Page 1 6F8C1388 Unified Controller Single-Loop Controller LC531/LC532 Instruction Manual...
Page 2 (1) The technical information provided herein describes typical operations and applications of the product and does not guarantee the intellectual property rights or other rights of Toshiba or third parties nor allows license of its use. (2) No part or the whole of this document may be reproduced without prior consent.
Page 3 Safety Precautions On the product and this instruction manual, important information for safe and correct use to prevent danger to the user and other people as well as property damage is described. Understand the following information (signs and symbols) before reading the text, and follow the described items.
Page 4 Checking the Warning Labels on the Main Unit Make sure warning markings are attached on the main unit. If any of them are missing or the wording is illegible, contact our Service Department. Safety Precautions on Installation WARNING Ground the device. Provide dedicated Type D grounding for Ground each of the transmission paths.
Page 5 Safety Precautions on Maintenance and Inspection WARNING Turn off power when you Make sure that the external remove or insert module or power is turned off when you boards, or connect any device. remove or insert modules after Mandatory Mandatory wiring is completed.
Page 6 Toshiba's If not, it may cause damage of the service representatives. device, or fire due to overheat, as well as not obtaining the original Using it as it is may cause fire due to performance of the device.
Page 7 CAUTION Do not touch components Do not insert or drop metallic such as the parts, terminals, objects or clips into the Prohibited connectors and soldered Prohibited device through any opening surfaces inside the module or in the device. on the boards. It may cause fire.
Page 8 Precautions on Transportation and Storage CAUTION Observe the care mark indicated on the packaged box during transportation and Mandatory storage. Modules may be damaged if the care mark is not observed. Do not give shock to the product during transportation and storage. Products are stored in a conductive mat and then packaged.
Page 9 ■ Toshiba shall not be responsible for any damage caused by an fire, earthquake, for which Toshiba is not responsible for, acts of a third party, other accidents, the user's willful acts or negligence, misuse, or use in abnormal conditions.
Page 10 Precautions for System Application CAUTION  System Redundancy The product is manufactured to the best possible quality, but is yet subject to failure due to accidental failure of electronic parts, for example. If your system requires a specially high degree of reliability, it is recommended that you provide such a system with product redundancy, or with other means of backup.
Page 11 • Toshiba is not liable to any responsibility whatsoever for any inconveniences arising from using the product contrary to the precautions specified in this manual or to the procedures for installation and operation specified in laws and ordinances.
Page 12 • Repacking When you are shipping parts for repairs, be sure to place internal parts in a case and package it in the same way as they were originally packaged in the factory. This is important to protect them from breakdown. Do not package internal parts without the protection of a case.
Page 13 Introduction Unified Controller nv series is new integrated controllers that can be applied to small- to large-scale electric control and instrument control. The LC531/LC532 controller is a controller for instrument control called a single-loop controller that covers ultra-small instrument control. This manual describes the Unified Controller nv series Single-Loop Controller LC531/LC532 .
Page 14 ●Notational conventions The following are the notational conventions for better understanding of this document. Describes what the user should be particularly aware of to handle the product correctly. Important: Describes what the user should observe to handle the product correctly. Note: Describes a remark.
Page 15 System Configuration ·················································· 4 Chapter 1 1.1.1 Connection with the monitoring system Overview of via Ethernet transmission ·················· 4 Single-Loop 1.1.2 Connection via EC bus transmission ························· 5 Controller 1.1.3 Connection with the CIEMAC-DS system LC531/LC532 via the PLC server ··························· 6 …1 1.1.4 Connection with the S3 controller...
Page 16 Program Operation ···················································· 42 Chapter 3 3.1.1 Program types ··················································· 42 Software 3.1.2 Program structure ··············································· 42 Functions 3.1.3 Program management ········································· 43 …41 Variables ··································································· 45 3.2.1 Variable types ···················································· 45 3.2.2 Variable classification table ··································· 47 3.2.3 Variable initialization ············································ 48 ·············································································...
Page 17 Registration of PU811 Controller Using Chapter 4 Inter-Controller Transmission ········ 78 Registration and 4.7.1 Registration of inter-controller transmission variables · 78 Setting Using 4.7.2 Registration of a program to start Engineering Tool inter-controller transmission ·············· 78 …53 Registration of PUM1* Controller Using Inter-Controller Transmission ········...
Page 18 System Log Function ··············································· 105 Chapter 7 Alarm Display Functions of Side Display ·················· 106 Troubleshooting Alarm Display Functions of Loop Display ················· 107 …103 WDT Signal Output ··················································· 108 Daily Check ······························································ 110 Chapter 8 Periodic Check ························································· 111 Maintenance and Expendable Parts ·····················································...
Page 19 LC531S*S/LC532S*S Type ········································ 136 Appendix C LC531E*S/LC532E*S Type ········································ 137 Outline Drawing …135 Error Log ·································································· 141 Appendix D Event Log ································································· 148 System Log Intervention Event Log ············································· 151 …139 Transmission Event Log ··········································· 152 System Variables (ZW) ············································· 155 Appendix E Tag Variables (PV, LP, PB) ·········································...
Page 20 Alarm Details ···························································· 190 Appendix H How to Operate Side Keyboard ································ 194 Details of Side H.2.1 Change the Side Display Indication (to English) ······· 195 Keyboard H.2.2 Display the Alarm Currently Generated ··················· 195 Operation and H.2.3 Change the Operation Mode ································ 196 Side Display H.2.4 Change the Tag ·················································...
Page 21 Chapter 1 Overview of Single-Loop Controller LC531/LC532 This chapter describes the following characteristics of the LC531/LC532 main unit and housing, and the names and functions. ···················································· 4 System Configuration 1.1.1 Connection with the monitoring system via Ethernet transmission ··················· 4 1.1.2 Connection via EC bus transmission ···························...
Page 22 Chapter 1 Overview of Single-Loop Controller LC531/LC532 The current output type single-loop controller LC531 and the pulse output type single-loop controller LC532 (hereafter LC531 and LC532 called "LC53*") is a controller of the Unified Controller nv Series for instrument control for ultrasmall scale.
Page 23 1.1 System Configuration ● Network installation It has the Ethernet communication port and RS485 communication port allowing connection with other LC53* units, connection with other controllers, and connection with the monitoring system for data exchange or display, operation, and monitoring from the monitoring system. Unified Controller nv Series Single-Loop Controller LC531/LC532 Instruction Manual...
Page 24 Chapter 1 Overview of Single-Loop Controller LC531/LC532 1.1 System Configuration The LC53* has the RS485 communication port and Ethernet communication port that allow flexible system configuration depending on the scale of the plant and purpose of usage. It also has I/O’s so there is no need to connect additional I/O modules.
Page 25 1.1 System Configuration 1.1.2 Connection via EC bus transmission The LC53* can perform EC bus transmission using the RS485 communication port. The LC53* can be connected to a system with the EC300 series controller via EC bus transmission. Up to 31 units of the EC300 series controllers and LC53* units in combination can be connected.
Page 26 Chapter 1 Overview of Single-Loop Controller LC531/LC532 1.1.3 Connection with the CIEMAC-DS system via the PLC server The LC53* can be connected to the CIEMAC-DS control LAN (Ethernet) via the PLC server. In this connection configuration, the following transmission can be performed.
Page 27 1.1 System Configuration 1.1.4 Connection with the S3 controller via the Ethernet module The LC53* can be connected to the S3 controller via the Ethernet module (EN311). This connection configuration enables inter-controller transmission with the S3 controller via the EN311. For details of the inter-controller transmission variables of the LC53*, refer to "Appendix E.5 Inter-controller Transmission Variables (STN_DATA)".
Page 28 Chapter 1 Overview of Single-Loop Controller LC531/LC532 Note • The network between the LC53* and EN311 is for inter-controller transmission only and not intended for other forms of communication (socket communication, computer link and PC link). • Use one of the S3 controller sockets (this means one less socket for socket communication). •...
