Disassembly

Removing the Keyboard

Figure 14
Keyboard Removal
1. Turn off the computer, and remove the battery
2. Press the three keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you
a. Press the three latches
may need to use a small screwdriver to do this).
to release the keyboard.
3. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable
b. Lift the keyboard up and
4. Disconnect the keyboard ribbon cable
disconnect
the
cable
5. Carefully lift up the keyboard
from the locking collar.
c. Remove the keyboard.
a.
Re-Inserting the Key-
board
When re-inserting the
keyboard firstly align
the three keyboard
tabs at the bottom of
the keyboard with the
slots in the case.
6. Keyboard Module.
2 - 18 Removing the Keyboard
All manuals and user guides at all-guides.com
(Figure
6
1
2
c.
6
(page 2 -
5).
from the locking collar socket
4
c) off the computer.
b.
3
(Figure
b).
.
5
4
5
6
Keyboard Tabs
