4.4 System Modules

The system modules are briefly introduced in the following sections. According to your or-
der configuration, some of these options might be installed.

4.4.1 Air Displacement Pipetting Arm (Air LiHa)

The PyroTec™ PRO is equipped with an Air LiHa which is a robotic arm having multiple pi-
pette tip for general pipetting tasks. The Air LiHa working principle is based on air displace-
ment technology where a Plunger Drive, directly mounted on top of a pipetting channel,
varies the volume of an air chamber for aspiration and dispensing. The Air LiHa is designed
for use with disposable tips only.
General Data
Usable tips
Number of channels
Tip spreading
Volume range
Theoretical resolution
Dispense speed
Dispense modes
DiTi pickup force
Pipetting Precision
Special functions
PyroTec™ PRO Hardw are User's Manual, V1.2
Disposable tips
Conductive
•
With filter
•
8
Distance from tip to tip
0.5 µl to 1000 µl (1 ml)
0.1 µl
1000 µl
0.5 µl to max. volume
5 µl to max. volume
23 N +/- 4 N
Refer to the tables in Air LiHa Pipetting Precision below.
Liquid level detection
pLLD and PMP
Lower DiTi eject
Return to TOC
1000 µl
9 to 38 mm (0.31 to 1.5 in.)
less than 2 seconds
Free (non-contact) dispense for
single pipetting or contact dis-
pense
Free (non-contact) dispense for
multi pipetting
See corresponding sections with
the same names.