Page 29 1.1 System Configuration 1.1.5 Connection with the PU811 controller via the Ethernet module The LC53* can be connected to the PU811 controller via the Ethernet module (EN911). This connection configuration enables inter-controller transmission with the PU811 controller via the EN911. For details of the inter-controller transmission variables of the LC53*, refer to "Appendix E.5 Inter-controller Transmission Variables (STN_DATA)".
Page 30 Chapter 1 Overview of Single-Loop Controller LC531/LC532 Note • The network between the LC53* and EN911 is for inter-controller transmission only and not intended for other forms of communication (socket communication, computer link and PC link). • Use one of the PU811 controller sockets (this means one less socket for socket communication).
Page 31 1.1 System Configuration 1.1.6 Connection with the Remote I/O via the MODBUS LC53* can be connected to remote I/O via MODBUS. Refer to “4.2.4 Remote I/O Registration” for the remote I/O registration method. For the structure of remote I/O data, refer to “Appendix E.6 Remote I/O Variables (MIO_EXT)”.
Page 32 Chapter 1 Overview of Single-Loop Controller LC531/LC532 1.1.7 Connection with the PUM1* controller via the Ethernet module The LC53* can be connected to the PUM1* controller via the Ethernet module (EN655). This connection configuration enables inter-controller transmission with the PUM1* controller via the EN655. For details of the inter-controller transmission variables of the LC53*, refer to "Appendix E.5 Inter-controller Transmission Variables (STN_DATA)".
Page 33 1.1 System Configuration ● inter-controller transmission specification 項目 Specification Remark Station number system Station number is between 1 and 32, Lower Maximum station quantity two-digit number of IP address (Decimal) is 32 Scan memory Transmit：64 words per station Receive ：64 words × 32 stations＝2048 words Maximum capacity ...
Page 34 Chapter 1 Overview of Single-Loop Controller LC531/LC532 1.2 Names and Functions of the LC531/LC532 The figure below shows the appearance of the single-loop controller LC53*. Loop display LC53* main unit Side display Loop display area Side keyboard Loop display operation area Figure 1-7 Appearance of the LC53* 6F8C1388...
Page 35 1.2 Names and Functions of the LC531/LC532 1.2.1 Loop display (front) The figure below shows the display area and operation area of the loop display of the LC53*. (18)TAG NO. plate (10)Numeric display (white) (3)SV setting pushbutton (7)HALT display (red) 1 0 0 (8)ALARM display (red) R･M...
Page 36 Chapter 1 Overview of Single-Loop Controller LC531/LC532 (2) MV Manual operation pushbutton Manipulated variable output can be changed by this switch in the M mode. means OPEN, means CLOSE operation. are pressed together, the rate-of-change (speed) becomes FAST. (3) SV setting pushbutton At the time of mode operation without SV change prohibition, or in the mode operation, the SV set point value can be changed by this pushbutton.
Page 37 1.2 Names and Functions of the LC531/LC532 (8) ALARM display Normally, the ALM display is off. ON display indicates a process alarm or error state. For details, refer to "Chapter 7 Troubleshooting". (9) CMP display Normally, the CMP display is off. ON display indicates a computer intervention state or error state.
Page 38 Chapter 1 Overview of Single-Loop Controller LC531/LC532 (16) Status display The target type PV, SV, or MV for numerical display is displayed. (17) USB communication port The nv Engineering Tool or maintenance tool can be connected directly. (18) TAG No. plate The TAG number is written on the plate.
Page 39 1.2 Names and Functions of the LC531/LC532 1.2.2 Switch area, side display/side keyboard area (side) Loop display Maintenance switch (Left Side View) Status indicator (LED) Maint.SW. LNK １００M １０M Rotary switch (0 to F) Eng.SW Engineering selection switch BATTERY CR2032 Battery ...
Page 40 Chapter 1 Overview of Single-Loop Controller LC531/LC532 Table 1-1 LC53* DIP switches Switch type SW No. Description Maintenance switch Reserved (Maint.SW.) Reserved Firmware DL (ON) (Note) Normally, set all Reserved switches to "OFF." Reserved Reserved Reserved Reserved Engineering switch Memory clear (ON) (Eng.SW.) Reserved Reserved...
Page 41 1.2 Names and Functions of the LC531/LC532 Table 1-2 LC53* rotary switches Description Setting of higher digits (0 to F) Setting of lower digits (0 to F) The switches are used to set an Ethernet IP address. The lowest address of the IP address is set in 2-digit hexadecimal.
Page 42 Chapter 1 Overview of Single-Loop Controller LC531/LC532 1.2.3 Terminal block part (back) Figure 1-9 shows the terminal block part on the back of the LC53*. The back of the instrument main unit consists of the Ethernet communication port (RJ45CN), terminal block (TB1) with screws, and RS485 terminating resistance switch.
Page 43 1.2 Names and Functions of the LC531/LC532 ■ TB1 terminal block (Right side) This is the terminal block to connect power supply and process I/O signals of the LC53*. Table 1-5 External connections of the TB1 terminal block (right) Terminal External connection Remark Right side...
Page 44 Chapter 1 Overview of Single-Loop Controller LC531/LC532 6F8C1388...
Page 45: Table Of Contents
Chapter 2 Installing, Removing and Connection This chapter describes the installing and removing of the LC531/LC532 main unit and housing, and the connection of terminal blocks and cables. ··················································· 26 Before Starting Work 2.1.1 Working conditions ················································ 26 2.1.2 Working procedures ··············································...
Page 46: Before Starting Work
Chapter 2 Installing, Removing and Connection 2.1 Before Starting Work Before starting work, confirm the working conditions and procedures as follows. 2.1.1 Working conditions ● A place as free of moisture and dust as possible and not exposed to direct sunlight.
Page 47 2.1 Before Starting Work Note • Never disassemble any part other than specified in this manual. It may cause damage to the equipment. Important • Before work, make sure to turn off the power of the LC53*. Otherwise, it may cause burnout or an electric shock.
Page 48: Installing Or Removing The Lc531/Lc532
Chapter 2 Installing, Removing and Connection Installing or Removing the LC531/LC532 This section describes how to mount and remove the LC53* main unit from the housing. The LC53* consists of the LC53* main unit and the housing. The LC53* can be installed with only the supplied hardware or with the supplied hardware and support angle, depending on the size of the housing.
Page 49 2.2 Installing or Removing the LC531/LC532 Clamping hardware Housing top 3 Rotate the bar to fix the housing to the installing panel. Installing panel Screwdriver Housing side Support angle Figure 2-3 Using the clamping hardware Housing back Housing side Support angle Support angle 4 Fix the housing to the support 2.5mm or more...
Page 50: Lc531E*S/Lc532E*S (Housing Depth 250Mm)
Chapter 2 Installing, Removing and Connection 2.2.2 LC531E*S/LC532E*S (housing depth 250mm) ■ Installing Insert the housing (in which the LC53* main unit is mounted) from the front of the panel. (Figure 2-5) Place the clamping hardware on the top and bottom. (Figure 2-5) Rotate the bar of the clamping hardware placed on the top and bottom with a slotted screwdriver to fix the housing to the panel.
Page 51 2.2 Installing or Removing the LC531/LC532 Mount the clamping hardware on the top Housing 3 Rotate the bar to fix the housing to the installing panel. Installing panel Screwdriver Housing side Housing bottom Installing panel Mount the clamping hardware on the bottom Figure 2-6 Using the clamping hardware Unified Controller nv Series Single-Loop Controller LC531/LC532 Instruction Manual...
Page 52: Removing The Lc531/Lc532 Main Unit
Chapter 2 Installing, Removing and Connection 2.2.3 Removing the LC531/LC532 main unit Push the bottom lock of the LC53* main unit upward to release the lock. With the lock released, pull out the LC53* main unit by holding the edge of the front operation panel.
Page 53: Panel Installation
2.2 Installing or Removing the LC531/LC532 2.2.4 Panel installation The dimensions of the panel cut opening for installing the LC53* to the panel are shown below. (72.3×n-4) +1.0 +0.7 +1.0 Stand-alone Install n units ● When installing the LC53* units in the vertical direction, allow a space (G) of 50mm or more in-between.
Page 54: Rs485 Communication Cable Connection
Chapter 2 Installing, Removing and Connection 2.3 RS485 Communication Cable Connection 2.3.1 RS485 communication cable connection For EC bus (or MODBUS) transmission, connect the RS485 communication cable to the terminal block (TB1) on the back of the LC53* as shown below. Transmission signal line (+) Transmission signal line (-) Transmission cable...
Page 55: Ec Bus Transmission Termination Process
2.3 RS485 Communication Cable Connection 2.3.2 EC bus transmission termination process To connect multiple units of the LC53* with EC bus transmission, you need to perform termination process for the LC53*s connected at the terminal position. For termination process, set the RS485 terminating resistance switch on the terminal part (back) of the LC53* main unit to ON.
Page 56: Direct Connection Of The Nv Engineering Tool
Chapter 2 Installing, Removing and Connection 2.4 Direct connection of the nv Engineering Tool LC53* and nv Engineering Tool can be connected as 1:1. The following explains how to make a connection. 2.4.1 Ethernet connection The nv Engineering Tool can be connected directly to the LC53* without using a hub.
Page 57: Usb Connection
2.4 Direct connection of the nv Engineering Tool 2.4.2 USB connection The nv Engineering Tool can be connected directly via the USB communication port on the front panel of the LC53*. When using USB connection for the first time, you need to install the USB driver to the PC for the nv Engineering Tool.
Page 58: Grounding
Chapter 2 Installing, Removing and Connection Grounding 2.5.1 Caution for grounding ■ Single grounding This unit should be grounded singly. Mixed grounding with other devices may cause malfunction. ■ Insulation from building Insulate the cabinet from the building to prevent the noise current flowing in the building from adversely affecting it.
Page 59: Ground Bus
