. When manually eject- ing a CD/DVD disc, Remember to:...

  • Page 68: Dvd Regional Codes

    Using The Computer DVD Regional Codes DVD region detection is device dependent, not OS dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This cannot be altered even if you change your operating system or you use the module in another computer. Figure 2 - 8 DVD Regional Codes (Windows XP)

  • Page 69: To Change The Regional Codes

    Using The Computer To Change the Regional Codes Go to the Control Panel in Windows XP/2000 and double-click Sys- Changing Region tem, click Device Manager, then click the + Next to DVD/CD- Codes in Windows ROM drives. Double-click on the DVD-ROM device to bring up the 98/Me Properties menu, and select the DVD Region (tab) to bring up the control panel as seen in “DVD Regional Codes (Windows XP)”...

  • Page 70: The Pc Card Slot

    Using The Computer The PC Card Slot The computer is equipped with a type II (PCI) PCMCIA 3.3V/5V The PC Card Problem socket. in Windows 98 Inserting And Removing PC Cards See “The PC Card Problem in Windows • Align the PC card with the slot and push the card in until it locks into 98”...

  • Page 71: Hot-Keys

    Using The Computer Hot-Keys The computer has three Hot-Key buttons for quick one button access to e-mail (“1”), the Internet (“2”) or a user-defined application (“3”). To use the “user-defined Hot-Key”, you must install the Hot-Key driver. Refer to “What To Install” on page 4 - 2 for driver installa- tion steps.

  • Page 72: Programming The Hot-Keys

    Using The Computer Programming the Hot-Keys Table 2 - 5 Hot-Key Functions Hot-Keys Function Activate the default e-mail program. Activate the default Internet browser. Activate the user specified application (e.g. Microsoft Word or Excel. After installing the Hot-Key driver (See “What To Install” on page 4 - 2), you may have to configure or change the settings.
  • Page 73 Using The Computer Right click the Hot-Key icon on the taskbar and the fol- lowing menu will appear. Application.exe You will need to locate the actual application executable (.exe) file, not just the shortcut. Select Setup from the menu and scroll to Application 1 and To find the application press Enter.

  • Page 74: Function Keys

    Using The Computer Function Keys On the bottom-left of the keyboard is the Fn key, or Function key. Other Keyboards The Fn key allows you to change some of the operational features of your computer instantly. Press and hold the Fn key; then press the If your keyboard is appropriate function key (Esc, F3, F5, etc.) located at the top of the damaged or you just...

  • Page 75: The Numeric Keypad

    Using The Computer The Numeric Keypad The keyboard has an embedded numerical keypad for easy numeric Special Characters data input. The keypad has a blue typeface. Some software appli- To use the embedded keypad simply activate the Num Lock feature cations allow number-keys...

  • Page 76: Function Keys And Numeric Keypad

    Using The Computer Function Keys and Numeric Keypad Figure 2 - 10 Function Keys Figure 2 - 11 Numeric Keypad The Numeric Keypad 2 - 23...

  • Page 77: Touchpad And Buttons

    Using The Computer TouchPad and Buttons The pointing device features a sensitive glide pad for precise move- ments. Its functions the same way as a two-button mouse (The cen- tral Rocker Switch may be configured as a “third” button if you prefer).

  • Page 78: Configuring The Touchpad And Buttons

    Using The Computer Configuring The TouchPad and Buttons Once you have installed the TouchPad driver, (See “What To In- stall” on page 4 - 2) you can configure the functions by double- clicking the TouchPad driver icon on the taskbar to bring up the Mouse Properties control panel (Figure 2 - 12).

  • Page 79: Mouse

    Using The Computer Mouse You can also add a mouse to your notebook computer. You can use a mouse through either the PS/2 interface or through one of the USB ports. Mouse Driver If you are using an ex- ternal mouse your op- erating system may be able to auto-configure your mouse during its...

  • Page 80: Adding A Printer

    Using The Computer Adding a Printer The most commonly used peripheral is a printer. The following con- ventions will help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options.

  • Page 81: Parallel Printer

    Using The Computer Parallel Printer This is still the most common type of printer. A Parallel to USB con- verter may be purchased at most computer stores. Parallel to USB Converter Note Install Instructions: If you are using a Par- Set up the printer according to its instructions (unpacking, allel to USB converter, paper tray, toner/ink cartridge etc.)

  • Page 82: Advanced Controls

    Advanced Controls Chapter 3: Advanced Controls Overview This chapter covers: Drivers • Advanced video controls You are unable to use • Power and battery management features most advanced con- • Installing the GPRS SIM card trols until the neces- sary drivers utilities are properly in- stalled.

  • Page 83: Advanced Video Controls

    Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD, switching dis- Protecting the LCD play devices. Do not allow any for- Opening the LCD eign objects (i.e. paper or plastic) to get be- you open the lid, adjust it so you can look at the screen straight tween the lid/LCD and on, without any glare.

  • Page 84: Making Adjustments For The Lcd: Resolution & Color

    Advanced Controls Making Adjustments For The LCD: Resolution & Color With the video driver installed, the LCD is capable of supporting a resolution of 1024 by 768 at 60Hz. The higher the resolution, the more information the LCD can display on screen. To change the LCD’s resolution and color depth.
  • Page 85 Advanced Controls To change the resolution: 4. Under Screen resolution/area move the slider to the setting you prefer (See sidebar note). Screen Resolution/ To change the color depth: Area Note 5. Under Color Quality/Colors click the arrow and select the set- ting you prefer.

