ASDA-B3
Motor model
ECM-B3 -E 1820
ECM-B3 -F 1830
1 2
Wire selection: use a 600 V
Note:
In the servo motor model name,
1.
represents the brake or keyway / oil seal type,
3
type, and represents the special code.
Power supply for the brake is 24 V
2.
The brake coil has no polarity. Its pin symbols are BRAKE1 and BRAKE2.
3.
Color of brake cable for motors with the frame size of 100 mm or above: red and black. The model
4.
number of UVW connector is MIL 22-22S and that of the brake connector is CMV1-2S.
Recommended brand
3 4 5
DDK
SUNCHU
PLT
Recommended brand
DDK
SUNCHU
U (Red) V (White)
A
PVC cable. Refer to Section 3.1.6 for more information.
AC
represents the motor inertia,
. Do not share the same power supply with control signals.
DC
UVW connector
Model number for UVW end
CE05-6A22-22SD-D-BSS(R1) (connector)
CE3057-12A-1-D(R1) (cable clamp)
CMS3106S22-22SBI
WPS3106A22-22S-R (connector)
WPS3057-12A-R (cable clamp)
Model number for brake end
CM10-SP2S-x-D or CMV1-SP2S-x-D
SC-CMV1-SP02C
Pin assignment
CASE
GROUND
W (Black)
(Green /
Yellow)
B C D
represents the encoder type,
represents the shaft diameter and connector
4
Wiring
BRAKE1 *4 BRAKE2 *4
1 2
3
3-15