2.5 Grounding 2.5.3 Ground bus ■ Connecting two or more controllers within a room to the ground bus To connect two or more controllers within a room to a ground bus, attach lead-in terminals to the ground bus, or use bolt connectors as shown in Figure 2-14.
Page 60: Withstand Voltage Test
Chapter 2 Installing, Removing and Connection 2.5.4 Withstand voltage test To carry out a withstand voltage test, apply a voltage (500 VAC) between the power supply common and the grounding of a terminal block for one minute. To protect the equipment from damage due to a stray test voltage, or to malfunction, disconnect the power cable and input signal cable in advance.
Page 61 Chapter 3 Software Functions This chapter describes the software functions such as program operations, variables, and standard inputs and outputs. ······················································ 42 Program Operation 3.1.1 Program types ····················································· 42 3.1.2 Program structure ················································· 42 3.1.3 Program management ··········································· 43 ·····································································...
Page 62: Program Operation
Chapter 3 Software Functions 3.1 Program Operation 3.1.1 Program types The LC53* can use only Main Scan Task as a user program. Main Scan Task can register 8 programs that are executed repeatedly at specific cycles. You can set an execution cycle with the nv Engineering Tool. Table 3-1 Main scan task specifications Program Purpose...
Page 63: Program Management
3.1 Program Operation Program main body Function Main Function block Scan Task Instruction User function Standard function User function block Task Program Standard function entry User function Standard function User function block Standard function User function block ...
Page 64 Chapter 3 Software Functions For example, if the following programs are created and downloaded at once, 34 blocks of code memory will be occupied. Number of Number of Program steps blocks Main Scan Task Entry 0 MS_0 Program 0 Main Scan Task Entry 1 MS_1 Program 1...
Page 65: Variables
3.2 Variables 3.2 Variables 3.2.1 Variable types A variable is memory (or memory area) that can be referred to from programs. Variables can be classified into different types depending on the purpose. The detailed specifications of variables are described below. (1) Classification of variables based on scope Variables can be classified into the following two types based on the scope of reference.
Page 66 Chapter 3 Software Functions (2) Classification of variables depending on definition method There are variables that allow the user to freely define their names and types (user variables), and variables that have predetermined names and data types depending on their use (standard variables). Variables that allow the user to define their names and types include the instance variables and temporary variable that are classified as local variables, and the user variables that are classified as controller global...
Page 67: Variable Classification Table
3.2 Variables 3.2.2 Variable classification table The table below shows variable classification based on scope, definition method, and usage. "EA" in the table means logical numbers for identifying classified variables. For normal control programs, you don't have to be aware of them because variable names are specified.
Page 68: Variable Initialization
Chapter 3 Software Functions 3.2.3 Variable initialization Variables are initialized automatically when the controller starts up (at power-on and when the mode changes from HALT to RUN). Table 3-5 Variable initialization Name Description Instance variable Zeroed Temporary variable Undefined System variable Continued User variable...
Page 69: I/O
3.3 I/O 3.3 I/O 3.3.1 Standard built-in I/O The LC53* has built-in I/Os by standard. Therefore, when standard built-in I/Os are used, no additional I/O module needs to be registered. I/O data can be input or output with I/O variables (SIO). The table below shows the description of the standard built-in I/Os.
Page 70: Standard I/O
Chapter 3 Software Functions 3.4 Standard I/O 3.4.1 Tags and standard I/O functions The relations between tags, standard I/Os, and programs are described below. Standard I/O functions consist of PV process, LP process, and PB process. Assuming general process control, the external sensor signal is input to the PV process as a feedback value first.
Page 71: Standard I/O Process
3.4 Standard I/O 3.4.3 Standard I/O process The standard I/O processes perform correction calculation, conversion process, and alarm process for the I/O data of the I/O module according to the parameters of the tag variables. The standard I/O process for different types of tags are described below.
Page 72 Chapter 3 Software Functions ■ Pulse instantaneous value conversion For pulse instantaneous values, only input from the intelligent serial PI module is used. The following instantaneous value calculation is performed. (Instantaneous Value) = [(Pulse Difference Count) X PU X D X K X T] /(Scan Time) Similarly to the analog instantaneous value, correction can be made in the application.
Page 73 3.4 Standard I/O (2) LP process The following processes are performed according to the controller (parameter) settings. ■ Current output conversion When Control Mode = For C, A, or RM, MV is converted to the output counter of intelligent serial AO. Output Direction＝R: MV is 0-100%, and AO is 4-20mA output.
Page 74: Process Alarm
Chapter 3 Software Functions 3.4.4 Process alarm When tag registration is performed, process alarm generation/recovery process is executed. The details of process are as follows. Table 3-8 Process alarm table TAG instrument variable Description DPL (PV change rate) alarm PL (PV lower limit) alarm Indicator variable PH (PV upper limit) alarm...
Page 75 Chapter 4 Registration and Setting Using Engineering Tool This chapter describes system registration and parameter setting methods for the LC531/LC532 using the nv Engineering Tool by using simple system examples. For how to operate the Engineering Tool 2, refer to " nv series/V series Engineering Tool 4 Instruction Manual –Basic- 6F8C1290".
Page 76 Chapter 4 Registration and Setting Using Engineering Tool Registration of PU811 Controller Using ·················· 78 Inter-Controller Transmission 4.7.1 Registration of inter-controller transmission variables ··· 78 4.7.2 Registration of a program to start inter-controller transmission ···· 78 Registration of PUM1* Controller Using ··················...
Page 77: Example Of System Configuration
4.3 Tag Registration 4.1 Example of System Configuration Because the I/O input and output of the LC53* are built-in, you don't need to register a new I/O module. The LC53* has multiple analog I/Os and digital I/Os. In the example below, 1 point of MV output, 1 point of analog output, 2 points of analog inputs, 3 points of digital input, and 3 points of digital output are used.
Page 78: Hardware Configuration Registration
Chapter 4 Registration and Setting Using Engineering Tool 4.2 Hardware Configuration Registration Register hardware configuration with the system product tree of the nv Engineering Tool. The system name and station configuration are as follows. Hardware configuration shall be registered using the product tree of the nv Engineering Tool.
Page 79 4.2 Hardware Configuration Registration Double-click the created system (LC531 Sample) at the upper right of the screen to open the system and select the "Station" folder shown at the lower left of the screen with the mouse and select <New> in the <File>...
Page 80 Chapter 4 Registration and Setting Using Engineering Tool Expand the created unit "00 (MainUnitLC)" at the upper left of the screen with the mouse, select the "Modules" folder with the mouse, and select <New> in the menu. Select the slot number (0) and module model name (LC531) in the input dialog.
Page 81: Network Registration
4.2 Hardware Configuration Registration 4.2.2 Network registration Select the "Networks" folder in the product tree with the mouse, and select <New> in the menu. Select the network number (1) and network model name (EtherLAN) to add the network. Figure 4-7 Adding a network Expand the created network "001 (EtherLAN)"...
Page 82 Chapter 4 Registration and Setting Using Engineering Tool As a result of the operations above, the network and LC531 module are registered as shown below. Figure 4-9 Network module screen after registration 6F8C1388...
Page 83: Module Parameter Registration
Chapter 4 Registration and Setting Using Engineering Tool 4.2.3 Module parameter registration Select the "Modules" (00(LC531)) at the lower left on the screen with the mouse and select <Module Parameters> in the <File> menu. Figure 4-10 Network module registration screen Enter necessary parameters on the Module Parameters screen.
Page 84: Tag Registration
4.3 Tag Registration 4.3 Tag Registration Next, register I/Os to be used to tags. In this example, register the tag types and I/Os as shown in the table below. Next, I/O to be used shall be registered to tags. The types of tags and I/O shown as below are registered.
Page 85 4.3 Tag Registration Select "PV: Indicator" for "Parameter". Specify "Record No." Figure 4-13 PV indicator setting screen Table 4-3 Available tag types and record numbers Tag type Parameter type Record No PV: Indicator 1 to 48 LP: Controller 1 to 8 PB: Pushbutton 1 to 32 Unified Controller nv Series Single-Loop Controller LC531 Instruction Manual...
Page 86 Chapter 4 Registration and Setting Using Engineering Tool Select < Parameter Copy> in the Edit menu on the toolbar of the tag editor, and copy the initial values of the tool. A dialog window is displayed. Select "Initial Value" in "Contents of copy" and click Figure 4-14 Parameter initial value copy setting screen Initial values are set to the tag parameters.
Page 87 4.3 Tag Registration Register necessary parameters to tag. Minimum required items for tag registration are shown below. Other items can be left as initial values. Set any of these items if necessary. For details of all parameters, refer to "Appendix E.2 Tag Variables (PV, LP , PB) ".