  • Page 86: Legacy Vga/Svga Memory

    Advanced Controls Video Memory The computer does not have dedicated video memory. The video memory available on your computer is configured in two modes of operation, Legacy VGA/SVGA memory and Dynamic Video Mem- ory Technology: Legacy VGA/SVGA Memory This is the pre-allocated memory size for VGA compatibility. This is fixed in the BIOS at 8MB (See “...

  • Page 87: Dynamic Video Memory Technology

    Advanced Controls Dynamic Video Memory Technology ® Intel DVMT automatically and dynamically allocates as much sys- tem memory (up to 32MB) as needed to the video system. DVMT re- DVMT Notes turns whatever memory is no longer needed to the operating system. DVMT is not user-con- figurable.

  • Page 88: Attaching A Monitor (Crt)

    Advanced Controls Attaching a Monitor (CRT) Besides the built-in LCD, you can also use an external CRT connect- Refresh Rates ed to the VGA port as your display device. If you prefer to use a mon- itor (CRT), connect it to the CRT port on the left side (See “Left Side The standard refresh View”...

  • Page 89: Intel Video Driver Controls

    Advanced Controls Intel Video Driver Controls With the video driver installed there is an additional control panel en- titled Intel(R) 830M Graphics Controller Properties. To get to the Taskbar control panel do the following: You may also access the control panel from 1.
  • Page 90 Advanced Controls Figure 3 - 5 Information (tab) Figure 3 - 6 Schemes Attaching a Monitor (CRT) 3 - 9...

  • Page 91: Schemes

    Advanced Controls Schemes Use Schemes to configure quick settings for applications which re- quire specific resolution and color settings in order to run properly Application.exe e.g. games, multimedia programs. You will need to locate the actual application To set the schemes: executable (.exe) file, not just the shortcut.

  • Page 92: Multi-Monitor Modes

    Advanced Controls Multi-Monitor Modes In addition to the single LCD display mode you have the following Multi-Monitor modes available when the external monitor (CRT) is attached. Intel Dual Display Clone This mode will drive multiple displays with the same content. Use this feature to display the screen through a projector for a presenta- tion.
  • Page 93 Advanced Controls To Enable Dual Display Clone Mode: 1. Attach the CRT to the port on the left side of the computer. 2. Go to the “Intel(R) 830M Graphics Controller Properties” Control Panel (See “Intel Video Driver Controls” on page 3 - 3.
  • Page 94 Advanced Controls To Enable Extended Desktop Mode: 1. Attach the CRT to the port on the left side of the computer. 2. Go to the “Intel(R) 830M Graphics Controller Properties” Control Panel (See “Intel Video Driver Controls” on page 3 - 3.

  • Page 95: Power Management Features

    Advanced Controls Power Management Features To conserve power, especially when using the battery, your note- OS Note book computer has two types of power management available, ACPI and APM. Power management conserves power by controlling indi- Power management vidual components of the computer (the monitor and hard disk drive) functions will vary...

  • Page 96: Enabling Power Management/Options

    Advanced Controls Enabling Power Management/Options The Power Management/Options are enabled through the Control BIOS V’s OS Panel in your Windows system (Power Management in Windows 98SE, and Power Options in the Windows ME, 2000 and XP). With Currently power man- other Operating Systems you may have power management avail- agement from...

  • Page 97: Conserving Power Through Individual Components

    Advanced Controls Conserving Power Through Individual Compo- nents Monitor Standby To conserve power, you can set the monitor to turn off after a speci- fied time. Hard Disk Standby The computer's hard disk motor will be turned off if the hard disk drive has not been accessed for a specified period of time.

  • Page 98: Conserving Power Throughout The Whole System

    Advanced Controls Conserving Power Throughout The Whole Sys- With this function you can stop the notebook’s operation and restart Hibernate Mode in Windows 98SE where you left off. This system features Standby and Hibernate suspend mode levels (Hibernate mode will need to be enabled by In Windows 98SE you clicking the option in the Hibernate tab in the Power Options con- will only have the Hi-...

  • Page 99: Standby

    Advanced Controls Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applica- tions are retained in memory.

  • Page 100: Hibernate

    Advanced Controls Hibernate Hibernate uses no power and saves all of your information on a part of the HDD before it turns the system off. Although it saves the most power it takes the longest time to return to full operation. You can set your notebook to automatically enter Hibernate mode when the bat- tery power is almost depleted.

  • Page 101: Configuring The Power Button

    Advanced Controls Configuring the Power Button The Power button may be set to send the computer in to either Stand- by or Hibernate modes (Figure 3 - 11). In Standby mode the LED will flash green, in Hibernate mode the LED will be off. If you are in a power saving mode set to save power through individual components (e.g.

  • Page 102: Battery Information

    Advanced Controls Battery Information Please follow these simple guidelines to get the best use out of your CAUTION battery. Danger of explosion if New Battery battery is incorrectly replaced. Always charge a new battery before using it. Replace only with the Battery Life same equivalent...

  • Page 103: Battery Faq

    Advanced Controls Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the com- puter use up all of the battery power and shut down on its own (it is best to disable the Power Management functions in the Control Panel).

  • Page 104: Conserving Battery Power

    Advanced Controls Conserving Battery Power Display Brightness The LCD display consumes a lot of power, so lowering the bright- ness level will save power. Applications and External Devices Different applications and external devices consume battery power even when they are not being used. To conserve battery power we recommend: •...

