How to Lift Lifting the Instrument
the
To lift the instrument, the transport handles must be applied to the base structure of the
Instrument
instrument. Consider the safety instructions above.
A – Transport handle
To apply the transport device, proceed as follows:
Attach all four transport handles
•
• Shift bars through the handles
• Secure the bars with the pins

7.2 Storage

Protect the instrument against dust and debris with a cover. For long-term storage, pack
the instrument in its original packing.

7.3 Packaging

Packing the PyroTec™ PRO
Packaging
The figure shows the packaging of the PyroTec™ PRO:
dimensions
Instrument
PyroTec™ PRO
PyroTec™ PRO Hardw are User's Manual, V1.2
B – Bar
Length Width
156 cm 92 cm
Approx. 61.4 in Approx. 36.2 in
C – Pin
Height Gross Weight
121 cm Approx. 250kg
Approx. 49 in Approx. 551
lbs.
RT-MN024-1.2 02/21
