ASDA-B3
B. Military connector
Model name
ACS3-CAE 2703
ACS3-CAE 2705
ACS3-CAE 2710
ACS3-CAE 2720
Note: select cables according to the
standard cables.
Connection method:
Caution Follow these instructions when wiring. Incorrect wiring may cause battery
explosion.
Connect to
the motor
Straight
CMV1-10S
CMV1-10S
CMV1-10S
CMV1-10S
in the model name. B represents flexible cables and A represents
Military connector
Pin No. Terminal
1
2
3
4
5
6
7, 8
9
10
L
mm
3000 ± 50
5000 ± 50
10000 ± 100
20000 ± 100
Battery box
CN2 connector
3 2 1
7
1 0 9 8
T+
T-
-
DC+5V
BAT-
BAT+
-
GND
Shield
Absolute System
L
inch
118 ± 2
197 ± 2
394 ± 4
788 ± 4
Connect to
the servo
drive
4
Color
White
White/Red
-
Brown
Black
Red
-
Blue
-
10
10-7
