T H E S C I E N C E O F S E C U R I T Y
™
O W N E R' S
G U I D E
M
O
D
E
L
4 706 X

Advertisement

Table of Contents
loading

Related Manuals for Directed Clifford 4706X

Summary of Contents for Directed Clifford 4706X

  • Page 1 T H E S C I E N C E O F S E C U R I T Y ™ O W N E R’ S G U I D E 4 706 X...

  • Page 3: Congratulations

    For any additional questions please contact your authorized Directed dealer, or contact Directed at 1-800-753-0600. (U.S. only) or 1-800-361-7271 (Canada only). Additional support is also avail- able at: http://support.directed.com.

  • Page 4: Replacement Remote Controls

    Replacement remote controls Please see your authorized dealer or visit us at www.directedstore. com to order additional remote controls. Remote control RPNs (Re- placement Part Numbers) are found on the back of the device. © 2016 Directed. All rights reserved.

  • Page 5: Table Of Contents

    Contents Congratulations ....................iii Important information ..................iii Government Regulations and Safety information ........iii Your Warranty ..................iii Replacement remote controls ..............iv Getting Started ....................4 Charging the remote control: ..............4 Keys to using this manual ..............5 Remote Control Information ..................
  • Page 6 Main Menu ....................... 21 Setup Remote Menu: ................21 Remote Start Info ................22 Runtime Alert ..................23 Car 2 ....................23 Screen Color ..................23 Temp Unit ..................23 Button Beep..................24 System Type ..................24 Clock Set ..................24 Review .....................
  • Page 7 Battery Information (Responder LC) ..............42 Low Battery ..................42 Battery Life ..................43 Battery Information (1-Way) ..............44 Battery Disposal ................44 Glossary of Terms ....................45 Patent Information ..................... 46 Government Regulations ..................47 Warning! Safety First ..................49 Limited lifetime consumer warranty ..............

  • Page 8: Getting Started

    Getting Started Your Responder LC remote is powered by an internal rechargeable battery that can only be serviced by an authorized Directed dealer. Due to transit and storage time prior to your purchase, the battery charge may have depleted. To ensure proper operation, check the battery level and if not fully charged, use the provided cable to con- nect to the USB port on a computer.

  • Page 9: Keys To Using This Manual

    • An asterisk (*) when used after a word or phrase denotes that additional details can be found in related sections usually noted at the bottom of the page or end of the section. © 2016 Directed. All rights reserved.

  • Page 10: Remote Control Information

    Remote Start commands. A U X Used to access function levels for commands, configura- Function Button tion menus for programming, Car Selection, and to request reports. USB Port The battery charger plugs into this port. © 2016 Directed. All rights reserved.

  • Page 11: Control Center

    The Control Center button, for placing the system into Valet Mode* and to perform the Emergency Override** operation. “Remote and System Operations” on page 34 * See for details. ** See “System Features” on page 27 for details. © 2016 Directed. All rights reserved.

  • Page 12: Status Screen Icons

    Smart Start is ON; Remote Start is ON. Note: When the icon is without an arrow head: Smart Start is ON; Remote Start is OFF. Manual Transmission Start mode is enabled, the engine can be started. Displays the vehicle interior temperature. © 2016 Directed. All rights reserved.
  • Page 13 The remote will emit Beeps and Tones when messages are received. Text field Displays the Clock, Runtime, Temperature, message text and feature menus. * This icon not present until the Car 2 is turned on in the Setup Re- mote configuration menu. © 2016 Directed. All rights reserved.

  • Page 14: Using Your System

    Silent Lock command. The system will Lock the doors and flash the parking lights without horn honks. The Responder LC remote will display in the text field and update the status screen SILENT LOCKED icons. © 2016 Directed. All rights reserved.

  • Page 15: Responder Lc Command Table

    OFF). Refer to the notes included in the command descriptions that address these faults or go to “Remote Start Error” on page 32 under “Re- mote Start Features” on page 28. © 2016 Directed. All rights reserved.

  • Page 16: Basic Commands (Direct Access)

    flash twice. The text and beeps play to UNLOCK confirm and the system status icons update. If Valet Mode* is ON the doors unlock and the text and tone play. VALET © 2016 Directed. All rights reserved.

  • Page 17: Aux/Trunk

    “Remote Start Error” on page 32 under “Remote Start Features” on page 28. For Manual transmission vehicles see “MTS Mode (Manual Trans- mission Start)” on page 31 in the Remote Start Features section for more details. © 2016 Directed. All rights reserved.

  • Page 18: Advanced Commands: (Level 1)

    Activates (or if ON, deactivates) the AUX 1 output. The AUX CHANNEL text and ON tones or OFF tones play to confirm. Runtime Reset Press and release If more time is needed while remote start is active, runtime reset © 2016 Directed. All rights reserved.

