13
TECHNICAL DATA
154 O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
Deviation from ideal flatness
of scan field at 5.5 m
2)
Deviation from ideal flatness
of scan field at 9.0 m 3)
Distance of mirror rotational
axis (zero point of x and y
axis) to rear side of device
Distance between center
point of scan plane and top
edge of the housing
Multiple sampling
1) Protective field resolution 60 mm only available for devices with max. protective field range of 9.0 m.
2) Devices with a max. protective field range of 4.0 m and devices with max. protective field range of 5.5 m.
3) Devices with a max. protective field range of 9.0 m
4) Can be adjusted collectively for all fields or individually for each field.
Safety-related parameters
Table 31: Safety-related parameters
Type
Safety integrity level
SIL claim limit
Category
Performance level
PFH (mean probability of a
D
dangerous failure per hour)
T (mission time)
M
Safe status when a fault
occurs
Interfaces
Table 32: Interfaces
Safety outputs via network
Quantity
Devices with a max. protec‐
tive field range of 4.0 m
Devices with a max. protec‐
tive field range of 5.5 m
Devices with a max. protec‐
tive field range of 9.0 m
Duration of OFF state
Automatic restart after
Voltage supply
Connection type
Length of cable (power supply unit tolerance ± 5%)
Length of cable with wire
cross-section 0.25 mm
microScan3 Core – EFI-pro
≤ ± 100 mm
≤ ± 100 mm
66 mm
40 mm
2 to 16
4)
microScan3 Core – EFI-pro
Type 3 (IEC 61496)
SIL 2 (IEC 61508)
SILCL 2 (IEC 62061)
Category 3 (ISO 13849-1)
PL d (ISO 13849-1)
8 × 10
–8
20 years (ISO 13849-1)
The safety outputs via the network are logic 0.
microScan3 Core – EFI-pro
4
4
4
≥ 80 ms
2 s to 60 s (can be configured)
Male connector, M12, 4-pin, A-coding
≤ 100 m
²
microScan3 Pro – EFI-pro
microScan3 Pro – EFI-pro
microScan3 Pro – EFI-pro
8
8
