Parameterization

Parameterization

In the configuration software, the IO-Link master is shown as modular slave with a IO-Link
master module (IOLMM) at Slot 1 and four IO-Link devices at slot 2 to slot 5.
Depending on the connected sensor and on the desired function of the slot, the IO-Link
devices are either defined as special TURCK IO-Link sensor (e.g. pressure sensor from the
PS-series), as generic IO-Link devices (e.g. sensors from third-party manufactuers) or as SIO
(Standard Input/Output).

Parameters of the IOLMM (slot 1, IO-Link master module)

The texts in the columns "Parameter name" and "Value/ Meaning" correspond to those deter-
mined in the GSD-file.
Table 11: Parameter name
Parameters of
the IOLMM
(slot 1)
A default- GSD parametrization
settings
single shot event recover delay
D301171 - IO-Link master 1108
Note
The parameters of the IO-Link master module (slot 1) control the communication of
the entire SDPX-IOL4-0001 including all connected sensors.
Value/ Meaning
0 = inactive
A
The IO-Link master will not accept a parameterization
via GSD-file. Only parameterization via Class 2-master
will be accepted.
1 = active
The parameterization of the IO-Link master and the
connected sensors is done by the PLC (Class 1-master).
Any possible parameterization via Class 2-master will
be overwritten by the Class 1-master.
Defines the time a Single Shot Event from an IO-Link
device will be shown on PROFIBUS.
00 = 5 sec.
A
01 = 30 sec.
10 = 5 min.
11 = 15 min.
3
3-19
