Parameterization

Parameters of slots 2 to 5, IO-Link device module (IOLDM)

Generic IO-Link devices

Table 12:
Parameter name
Parameters of
the generic IO-
Link devices
A default
Identification
setting
vendor
device-ID 1
to
device-ID 3
The following parameters describe the IO-Link index 1 (subindex 1 to 12), which, in prin-
ciple, hass to be supported by all IO-Link devices. If this index is used for the sensors'
parameterization or not, depends on the respective sensor. Please find the meaning of the
subindices in the documentaion for the respective sensor.
parametrization IO-Link
Index 1
D301171 - IO-Link master 1108
Note
The parameters for the IO-Link device modules (slot 2 to slot 5) always depend on
the connected device.
Note
Sensors which are not part of the IO-Link master's GSD-file (e.g. sensors from 3rd-
party-manufaturers) are treated as generic IO-Link devices.
Please observe, that the selected data width in the hardware configurator has to be
≥ the process data width of the connected device. →
the IO-Link
ports".
Value/ Meaning
00 = any device
The data width of the connected sensor has to match the
data width of the configured one. In addition to that, the
cylce time for the cycle modes "fixed value" and "synchro-
nous" has to be ≥ the devices minimum cycle time .
10 = same device type
The connected sensor has to be the same as the config-
ured one. Vendor- and device-ID have to match.
0
A
Enter the vendor-ID for the connected sensor
(TURCK e. g. 317).
0
A
Enter the device-ID for the connected sensor.
Defines whether (and if yes, which) parameter settings from
"parameter in subindex 1" to "parameter in subindex 12"
should be downloaded to the connected device.
0000 = inactive
0001 = write subindex 1
0010 = write subindex 1 to 2
...
1100 = write subindex 1 to 12
A
to 32767
to 255
A
Chapter
4,
"Configuration of
3-21
3