Page 88 Chapter 4 Registration and Setting Using Engineering Tool Figure 4-16 Example of settings PV: Indicator and LP: Controller for Loop 1 (LP001) Figure 4-17 Example of settings PV: Indicator and LP: Controller for Loop 2 (LP002) 6F8C1388...
Page 89 4.3 Tag Registration To associate a PV tag and LP tag, first define a tag number for the PV tag, and register other parameters. Next, define a PV record number for the LP tag, and register other parameters. When the PV tag and LP tag are associated, the tag variable is automatically registered as shown below.
Page 90 Chapter 4 Registration and Setting Using Engineering Tool For the PB tag, define a tag number (tag variable name) and various parameters. Table 4-6 PB: Examples of pushbutton configuration Record No. (Array notation) Record 1 Record 2 Record 3 Supplementary ( PB[0]) ( PB[1]) ( PB[2])
Page 91: Variable Registration
Chapter 4 Registration and Setting Using Engineering Tool 4.4 Variable Registration 4.4.1 Registration of standard variables Variables such as tags, I/O, and work registers can be referred to from the user program. The variables referred to from the program need to be registered as standard variables in the corresponding controller variable registration screen.
Page 92: Registration Of System Variables (Zw)
Chapter 4 Registration and Setting Using Engineering Tool 4.4.2 Registration of system variables (ZW) Select the controller variable. Figure 4-24 Selecting the system variable (ZW) Clear "Lock up (L)," select "Default Variable (D)," and register standard variables of system variable (ZW). Figure 4-25 System variable (ZW) registration screen 6F8C1388...
Page 93: Registration Of I/O Variables (Sio1)
4.4 Variable Registration 4.4.3 Registration of I/O variables (SIO1) Select the controller variable. Figure 4-26 Selecting the I/O variable (SIO1) Clear "Lock up (L)," select "Default Variable (D)," and register standard variables of I/O variable (SIO1). Figure 4-27 I/O variable (SIO1) registration screen Remark For details of I/O variables, refer to "Appendix E.3 Built-in I/O Variables (SIO1)".
Page 94: Program Creation
Chapter 4 Registration and Setting Using Engineering Tool 4.5 Program Creation In this example, a control loop is configured with PV[0] and LP[0], and referred to with the tag number LP001. The pointers of LP_D and LP_P are referred to with the standard variable name (array variable name).
Page 95: Registration Of S3 Controller Using
4.6 Registration of S3 Controller Using Inter-Controller Transmission 4.6 Registration of S3 Controller Using Inter-Controller Transmission This section describes a method to configure the nV-Tool of the S3 controller in order to connect the S3 controller via inter-controller transmission. To achieve inter-controller transmission, the inter-controller transmission variables must be declared and a program to start inter-controller transmission needs to be created.
Page 96: Registration Of A Program To Start
Chapter 4 Registration and Setting Using Engineering Tool Remark To reduce the size of the inter-controller transmission variable, register the LC53* stations as follows: for example, when there are four receiving stations (stations 1,2,3,6) and the maximum station number is 6, the inter-controller transmission variable size is found as below.
Page 97 4.6 Registration of S3 Controller Using Inter-Controller Transmission The inter-controller transmission start command (16#0320) of the USEND_T command is dedicated for inter-controller transmission with the LC531. It is a compound command to continuously perform opening, transmission and reception of sockets. Once it is started normally, it operates continuously until the S3 controller or EN311 is stopped.
Page 98 Chapter 4 Registration and Setting Using Engineering Tool 4.7 Registration of PU811 Controller Using Inter-Controller Transmission This section describes a method to configure the nV-Tool of the PU811 controller in order to connect the PU811 controller via inter-controller transmission. To achieve inter-controller transmission, the inter-controller transmission variables must be declared and a program to start inter-controller transmission needs to be created.
Page 99 4.6 Registration of S3 Controller Using Inter-Controller Transmission The inter-controller transmission start command (16#0920) of the USEND_N command is dedicated for inter-controller transmission with the LC53*. It is a compound command to continuously perform opening, transmission and reception of sockets. Once it is started normally, it operates continuously until the PU811 controller or EN911 is stopped.
Page 100 Chapter 4 Registration and Setting Using Engineering Tool 4.8 Registration of PUM1* Controller Using Inter-Controller Transmission This section describes a method to configure the nV-Tool of the PUM1* controller in order to connect the PUM1* controller via inter-controller transmission. To achieve inter-controller transmission, the inter-controller transmission variables must be declared and a program to start inter-controller transmission needs to be created.
Page 101 4.6 Registration of S3 Controller Using Inter-Controller Transmission 4.8.2 Registration of a program to start inter-controller transmission A procedure to start inter-controller transmission is as follows. User variable ...
Page 102 Chapter 4 Registration and Setting Using Engineering Tool The inter-controller transmission start command (16#0320) of the USEND_N command is dedicated for inter-controller transmission with the LC53*. It is a compound command to continuously perform opening, transmission and reception of sockets. Once it is started normally, it operates continuously until the PUM1* controller or EN655 is stopped.
Page 103 Chapter 5 Startup and Stopping ······················································ 84 Checking Switches ·································································· 85 Starting Up 5.2.1 Display on the loop display during startup ·················· 86 5.2.2 Memory clear, download, and startup ························ 86 ······································································ 87 Stopping ······································ 88 Transition of Operation Mode ··············································...
Page 104: Checking Switches
Chapter 5 Startup and Stopping 5.1 Checking Switches Before starting the LC53*, make sure to check the validity of the switch settings. The following describes switch settings. ■ DIP switch (1) Maintenance switch (Maint.SW) Check that all are set to OFF. (2) Engineering switch (Eng.SW) Check that Switches 1-5 are set to the OFF side.
Page 105: Starting Up
5.2 Starting Up 5.2 Starting Up The startup procedure for the LC53* is shown in the figure below. Start Starting up for the first time? Ａ Turn on the power. Execute memory clear. Waiting for download? Download application with the engineering tool. Request RUN execution.
Page 106: Display On The Loop Display During Startup
Chapter 5 Startup and Stopping 5.2.1 Display on the loop display during startup ・ When the LC53* starts up normally in the RUN mode, the numerical display area of the loop display shows the numerical data of process information (PV, SV, MV). Also, the RUN (LED) display on the side panel illuminates. ・...
Page 107: Stopping
5.3 Stopping 5.3 Stopping There are the following 3 methods to stop the LC53*. ■ Operation stop (HALT) When the HALT mode is requested by "System view" operation of the nv Engineering Tool or side keyboard operation of the LC53* during RUN execution of the LC53*, the operation mode of the LC53* changes to the HALT mode, and it enters the operation stop state.
Page 108: Transition Of Operation Mode
Chapter 5 Startup and Stopping Transition of Operation Mode The types of operation modes and operation mode transitions of the LC53* are shown in the table below. Table 5-1 Types of operation modes of the LC53* Operation Operation state Remark mode signal Control is performed...
Page 109: Operation Mode Display
5.5 Operation Mode Display 5.5 Operation Mode Display The numerical display area of the display panel of the LC53* normally shows numerical data such as MV, PV, and SV. In the error stop, download wait, or HALT state, it displays the operation mode. Table 5-2 Operation mode display Operation mode Display in numerical display area...
Page 110 Chapter 5 Startup and Stopping 6F8C1388...
Page 111 Chapter 6 Side Keyboard and Side Display In the LC53*, you can operate most of the functions such as displaying and setting various data and changing the operation mode of the controller by operating the side keyboard without using the nv Engineering Tool.
Page 112: Side Keyboard And Side Display Overview
Chapter 6 Side Keyboard and Side Display In the LC53*, you can operate most of the functions such as displaying and setting various data and changing the operation mode of the controller by operating the side keyboard without using the nv Engineering Tool. This chapter describes how to use the side keyboard and the display.
Page 113: Key Arrangement Of Side Keyboard
6.1 Side Keyboard and Side Display Overview 6.1.2 Key arrangement of side keyboard The key arrangement of the side keyboard is shown below. The keyboard consists of alphanumeric keys (white), special keys (orange), arrow keys (green), and the Enter key (orange). Help PQRS WXYZ...
Page 114: Key Operation Overview (Rule)
Chapter 6 Side Keyboard and Side Display Table 6-1 Key type and functions Key Type Notation Key Name Function Escape key Returns one step back. Pressing the key longer (2 seconds or more) sets or releases the key operation lock. Help key Shows Help information for each screen.
Page 115: Screen Execution Overview
6.1 Side Keyboard and Side Display Overview 6.1.4 Screen execution overview The state transition diagram (overview) of the side display screen execution is shown below. When power is turned on, the initial screen appears and when initialization is completed, main menu screen appears. When you select the desired item (select the desired item with key and press...
Page 116: Screen Configuration List
Chapter 6 Side Keyboard and Side Display Screen Configuration List All screens that appear on the side display are described below. Table 6-2 Type of displayed screen Screen Screen configuration Description classification Menu display : Changes menu item and menu Title Menu number screen / Submenu...
