Removing the Wireless LAN Module

1. Turn off the computer, remove the battery
2. The Wireless LAN module will be visible at point
3. Carefully disconnect cable
2
4. The Wireless LAN module
5. Lift the Wireless LAN module
a.
1
c.
4
All manuals and user guides at all-guides.com
(page 2 -
5) and the CPU/RAM bay cover
on the mainboard.
1
, then remove the screw
from the module socket.
3
will pop-up.
4
(
)
Figure d
up and off the computer.
b.
d.
.
(page 2 -
10)
3
2
4
Removing the Wireless LAN Module 2 - 15
Disassembly
Figure 11
Wireless LAN Module
Removal
a. Remove the cover and Io-
cate the heat sink.
b. Disconnect the cable and
remove the screw.
c. The WLAN module will pop
up.
d. Remove the WLAN mod-
ule.
Note: Make sure you re-
connect the antenna ca-
ble to the "Main" socket
(Figure
b).
4. WLAN Module
• 1 Screw
