ZYNQ FPGA Development Board AC7010/AC7020 User Manual
J12 Expansion Header Pin Assignment
J11 Pin
PIN1
PIN2
PIN3
PIN4
PIN5
PIN6
PIN7
PIN8
PIN9
PIN10
PIN11
PIN12
PIN13
PIN14
PIN15
PIN16
PIN17
PIN18
PIN19
PIN20
PIN21
PIN22
PIN23
PIN24
PIN25
PIN26
PIN27
PIN28
PIN29
PIN30
PIN31
PIN32
PIN33
PIN34
39 / 40
Signal Name
GND
+5V
IO35_L3N
IO35_L3P
IO35_L6P
IO35_L6N
IO35_L18P
IO35_L18N
IO35_L14P
IO35_L14N
IO35_L17N
IO35_L17P
IO35_L12N
IO35_L12P
IO35_L16P
IO35_L16N
IO35_L13P
IO35_L13N
IO35_L10N
IO35_L10P
IO35_L19P
IO35_L19N
IO35_L20P
IO35_L20N
IO35_L8P
IO35_L8N
IO35_L2P
IO35_L2N
PS_MIO9
PS_MIO14
PS_MIO11
PS_MIO8
PS_MIO13
PS_MIO15
Amazon Store: https://www.amazon.com/alinx
ZYNQ Pin Number
-
-
D18
E17
F16
F17
G19
G20
J18
H18
H20
J20
K18
K17
G17
G18
H16
H17
J19
K19
H15
G15
K14
J14
M17
M18
B19
A20
B5
C5
C6
D5
E8
C8
