Learning the Tach (not needed with Virtual Tach)

To learn the tach signal:
1. Start the vehicle with the key. Within 5 seconds, press and hold the Control button (on the Control Center).
2. After 3 seconds, the status LED on your Control Center lights constant when the tach signal is learned.
3. Release the Control button.
Note: When the tachometer is programmed, the main unit automatically enters the Tachometer engine checking
mode.

Remote start shutdown/startup diagnostics

Shutdown diagnostics: If the remote start activates but fails to stay running, the remote start module has the ability
to inform you of what may have caused the failure. Before performing shutdown diagnostics it is important that you
let the remote start shut off on its own (i.e. let it attempt to start 3 times then shut down), if this is not done the unit
will report the shutdown you used to shut off the remote start.
Note: Shutdown diagnostics does not report if the vehicles factory immobilizer is causing the problem.
To perform shutdown diagnostics:
1. With the ignition Off, press and hold the Control button (on the Control Center).
2. Turn the ignition On and then back Off while holding the Control button.
3. Release the Control button.
4. Press and release the Control button. The status LED flashes to report the last shutdown for one minute (or until
the ignition is turned on) , as shown in the following table:
Status LED
Shutdown Mode
Flashes
1 Runtime expired.
2 Over-rev shutdown.
3 Low or no RPM.
4 Transmitter shutdown (or optional push button).
5 (+) Brake shutdown.
6 (-) Hood shutdown
7 Time mode/Turbo mode/Manual mode error.*
8 Neutral safety shutdown.
9 Low battery (voltage mode).
10 Alarm triggered.**
11 Wait-to-start input timed out.
* Time mode error: Ignition is on or shutdown in put is active when activating timer mode.
Turbo mode error: Turbo mode is programmed off, engine is not on or shutdown input is active.
Manual mode error: MTS mode not enabled.
** Alarm was triggered during remote start sequence.