  • Page 105: Removing And Replacing The Battery

    Advanced Controls Removing And Replacing The Battery For the most part you will not need to remove your battery. If you follow the tips given to manage and extend your battery life on the preceding pages your battery should last a long time. However there may be times when you are required to remove, swap or replace the battery.
  • Page 106 Advanced Controls 3. Latch "1" should slide to the right and remain in place, and you will need to hold latch "2" in place as you slide the battery out towards you. 4. Slide the battery out, and replace it with the new battery. Figure 3 - 13 Battery Out Battery Information 3 - 25...

  • Page 107: Installing The Gprs Sim Card

    Advanced Controls Installing the GPRS SIM Card If you have the optional GPRS module in your computer you will be able to use the telephone functions. Firstly install your SIM card. 1. Turn the computer off. 2. Turn the computer over. 3.
  • Page 108 Advanced Controls 5. Slide the SIMLOCK forward (Figure 3 - 15 - A) and lift it up (Figure 3 - 15 -B). Figure 3 - 15 6. Insert the SIM card as illustrated in (Figure 3 - 15 - C) and close the SIMLOCK.
  • Page 109 Advanced Controls 7. The card will only fit one way (Note point 1 in Figure 3 - 16). Figure 3 - 16 8. Close the SIMLOCK by pushing it in the direction of the arrow SIMLOCK Closed in Figure 3 - 16. 9.

  • Page 110: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities Overview • W indows 98 Second Edition • Windows Me • W indows 2000 Professional • Windows XP This chapter deals with installing the drivers and utilities essential to the operation or im- provement of some of the notebook PC’s sub- systems.

  • Page 111: What To Install

    Drivers & Utilities What To Install The Device Drivers & Utilities + User’s Man- ual CD-ROM contains the drivers and utilities Navigate (Browse.\.) to D: necessary for the proper operation of the note- You will notice that many of the instructions for book PC.

  • Page 112: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message If you receive a message stating that the driver you are installing is not authorized ( Digital Signature Not Found) , just click Yes ( Con- What To Have Ready tinue Anyway ) to ignore the message and In some cases when drivers are to be installed continue the installation procedure.
  • Page 113 Drivers & Utilities Table 4 - 1 - What to Install Feature Win98SE WinME* Win 2000* Win XP Save to Disk - Hibernate page 5 Chipset page 7 page 15 page 19 page 23 Audio page 8 page 15 page 19 page 23 Video page 8...

  • Page 114: Windows 98 Second Edition

    Drivers & Utilities Windows 98 Second Edition Save To Disk - Hibernate This section covers driver and utility installa- tion instructions for Windows 98 Second Edi- In order to get the Hibernate options to show tion . in your Power Management control panel in Windows 98 Second Edition, you will need to create a Save to Disk (Hibernate) file .
  • Page 115 Drivers & Utilities 1. Start the system at the DOS prompt with (The n indicates the amount of physical CD-ROM support. You may use your RAM you have installed in the system Windows Startup Floppy Disk in drive A: plus two megs, i.e. if you have 64 megs and have your Device Drivers &...

  • Page 116: Chipset (Win98Se)

    Drivers & Utilities 8. Install the Windows 98SE Operating Chipset (Win98SE) System. 1. Click Start (menu) > Run... 9. Install the Chipset driver as per the 2. Navigate ( Browse.. ) to D:\Driv- instructions in “Chipset (Win98SE)” on ers\Inf_update\infinst_autol.exe and page 4-7 .

  • Page 117: Audio (Win98Se)

    Drivers & Utilities Audio (Win98SE) the sounds marked with a speaker to pre- view. You will see the Sound Effect 1. Click Start (menu) > Run... Manager appear in the Task Bar along- 2. Navigate ( Browse.. ) to D:\Driv- side the date, and the AV Rack control ers\Audio\Setup.exe and click OK.

  • Page 118: Lan (Win98Se)

    Drivers & Utilities LAN (Win98SE) eject the CD-ROM in your drive and insert the Windows CD. 1. Click Start (menu), point to Settings and 8. Give the computer a few seconds to rec- click Control Panel . Double-click Sys- ognize that the disk is in the drive, then tem (icon) and then click Device Man- click OK .

  • Page 119: Modem (Win98Se)

    Drivers & Utilities Modem (Win98SE) ties (dialog box) . The modem is ready for dial-up configuration. 1. Click Start (menu), point to Settings and click Control Panel . Double-click Sys- tem (icon) and then click Device Man- ager . 2. Click “+” next to Other devices (if its Modem Country Selection sub-items are not shown).

  • Page 120: Touchpad (Win98Se)

    Drivers & Utilities TouchPad (Win98SE) 5. Click Next . 6. When the Update Device Driver Wizard 1. Click Start (menu) > Run... appears, click Next (make sure that you 2. Navigate ( Browse.. ) to D:\Driv- have selected “Search for a better ers\TouchPad\Win9x_me\Setup.exe driver than the one your device is using and click OK .

  • Page 121: Infrared (Fir) (Win98Se)

    Drivers & Utilities Infrared (FIR) (Win98SE) 8. Use the up and down arrow keys ( ) to select Fast IR . Enabling the FIR mode for your Infrared con- 9. Press the Space bar to select the Fast IR nection is a two part process. setting.
  • Page 122 Drivers & Utilities eject the CD-ROM in your drive and 11. Click OK > Next > Next > Finish . insert the Windows CD. 12. You may setup your Infrared from either 3. Give the computer a few seconds to rec- the taskbar at the bottom right of the ognize that the disk is in the drive, then screen, or by going to the Start (menu),...

