Page 1 Original Operating Instructions Document no.: 150001050_01_en Status: 05/11/2019 RP701-21 Round Baler Comprima F 155 XC From machine no.: 1022623...
Page 2 Contact Maschinenfabrik Bernard Krone GmbH & Co. KG Heinrich-Krone-Straße 10 48480 Spelle Germany Telephone main office + 49 (0) 59 77/935-0 Telefax main office + 49 (0) 59 77/935-339 Telefax spare parts warehouse na- + 49 (0) 59 77/935-239 tional territory...
Page 3: Table Of Contents
Identification plate ........................ 39 Function description net wrapping ..................... 39 Function description net and chamber film wrapping .............. 40 Function description cutting unit .................... 41 Technical data .......................... 42 Consumables .......................... 44 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 4 Connecting the KRONE ISOBUS terminal (CCI 800, CCI 1200).......... 63 7.12 Connecting foreign ISOBUS terminal .................. 65 7.13 Connecting the camera to the KRONE ISOBUS terminal CCI 800 or CCI 1200 ....... 67 7.14 Connecting the road lighting ...................... 67 7.15 Mounting safety chain ........................
Page 5 KRONE Terminal DS 500 ....................... 110 11.1 Touchable display ........................ 110 11.2 Switching terminal on/off...................... 110 11.3 Design DS 500......................... 111 KRONE ISOBUS terminal (CCI 800, CCI 1200) .............. 113 12.1 Touchable display ........................ 113 12.2 Switching terminal on/off...................... 114 12.3 Design of display ........................ 115 12.4...
Page 6 Setting the lock of the tapered roller .................. 180 17.11 Checking the retaining comb for net wrapping ................ 181 17.12 Checking the retaining comb for chamber film wrapping ............ 182 17.13 Setting the retaining comb for chamber film wrapping............. 183 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 7 19.3 Disturbances at the tying unit or during the tying cycle ............ 225 19.4 Malfunctions on the chain lubrication unit ................ 226 19.5 Faults of the electrics/electronics..................... 227 19.5.1 Error Messages........................ 227 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 8 Setting transmission linkage and brake lever on the tandem axle........... 260 20.2 Car jack contact points ...................... 263 Waste disposal........................ 264 Appendix.......................... 265 22.1 Hydraulic diagram ........................ 265 Index............................ 266 Declaration of conformity ..................... 277 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 9: Information On This Document
Information on This Document Validity This document is valid for machines of type: RP701-21 (Comprima F 155 XC) All information, illustrations and technical data in this document correspond to the latest state at the time of publication. We reserve the right to make design changes at any time and without notification of reasons.
Page 10: Figures
This arrow identifies the result of an action step or sequence of actions. This bullet point identifies an enumeration. If the bullet point is intended, it identifies the second level of the enumeration. Icons in figures The following icons can be used in illustrations: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 11 CAUTION The signal word CAUTION warns of a hazardous situation which will result in minor to moderate injuries if the warning sign is ignored. Example of a warning sign: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 12: Conversion Table
Volume flow Litres per minute L/min 0.2642 US gallons per minute Cubic metres m³/h 4.4029 per hour Force Newton 0.2248 Pound force Length Millimetre 0.03937 Inch Metre 3.2808 Foot Power Kilowatt 1.3410 Horsepower Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 13 Kilometres per km/h 0.6215 Miles per hour hour Volumes Litres 0.2642 US gallon US gal. Millilitre 0.0338 US ounce US oz. Cubic centi- cm³ 0.0610 Cubic inch in³ metre Weight Kilogram 2.2046 Pound Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 14: Safety
• Attachment of unauthorised or unapproved additional equipment • Use of spare parts which are not KRONE original spare parts • Stationary operation of the machine Unauthorised modifications to the machine may affect the properties of the machine or disrupt proper operation.
