Delta ASDA-B3 Series User Manual page 75

Wiring
Specifications and pin assignment for the military connector of the B3 incremental encoder
3
ACS3-CAE 2703
ACS3-CAE 2705
ACS3-CAE 2710
ACS3-CAE 2720
Note: select cables according to the
standard cables.
Connect to
the motor
3-22
Model name
Military connector
Pin No.
1
2
3
4
5, 6, 7, 8
9
10
L
Straight
CMV1-10S
CMV1-10S
CMV1-10S
CMV1-10S
in the model name. F represents flexible cables and N represents
7
Terminal
T+
T-
-
DC+5V
-
GND
Shield
L
mm inch
3000  50 118  2
5000  50 197  2
10000  100 394  4
20000  100 788  4
CN2 connector
Connect to the
servo drive
3 2 1
4
1 0 9 8
Color
White
White/Red
-
Brown
-
Blue
-
ASDA-B3