  • Page 123: Hot-Key (Win98Se)

    Drivers & Utilities Hot-Key (Win98SE) Bay Manager (Win98SE) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate ( Browse.. ) to D:\Drivers\Ap- 2. Navigate ( Browse.. ) to D:\Driv- Key\CNK001.exe and click OK . ers\Bay\Setup.exe and click OK . 3.

  • Page 124: Windows Me

    Drivers & Utilities Windows ME Audio (WinME) 1. Click Start (menu) > Run... This section covers driver and utility installa- 2. Navigate ( Browse.. ) to D:\Driv- tion instructions for Windows Me. ers\Audio\Setup.exe and click OK . 3. Click Next . Chipset (WinME) 4.

  • Page 125: Video (Winme)

    Drivers & Utilities Video (WinME) 5. When the Update Device Driver Wizard appears, select “ Specify the location of 1. Click Start (menu) > Run... the driver (advanced) ” and click Next . 2. Navigate ( Browse.. ) to D:\Driv- 6.

  • Page 126: Modem (Winme)

    Drivers & Utilities Modem (WinME) 9. After the updated driver is installed, click Finish . 1. Click Start (menu), point to Settings and 10. Close the Smart Link 56K Voice click Control Panel . Double-click Sys- Modem Properties and System Proper- tem (icon) and then click Device Man- ties (dialog box) .

  • Page 127: Touchpad (Winme)

    Drivers & Utilities TouchPad (WinME) Hotkey (WinME) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate ( Browse.. ) to D:\Driv- 2. Navigate ( Browse.. ) to D:\Drivers\Ap- ers\TouchPad\Win9x_me\Setup.exe Key\CNK001.exe and click OK . and click OK . 3.

  • Page 128: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional This section covers driver and utility installa- Audio (Win2000) tion instructions for Windows 2000 Profes- 1. Click Start (menu) > Run... sional. 2. Navigate ( Browse.. ) to D:\Driv- ers\Audio\Setup.exe and click OK . Chipset (Win2000) 3.

  • Page 129: Video (Win2000)

    Drivers & Utilities Video (Win2000) LAN (Win2000) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate ( Browse.. ) to D:\Driv- 2. Navigate ( Browse.. ) to D:\Driv- ers\VGA\W2k_XP\Setup.exe and click ers\Lan\Setup.exe .and click OK . OK .

  • Page 130: Modem (Win2000)

    Drivers & Utilities Modem (Win2000) ties (dialog box) . The modem is ready for dial-up configuration. 1. Click Start (menu), point to Settings and click Control Panel . Double-click Sys- tem (icon) and then click Hardware (tab) > Device Manager (button). 2.

  • Page 131: Touchpad (Win2000)

    Drivers & Utilities TouchPad (Win2000) Hot-Key (Win2000) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate ( Browse.. ) to D:\Driv- 2. Navigate ( Browse.. ) to D:\Drivers\Ap- ers\TouchPad\W2k\Setup.exe and click Key\CNK001.exe and click OK . OK .

  • Page 132: Windows Xp

    Drivers & Utilities Windows XP Audio (WinXP) 1. Click Start (menu) > Run... This section covers driver and utility installa- 2. Navigate ( Browse.. ) to D:\Driv- ers\Audio\Setup.exe .and click OK . tion instructions for Windows XP . 3. To continue press Next . Chipset (WinXP) 4.

  • Page 133: Video (Winxp)

    Drivers & Utilities Video (WinXP) ers\Video\W2k_xp\Win2000 and click Open > OK . 1. Click Start (menu) > Run... 9. Click Finish to close the wizard. 2. Navigate ( Browse.. ) to D:\Driv- 10. Restart the computer. ers\Video\W2k_xp\Setup.exe and click OK . 3.

  • Page 134: Modem (Win Xp)

    Drivers & Utilities Modem (Win XP) 7. Select “Search for the best driver in these locations:” and select ONLY 1. If you can see the My Computer icon on “Include this location in the search:” . your desktop (if you cannot see the My 8.

  • Page 135: Touchpad (Winxp)

    Drivers & Utilities TouchPad (WinXP) Hotkey (WinXP) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate ( Browse.. ) to D:\Driv- 2. Navigate ( Browse.. ) to D:\Drivers\Ap- ers\TouchPad\W2k\Setup.exe and click Key\CNK001.exe and click OK . OK .

  • Page 136: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview This chapter is about the notebook’s built-in software: Your computer comes with built-in BIOS (Basic Input Output Sys- tem) which is an essential set of software routines stored on a chip n tour computer. These routines serve to describe your computer’s hardware to your chosen operating system, and provides an interface between the two.
  • Page 137 BIOS Utilities If your computer has never been set up, or you are making important changes to the system (e.g. power management features), then you should review this chapter first and note the original settings found in Setup . Even if you are a beginner, keep a record of the settings you find and any changes you make.

  • Page 138: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM. As the POST proceeds, the computer will tell you if there is anything wrong.

  • Page 139: Post Screen

    BIOS Utilities POST Screen Figure 5 - 1 The POST Screen SystemSoft MobilePRO BIOS Version 1.01 Copyright 1983 - 1996 SystemSoft Corp. All Rights Reserved H8 VERSION 01.15.00 1000MHz Pentium III with MMX CPU Startup Screen: The CPU Microcode Update Rev 01Dh Complete LZ Cache : 512K installed POST (Figure 5 - 1) 8MB Video RAM...

  • Page 140: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 141: The System Configuration Utility

    BIOS Utilities The System Configuration Utility The SCU program tells the system how to configure itself and man- BIOS Settings V’s OS age basic features and subsystems (e.g. port configuration and power Settings management). The settings are stored in a nonvolatile battery and written to the CMOS RAM.

