Technical features
Table 11: Parameter name
Parameters of
the IOLMM
(slot 1)
port x: cycle mode
port x: cylce time
3-20
Value/ Meaning
00 = free running
A
The IO-lnik master calculates the quickest possible IO-
Link cycle time.
01 = synchronous
The cylce time is defined per port through the parameter
"port x: cylce time" (see below).
All IO-Link devices connected to the ports at which the
same cylce time is set, start synchronously.
10 = fixed value
The IO-Link cylce is fixed, whereas the cylce time on
which this value is based on, is set in parameter "port x:
cycle time" (see below).
Setting the I/O-Link cycle time at the respective port.
It is only valid, if the parameter "cylce mode" (see
above) is set to the values "fixed value" or "synchro-
nous".
– Steps 0.1 ms:
0000 1111 = 1.5 ms
to
0011 1111 = 6.3 ms
– Steps 0.4 ms:
0010 0000 = 6.4 ms
to
0111 1111 = 31.6 ms
– Steps 1.6 ms:
1000 0000 = 32.0 ms
to
1011 1111 = 132.8 ms
