Printer Status Led; Table 2 Printer Status Led Indication Descriptions - TransAct Ithaca 800 Series Maintenance Manual

Series 800 Maintenance Manual

Printer Status LED

The printer has been outfitted with a LED indicator system that provides the condition of the printer by
using a series of blinks to communicate the status of the printer. If a customer supplied Bezel is installed,
the status of the Bezel will be identical to the LED
The following table lists the different LED indications and provides a brief description.
Condition
Unit Ready
Head Up
Door Open
Paper Out
Temperature Error
Paper Jam
Ram Error
Checksum Error

Table 2 Printer Status LED Indication Descriptions