  • Page 142: Scu Menu

    BIOS Utilities SCU Menu The initial menu screen will appear as below: SCU Screens SystemSoft SCU For Intel 830MG Chipset Nov, 19 2001 6:40:02 am Startup Memory Disks Components Power Exit The screens which ap- Devices System pear on the following Floppy Drive A = 1.44MB pages are intended as...

  • Page 143: Working With The Menu Bar

    BIOS Utilities Working with the Menu Bar You can use the mouse to navigate around the various menus and submenus of the SCU, or alternatively, you can use the following key combinations: Keys Action Activates the menu bar. Selects an option in the menu Left arrow/Right arrow bar.

  • Page 144: Working With The Pull-Down Menu

    BIOS Utilities Working with the Pull-Down Menu Once your desired menu bar item is highlighted, press Enter or the down arrow ( ) to see the pull-down menu items. The following keys allow you to move about the pull-down menu: Keys Action Moves from one record to another.
  • Page 145 BIOS Utilities Keys Action Selects a pull down menu item. Down/Up arrows ( Enter Enables/Disables the specified function. A ( ) indicates the function is enabled. Closes the pull-down menu and saves the changes. Table 5 - 3 The following pages will show some of the menu screens available Pull-Down Menu Keys and will outline some of the main functions which may be set in the (right arrow enabled)

  • Page 146: Startup Menu

    BIOS Utilities Startup Menu SystemSoft SCU For Intel 830MG Chipset Nov, 19 2001 6:40:02 am Startup Memory Disks Components Power Exit Date and Time Devices System √ Fast Boot Floppy Drive A = 1.44MB √ Boot Device Hard Drive C = 20005MB √...

  • Page 147: Boot Device (Startup Menu)

    BIOS Utilities Boot Device (Startup Menu) Specify which device your computer should look on for an operating system by priority. The most common setting is to look for the dis- kette A first, then the CD Device, and lastly the hard disk. In most cases your computer “boots”...

  • Page 148: Boot And Scu Passwords (Startup Menu)

    BIOS Utilities Boot and SCU Passwords (Startup Menu) You can set the passwords for when the computer starts-up (Boot Password), and for access to the SCU to make changes (SCU pass- Password Warning word). See the sidebar for a warning on setting the password. If you choose set a boot password, NEV- Other settings (Startup Menu)

  • Page 149: Memory

    BIOS Utilities Memory Legacy VGA/SVGA memory size (fixed). SystemSoft SCU For Intel 830MG Chipset Nov, 19 2001 6:40:02 am Startup Memory Disks Components Power Exit Devices System VGA Shared Memory Floppy Drive A = 1.44MB Hard Drive C = 20005MB CPU Clock = 1000MHz Hard Drive D...

  • Page 150: Disks Menu

    BIOS Utilities Disks Menu Here you may enable or disable the different settings and functions for your floppy disk drive, hard disk drive, and CD-ROM/DVD ROM. SystemSoft SCU For Intel 830MG Chipset Nov, 19 2001 6:40:02 am Startup Memory Components Power Exit Disks Devices System...

  • Page 151: Components Menu

    BIOS Utilities Components Menu Here you may setup your COM ports, enable/disable support for a Padlock Function PS/2 Mouse, startup the computer with Numlock enabled, and en- able the Padlock function (See sidebar). If Num Lock is acti- vated (And you have enabled the padlock SystemSoft SCU For Intel 830MG Chipset Nov, 19 2001 6:40:02 am...

  • Page 152: Power Menu

    BIOS Utilities Power Menu Here you may set the various power options for your computer in- cluding suspend mode, wake up from modem ring (to answer incom- ing calls) etc. These settings are overridden by those in the OS, and therefore, are best set there.

  • Page 153: Exit Menu

    BIOS Utilities Exit Menu From here you may exit the SCU, and you have the option to save the changes you made, or not to do so. You may also choose to restore the original default settings, or to the last set of custom settings (these are useful options in case of errors made due to incorrect setting changes).

  • Page 154: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Fol- low the steps outlined to make the desired upgrades. If you have any trouble or problems you can contact your service representative for further help.

  • Page 155: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts. You should not perform any of these upgrades if: • your system is still under warranty or a service contract • you don’t have all the necessary equipment •...

  • Page 156: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive is used to store your data internally in the note- book computer. It is mounted in a removable case and can be taken out to accommodate other 2.5"/9.5mm (h) IDE hard disk drives. Removing The Hard Disk 1.
  • Page 157 Upgrading The Computer 5. Place the HDD on a flat surface and remove the 4 ("1" - "4") screws holding the case to the HDD, and gently ease off the HDD System connector "5". Warning 6. Pay careful attention to the alignment of the connector pins, and the orientation of the hard disk, when you install the new/ New HDD’s are blank.

  • Page 158: Some Things To Watch Out For

    Upgrading The Computer Some Things To Watch Out For Software Allow the system to auto-detect the new HDD, or if necessary, run the Setup Utility in the BIOS to customize the system ( “Disks Menu” on page 5 - 15 ). Setting Up A New HDD Follow your operating system’s installation instructions and install all necessary drivers and utilities as outlined in “What To Install”...

  • Page 159: Upgrading The System Memory

    Upgrading The Computer Upgrading The System Memory The computer has two memory sockets for 64-bit wide Small Outline Dual In-line Memory Modules (SO-DIMM) and supports PC-133 SDRAM. The main memory can be expanded up to 1GB. The mod- ules supported are 64Mb, 128Mb, 256Mb, and 512Mb. The total memory size is automatically detected by the POST routine once you turn on your computer.

