Krone Comprima CF 155 XC Original Operating Instructions page 281

Pos: 59.24 /Überschriften/linke Maschinenseite @ 60\mod_1297934981687_78.docx @ 562715 @ @ 1
Left-hand Side of the Machine
Pos: 59.25 /BA/Wartung/Rundballenpresse/Lage der Sensoren Links CF/CV @ 200\mod_1385454417899_78.docx @ 1683172 @ @ 1
Fig. 219
Pos. Sensor designation
1 Position of cutter base (B8)
2 Bale chamber closed left (B11)
3a Bale firmness left (B9)
(CF155 XC)
3b Bale diameter left (B9)
(CV150 XC /CV210 XC)
4 Bale chamber open (B14)
5 Slip sensor (B5)
Pos: 59.26 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
4
1
Distance
Transmitter/
sensor
2 mm
2 mm
4 mm
2 mm
5
3b
3a
2
Operating Sensor type
terminal CCI
X Namur
X Namur
X Rotary
potentiomete
r
X Rotary
potentiomete
r
X Namur
X Namur
Maintenance
COM00308
Tightening
torque
10 Nm
10 Nm
10 Nm
10 Nm
281