Page 117: Menu Tree List
6.3 Menu Tree List Menu Tree List Menu tree list is shown below. Table 6-3 Menu tree list Menu name Screen Description classification Main menu Menu Highest level display 0 Alarm menu Submenu Alarm screen 0 System alarm List type System alarm display (content of ZW410-665) 1 I/O alarm List type...
Page 118 Chapter 6 Side Keyboard and Side Display 3 Version information Submenu 0 Standard section List type Version display of main board, sub board, system, and boot 4 System information Tag item selection Display/setting of control cycle (MSCN) and mode (MODE), etc. Enter system information Numeric value type Display/change of system information...
Page 119: Alarm Display
6.4 Alarm Display Alarm Display Alarms to be indicated on the side display are categorized into 2 types: System alarms and Process alarms. In addition, when any one of these 2 types of alarms is generated, an alarm icon is automatically displayed on the display. In addition to the two types of alarms above, there are error messages displayed in case of a key operation error or setting error.
Page 120: Process Alarm
Chapter 6 Side Keyboard and Side Display 6.4.2 Process alarm Process alarm is the function to display an alarm on the side display when an error related to process control such as a PV upper limit alarm or MV error occurs.
Page 121: Alarm Icon
6.4 Alarm Display 6.4.3 Alarm icon This is an icon display to notify that a system alarm or process alarm is generated. This icon appears automatically when an alarm occurs and disappears when the alarm condition returns to normal. PV[127].SIG ! ...
Page 122 Chapter 6 Side Keyboard and Side Display 6F8C1388...
Page 123 Chapter 7 Troubleshooting ················································· 105 System Log Function ···················· 106 Alarm Display Functions of Side Display ··················· 107 Alarm Display Functions of Loop Display ····················································· 108 WDT Signal Output ...
Page 124 Chapter 7 Troubleshooting The LC53* can detect errors with the alarm display on the loop display (front panel) of the LC53* main unit, the RUN display on the side panel, and the alarm display on the side display. You can also check error information in detail by reading the system log from the LC53* with the nv Engineering Tool.
Page 125: System Log Function
7.1 System Log Function 7.1 System Log Function The LC53* performs self-diagnosis via hardware or software. When an error occurs, the detailed information is recorded in the internal memory of the LC53*, which can be read with the nv Engineering Tool when needed. Also, the operation history and operation/transmission events of the LC53* can be recorded in the internal memory.
Page 126: Alarm Display Functions Of Side Display
Chapter 7 Troubleshooting 7.2 Alarm Display Functions of Side Display By operating the side key, you can display alarm information currently generated on the side display without using the nv Engineering Tool. Remark • For alarm details of side display, refer to "Appendix H.1 Alarm Details". 6F8C1388...
Page 127: Alarm Display Functions Of Loop Display
7.3 Alarm Display Functions of Loop Display 7.3 Alarm Display Functions of Loop Display The HLT in the HALT display area, ALM in the ALARM display area, and CMP in the CMP display area on the loop display shows the currently-generated alarm. The table below shows the details of the displays.
Page 128: Wdt Signal Output
Chapter 7 Troubleshooting 7.4 WDT Signal Output WDT signal output of the LC53* can output the operation state of the LC53* to the outside. The WDT signal is ON when the LC53* is operating normally, or OFF when it is stopped.
Page 129 Chapter 8 Maintenance and Inspection ································································ 110 Daily Check ··························································· 111 Periodic Check ······················································· 113 Expendable Parts 8.3.1 Replacing the battery (lithium battery) ······················ 113 8.3.2 Disposing of the lithium battery ······························· 114 ····························································· 115 Replacements 8.4.1 Replacing the tag number plate ······························ 115 8.4.2 Replacing the scale plate ······································...
Page 130: Daily Check
Chapter 8 Maintenance and Inspection 8.1 Daily Check Check the following items while the system is operating. • LC53* state display Check the display state of "HLT", "ALM", and "CMP" on the loop display (front panel) and the state of the LED display "RUN" on the side panel of the LC53*. If any error is found, check the system and bring it back to normal condition, referring to "Chapter 7 Troubleshooting".
Page 131: Periodic Check
8.2 Periodic Check 8.2 Periodic Check Check the following items periodically (every 6 months). • Saving memory program data to the flash memory Save the user memory data and user program data to the flash memory. Use then nv Engineering Tool to save them. •...
Page 132 Chapter 8 Maintenance and Inspection • Clean the ventilation holes periodically. • Check that the terminal screws of input power supply, external signals, and transmission signals are not loosened. If any of these screws are loosened, tighten them again. Before checking the LC53* main unit or WARNING cables directly, make sure that the input Mandatory...
Page 133: Expendable Parts
8.3 Expendable Parts 8.3 Expendable Parts Check the following items periodically (about every 6 months), Also, check the same if ambient conditions have changed. 8.3.1 Replacing the battery (lithium battery) The lithium battery installed on the LC53* main unit is a consumable item. Under normal operating conditions, it is recommended to replace it every 2 years (standard).
Page 134: Disposing Of The Lithium Battery
Chapter 8 Maintenance and Inspection 8.3.2 Disposing of the lithium battery Dispose of the consumed battery appropriately by observing the ordinance or regulation of the local government. Product name: Lithium battery Type: CR2032 (Sony or a product of compatible manufacturer) WARNING Do not throw a lithium battery into fire.
Page 135: Replacements
8.4 Replacements 8.4 Replacements The tag number plate and scale plate on the loop display unit (front panel) of the LC53* main unit can be replaced. Replace them as required. 8.4.1 Replacing the tag number plate If you lift the front frame at the top of the tag number plate, the part of the frame will be removed and you can take out the tag number plate.
Page 136 Chapter 8 Maintenance and Inspection 6F8C1388...
Page 137 Appendix A LC531/LC532 Specifications ················································ 119 A.1 General Specifications ··························· 120 A.2 Electric and External Specifications ········································· 121 A.3 I/O Specifications (built-in) ························ 122 A.4 RS485 Communication Specifications ························ 122 A.5 Ethernet Transmission Specifications ····················································· 123 A.6 USB Specifications ·····································...
Page 138 Appendix A LC531/LC532 Specifications This chapter describes each specification of LC53*.  General Specifications It explains the specifications of installation, usage, and environmental conditions.  Electric and External Specifications It explains the electric and external specifications.  I/O Specifications (built-in) It explains the I/O specifications, which are built in LC53*.
Page 139: General Specifications
A.1 General Specifications A.1 General Specifications Table A-1 General specifications Item External specification Remarks Operating ambient 0 to 55  C temperature Complied with -40 to 70  C Storage temperature IEC 60068-2-2,test Bb and IEC 60068-2-2,test Ab Relative humidity 10% to 95% Level RH2 (with no condensation) IEC 60068-2-30,test Db Dust...
Page 140: Electric And External Specifications
Appendix A LC531/LC532 Specifications A.2 Electric and External Specifications Table A-2 Electric and external specifications Item External specification Remarks Power supply 24Vdc +10%-15% (ripple of 1% or less) Main unit power supply: 24VDC-Approx.0.2A Consumption power DI/O power supply: 24VDC-50mA or less Insulation resistance 50MΩ...
Page 141: I/O Specifications (Built-In)
A.3 I/O Specifications (built-in) Table A-3 I/O specifications (Built-in) Item Specifications Product specifications Number of input points 6 points Input range 1 to 5Vdc (Signal common terminal SC, terminal No. 6) Insulation unit No insulation between channels During energization: 1MΩ or more During power down: 1MΩ or Input impedance more Analog input...
Page 142: Rs485 Communication Specifications
Appendix A LC531/LC532 Specifications (LC532 only) External ＯＮresistance 200Ω or less External ＯＦＦresistance 100kΩ or more A.4 RS485 Communication Specifications Table A-4 RS485 bus specifications External Item Specifications Specifications ECBUS/H Function Connection between LC53* and EC329 Standard RS485 Topology Bus type Protocol ECBUS (MODBUS base) Transmission...
Page 143: Usb Specifications
A.5 Ethernet Transmission Specifications A.6 USB Specifications Table A-6 USB specifications Item Specifications Function Connection to nv Engineer Tool 4 Standard USB 2.0 (full speed) Transmission path specifications Topology Transmission speed 12Mbps PC side: USB, Terminal A (male) Connection connector LC53* side: USB, Terminal B (male) Length of cable 2m or less (Extension cable cannot use)
Page 144: Lc531/Lc532 Wiring Diagram
Appendix A LC531/LC532 Specifications A.7 LC531/LC532 Wiring Diagram Connector for Ethernet RJ45 Digital Insulated power input +24V Contact input supply circuit circuit Main power 24V (24V-5mA) input DIO+ DIO 24V input DIO− Analog signal Digital output Digital common (open collector)
Page 145: Lc531/Lc532 Software Specifications
A.7 LC531/LC532 Wiring Diagram A.8 LC531/LC532 Software Specifications Table A-7 LC53* software specifications Item Specifications Control mode RUN／HALT／ERROR Programming language ICE61131-3 compliant Program capacity 64POU Program type Task type 1 Program Control loop 8 loops processing Program 6k steps capacity capacity (Note 1) Performance...
Page 146 Appendix A LC531/LC532 Specifications 6F8C1388...
