Application example with Siemens PLC and FB 102 (IO-Link CALL)
Whether (and if yes, which) parameter bytes are really written, depends on the setting for
the parameter "parameterization IO-Link Index1". In this case, the option "write Subindex 1
to 8" has to be chosen.
Figure 20:
Writing the
parameter
indices
3 IO-Link ports which are eventually not used can be configured as "unused port" or as
"Generic 0 Byte (SIO mode)".
Figure 21:
Unused ports
D301171 - IO-Link master 1108
Attention
During the writing process, all parameter in the selected subindices are overwritten.
This means that all subindices (here in the example 1 to 8) have to contain the de-
sired parameter values in order not to be overwritten with "0".
