Fieldbus Integration; Io-Link And Fdt/Dtm - turck IO-LINK MASTER User Manual

IO-Link
Figure 3:
Communica-
tion with IO-Link
Industrial Ethernet
Fieldbus

Fieldbus integration

usage of the standard-transport mechanisms of established fieldbusses/ sensor / actuator
busses (DPV0, DPV1, ...)
simple integration in engineering systems by means of configuration files (GSD, GSDML,
...)
comfortable usage of even complex product features by means of tool based engineering
(FDT/DTM, ...)

IO-Link and FDT/DTM

FDT enables a fieldbus and system independent engineering environment to be set up.
Generic DTMs allow any type of sensor and actuator to be integrated easily in the system.
2-4
Control
Decentralised
Periphery
S1 S1
S2 S2
S1 S1
– –
S2 S2
+ +
M M
Communication
S1
S2
S1
–
S2
+
M
D301171 - IO-Link master 1108
