11.18.5

Inserting Sheet

Pos: 55.168.31 /BA/Bedienung /Rundballenpresse/Ballenwickler/Folienrollen einlegen @ 75\mod_1309264497329_78.docx @ 661286 @ @ 1
1
2
Fig. 197
Note
Up to 10 sheet rolls can be stored in both sheet boxes (2) to the right and to the left.
• Open sheet box door (1)
• For swivelling the sheet roll holder (3), loosen the locking (4) and pull the sheet roll holder
forward until the indentation (5) snaps into place in the locking lever
Pos: 55.168.32 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
CPN00004_2
Operation
3
5
4
CPN00003_1
257
