Assembly/Disassembly
PCB Cover Plate Assembly
No. Description (standard parts)
1 Plate-PCB Cover
2 Sensor Assembly-Paper Low
3 Nest-Sensor
4 Screw-M3X0.5X10MM Ph Phl Sems
5 Window-LED
6 Ring-.187 dia. Push on Retaining
7 Button-Dark Gray
8 Mount-Switch Button
9 Spring-Compression
10 Retainer-'E' Ring
11 Ty-Wrap
Mar-03
Confidential Information: Not for Distribution.
Part No. (History)
M068261-01
RM034658-01
85-03531
M067831-02*
M068326-01
M068334-01
M067906-01
M068327-01
M067865-02
520-9800006*
98-0941*
* Not available as a spare part