Page 147 Appendix B Details of Loop Display Panel ······································· 129 B.1 FAST/SEL Switch Operation ····························· 130 B.2 NORMAL Mode and SELECT Mode ····························· 131 B.3 Display/Operation Mode Transition B.4 Operation Methods for the NORMAL Mode ··········· 132 and SELECT Mode ············ 133 B.5 Special Display in the Numerical Display Area...
Page 148 Appendix B Details of Loop Display Panel This chapter describes operation and display of the loop display (front panel) of the LC53*. Numerical display area SV setting pushbutton R･M Mode switch pushbutton Bar display area MV manual operation pushbutton FAST FAST/SEL pushbutton PV S V MV Figure B-1 LC53* loop display (front panel)
Page 149: Fast/Sel Switch Operation
B.1 FAST/SEL Switch Operation B.1 FAST/SEL Switch Operation ■ MV/SV operation Normally, the FAST/SEL pushbutton is used to increase the change rate of MV or SV. In this case, press the FAST/SEL pushbutton along with the MV manual operation pushbuttons ( ) or SV setting pushbutton( ■...
Page 150: Normal Mode And Select Mode
Appendix B Details of Loop Display Panel B.2 NORMAL Mode and SELECT Mode Display and operation of the loop display are divided into the NORMAL mode and SELECT mode. You can switch between the NORMAL mode and SELECT mode by using the operation method described above. ■...
Page 151: Display/Operation Mode Transition
B.3 Display/Operation Mode Transition B.3 Display/Operation Mode Transition The figure below shows mode transitions of display/operation of the loop display. ･Alarm check ･PH/PL display For operation, refer to “Appendix FAST/SEL: ON RUN startup Table B-1 NORMAL mode (hold for 1 sec or operation”.
Page 152: And Select Mode
Appendix B Details of Loop Display Panel B.4 Operation Methods for the NORMAL Mode and SELECT Mode The table below shows the operation method in the NORMAL mode. Table B-1 NORMAL mode operation Operation type Operation Remark Alarm check operation Press the FAST/SEL While the FAST/SEL pushbutton is pushbutton for 1 sec or longer.
Page 153: Special Display In The Numerical Display Area
B.5 Special Display in the Numerical Display Area Special Display in the Numerical Display Area In the RUN mode, the PV value, SV value, and MV value are displayed in the numerical display area. In other modes, the numerical display area has special display.
Page 154 Appendix B Details of Loop Display Panel 6F8C1388...
Page 155 Appendix C Outline Drawing ··········································· 136 C.1 LC531S*S/LC532S*S Type ··········································· 137 C.2 LC531E*S/LC532E*S Type...
Page 156 To mount the LC531S*S/LC532S*S type on a panel, use clamping hardware and support angle to secure it. Clamping hardware Side view Front view R･M Housing FAST PV SV MV TOSHIBA 300 to 400 Support angle LC53* main unit Figure C-1 LC531S*S/LC532S*S module outline drawing 6F8C1388...
Page 157 Clamping this direction. hardware Side view Front view R･M Housing FAST PV SV MV TOSHIBA Clamping LC53* hardware main unit Figure C-2 LC531E*S/LC532E*S module outline drawing Unified Controller nv Series Single-Loop Controller LC531/LC532 Instruction Manual...
Page 158 Appendix C Outline Drawing 6F8C1388...
Page 159 Appendix D System Log ···································································· 141 D.1 Error Log ··································································· 148 D.2 Event Log ··············································· 151 D.3 Intervention Event Log ············································· 152 D.4 Transmission Event Log...
Page 160 Appendix D System Log This chapter describes details of the system logs of the LC53*. The LC53* records error information in case of an error, history operation such as behaviors and operations during normal operation, and transmission event information to the system log memory. This system log information can be read and viewed from the nv Engineering Tool when necessary.
Page 161 Error Log Table D-1 Error log (1/7) Event Trace Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance Contents 8000 NMI Interrupt Caution Interrupt Error NMI interrupt Status Status Runaway Turn on the power again and restart the system.
Page 162 Table D-1 Error log (2/7) Event Trace Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance Contents 8113 Memory Major Periodic Error Loss of memory Battery error or Replace the battery, then execute Memory Clear and Batch DL and erased failure diagnosis...
Page 163 Table D-1 Error log (3/7) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 880E IP address overlap Major Executed Error IP address is Device with same IP Check the IP address setting error failure rundown overlapping.
Page 164 Table D-1 Error log (4/7) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 9108 User task real Caution Executed Continued Invalid operation was Invalid parameter is set in Modify it to the correct operation error performed in real (absolute)
Page 165 Table D-1 Error log (5/7) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 9122 Detection of main Minor Executed Continued Main scan task Main task execution Set a longer main scan cycle, or scan task failure execution period...
Page 166 Table D-1 Error log (6/7) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 9138 Program DL error Caution Executed Continued Code memory could Insufficient free If it occurred at batch DL, the amount not be reserved. memory area of instances used in the user program exceeds memory capacity.
Page 167 Table D-1 Error log (7/7) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 9901 ECBUS external Minor Periodic Continued Reception error ECBUS wiring is When ECBSU is not used, clear variable all point failure diagnosis detected for all...
Page 168 Event Log Table D-2 Event log (1/3) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 8000 Power ON Initial 8001 Reset Initial 8002 Power OFF Initial 8101 Error rundown Executed Error stop 8102 Initialize Initial Initialization 8103...
Page 169 Table D-2 Event log (2/3) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 9102 Main scan control cycle Executed Main scan control cycle has been Scan change changed. cycle time setting value 9104 Time change Executed Date/time is changed.
Page 170 Table D-2 Event log (3/3) Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 9120 User information download Initial 9121 Save on Flash ROM Executed User information is saved to flash complete ROM. 9130 Tag parameter information Executed registration 9131...
Page 171 Intervention Event Log Table D-3 Intervention Event log Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 8000 Control mode change 8001 SV change 8002 MV change 8003 DO output 8004 Scan ON/OFF 8005 PV change 8006 DI change...
Page 172 Transmission Event Log Table D-4 Transmission Event Log Event Trace Contents Level Timing Exec Remark Task Address Aux1 Aux2 Aux3 Cause Maintenance 98B2 Socket request 98B3 Socket BIND request 98B4 Socket LISTEN request 98B5 Socket CONNECT request 98B6 Socket ACCEPT request 98B7 Socket SHUTDOWN...
Page 173 Appendix E Details of Variables ················································ 155 E.1 System Variables (ZW) ··········································· 160 E.2 Tag Variables (PV, LP, PB) E.2.1 Indicator Variables (PV_PARA, PV_DATA) ················ 161 E.2.2 Controller Variables (LP_PARA, LP_DATA) ··············· 168 E.2.3 Pushbutton Variables (PB_PARA, PB_DATA) ············ 174 ········································...
Page 174 Appendix E Details of Variables This chapter describes the configurations and roles of the following variables in detail. ● System Variables (ZW) Variables used to access internal information of the LC53*. ● Tag Variables (PV, LP , PB) Variables used to access control information of the LC53*. ●...
Page 175: System Variables (Zw)
E.1 System Variables (ZW) E.1 System Variables (ZW) The system variable is a variable with predetermined purpose. This variable can be used to monitor and set the condition of the system by user program. The system variable contains 1024 words of ZW [0] to ZW [1023], the usable area is limited.
Page 176 Appendix E Details of Variables Table E-2 Operation data (read-only data) Operation mode 1:INZ, 3:DL-WAIT, 14/30:HALT, 15/31:ERROR, 61/62:RUN Battery error Battery status (0: Normal, 1: Error) Execution cycle Scan execution cycle of MS task currently running (floating-point value) ＝Scan cycle  Sub-schedule value (ms) Stall data Stall data of main scan (0: Normal, 1: Stalled, 2: Restored) Stall count...
Page 177 E.1 System Variables (ZW) Table E-4 Error data map (read-only data) 400 Latest error code Major classification Medium classification Minor classification Major fault error map Minor classification 410 Major Medium classification 0 classification 0 （HW） Medium classification F 474 Major Medium classification 1 classification 0...
Page 178 Appendix E Details of Variables Table E-5 System signal output (write) WDT signal output Normal (External output signal=ON) (write) WDT output (External output signal=OFF) (External output signal is OFF while continuous output ZW800 is "1") Loop ALM display output (write) <0>...
Page 179 E.2 Tag Variables (PV, LP, PB) Table E-7 Remote I / O information I / O implementation state Showing a mounting state of the I / O module (0: not implemented / 1: Implementation)(Bit0 = module 1 ~ bitF = module 16) I / O Unit Error Show a major fault response from the expansion I / O (0: normal / 1: Error)(Bit0 = module 1 ~ bitF = module 16)
Page 180: Tag Variables (Pv, Lp, Pb)
Appendix E Details of Variables E.2 Tag Variables (PV, LP, PB) Details of tag variables (PV, LP , PB) that can be used for LC53* are described below. ■ About explanation items in the table Item name Parameters with are saved as tool information but not ۞...
Page 181: Indicator Variables (Pv_Para, Pv_Data)
E.2 Tag Variables (PV, LP, PB) E.2.1 Indicator Variables (PV_PARA, PV_DATA) [Indicator variable] parameters are valuables to register parameter information, such as signal process of field device (sensors), calculation process of indicator, and display of indicator. The data of [Indicator variables] are valuable to indicate the status information, value information, alarm information, and others of indicator.
