Introduction

4x10/5x10 Analog is a complete solution for remote start and/or security, bypass and digital
interface. This guide provides information on the installation of the 4x10/5x10 module as an
analog unit. If you would prefer using 4x10/5x10 as a digital solution, go to www.xpresskit.
com, and search for the make, model and year of the vehicle.
Warning! This module must be connected to the internet and configured prior to installation
using an XKLoader2, as well as the web-based Config Wizard found at www.xpresskit.com.
Note: When used in digital mode, use the firmware-specific guide, which can be found online.

XpressStart ONE 4x10/5x10 compatibilities

For further information on the products listed below, refer to the corresponding documentation.
Product
SmartStart
SmartStart BLUETOOTH
®
Passive Keyless Entry (PKE)

What you get

Welcome to the best generation of security with remote start. Your system contains everything you need.
4x10 remote start system content
• XpressStart ONE KA4x10 Module.
• M501 Remote Start Relay Module.
• KA4x10 Series Control Module (IVU).
• Wiring cables.
• 2x remote controls (model and technology depend on the kit you have purchased).
• Owner's Guide and Security Registration Card.
5x10 remote start and security system content
• XpressStart ONE KA5x10 Module.
• M501 Remote Start Relay Module.
• KA5x10 Series Control Module (IVU).
• 514LN Revenger Soft Chirp 6-Tone Siren.
• 504D Double Guard Stinger Shock Sensor.
• Wiring cables.
• 2x remote controls (model and technology depend on the kit you have purchased).
• Owner's Guide and Security Registration Card.
4
Description
Remote start, lock and unlock your car by only pushing a button on your smartphone; using the simple graphical
interface of the Directed SmartStart App.
Access and remote start your vehicle using the Bluetooth
graphical interface of the Directed SmartStart App.
Unlock your vehicle doors simply by walking up to the vehicle, or walking away to lock. It can be installed in
combination with any Directed or Autostart remote start by connecting to the D2D port – with no additional
wires to connect.
technology from your smartphone, with the simple
®
XpressStart ONE 4x10/5x10 Analog
