Disassembly
Removing the System Memory (RAM)
Figure 6
The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting
RAM Module
Removal
DDRII 667/800MHz. The main memory can be expanded up to 4GB. The SO-DIMM modules supported are 256MB,
512MB and 1024MB DDRII Modules. The total memory size is automatically detected by the POST routine once you
a. Remove the screws.
turn on your computer.
b. Disconnect the fan
Memory Upgrade Process
cable and the cover.
c. Locate
the
RAM
1. Turn off the computer, remove the battery
module.
2. Locate the CPU/RAM bay cover, and remove screws
3. Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover.
4. Carefully disconnect the fan cable
5. Remove the bay cover
6. The RAM will be visible at point
Contact Warning
Be careful not to touch
the metal pins on the
module's
connecting
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's
perfor-
mance.
6. CPU/RAM Bay Cover
• 4 Screws
2 - 10 Removing the System Memory (RAM)
All manuals and user guides at all-guides.com
(page 2 -
.
5
.
6
on the mainboard.
7
a.
2
3
1
c.
7
5).
-
.
1
4
b.
4
5
6
Fan Cable
Make sure you reconnect the fan
cable
5
before screwing down
the bay cover.
