5-BUTTON AUTOMATIC / MANUAL TRANSMISSION
REMOTE STARTER
AS-1774 / 1774U
User Guide
It is the responsibility of the vehicle operator to ensure that their
vehicle is parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL
position and the parking brake is engaged in order to avoid accidents
upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to
avoid accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is
disabled or put into valet mode before servicing.
Designed & engineered in Canada
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of
the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (EIRP) is not more than that required for successful
communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the
equipment.
Doc#: 120810
Rev:1.8
© 2011
W W ARNING ! !
- AS-1774 -
- FcN -
Canada

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-1774 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Directed AS-1774

Summary of Contents for Directed AS-1774

  • Page 1 5-BUTTON AUTOMATIC / MANUAL TRANSMISSION REMOTE STARTER AS-1774 / 1774U User Guide W W ARNING ! ! It is the responsibility of the vehicle operator to ensure that their vehicle is parked in a safe and responsible manner. 1. a) Manual transmission: When leaving the vehicle, it is the user’s...

  • Page 2: Table Of Contents

    Table of Contents Government regulations ........................3 Introduction ..........................3 Using the Remote Control ....................... 4 Vehicle Presets ..........................4 Heater ............................4 Windshield Wipers, Radio & Headlights ..................4 Arming and disarming the Starter Kill .................... 4 Remote-Starting Your Vehicle ......................5 Setting Your Vehicle into Ready Mode ..................

  • Page 3: Government Regulations

    . Note: SmartStart™ must be professionally installed. For more information, see your nearest authorised Directed Canada dealer. With many advanced functions, this product will satisfy any one of your expectations from high-end commodity and security systems, without neglecting any standard feature commonly offered by entry-level starters.

  • Page 4: Using The Remote Control

    Using the Remote Control Your Remote Car Starter is equipped with a 5-button multi-channel remote control. It can operate two independent vehicles equipped with a Remote Car Starter (see Multi-Car Operation page-12, for second-car transmitter functions). The functions of the transmitter are as follows: (Picture serves as example only) UNLOCK: Unlocks the doors and disarms the STARTER...

  • Page 5: Remote-Starting Your Vehicle

    Note: If the Starter Kill is installed, the vehicle will benefit from a protection against starter motor damage that could occur after remote-starting the engine should the user, by force of habit, turn the ignition key to the CRANK position. The Starter Kill (if installed) can be configured by the installer either to Passive Mode (so as to arm automatically) or Active Mode (so as to require the user’s intervention for arming).

  • Page 6: Remote-Starting

    To set the system to Ready Mode: If Ready Mode is enabled by remote If Ready Mode is enabled by handbrake 1. Ensure that all the doors, hood and trunk are closed. Make sure that the gear selector is in the neutral position.

  • Page 7: Remote Starter Features

    Remote Starter Features Remote Door Locks If your system was installed with the Remote Door Locks option, you will have the convenience of remote keyless entry. To lock your doors and arm the starter kill (if installed): Press and hold the button for approx.

  • Page 8: Valet Mode

    Close all doors. You have 1.5 minutes (or 3 minutes) to press on the brake pedal, to get in gear and drive off. Note 1: Pressing on the brake pedal after the allocated period will shut the engine down. Note 2: The engine will continue running until the user re-enters the vehicle or until the expiration of the engine run time.

  • Page 9: Panic Mode

    Panic Mode Note: Panic mode can only be activated if the horn has been adequately configured by the installer. In an emergency situation, you can activate panic mode by pressing and holding the STOP button for more than 3 seconds, until the horn starts honking. If the vehicle is under a remote start, the engine will shutdown automatically before setting off the horn.

  • Page 10: Disable/Enable Led Flashing

    Example: If your Module is programmed for a runtime of 3 minutes and your vehicle has been running for 2 minutes already, pressing the button will reset the counter to zero and the Engine will run for another cycle (in this case, 3 minutes). Disable/Enable LED flashing To disable the LED: Press simultaneously until the parking lights flash three...

  • Page 11: Safe Start

    Safe Start Safe start enabled: If this feature is enabled, the user must press the button twice within 3 seconds to remote-start the vehicle. This will eliminate accidental remote starts, e.g. when children are playing with the transmitter. Swap start: If this feature is enabled, press simultaneously to remote start the vehicle.

  • Page 12: Aux 1

    Within 3 seconds, press the buttons simultaneously for 3 sec. The P-lights will flash once To take the system out of home valet mode: Turn the ignition key to the IGNITION ON (RUN) position. The system will warn you if someone attempts to start your vehicle while it stands in home valet mode.

  • Page 13: Car Finder

    -To stop the horn from sounding if the OEM-style alarm is triggered, press the button, or put the system in and out of Valet Mode (page-8) Car Finder If configured by your installer, the Car Finder option will help you locate the vehicle by sending a pulsating signal through the horn.

  • Page 14: Troubleshooting Poor Transmitting Range

    Troubleshooting Poor Transmitting Range Many factors may affect the operating range of the transmitter. Some of these are: The condition of the battery in the transmitter. The operating environment (for example: downtown radio-frequency noise, airports, cellular phone towers…). Metal: any type of metal will affect operating range. This includes the vehicle itself. The shape of the vehicle can affect range as well (vans in general have less range).
