Delta ASDA-B3 Series User Manual page 347

Parameters
P1.098
Default:
Unit:
8
Format:
Settings:
When the disconnection detection protection (UVW) function is enabled (P2.065 [Bit 9] = 1), select the
detection response time with this parameter.
Set P1.098 to 0 to use the servo's default response time.
When P1.098 is not set to 0, the setting range should be between 100 and 800 as the detection
response time.
Note:
If it is necessary to shorten the response time, it is recommended that you use this parameter.
1.
When the servo is on and the motor does not move (servo drive has not issued the command),
2.
it is recommended that you set this parameter if disconnection detection is needed.
P1.099 -
P1.100
P1.101■
Default:
Unit:
Format:
Settings:
When you set 6 for the monitor source of P0.003 [YX], then the analog monitor output voltage refers to
the voltage value of P1.101.
Note: the analog monitor output voltage should be within the range of -8V to 8V.
P1.102■
Default:
Unit:
Format:
Settings:
When you set 7 for the monitor source of P0.003 [YX], then the analog monitor output voltage refers to
the voltage value of P1.102.
Note: the analog monitor output voltage should be within the range of -8V to 8V.
8-62
Disconnection detection protection (UVW) response time
0
ms
DEC
Reserved
Analog monitor output voltage 1
0
mV
DEC
Analog monitor output voltage 2
0
mV
DEC
Control mode: All
Setting range: 0, 100 - 800
Data size: 16-bit
Control mode: All
Setting range: -10000 to 10000
Data size: 16-bit
Control mode: All
Setting range: -10000 to 10000
Data size: 16-bit
ASDA-B3
Address: 01C4H
01C5H
Address: 01CAH
01CBH
Address: 01CCH
01CDH
