Directed XPRESSSTART ONE Installation Manual page 17

3 Confirmation Chirps
4 Horn Function
5 Override Pulse Count
6 Sensor Icon Type
Trigger/Panic Duration
7
(seconds)
8 One-time Bypass
9 NPC - Nuisance Preven-
tion Circuitry
10 Door Trigger Error Chirp
Remote start features
Note that the availability of features and their predetermined default values is in direct relation to the firmware
you are using.
Default settings are in bolder type.
Menu
Feature
Item
1 Engine Checking Mode
Cranking Time (sec-
2
onds)
3 Activation Pulse Count
Diesel Delay Type/
4
Duration
Accessory Output Dur-
5
ing Diesel Start Delay
6 Turbo Mode Runtime
Remote Start Runtime
7
(minutes)
SmartStart/Timer Mode
8
Runtime (minutes
SmartStart/Timer Mode
9
Start Count
17
On - Warn Chirps On: arm, disarm, and sensor warn-away chirps are active.
1.
2. On - Warn Chirps Off: arm and disarm chirps are active; warn-away chirps are disabled.
3. Off - Warn Chirps On: arm and disarm chirps are disabled; warn-away chirps are active.
4. Off - Warn Chirps Off: arm, disarm, and sensor warn-away chirps are disabled.
Trigger & Panic Only: horn output will pulse only during full trigger events.
1.
2. Siren Function 20/30/40/50ms: output will emulate the siren output with the predefined output
timing to compensate for OEM horn inefficiency.
1-5: sets the number of times the Control button should be pressed (1-5) to override the alarm system. *The
default value is 1.
Sets the Zone 2 text or icon to be displayed for Warn-Away and Full Trigger activations:
1. None
2. Shock
3. Field Disturbance
4. Tilt Sensor
5. Glass Break
6. Ultrasonic
1 to 180 seconds: sets the Full Trigger and Panic mode output duration seconds, with a maximum of 120
seconds. The default value is 30 seconds.
1. On: this feature will disable Passive Arming once and, if armed by remote control it will disable the
Comfort Closure and Aux outputs linked to arming.
2. Off: feature NOT available.
On: sensors that trigger excessively will be disabled until they have been stable for more than
1.
one hour.
2. Off: sensors will NOT be disabled if triggered excessively.
1. Off: an active door trigger when arming will NOT create an alert output.
2. On: if the door trigger is active when arming, the siren will emit a chirp and a message will be
sent to the 2-way remote control as an alert.
Opt. 1 Opt. 2
Virtual Tach Voltage
0.6 sec. 0.8 sec.
1 2
Wait for Glow-
1 to 90 seconds.
plug input
On Off
Turbo Mode dis-
1 to 10 minutes. The default value is 3 minutes.
able
Options: 1 to 60 minutes. The default value is 12 minutes.
Options: 1 to 16 minutes. The default value is 3 minutes.
Options: 1/2/3/4 to 24 (Starts) in increments of 2. The default value is 1 start.
Opt. 3 Opt. 4
Off Tachometer
1.0 sec. 1.2 sec.
3
Opt. 5+
1.4 sec. (5)/
1.6 sec. (6)/
1.8 sec. (7)/
2.0 sec. (8)/
4.0 sec. (9)
XpressStart ONE 4x10/5x10 Analog
© 2013 Directed. All rights reserved.