Page 15: Service Life Of The Machine
He has read the operating instructions and can implement the information in the operating instructions accordingly. • He is familiar with driving vehicles safely. • For road travel he has adequate knowledge of the highway code and has the stipulated driving licence. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 16: Personnel Qualification Of The Technicians
Additional equipment and spare parts that do not correspond to the requirements of the manufacturer may affect the operational safety of the machine and cause accidents. „ To ensure operational safety, use original parts or standard parts which correspond to the requirements of the manufacturer. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 17: Jobs On The Machine
„ In case of damage which may affect operational safety and cannot be repaired according to these operating instructions: Have damage repaired by a qualified service centre. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 18: Danger Zones
„ Consider the information in all relevant operating instructions: • The operating instructions of the tractor • The operating instructions of the machine • The operating instructions of the universal shaft Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 19 „ In case of dangerous situations, immediately switch off drives and instruct people to leave the danger zone. Danger zone due to trailing machine parts If machine parts are trailing, people may be seriously injured or killed. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 20: Ensuring Functionality Of Safety Devices
„ Use only personal protective equipment which is in proper condition and offers effective protection. „ Adjust personal protective equipment to the person, for example the size. „ Remove unsuitable clothing and jewellery (e.g. rings, necklaces) and cover long hair with a hairnet. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 21: Safety Markings On The Machine
„ Consider the overall width of the combined tractor and machine. „ Consider the larger swivel range when cornering. „ Adjust the driving speed when cornering. „ When turning, watch out for people, oncoming traffic and obstacles. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 22: Parking The Machine Safely
2.4.17 Dangers arising from environment Fire hazard Combustible materials may accumulate in the machine due to operation or animals, such as rodents or nesting birds, or dust resuspension. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 23 „ Jump away from the machine. Jump into a safe standing position. Do not touch the machine from the outside. „ Move away from the machine with very small steps. In doing so, make sure that your feet are close to one another. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 24: Sources Of Danger On The Machine
Damaged compressed air hoses of compressor unit may tear off. Hoses that move uncontrollably may hurt people seriously. „ If it is suspected that the compressor unit is damaged, immediately contact a specialist workshop. „ Shut down and safeguard the machine, refer to page 27. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 25: Dangers In Connection With Certain Activities: Working On The Machine
„ Prior to any work, stop and safeguard the machine, refer to page 27. „ Make sure you stand securely. „ Use a suitable fall protection. „ Secure the area below the assembly point against falling objects. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 26: Dangers In Connection With Certain Activities: Working On Wheels And Tyres
The fitting of wheels and tyres requires adequate knowledge and approved mounting tools. „ If there is a lack of knowledge, have the wheels and tyres fitted by the KRONE dealer or by a qualified tyre service.
Page 27: Behaviour In Dangerous Situations And In Case Of Accidents
„ Before working on or under raised machine parts: Secure machine or machine parts against lowering by means of hydraulic shut-off device (e.g. stop cock) on machine side. „ Before working on or under raised machine parts: Safely support machine or machine parts. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 28: Carrying Out Oil Level Check And Oil And Filter Element Changes Safely
„ Lower raised machine parts or secure them against falling, refer to page 27. „ Shut down and secure the machine, refer to page 27. „ Cordon off the danger zone of the actuated moving machine parts in a clearly visible manner. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 29: Safety Labels On The Machine
Safety labels on the machine Every safety label is provided with an order number and can be ordered directly from the authorised KRONE dealer. Immediately replace missing, damaged and unrecognisable safety labels. When attaching safety labels, the contact surface on the machine must be clean and free of dirt, oil and grease to ensure optimum adhesion of the labels.