  • Page 160: Upgrading The Memory In Socket 2

    Upgrading The Computer Upgrading the Memory in Socket 2 1. Turn off the computer. 2. Turn the computer over. 3. Remove screws "1" & "2" from the memory socket cover "4". 4. Carefully lift the memory socket cover up and set it aside. Figure 6 - 3 Memory Socket Upgrading The System Memory 6 - 7...
  • Page 161 Upgrading The Computer 5. If there is a module currently installed which needs to be upgraded/replaced then remove it. 6. Gently pull the two release latches ("1" & "2" in Figure 6 - 4) on Contact Warning the sides of the memory socket toward the front and rear of the Be careful not to touch computer, as indicated in Figure 6 - 4.
  • Page 162 Upgrading The Computer 9. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go. DO NOT FORCE IT; it should fit without much pressure. 10.

  • Page 163: Upgrading The Processor

    Upgrading The Computer Upgrading The Processor If you want to upgrade your computer by replacing the existing pro- cessor with a faster/new one you will need to contact your customer service representative. We recommend that you do not do this your- self, since if it is done incorrectly you may damage the processor or mainboard.

  • Page 164: Troubleshooting

    Troubleshooting Chapter 7: Troubleshooting Overview Should you have any problems with your computer, before consult- ing the service center, you may want to try to solve the problem your- self. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic.

  • Page 165: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the so- lution to a problem when your computer appears not to be working. •Power: Is the computer actually plugged into a working electrical outlet? If plugged into a power strip , make sure it is actually working.
  • Page 166 Troubleshooting •System Power: Check the LED Power Indicators ( See Chap- ter 2:“LED Power Indicators” on page 2-8 ) to show the current status of the computer’s power input. •Connections: Check the brightness of the screen by pressing the F3 + F4 keys to adjust the brightness ( See Chapter 3:“Opening the LCD”...

  • Page 167: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and Warrantee programs safe, but close to hand. Don’t forget to note the serial num- bers if you are storing them out of their original cases e.g. in a CD wal- The CPU is not a user let.

  • Page 168: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 169: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/ Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 170 Troubleshooting • Make sure you have installed the drivers for any new hardware you have installed (latest driver files are usually available to download from vendor’s websites). • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs.

  • Page 171: Power

    Troubleshooting Power You turned on the power but it doesn’t work. possible cause: Battery missing / incorrectly installed. solution: Check the battery bay, make sure the battery is present and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 172 Troubleshooting possible cause: The suspend key combination, Fn + Suspend (Esc), or other configured key combination, has been toggled. Battery Charging indicator: The various LEDs light up, but no picture appears. Make sure the battery is totally used up be- solution: Press Fn + Suspend (Esc), or other configured fore recharging and...
  • Page 173 Troubleshooting computer isn’t sitting on a thermal surface. Make sure you’re using the correct adapter. possible cause: The system is using too much power. solution: If your OS has a Power Management/Power Options scheme ( See Chapter 3:“Power Man- agement Features” on page 3-14 ) check its set- tings.
  • Page 174 Troubleshooting The battery pack will not charge. possible cause: The battery pack is exposed to an excessively hot or cold environment. solution: 1. Place the battery in a suitable environment and after it returns to normal temperature try again. 2. :The battery may be bad and may need to be replaced, contact your service center for more details.
  • Page 175 Troubleshooting A beeping sound is heard and the low-battery indicator is on. solution: The battery power is nearly used up. Connect the AC adapter to your computer. A beep isn’t heard when the low-battery indicator turns on, or the gauge indicates power is less than 10%. solution: The battery power is nearly used up and the vol- ume control may be turned down.
  • Page 176 Troubleshooting possible cause: The battery has not been fully discharged before being recharged. solution: Make sure the battery is fully discharged and recharge it completely before reusing. possible cause: Power Management / Power Options have been disabled. solution: Go to the Control Panel in Windows and re-ena- ble the options.

  • Page 177: Display

    Troubleshooting Display Nothing appears on screen. possible cause: The system is in a power saving mode. indicator: The LED power indicator , , is blinking green. solution: Toggle the suspend key combination, Fn + Esc ( See Chapter 2:“Function Keys” on page 2- 21 ).
  • Page 178 Troubleshooting possible cause: The computer is set for a different display. solution: Toggle the screen display key combination, Fn + F6 . ( See Chapter 3:“Opening the LCD” on page 3-2 ). If an external monitor is connected, turn it on. possible cause: The screen saver is activated.
  • Page 179 Troubleshooting The screen images aren’t clear. possible cause: The screen controls need to be adjusted. solution: Toggle the screen control key combinations Fn + F3/F4 ( See Chapter 3:“Opening the LCD” on page 3-2 ). possible cause: The viewing angle of the LCD is bad. indicator: The screen appears shiny or too dim.
  • Page 180 Troubleshooting possible cause: The screen is suffering from burn-in . indicator: The screen has ghost images, even when it’s off. solution: This problem is usually associated with external CRT monitors. Use power saving options ( See Chapter 3:“Monitor Standby” on page 3-16 ) to turn off the LCD.
  • Page 181 Troubleshooting possible cause: You haven’t installed the video driver and con- figured it appropriately from the Control Panel . solution: Please see “What To Install” on page 4 - 2 for instructions on installing the driver, and “Intel Video Driver Controls” on page 3 - 8 for instructions on configuring the video driver.

