Shutdown codes

LED Description
Run safe shutdown.
Flashes red x 1
Brake shutdown.
Flashes red x 2
No key detected shut-
down.
Flashes red x 3
Speed detected.
Flashes red x 4

Active ground while running (status)

LED Description
GROUND OUT ON
(GWR) command re-
ceived.
Flashes green
IGNITION ON com-
Solid red, then
mand received.
flashes orange
START ON command
received.
Flashes green
quickly

D2D and W2W commands

LED Description
LOCK command re-
ceived.
Flashes orange
x 1
UNLOCK command
received.
Flashes orange
x 2
TRUNK command re-
ceived.
Flashes orange
x 3
AUX1 command re-
ceived.
Flashes orange
x 4
AUX2 command re-
ceived.
Flashes orange
x 5
12
Troubleshooting
Used to check the installation and for trouble-
shooting purposes.
Troubleshooting
Otherwise, the Ground While Running (status)
signal was lost or was never received by the
module.
Otherwise, the ignition signal was not re-
ceived by the module.
Otherwise, the start signal was not received
by the module.
Troubleshooting
If the bypass module fails to flash, it means the
module did not receive the signal.
Comment
Used to check for internal safety operation. Does not
represent an error.
Comment
Commands can come from RF, D2D or W2W.
In a W2W install, it will show only if the ignition
input wire is used.
Comment
Commands can come from RF, D2D or W2W.
XpressStart ONE 4x10/5x10 Analog