Page 182 Appendix E Details of Variables Table E-9 Parameter of [Indicator variable] (PV_PARA) (2/6) Item name Abbr. Description Input point ● Register the address of the PV input point. × ― ○ variable name ・ For the registration method, refer to "Chapter 4 Registration and Setting Using Engineering Tool".
Page 183 E.2 Tag Variables (PV, LP, PB) Table E-9 Parameter of [Indicator variable] (PV_PARA) (3/6) Item name Abbr. Description Sensor high limit This is used to set whether sensor error (PVI) should be suppressed or × ― ○ error suppression not when input count value is larger than the input count high limit (CH). ●No/Yes Sensor low limit This is used to set whether sensor error (PVI) should be suppressed or...
Page 184 Appendix E Details of Variables Table E-9 Parameter of [Indicator variable] (PV_PARA) (4/6) Item name Abbr. Description Low cutoff value At the time of instantaneous value processing, an instantaneous value ○ ↓↑ ○ [0.01%] equal to or less than this value is treated as 0%. If this low cutoff value is a negative value, low cutoff will not be performed.
Page 185 E.2 Tag Variables (PV, LP, PB) Table E-9 Parameter of [Indicator variable] (PV_PARA) (5/6) Item name Abbr. Description Pulse weigh factor At the time of pulse input, the process amount corresponding to one ○ ↓↑ ○ [EU/pulse] pulse is registered. ●...
Page 186 Appendix E Details of Variables Table E-9 Parameter of [Indicator variable] (PV_PARA) (6/6) Item name Abbr. Description PV rate-of-change Dead band for rate-of-change alarm ○ ↓↑ ○  0  DPB alarm dead band [EU/sec] Note: [How to determine the rate-of-change alarm for PV value] Suppose PV rate-of-change per scan is dPV and absolute value is ABS(), a rate-of-change alarm (PVD) is generated when ABS(dPV) >...
Page 187 E.2 Tag Variables (PV, LP, PB) Table E-10 Data of [indicator variable] (PV_DATA) Item name Abbr. Description PV value ○ Displays the PV value. ○ ↓↑ ○ [EU] Note: When scan OFF (SCN＝1) is set, the PV value can be rewritten.
Page 188: Controller Variables (Lp_Para, Lp_Data)
Appendix E Details of Variables E.2.2 Controller Variables (LP_PARA, LP_DATA) [Controller variable] parameters are valuables to register parameter, such as interface signal process of field device (actuators), calculation process of controller, and display of controller. The data of [Controller variables] are valuable to indicate the status information, value information, alarm information, and others of controller.
Page 189 E.2 Tag Variables (PV, LP, PB) Table E-11 Parameter of [Controller variable] (LP_PARA) (2/4) Item name Abbr. Description MV output direction ● Select the output direction of the valve. ○ ↓↑ ○ The output direction of valve is selected. 4  20mA output with 0  100% or 20  4mA output with 0  100% Proportional gain Proportional gain of PID operation ○...
Page 190 Appendix E Details of Variables Table E-11 Parameter of [Controller variable] (LP_PARA) (3/4) Item name Abbr. Description MV high limit value MV high limit value ○ ↓↑ ○ ● ML < MH MV low limit value MV low limit value ○...
Page 191 E.2 Tag Variables (PV, LP, PB) Table E-11 Parameter of [Controller variable] (LP_PARA) (4/4) Item name Abbr. Description LDU decimal point Decimal places for PV and SV for LDU are set. × ― ○ position ●0≤LDP≤4 LDU display method ● Display form of LDU bar graph is set.(not available) ×...
Page 192 Appendix E Details of Variables Table E-12 Data of [Controller variable] (LP_DATA) (1/2) Item name Abbr. Description SV value ●Set-point value [EU] ○ ↓↑ ○ [EU] MV value ●Manipulated variable [%] ○ ↓↑ ○ Note: When “Ratio setter” is selected for Control operation type (CTL), MV becomes an engineering unit value and I/O will not be output.
Page 193 E.2 Tag Variables (PV, LP, PB) Table E-12 Data of [Controller variable] (LP_DATA) (2/2) Item name Abbr. Description SEQ-SV intervening Used for user application ○ ↑ ○ CMP-SV intervening Used for user application ○ ↑ ○ SEQ-MV intervening Used for user application ○...
Page 194: Pushbutton Variables (Pb_Para, Pb_Data)
Appendix E Details of Variables E.2.3 Pushbutton Variables (PB_PARA, PB_DATA) [Pushbutton variable] parameters are valuables to register parameter, such as interface signal process of field device (motor, valves, etc.), the process of pushbutton operation, and display of instrument. The data of [Pushbutton variables] are valuable to indicate the status information, value information, alarm information, and others of instrument.
Page 195 E.2 Tag Variables (PV, LP, PB) Table E-13 Parameter of [Pushbutton variable] (PB_PARA) (2/2) Item name Abbr. Description Alarm monitoring AMON Set whether to perform alarm monitoring of this instrument. ۞ ● OFF, ON Alarm grade AGRD Set the alarm grade. ۞...
Page 196 Appendix E Details of Variables Table E-14 Data of [Pushbutton variable] (PB_DATA) Item name Abbr. Description Alarm suppression Set whether to perform alarm suppression. ○ ↓↑ ○ ●OFF, ON When ON (1) is set, alarm unconfirmed (IU1-IU3) is reset. Interlock ○...
Page 197: Built-In I/O Variables (Sio1)
E.2 Tag Variables (PV, LP, PB) E.3 Built-in I/O Variables (SIO1) The LC53* can perform input and output directly to built-in I/Os by using built-in I/O variables. The built-in I/O variables can be used by registering standard variables in the controller variable (SIO1).
Page 198 Appendix E Details of Variables E.4 EC Bus Variables (EC_BUS) This information is compatible with the EC3* series. The LC53* can refer to EC bus information by using the variables. The EC bus variables can be used by registering standard variables in the controller variable (EC_BUS).
Page 199 E.4 EC Bus Variables (EC_BUS) Table E-16 EC Bus Variables (EC_BUS) (2/2) Variables Address Item name Description Type Bit No (atom) External variable External variable 3(data type REAL) REAL ― ○ (data type) V02D External variable 3(data type DINT) DINT ―...
Page 200: Inter-Controller Transmission Variables (Stn_Data)
Appendix E Details of Variables E.5 Inter-controller Transmission Variables (STN_DATA) Data can be exchanged among the LC53* connected on the Ethernet. This is called inter-controller transmission. The inter-controller transmission variable (STN_DATA) consists of send area, receive area, and healthy map area. The send area is used to send data to other controller.
Page 201 Appendix F Details of Module Parameters This chapter describes the module parameters of the LC53* that can be set and displayed from the nv Engineering Tool. ································· 182 Module Parameter Setting ························· 183 Module Parameter Data Display...
Page 202 Appendix F Details of Module Parameters F.1 Module Parameter Setting Module parameters are used to specify basic parameters of the LC53*. Table F-1 Module parameters (parameter) Items name Description Setting range Remarks MS task scan The cycle time of main scan is set. 0,50-5000[ms] Default: 1000 cycle (ms) (in units of 50[ms])
Page 203 F.2 Module Parameter Data Display F.2 Module Parameter Data Display Data display of module parameters indicates the operation state of the LC53*. Table F-2 Module parameters (data) Display range Item name Description (read-only data) MS scan time current value (ms) Main scan current execution time MS scan time maximum value Main scan execution time...
Page 204 Appendix F Details of Module Parameters Ｆ 6F8C1388...
Page 205 Appendix G Execution Performance of the LC531/LC532 ······· 186 G.1 Execution Performance of the LC531/LC532 ··································· 187 G.2 Main Scan and Free Time...
Page 206 Appendix G Execution Performance of the LC531/LC532 G.1 Execution Performance of the LC531/LC532 Execution times of programs (instruction words) and tags of the LC53* are shown below. Use them as a guide to determine capacity of one unit of the LC53* or control cycle when building a system. Instruction word execution time （TYP）...
Page 207 G.2 Main Scan and Free Time G.2 Main Scan and Free Time The LC53* executes main scan task applications as well as other system processing. System processing includes transmission processing with the PLC server, inter-controller transmission among LC53*, and EC bus transmission, etc.
Page 208 Appendix G Execution Performance of the LC531/LC532 6F8C1388...
Page 209 Appendix H Details of Side Keyboard Operation and Side Display The details on alarm contents shown on Side display and operation method for Side keyboard are described. ······························································ 190 H.1 Alarm Details ··································· 194 H.2 How to Operate Side Keyboard H.2.1 Change the Side Display Indication (to English) ·········...
Page 210: Alarm Details
Appendix H Details of Side Keyboard Operation and Side Display The details on alarm contents shown on Side display and operation method for Side keyboard are described. H.1 Alarm Details The table below shows the details of alarms displayed on the side display. For information on how to display alarms, refer to "6.4 Alarm Display."...
Page 211 H.1 Alarm Details Table H-1 Types of system alarms (2/2) Abbr. Display contents Description Corrective action Ether comm.-related Ethernet related error: Check the IP address of the module Ethernet transmission error parameter. Ether ｶﾝﾚﾝｲｼﾞｮｳ Check the Ethernet connection. RS485 comm.-related RS485 related error: Check external variable registration EC bus transmission error...
Page 212 Appendix H Details of Side Keyboard Operation and Side Display Table H-2 Types of process alarms (2/2) Tag Abbr. Display contents Description Corrective action PV Low Level Alarm PV Low alarm: Check the PV signal source so that PV PV < PL stays above PL.
Page 213 H.1 Alarm Details Table H-3 Other alarm messages Item Display contents Description Reset method Initial screen ** SELF CHECK ** Initial diagnosis in progress Wait for a while after turning on power. Wait a moment... ** ｼﾞｺｼﾝﾀﾞﾝﾁｭｳ** ｼﾊﾞﾗｸｵﾏﾁｸﾀﾞｻｲ.. FROM error FROM ERROR FROM checksum error: Display can be restored by pressing any...
Page 214: How To Operate Side Keyboard
Appendix H Details of Side Keyboard Operation and Side Display H.2 How to Operate Side Keyboard This section describes how to operate the keys of the side keyboard and displays. All key operations are started from the main menu. For selection of item numbers from expanding from the main menu, refer to "6.3 Menu Tree List."...
