ASDA-B3
P4.016
Default: Factory setting
Unit: -
Format: DEC
Settings:
Manually adjust the offset. The function must be enabled by setting P2.008. Do not change the auxiliary
adjustment as this parameter cannot be reset.
P4.017
Default: Factory setting
Unit: -
Format: DEC
Settings:
Manually adjust the offset. The function must be enabled by setting P2.008. Do not change the auxiliary
adjustment as this parameter cannot be reset.
P4.018
Default: Factory setting
Unit: -
Format:
DEC
Settings:
Manually adjust the offset. The function must be enabled by setting P2.008. Do not change the auxiliary
adjustment as this parameter cannot be reset.
P4.019
Default: Factory setting
Unit: -
Format: DEC
Settings:
Cool down the drive to 25°C (77°F) before adjustment. The function must be enabled by setting P2.008.
Current encoder (V2 phase) offset adjustment
Current encoder (W1 phase) offset adjustment
Current encoder (W2 phase) offset adjustment
IGBT NTC adjustment level (cannot reset)
Control mode: All
Setting range: 0 - 32767
Data size: 16-bit
Control mode: All
Setting range: 0 - 32767
Data size: 16-bit
Control mode: All
Setting range: 0 - 32767
Data size:
16-bit
Control mode: All
Setting range: 1 - 4
Data size: 16-bit
Parameters
Address: 0420H
0421H
Address: 0422H
0423H
Address: 0424H
0425H
Address: 0426H
0427H
8
8-105