  • Page 19: Temp Request

    Remote Start must be ON to use Runtime Reset. Temp Request Press and hold the button Requests the vehicle’s interior temperature and temporarily displays it via status screen icon and text field. * See”Remote and System Operations” on page 34 for details. © 2016 Directed. All rights reserved.

  • Page 20: Advanced Commands: (Level 2)

    TIMER START ON TIMER START OFF firm and the Remote start status icons update. Note System needs to be Locked or Timer Start will not start the engine. © 2016 Directed. All rights reserved.

  • Page 21: Runtime Remaining

    Requests the remaining Remote start runtime and temporarily displays it in the text field. Note Remote Start must be ON to use this feature. * See”Remote and System Operations” on page 34 for details. © 2016 Directed. All rights reserved.

  • Page 22: Advanced Commands: (Level 3)

    Press and release Activates (or if ON, deactivates) the AUX 3 output. The AUX CHANNEL text and ON tones or OFF tones play to confirm. ”Remote and System Operations” on page 34 * See for details. © 2016 Directed. All rights reserved.

  • Page 23: Advanced Commands: (Level 4)

    10 seconds after remote starting if the temperature is below 55°F. Note Remote Start must be active to use this feature. * This feature must be installed and turned on by an authorized Directed dealer. © 2016 Directed. All rights reserved.

  • Page 24: Responder Lc Configuration

    • button to choose the feature in the text field and view its options. Press it when the desired feature or option is in the text field to set it as the new setting. © 2016 Directed. All rights reserved.

  • Page 25: Main Menu

    Unlocking is not desired this message can be turned off by an authorized Directed Dealer. Page Mode Options: POWER SAVE Paging is how the Responder LC remote monitors your system’s messages. extends battery life by turning Paging POWER SAVE © 2016 Directed. All rights reserved.

  • Page 26: Remote Start Info

    The text field can be set to display the information you prefer dur- ing remote start. : Remote Start Runtime, : vehicle RUNTIME TEMP interior Temperature, or the will be displayed in the text CLOCK field while Remote Start is on. © 2016 Directed. All rights reserved.

  • Page 27: Runtime Alert

    , or will illuminate with a selected color during output when set to one of the option colors. Temp Unit Options: Temperature can be displayed in your choice of temperature scales, Fahrenheit or Celsius. © 2016 Directed. All rights reserved.

  • Page 28: Button Beep

    Entry to which the remote has been paired, and adjusts the text and main menu accordingly. This has been pre-set by the factory for your system. Clock Set Options: HOUR Review Displays firmware version. Exit Exits and returns to the main menu. © 2016 Directed. All rights reserved.

  • Page 29: Remote Pairing

    PAIR remote is ready to pair. Press the button. Wait several seconds as the remote generates a security encryp- tion and sends it to the Control Center. If Pair is successful the © 2016 Directed. All rights reserved.

  • Page 30: Demo Mode

    The remote also turns itself on and begins charging when the battery charger is connected. Exit To return to normal operation, press the button while EXIT is dis- played. © 2016 Directed. All rights reserved.

  • Page 31: System Features

    Note As a precaution, if programmed for Passive Locking or Auto Re-locking the system should be placed into Valet Mode until a remote is available. © 2016 Directed. All rights reserved.

  • Page 32: Remote Start Features

    ON position to resume normal operation. Advanced Start The Advanced start features Timer Mode and Smart Start will automat- ically start the engine to maintain battery charge or combat extreme cold when parked for an extended period of time. © 2016 Directed. All rights reserved.
  • Page 33 When the Remote start runtime expires the engine shuts off, message is sent to the remote control and the REMOTE START OFF countdown timer restarts. Smart Start is exited after the final start. © 2016 Directed. All rights reserved.

  • Page 34: Temperature Reporting

    Note The temperature and battery thresholds can be changed by an authorized Directed dealer if a higher or lower threshold is desired. Temperature Reporting During Remote start the vehicle interior is checked regularly for tem- perature changes. If a change in temperature is detected this report will be sent to the remote for display.

  • Page 35: Mts Mode (Manual Transmission Start)

    Turn OFF and remove the key from the ignition switch, the engine remains running. Exit the vehicle, close all the doors and Lock the system. The engine turns off and after a few seconds, the REMOTE START OFF © 2016 Directed. All rights reserved.

  • Page 36: Turbo Timer Mode

    Exit the vehicle, close all the doors and Lock the system. The engine runs for the Turbo Mode runtime. Note Turbo Timer must be turned on by an authorized Directed dealer. Note For Turbo Timer mode on manual transmission vehicles fol-...
  • Page 37 Enable MTS mode command - MTS not enabled After performing Timer Mode or Check all Solutions Smart Start command Toggle Switch OFF Turn switch ON * Refers to the number of parking light flashes. © 2016 Directed. All rights reserved.