  • Page 182: Hard Disk Drive (Hdd)

    Troubleshooting Hard Disk Drive (HDD) The computer takes longer during Startup. Warning possible cause: Data saved on the hard disk drive may be lost or damaged. If you choose set a solution: Please operate the scan disk or disk defragmenter boot password, NEV- ER forget your pass- to check for any lost or damaged data.

  • Page 183: Floppy Disk Drive (Fdd)

    Troubleshooting Floppy Disk Drive (FDD) The floppy disk drive will not write data to disk. Media Warning possible cause: The floppy disk is not formatted. solution: Format the disk (you may do this by right-click- Don’t try to remove a floppy disk while the ing the disk icon in My Computer in Windows system is accessing it.

  • Page 184: Audio

    Troubleshooting “Invalid system disk - Replace the disk, and then The message press any key” appears. possible cause: The computer is trying to boot from an incorrect floppy disk. solution: Remove the floppy and insert a correct one, or boot from your hard disk or CD. you will need to restart the computer.

  • Page 185: Cd Device

    Troubleshooting CD Device The compact disc cannot be read. Media Warning possible cause: The compact disc is dirty. solution: Clean it with a CD-ROM cleaner kit. When manually eject- ing a CD/DVD disk, DO NOT use a sharp- The compact disc tray will not open when there is a disc in the ened pencil or similar tray.
  • Page 186 Troubleshooting The CD Device cannot be accessed. possible cause: The external IDE device drive is not plugged in correctly to the port on the left ( See “External Bay Manager Driver IDE Port” on page 1 - 16) of the computer. solution: Check that the connector is fully locked into the Please make you have...
  • Page 187 Troubleshooting All compact discs cannot be read. possible cause: The Windows system does not recognize the CD- ROM drive, or the CD-ROM drive is not com- patible with other devices. solution: 1. Make sure you have the CD-ROM drive prop- erly installed and configured.

  • Page 188: Pc Card

    Troubleshooting PC Card The system cannot recognize the PC card. possible cause: The PC card is not inserted into the socket or inserted incorrectly. solution: Remove the card and re-insert it aligning the PC card with the slot. Push the card in until it locks into place.

  • Page 189: The Pc Card Problem In Windows 98

    Troubleshooting The PC Card Problem in Windows 98 After installation of Windows 98 or Windows 98 Second Edition , you may find that the PC cards are not working normally and you may also notice one or more of the following: •...

  • Page 190: Keyboard And Mouse

    Troubleshooting Keyboard and Mouse Unwelcome numbers appear when typing. Other Keyboards possible cause: The NumLock is turned ON . If your keyboard is indicator: The LED is lit. damaged or you just solution: Press and release the NumLock key. want make change, you can use I have installed a new external Keyboard or mouse but cannot...

  • Page 191: Printer

    Troubleshooting Printer The printer cannot be added to the system or will not work. possible cause: The printer power is off or the printer is not cor- rectly connected to the computer. solution: Check all connections and cables and the try to reinstall the driver.
  • Page 192 Troubleshooting possible cause: There is no paper in the printer, or the paper is incorrect for the settings designated in your soft- ware. solution: Put more paper in the printer (also fan the paper to make sure it doesn’t stick together and cause a paper jam) and check the paper size matches your software’s “print”...

  • Page 193: Operation

    Troubleshooting Operation The system freezes. possible cause: The system’s power saving features have timed- out. indicator: The screen goes dark. solution: Use the AC adapter, press the Fn + Esc (Sus- pend) key combination, or press the Power But- ton if no LEDs are lit. possible cause: The system cannot access the Save to Disk parti- tion.
  • Page 194 Troubleshooting Chapter 4:“Save To Disk - Hibernate” on page 4-5 ). possible cause: A software conflict made the system “crash”. solution: Consult your OS manual. As a last resort, since you will lose any unsaved data, try to reboot the system or if that doesn’t work, turn the computer off and on again.
  • Page 195 Troubleshooting 3. Run the 0VMAKFIL utility if you installed a different hard disk with a Save to Disk partition on it, or there has been a CMOS or Checksum failure ( See Chapter 4:“Save To Disk - Hiber- nate” on page 4-5) . The system never goes into hibernate mode.
  • Page 196 Troubleshooting The Infrared device doesn’t work in Windows 98SE. possible cause: The drivers are not loaded. indicator: The system cannot access the card after it is installed. solution: Please read the documentation which comes with any new external device, and make sure you install the driver for it as this will allow you to access any extra functions which come with your device.
  • Page 197 Troubleshooting 7 - 34...

  • Page 198: Appendix A. Specifications

    Appendix A. Specifications Structure • PC 99 Compliant (PC 2001 Compliant) • PCI 2.2 Compliant • ACPI v1.0b Compliant (ACPI v2.0 Compliant) • APM v1.2 Compliant Processor • Intel Pentium Mobile Processor 1GHz/1.06GHz/1.13GHz/1.26GHz/ µ • Supports FC-PGA2 Package? Memory • Two 144-pin SODIMM sockets, supporting Synchronous PC-133 DRAM SODIMM (3.3V) •...

  • Page 199: Lcd

    • 12.1" XGA TFT flat panel Display • Dynamic Video Memory Technology used to allocate system memory for use by graphics device • 128-bit 2D/3D Graphics Engine • Motion Compensation and IDCT for DVD Accelerator • Fully DirectX 7/8 Compliant Graphics Engine •...