Page 215: Change The Side Display Indication (To English)
H.2 How to Operate Side Keyboard H.2.1 Change the Side Display Indication (to English) (Example) Change the displayed language to English. Setting[Enter][  ][Enter] Operation Display[6][5][1] SYSTEM.LANG SYSTEM.LANG Screen English ニホンゴ (Example) Release the auto lock Setting[Enter][  ][Enter] Operation Display[6][5][2] SYSTEM.HOLD SYSTEM.HOLD Screen...
Page 216: Change The Operation Mode
Appendix H Details of Side Keyboard Operation and Side Display H.2.3 Change the Operation Mode (Example) Change the mode of LC53* from HALT to RUN. Setting[Enter][  ] [Enter] Operation Display[6][0][0] SYS[0].MODE SYS[0].MODE Screen HALT H.2.4 Change the Tag (Example) Display LP[000].SV and change the value to 50.4. Display [2]→[1]→[←] Setting [Enter]→[50.4] Operation...
Page 217: Change The General Variables
H.2 How to Operate Side Keyboard H.2.5 Change the General Variables (Example) Change the internal variable Y4 of EC_BUS to 20.5. (Real type) Setting[Enter][  20.5] Operation Display[4][6][0003] Check → [Enter] Y [0003]Real Y [0003].Real Y [0003]Real Screen  20.5 -20.50000 (Example) Change the internal flag S6 of EC_BUS to ON.
Page 218: Change The Data Of Polynomial Line Variable
Appendix H Details of Side Keyboard Operation and Side Display H.2.6 Change the Data of Polynomial Line Variable (Example) Change 3rd coordinate X and 5th coordinate Y of the polygonal line parameter of Polygonal line No. 3 Display [3]→[02] 02X Setting[Enter] Operation 02X Check [Enter] →[35.5]→[DEL] ...
Page 219: Display The Version
H.2 How to Operate Side Keyboard H.2.7 Display the Version (Example) Display the version of the CPU section. Next version[  ] Operation Display[6][3][0] LC(00).Hard LC(00).SYS Screen R A.0 V2.30 Remark • The versions of the LC53* include 6 types; Hard (CPU board revision), FPGA (FPGA version), BOOT (controller BOOT version), SYS (controller basic software version), OS (kernel (OS)), and TEST (test pro version).
Page 220: Restore The Mv Error (Mve)
Appendix H Details of Side Keyboard Operation and Side Display H.2.9 Restore the MV Error (MVE) An MV error (MVE) can be restored by performing confirmation operation [Enter] when the alarm is displayed. (Example) When LP[000].MVE is generated Process alarm display Operation Check[Enter] [0][2]...
Page 221 Appendix I USB Driver Installation To use the nv Engineering Tool via the USB port of the LC53*, you need to install the USB serial port driver for the LC53* to the PC for the nv Engineering Tool. This chapter describes how to install the USB serial port driver. ·················...
Page 222 Appendix I USB Driver Installation Making USB Connection for the First Time When you connect the PC and LC53* via USB for the first time, the PC automatically detects the USB connection, and the New Hardware Wizard starts up as shown below. Follow the instructions of the New Hardware Wizard and install the USB serial port driver for the LC53*.
Page 223 I.2 USB Driver Installation USB Driver Installation Install the USB serial port driver in the following steps. In "Welcome to the Found New Hardware Wizard," select "Install from a list or specific location (Advanced)" and click Next. In "Please choose your search and installation options", select "Search for the best driver in these locations,"...
Page 224 Appendix I USB Driver Installation Installation of the USB serial port driver starts, and the following dialog is displayed. If the following warning dialog is displayed, click Continue to continue the installation. 6F8C1388...
Page 225 I.2 USB Driver Installation When the installation of the USB serial port driver is complete, the following dialog is displayed. Click "Finish" to end installation. The installation of the USB serial port driver is now complete. From now on, it will be automatically recognized when the USB cable is connected and USB connection will be ready for use.
Page 226 Appendix I USB Driver Installation Setting the nv Engineering Tool and Communication Parameters When you connect the PC and LC53* with the USB cable, the USB serial port driver is automatically allocated to the COM port of the PC. You can check the COM port allocation state (COM number) with the device manager of the Windows system.
Page 227 Appendix J MODBUS reference Specifications The MODBUS reference specification for accessing from an ECBUS (or MODBUS) master is shown below. ································· 208 How to take a reference number ················································ 208 Reference number list ····················································· 217 Raw data structure ...
Page 228 Appendix J MODBUS reference Specifications How to take a reference number ■How to take a reference number ・The number specified by a master specifies the relative number to a reference number. Table J-1 The classification of a reference number Item Reference number Relative number Function Code Coil Reference − 1 0**** 1,5,15 Input relay ...
Page 229 J.3 Raw data structure Table J-2 Analog Table No.1 MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number 40001 Proportional 0.00≦327.67 LP_PARA[0].KP 40002 gain LP_PARA[1].KP 40003 LP_PARA[2].KP 40004 LP_PARA[3].KP 40005 Integration 0.00≦327.67 LP_PARA[0].TI 40006 time LP_PARA[1].TI 40007 LP_PARA[2].TI 40008 LP_PARA[3].TI 40009 Differentiati...
Page 230 Appendix J MODBUS reference Specifications Table J-2 Analog Table No.2 MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number 40045 DMV1 DMV limit 0.00≦100.00 LP_PARA[0].DMV R/W 40046 DMV2 LP_PARA[1].DMV 40047 DMV3 LP_PARA[2].DMV 40048 DMV4 LP_PARA[3].DMV 40049 ALPHA1 2DOF KP 0.00≦100.00 LP_PARA[0].ALP...
Page 231 J.3 Raw data structure Table J-2 Analog Table No.3 MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number RL ≦ 327.67 40093 RH30 PV range PV_PARA[0].RH -327.68 ≦ RH 40094 RL30 (upper and PV_PARA[0].RL 40095 RH31 lower limits) PV_PARA[1].RH 40096 RL31...
Page 232 Appendix J MODBUS reference Specifications Table J-2 Analog Table No.4 MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number 40141 PVBND1 PV band gap 0.00≦5.00 PV_PARA[0].PVB R/W 40142 PVBND2 PV_PARA[1].PVB 40143 PVBND3 PV_PARA[2].PVB 40144 PVBND4 PV_PARA[3].PVB 40145 PVBND5 PV_PARA[4].PVB 40146...
Page 233 J.3 Raw data structure Table J-3 Analog(Read only) Table MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number 30001 BETA1 Beta -327.68≦327.67 LP_PARA[0].BET R 30002 BETA2 LP_PARA[1].BET 30003 BETA3 LP_PARA[2].BET 30004 BETA4 LP_PARA[3].BET 30005 GAMMA1 Gamma -3276.8≦3276.7 LP_PARA[0].GAM R ...
Page 234 Appendix J MODBUS reference Specifications Table J-4 Digital Table MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number 00001 Direct/ LP_PARA[0].CDR 0:Increase MV while R/W 00002 reverse LP_PARA[1].CDR SV-PV increase 00003 LP_PARA[2].CDR 1:Decrease MV while 00004 LP_PARA[3].CDR SV-PV increase...
Page 235 J.3 Raw data structure Table J-5 Digital(Read only) Table No.1 MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number 10013 CMEF1 C mode 0:Disable LP_PARA[0].CMD Enable : CMD<4 R 10014 CMEF2 enable flag 1:Enable LP_PARA[1].CMD Disable: CMD>=4 10015 CMEF3 LP_PARA[2].CMD 10016 CMEF4...
Page 236 Appendix J MODBUS reference Specifications Table J-5 Digital(Read only) Table No.2 MODBUS Specifications The applicable Remarks Read/ Upper and lower Reference variable in LC53* Code Designation Write limit number 10104 C mode flag LP_DATA[0].C R 10105 LP_DATA[1].C 10106 LP_DATA[2].C 10107 LP_DATA[3].C 10108 A mode flag LP_DATA[0].A R 10109 LP_DATA[1].A 10110...
Page 237 J.3 Raw data structure Raw data structures There are 2 types of the raw data structures. (EC300/EC329) EC300: Transmit a message after processing necessary data into the raw data structure automatically. EC329: Transmit a message of the raw data transmission area. The raw data transmission area of EC329 uses expand I/O input and output data (MIO/EXT) . By defining variable to (MIO̲EXT) as below, it prepares the transmit data. efining variable to (MIO̲EXT) Figure J-1 EC329 D The list of the raw data structures (EC300/EC329) are shown in the following pages. Unified Controller nv Series Single-Loop Controller LC531 Instruction Manual...
Page 238 Appendix J MODBUS reference Specifications J-6 EC300 Raw data structure（Part.1） Table MODBUS specification LC53* correspondence Remarks Size ﾞ Name Content ※1 ※2 (byte) Station type 11h=Y No Module parameter 12h=Y Yes (Raw data type) bit0 ： SM − (Not applicable) Station abnormality bit1 ： ADC information SIO_DATA.ADE −...
Page 239 J.3 Raw data structure J-6 EC300 Raw data structure（Part.2） Table MODBUS specification LC53* correspondence Remarks Size ﾞ Name Content ※1 ※2 (byte) bit0 ： INP PV_PARA[0].SIG bit1 ： SOF PV_DATA[0].SCN bit2 ：− bit3 ： SPVE bit4 〜 7 の OR bit4 ： PVD PV_DATA[0].PVD bit5 ：...
Page 240 Appendix J MODBUS reference Specifications J-7 EC329 Raw data structure（Part.1） Table MODBUS specification LC53* correspondence Remarks Size Name Content ※1 ※2 (byte) Station type 40h=EC329 bit0 ： SM − (Not applicable) Station abnormality bit1 ： ADC information SIO_DATA.ADE − − Reserve − Maximum station number Module parameter (EC bus maximum station...
Page 241 Sep 05, 2016 6rth Edition Infrastructure Systems & Solutions Company Industrial Systems Division 72-34, Horikawa-cho, Saiwai-ku, Kawasaki 212-8585, Japan © Toshiba Corporation 2013-2016 No part of this document may be reproduced All Right Reserved. without the prior written consent of Toshiba.
Page 242 1388.6.1609...

This manual is also suitable for:

Lc532 series Lc531s s series Lc532s s series Lc531e s series Lc532e s series

Toshiba LC531 Series Instruction Manual

Chapter 2 Installing, Removing and Connection

Chapter 3 Software Functions

Chapter 4 Registration and Setting Using Engineering Tool

Chapter 5 Startup and Stopping

Chapter 6 Side Keyboard and Side Display

Chapter 7 Troubleshooting

Chapter 8 Maintenance and Inspection

Appendix A Lc531/Lc532 Specifications

Appendix B Details of Loop Display Panel

Appendix E Details of Variables

Appendix H Details of Side Keyboard Operation and Side Display

Quick Links

Chapters

Related Manuals for Toshiba LC531 Series

Summary of Contents for Toshiba LC531 Series

This manual is also suitable for:

Table of Contents
