Feature
Memory Two 200 Pin SO-DIMM Sockets Supporting DDRII (DDR2) 667/ 800 MHz
64-bit Wide DDRII (DDR2) Data Channel
Memory Expandable up to 4GB (512/ 1024/ 2048 MB DDRII Modules)
Supports Dual Channel DDRII (DDR2) SDRAM
2GB OR 4GB Intel® Turbo Memory Module (Option)
Video Adapter Intel GMA X4500HD Integrated Video
Shared Memory Architecture - Supports up to 256MB of Video Memory (dynamically allocated from system memory
where needed)
Supports DirectX10.0
High Preference 3D/2D Graphics Accelerator
Security Security (Kensington® Type) Lock Slot
Fingerprint ID Reader Module (Factory Option)
BIOS One 32Mb SPI Flash ROM
Storage One Changeable 12.7mm(h) Optical Device (CD/DVD) Type Drive (see "Optional" on page 1 - 5) Easy Changeable 2.5"
9.5 mm (h) SATA (Serial) HDD
Audio High Definition Audio
Compliant with Microsoft UAA (Universal Audio
Architecture)
Direct Sound 3D™ Compatible
Keyboard & Winkey Keyboard
Pointing Device Stylus Pen for Touch Panel
Interface Three USB 2.0 Ports
One Headphone-Out Jack
One Microphone-In Jack
One S/PDIF Out Jack
One Internal Microphone
Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note: MS Duo/ Mini SD/ RS
MMC Cards require a PC adapter
All manuals and user guides at all-guides.com
Specification
BIOS Password
Phoenix™ BIOS
2 * Built-In Speakers
Built-In Microphone
Built-In Touchpad with Scrolling Function
2 Built-In Instant Keys (Menu, Rotation)
One RJ-11 Modem Jack
One RJ-45 LAN Jack
One DC-in Jack
One External Monitor Port
One Mini-IEEE 1394a Port
Introduction
System Specifications 1 - 3