  • Page 200: Storage

    Storage • External COMBO Drive Bay (IDE interface) for following drive com- bination: External IDE 24x CD-ROM/ FDD Combo Drive External IDE 8x DVD-ROM/ FDD Combo Drive External IDE 8/4/24 CD-RW/ FDD Combo Drive External IDE 8/4/24 CD-RW/ 24x CD-ROM Combo Drive External IDE 8/4/24 CD-RW/ 8x DVD-ROM Combo Drive External IDE Combi/FDD Combo Drive •...

  • Page 201: Audio

    Audio • AC'97 2.1 Compliant • Advanced Wavetable Synthesizer • DirectSound™ 3D Accelerator • Compatible with Sound-Blaster PRO/ 16 • Full-duplex • Virtual AC3 • Built-in microphone • 2 speakers built-in Keyboard • B5 Size WinKEY keyboard • Built-in Touchpad with scrolling function Instant Keys •...

  • Page 202: Interface

    Interface • One PS2 port • Two USB 1.1 ports (USB 2.0 support) • One mini- IEEE 1394 port • One external IDE connecter for COMBO Drive (FDD/ CD-ROM/ DVD-ROM/ CD-RW Combi/FDD) • One infrared file transfer IrDA1.1, SIR/ FIR •...

  • Page 203: Communication

    Communication • 56K Plug & Play Fax/Modem v.90 compliant • 10M/100M Fast Ethernet (IEEE 802.3 and 802.3u Standard Compliant) • Infrared file transfer IrDA1.1, SIR/ FIR • GPRS module (Option) Power Management • Support ACPI v1.0b (ACPI 2.0) • Support APM v1.2 •...

  • Page 204: Indicator

    Indicator LED indicator (GSM/GPRS, Power/Suspend, Charger, FDD/ • CD-ROM, HDD, Num Lock, Caps Lock, Scroll Lock) H/W Certificate • FCC Class B, CE, VCCI, CTICK, UL, CSA, CNS, TUV S/W Certificate • Windows Logo Environmental Spec • Temperature Relative Humidity º...

  • Page 205: Optional

    Optional • 1001 Standard smart Lithium-ion battery pack, 40 Watt • 1002 Ultra smart Lithium-ion battery pack, 80 Watt • 1003 External IDE 24x CD-ROM/ FDD Combo Drive • 1004 External IDE 8x DVD-ROM/ FDD Combo Drive • 1005 External IDE 8/4/24 CD-RW/ FDD Combo Drive •...

  • Page 206: Glossary

    Glossary AC ( A lternating C urrent) - The power from a standard household electrical outlet. adapter - A device that allows compatibility between different equipment. An AC adapter converts AC current to DC current which is needed to operate a computer. AGP ( A ccelerated G raphics P ort) - A high-speed graphics port that provides a direct connection between the display adapter and mem- application - A program such as a word processor, database or im-...
  • Page 207 boot - The loading of the operating system and other basic software which occurs when you start-up the computer. bus - A collection of wires through which data is transmitted from one part of a computer to another. byte ( b inar y te rm) - A unit of storage capable of holding a single character.
  • Page 208 DC ( D irect C urrent) - Power which a computer requires for opera- tion. DIP switch - A series of tiny switches built into circuit boards which enable you to configure a circuit board for a particular type of com- puter or application.
  • Page 209 flash ROM BIOS - see flash BIOS. function key - The keys F1, F2, … which have specific functions as- signed to them. By pressing one of the function keys you can execute certain commands depending on the computer and operating system you are using.
  • Page 210 change data or use a printer without a cable connection. jack - A connector used primarily to connect external devices to your computer such as a microphone, video source, phone line, etc. jumper - A metal bridge that closes an electrical circuit. They are sometimes used to configure expansion boards.
  • Page 211 puter are LEDs. load - To copy a program from some source, such as a disk or tape, into memory for execution. Lithium-Ion battery - A type of battery which is ideal for notebook computers because of its light weight and high energy density. Also, lithium-ion batteries do not use poisonous metals, such as lead, mer- cury or cadmium.
  • Page 212 when receiving a signal from the telephone line. module - Referring to hardware, a module is a self-contained com- ponent. mouse - The most popular pointing device. It was called a mouse be- cause it more or less resembled one, with the cord being the mouse’s tail.
  • Page 213 PCMCIA Card - A credit-card sized, removable module for porta- ble computers standardized by PCMCIA. Also known as PC Cards, they are 16-bit devices that are used to attach modems, network adapters, sound cards, radio transceivers, solid-state disks and hard disks to a portable computer.
  • Page 214 RAM ( R andom A ccess M emory) - The memory available to pro- grams, different programs will need more or less RAM depending on what they are doing. RAM is the most common type of memory found in computers. reboot - To restart a computer.
  • Page 215 break down. SDRAM ( S ynchronous DRAM ) - A type of DRAM that can run at much higher clock speeds than conventional memory. serial port - A socket on a computer used to connect a modem, mouse, scanner or other serial device to the computer. setup - (1) A utility program which modifies the BIOS.
  • Page 216 TFT ( T hin F ilm T ransistor) - The term typically refers to active ma- trix screens on laptop computers. Active matrix LCD provides a sharper screen display and broader viewing angle compared to pas- sive matrix. USB ( U niversal S erial B us) - Hardware interface for low-speed pe- ripherals such as the keyboard, mouse, joystick, scanner, printer and telephony devices.
  • Page 217 Zoomed Video (ZV) Port - An extension to the PC Card (PCMCIA) standard that provides a high transfer rate for video applications on portable computers. The ZV Port is built into the notebook computer and activated by plugging in an MPEG PC Card that is ZV Port-com- pliant.
