- Page 1 T R A N S M I S S I O N R E M O T E S T A R T E R Model: ASRA-2510 User Guide Designed & Engineered in Canada Doc#: 120706 Rev:1.89 © 2012 Directed. All Rights Reserved...
- Page 2 WARNING! It is the responsibility of the vehicle operator to ensure that their vehicle is parked in a safe and responsible manner. 1. a) Manual Transmission: When leaving vehicle, it is the user’s responsibility to ensure that the gearshift lever is in the NEUTRAL position and the parking brake is engaged in order to avoid accidents upon remote starting.
-
Page 3: Table Of Contents
Table of Contents Government Regulations ................... 4 Introduction ..................... 5 Using the Remote Control ................. 6 Vehicle Presets ....................7 Heater ......................7 Windshield Wipers, Radio & Headlights ............7 Arming and disarming the Starter Kill .............. 7 Remote-Starting Your Vehicle ................9 Setting Your Vehicle into Ready Mode ............ -
Page 4: Government Regulations
Government Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Introduction
With many advanced functions, this product will satisfy any one of your expectations from high-end commodity and security systems, without neglecting any standard feature commonly offered by entry-level starters. Certain conditions apply. See your authorised Directed Canada dealer. User guide... -
Page 6: Using The Remote Control
Using the Remote Control Your Remote Car Starter is equipped with a 5-button multi-channel remote control. It can operate two independent vehicles equipped with a Remote Car Starter (see Multi-Car Operation page 22, for second-car transmitter functions). The functions of the transmitter are as follows: STOP and PANIC button. -
Page 7: Vehicle Presets
Vehicle Presets Heater When leaving the vehicle it is recommended to preset the accessory controls in preparation for the next remote start. Settings for the blower motor (fan), front and rear, should not be left on HIGH. It is recommended to leave the settings on LOW or MEDIUM instead. - Page 8 Passive Mode: To arm the Starter Kill, press the button on the transmitter, OR In Passive mode, the Starter Kill will automatically arm 1 minute (by default) or 3 minutes (if configured this way) after the ignition is turned OFF or once the last door is closed (if the doors are monitored). The LED on the antenna will flash quickly during the countdown preceding the activation of the Starter Kill.
-
Page 9: Remote-Starting Your Vehicle
Remote-Starting Your Vehicle Setting Your Vehicle into Ready Mode If your vehicle has a manual transmission you must read the following indications. The unit must first be set to Ready Mode in order to start the vehicle by remote. If the unit is not set to Ready Mode, it cannot remote start the vehicle. Please note that Ready Mode can be enabled by the remote or the handbrake, depending on the option that was selected by your installer. - Page 10 To set the system to Ready Mode: If Ready Mode is enabled by remote If Ready Mode is enabled by handbrake 1. Ensure that all the doors, hood and trunk are closed. Make sure that the gear selector is in the neutral position. 2.
-
Page 11: Remote-Starting
Remote-starting Press the button for approximately 1 second. The parking lights will turn ON to inform you that the Remote Car Starter has received your signal. Approximately 5 seconds later, the engine will start. The parking lights will remain during the pre-programmed run time of the engine. If your vehicle has an automatic transmission and it does not start at the first attempt, the system will shut down, wait a few seconds and try to start the engine again. -
Page 12: Remote Starter Features
Remote Starter Features Remote Door Locks If your system was installed with the Remote Door Locks option, you will have the convenience of remote keyless entry. To lock your doors and arm the starter kill (if installed): 1. Press and hold the button for approx. - Page 13 Activating Idle mode (Automatic Transmission): With the engine running, make sure to release the brake pedal and press the button on the transmitter until the parking lights come ON. Note: SmartStart™ can be setup to use the icon to activate Idle mode, Turbo mode or Ready mode.
-
Page 14: Valet Mode
Note 1: Pressing on the brake pedal after the allocated period will shut the engine down. Note 2: The engine will continue running until the user re-enters the vehicle or until the expiration of the engine run time. Note 3: If the pre-programmed run-time expires or if the user shuts down the engine remotely, the vehicle will enter Ready Mode. - Page 15 To put the system into Valet mode using the TRANSMITTER (Remote Valet mode): Press the buttons simultaneously until the parking lights flash three times. The LED on the antenna will come ON solid to indicate that the vehicle has successfully entered Valet mode. To take the system out of Valet Mode To take the system out of Valet mode using the KEY (Ignition Valet mode): Insert the ignition key into the ignition switch.
-
Page 16: Panic Mode
Panic Mode Note: Panic mode can only be activated if the horn has been adequately configured by the installer. In an emergency situation, you can activate Panic mode by pressing and holding button for more than 3 seconds, until the horn starts honking. If the vehicle is under a remote start, the engine will shutdown automatically before setting off the horn. -
Page 17: Extended Run Time
Turn the ignition key to the IGNITION ON (RUN) position. Press and hold the button until the parking lights come ON for 2 seconds, pause, and then flash once. If Safe Start is enabled, you can activate Cold Weather Mode by: ... -
Page 18: Constant Output
Constant output Pressing and holding the button for more than 3 seconds will lock all doors and will send a constant pulse as long as the LOCK button is held down (maximum of 15 seconds). This constant pulse can be configured to activate certain functionalities such as rolling up the windows –... -
Page 19: Secure Lock
Secure Lock (Disabled by default.) Before your vehicle can be remote-started, the factory security system must first be disarmed. The Secure Lock feature may be required on certain vehicle models with factory security systems that automatically unlock the doors when the security system is disarmed. To keep your vehicle protected when the factory security system is disarmed for a remote start, Secure Lock will relock your doors as soon as the vehicle is started. -
Page 20: Turbo Mode
Turbo Mode If Turbo Mode is configured at installation, it will allow a turbocharger to idle down after the user leaves the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it is shut down by remote control), then shut down the engine. -
Page 21: Home Valet Mode
Home Valet Mode If configured at installation, this feature will remotely set the vehicle to a no- remote-start mode: if the vehicle is parked indoors there is no danger of it starting accidentally by remote control. If the vehicle has a manual transmission, it should be set into ready mode before activating the Home Valet™. -
Page 22: Horn Chirp Timing
The output will provide a 1-second negative output when the button is pressed a second time on the transmitter. Horn Confirmation: AUX 1 can be programmed to trigger the horn every time the button is pressed, or when the button is pressed twice within 3 seconds. -
Page 23: Car Finder
To arm the OEM-style alarm, press the button on the transmitter. The OEM-style alarm will ONLY arm if the button on the transmitter is pressed. The LED on the antenna will flash slowly to indicate that the OEM-style alarm is now armed. ... -
Page 24: Troubleshooting Poor Transmitting Range
Troubleshooting Poor Transmitting Range Many factors may affect the operating range of the transmitter. Some of these are: The condition of the battery in the transmitter. The operating environment (for example: downtown radio-frequency noise, airports, cellular phone towers…). ... -
Page 25: Parking Light Flash Table
Parking Light Flash Table Parking lights Description flashes Doors locked. Trunk released. Start signal received from the remote. Runtime has expired 2 slow Shutdown by remote 2 fast Doors unlocked Valet mode is deactivated ... -
Page 26: Battery Replacement
Battery Replacement The transmitter is powered by two lithium cells (CRXXXX). When the transmitter stops functioning, replace the batteries. Release the lock on the battery cover. Remove the battery cover. Remove the old batteries. Install two new lithium batteries (CRXXXX) into the transmitter with the positive (+) mark toward the battery cover.
