13
TECHNICAL DATA
13.3

Data sheet

13.3.1 microScan3 – EFI-pro
152 O P E R A T I N G I N S T R U C T I O N S | microScan3 – EFI-pro
Table 29: Compatibility
Label on the device
–
–
Rev 1.1.0
Rev 1.1.0
Rev 1.2.0
Rev 1.2.0
Features
Table 30: Features
Protective field range
Devices with a max. protec‐
tive field range of 4.0 m
Devices with a max. protec‐
tive field range of 5.5 m
Devices with a max. protec‐
tive field range of 9.0 m
Scanning range of the refer‐
ence contour field
Scanning range of the con‐
tour detection field
Warning field range
Devices with a max. protec‐
tive field range of 4.0 m
Devices with a max. protec‐
tive field range of 5.5 m
Devices with a max. protec‐
tive field range of 9.0 m
Distance measurement range
Devices with a max. protec‐
tive field range of 4.0 m
Devices with a max. protec‐
tive field range of 5.5 m
Devices with a max. protec‐
tive field range of 9.0 m
Fields
Simultaneously monitored fields
Devices with a max. protec‐
tive field range of 4.0 m
Devices with a max. protec‐
tive field range of 5.5 m
Label on the system plug
–
Only compatible with Rev
≥ 1.1.0
–
Only compatible with Rev
≥ 1.1.0
–
Only compatible with Rev
≥ 1.1.0
microScan3 Core – EFI-pro
≤ 4.0 m, details: see "Sensing range", page 158
≤ 5.5 m, details: see "Sensing range", page 158
≤ 9.0 m, details: see "Sensing range", page 158
Same as protective field range,
Same as protective field range,
≤ 40 m
≤ 40 m
≤ 64 m
≤ 40 m
≤ 40 m
≤ 64 m
≤ 8
≤ 4
≤ 4
Compatible
Yes
Information is available from
your SICK subsidiary.
Yes
Yes
Yes
Yes
microScan3 Pro – EFI-pro
see "Sensing range", page 158
see "Sensing range", page 158
≤ 128
≤ 8
≤ 8
8021913/15ZW/2019-11-14 | SICK
Subject to change without notice