  • Page 38: Remote And System Operations

    It also bypasses the comfort closure and auxiliary channel outputs programmed to activate when Locking. After the next Unlock all operations return to normal. * These features must be turned on by an authorized Directed dealer. © 2016 Directed. All rights reserved.

  • Page 39: Valet Mode

    When the remote receives this message it updates the status screen icons. This way all users are able to quickly review the system status just by accessing the status screen. © 2016 Directed. All rights reserved.

  • Page 40: Out Of Range

    Remote Start is OFF. Only available when Remote Start is ON. Defroster Remote Start is OFF. Only available when Remote Start is ON. Not configured for Only available when configured for this. Defroster control. © 2016 Directed. All rights reserved.

  • Page 41: 1-Way Companion Remote Control

    4 times. The LED flashes in groups for a few seconds to indicate the level. Press the desired command button while the LED is flashing to perform the command. © 2016 Directed. All rights reserved.

  • Page 42: Button Auto Lock

    2 LED flashes and beeps indicate the remote features menu is accessed and can be set. Press buttons indicated below, 1beep and flash turns the feature on, 2 beeps and flashes turns the feature off. • Autolock feature: Press to turn on/off. © 2016 Directed. All rights reserved.
  • Page 43 Control Center. The horn honks to indicate Pairing is complete. Once the desired feature has been changed you can exit pro- gramming by following the procedure described previously. © 2016 Directed. All rights reserved.

  • Page 44: System Expansion Options

    System Expansion Options Note These features must be turned on by an authorized Directed dealer. Controlling Two Vehicles (Car Select) The Responder LC and 1way companion remote can control systems in two different vehicles saving the need for multiple remote controls.
  • Page 45 • Trunk release • Windows open/close • Left Sliding door open/close • Right Sliding door open/close • Rear Hatch open/close • Sunroof open/close • Audio system • Headlights © 2016 Directed. All rights reserved.

  • Page 46: Battery Information (Responder Lc)

    Battery Information (Responder LC) The Responder LC remote control is powered by an internal recharge- able battery that can be serviced only through an authorized Directed Electronics dealer. The information and precautions in this section can help maximize your battery’s life and usage in providing your Re- sponder LC remote control with many years of trouble free operation.

  • Page 47: Battery Life

    Paging off in the Setup Remote Menu. Caution! The remote will not receive messages from the system. • Turn Beeps OFF: The Button beeps can be turned off in the Setup Remote Menu. The command beeps still play normally. © 2016 Directed. All rights reserved.

  • Page 48: Battery Information (1-Way)

    Reposition case parts, and snap together by pressing firmly and evenly on the front and back. Reinstall screw (if applicable). Battery Disposal Directed cares about the environment. If you need to dis- pose of the battery, please do so in accordance with your municipal requirements for battery disposal.

  • Page 49: Glossary Of Terms

    Control Center Button A small push button located on your system’s Control Center. It is used to override (Unlock) the system when a remote is not available or to enter or exit Valet Mode. © 2016 Directed. All rights reserved.

  • Page 50: Patent Information

    Remote Start Patents: 5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936; 5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053; 7,483,783 Vehicle Security Patents: 5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591; 5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667; 5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484 Other patents pending. © 2016 Directed. All rights reserved.

  • Page 51: Government Regulations

    RF exposure compliance. This device is designed to be used in a person’s hands and its operating configu- rations do not support normal transmissions while it is carried in pockets or holsters next to a person’s body. © 2016 Directed. All rights reserved.
  • Page 52 WARNING! Changes or modifications not expressly approved by the party re- sponsible for compliance could void the user’s authority to operate this device. © 2016 Directed. All rights reserved.

  • Page 53: Warning! Safety First

    Installation Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer. If you have any questions, ask your retailer or contact Directed directly at 1-800-753-0600. Remote Start Capable When properly installed, this system can start the vehicle via a command signal from the remote control transmitter.
  • Page 54 This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in the product installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the authorized Directed dealer to fix the problem.

  • Page 55: Limited Lifetime Consumer Warranty

    Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other dated proof of purchase bearing the following information: consumer’s name, telephone number and address;...
  • Page 56 For further details relating to warranty information of Directed products, please visit the support section of Directed’s website at: www.directed.com This product may be covered by a Guaranteed Protection Plan (“GPP”). See your authorized Directed dealer for details of the plan or call Directed Customer Service at 1-800-876-0800. 920-10011-01-2011-06...
  • Page 57 © 2016 Directed. All rights reserved.
