Serial Number The identification data is also printed on the serial number label (B). This label can be
Label viewed from the front side of the instrument and is attached below the diluters.
Instrument
Instrument equipped with:
Heights
Air displacement pipetting arm, Air LiHa
Robotic manipulator arm, RoMa
Dimensions
Safety Panel
Opening
Dimensions of the opening in the front safety panel:
PyroTec™ PRO: 1130 x 170 mm (44.5 x 6.7 in.)
Supply Ratings
Line voltage (single phase)
Frequency
Power
Fuses
Note: Considering possible under voltage on the mains supply, the combined power con-
sumption in the lower input voltage band (100 - 120 VAC) must not exceed 1000 VA in or-
der to keep the input current below the fused values.
Electrical
Classification with regard to electrical safety according to EN/IEC standards:
Safety
Overvoltage category
Pollution degree
Power Switch
The power switch is placed at the level of the front access panel. The power switch does
not switch the mains voltage directly, but gives a control signal to the power supply.
Specification
Circuit break
Power on delay
Power off delay
PyroTec™ PRO Hardw are User's Manual, V1.2
II IEC 60664-1
2 (EN) IEC 61010-1
Description
By unplugging the instrument.
0.2 - 0.5 sec.
1 - 2 sec.
Return to TOC
Instrument height:
1070 mm 42.1 in.
920 mm 36.2 in.
PyroTec™ PRO
100 - 120, 220 - 240 V AC
(-15% / +10%)
50/60 Hz
1200 VA
2 x T10A (instrument power)
x T2A (main powered op-
•
tions)
