Delta ASDA-B3 Series User Manual page 305

Parameters
8
When PH = PL = P, it indicates that the content of P0.025 includes one 32-bit parameter.
2.
Example: Target: set P6.010 to 0x00050064 in the mapping parameter.
P0.036
Default:
Unit:
Format:
Settings:
P0.036
P0.026
P0.037
Default:
Unit:
Format:
Settings:
P0.037
P0.027
8-20
Write: in the mapping content, set P0.025 to 0x00050064, and the values of P2.003 and
P2.005 are:
Setting: set both the high bit and low bit of P0.035 to 060A (P6.010).
Thus, P6.010 = 0x060A060A.
Write: in the mapping content, set P0.025 to 0x00050064 and P6.010 changes
immediately.
Target setting for mapping parameter P0.026
-
-
HEX
High bit Low bit
Position of mapping Position of mapping
parameter parameter
Content of mapping Content of mapping
parameter parameter
Target setting for mapping parameter P0.027
-
-
HEX
High bit Low bit
Position of mapping Position of mapping
parameter parameter
Content of mapping Content of mapping
parameter parameter
Control mode: All
Determined by the communication
Setting range:
address of the parameter group
Data size: 32-bit
Control mode: All
Determined by the communication
Setting range:
address of the parameter group
Data size: 32-bit
ASDA-B3
Address: 0048H
0049H
Address: 004AH
004BH
