Air LiHa
Operating
Ranges
X-axis
Y-axis
Z-axis
Clearance The tip clearance is the maximum space between the worktable surface and the mounted
tip (initial position).
Tip type
DiTi adapter (A)
Reference tip (B)
DiTi 1000 µl (C)
Air LiHa
The positioning accuracy of the Air LiHa allows for the following applications:
Accuracy/
Precision
• Air LiHa can be used in combination with 96-well microplates.
The equidistant movement of sampling tips in Y direction is:
Equidistant Tip
• from 9 mm ± 0.4 mm
Movement
• to 38 mm ± 1 mm
Disposable
Use only Lonza disposable tips. Conductive disposable tips are available with filter, in fol-
Tips
lowing volumes:
• 1000 µl
DiTi Carrier
A DiTi Carrier holds up to three trays of 96 disposable tips.
Air LiHa Tip Adapter
The Air LiHa is equipped with a special type of tip adapters, which contain a pressure sen-
sor, the electronics for the Air LiHa MultiSense functions and a user replaceable Inline fil-
ter.
PyroTec™ PRO Hardw are User's Manual, V1.2
Axis
Tip clearance
260 mm (10.24 in.)
210 mm (8.27 in.)
178 (7.01 in.)
Axis
X
Y
Z
LiHa type
All Refer to section on Worktable
8-tip LiHa
All
Repeatability
±0.15 mm (0.006 in.)
±0.15 mm (0.006 in.)
±0.3 mm (0.012 in.)
Return to TOC
PyroTec™ PRO
Access Range
373 mm (14.7 in.)
mm (8.27 in.)
210
