Process image

Process image

The module SDPX-IOL4-0001 sends 2 byte process input data. It has no process output data.

Process input data

Byte Bit Name
0 0 DI channel 0 (port 1)
1 DI channel 1 (port 1)
2 DI channel 2 (port 2)
3 DI channel 3 (port 2)
4 DI channel 4 (port 3)
5 DI channel 5 (port 3)
6 DI channel 6 (port 4)
7 DI channel 7 (port 4)
1 0 PD valid channel 0 (port 1) 0
1 PD valid channel 1 (port 1) 0
2 PD valid channel 2 (port 2) 0
3 PD valid channel 3 (port 2) 0
4 PD valid channel 4 (port 3) 0
5 PD valid channel 5 (port 3) 0
6 PD valid channel 6 (port 4) 0
7 PD valid channel 7 (port 4) 0
D301171 - IO-Link master 1108
Default Description
0 status PIN 4 of port 1, if in SIO-mode
0 status PIN 2 of port 1
0 status PIN 4 of port 2, if in SIO-mode
0 status PIN 2 of port 2
0 status PIN 4 of port 3, if in SIO-mode
0 status PIN 2 of port 3
0 status PIN 4 of port 4, if in SIO-mode
0 status PIN 2 of port 4
process data (PD) valid at "1"
process data (PD) valid at "1"
process data (PD) valid at "1"
process data (PD) valid at "1"
process data (PD) valid at "1"
process data (PD) valid at "1"
process data (PD) valid at "1"
process data (PD) valid at "1"