Page 30 Safety Safety labels on the machine Position and meaning of safety labels RPG000-064 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 31 There is a danger of being drawn in if you approach the danger zone and if you use your hands or feet to remove crop blockages. „ Before working on the pick-up, switch off the PTO shaft and the engine. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 32 Risk of injury due to the machine rolling away or overturning. „ Before opening the tailgate, ensure that the machine has been correctly coupled to the tractor. „ When uncoupling the machine, ensure that the tailgate is closed. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 33 When opening the tailgate, there is a risk of people being crushed in the danger zone between the tailgate and a fixed obstacle. „ Ensure that there is nobody between the tailgate and a fixed obstacle. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 34 „ When actuating the lever, maintain an adequate distance. 15. Ord. no. 27 024 736 1 (2x) Danger due to spring under tension Risk of injury from ejected machine parts. „ Never loosen the screw connection. 27 024 736 0 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 35: Safety Equipment
• The country-specific regulations for using the safety chain during transportation of the machine must be observed. Catch loop • The catch loop is used for the additional protection of hitched machines. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 36: Smv Emblem
The SMV emblem (1) is at the rear in the centre or on left. If the machine is transported on transport vehicles (for example lorry or train), the SMV emblem must be covered or dismounted. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 37: Data Memory
- if applicable in consultation with an expert. Additional functions regulated by a contractual agreement with the customer (e.g. remote maintenance) permit the transmission of certain machine data from the machine. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 38: Machine Description
Pick-up drive To prevent an overload, there is a cam clutch on the pick-up drive. This cam clutch has been set at the factory and must not be adjusted without consulting your KRONE service partner. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 39: Identification Plate
To ensure that these data are always available, we recommend to enter them in the fields on the front cover page of these operating instructions. Function description net wrapping RP000-533 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 40: Function Description Net And Chamber Film Wrapping
15 Deflection roll on the cross tube 7 Retaining sheet 16 Feed rocker arm 8 Feed strips 17 Spherical button for locking the tension lever 9 Wrapping material path of net or film 18 Tension lever Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 41: Function Description Cutting Unit
The single blade locking device prevents the blades from being damaged by foreign objects. The cutting unit can also be switched off mechanically. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 42: Technical Data
Size of round bales (width) 1,200 mm Net wrapping Net max. width 1,300 mm Net sleeve length 1,250-1,330 mm Net sleeve diameter ø 75-80 mm Net roll diameter ø max. 310 mm Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 43 This recommendation applies especially to the typical mixture of operation (field/road) at the maximum permitted machine speed. If required, the tyre pressure can be reduced to the indicated minimum air pressure. However, the associated maximum speed must then be observed. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 44: Oils
If oils, which have different specifications, are mixed with each other, the machine may be damaged. „ Never mix oils, which have different specifications, with each other. „ Contact your KRONE service partner before using an oil with a different specification after changing the oil. Biodegradable consumables can be used on request.
Page 45: Initial Operation
1 Protective cap 8 Mounting material 2 Universal shaft 9 Can of spray paint 3 Ring spanner 10 Warning foil 4 Terminal (depending on version) 11 Test roll KRONE excellent, net for net wrapping Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 46: Mounting Hose And Cable Support
(2) and discard. Checking/adapting the tyre pressure Before the initial operation, check and adjust the tyre pressure. A label at the PTO shaft end draws the attention to this important test: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 47: Adjusting The Drawbar Height
„ To ensure optimum operating conditions, hitch the machine so that the dimension X matches the aforementioned values. ð If the measured dimension differs from dimension X, adjust the drawbar height as follows. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 48 „ Align the drawbar eye (6) parallel to the ground. „ Ensure that the toothed disc connections (5) mesh. „ Tighten the screw connections (1) and (5). Torque, refer to page 192. „ After 10 operating hours tighten the screw connections (1) and (5). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 49: Universal Shaft
„ Switch off the engine and remove the ignition key and carry it with you. „ Secure machine and tractor against rolling away. „ Instructions on how to shorten the universal shaft (1) can be found in the operating instructions of the universal shaft manufacturer. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 50: Mounting Protective Cap Of Universal Shaft
„ Clamp the ends of the bolt (2) on both sides in the boreholes of the universal shaft chain which was removed beforehand. „ Mount the screw connection (3). Æ The universal shaft can be deposited with the bottom hitching of the drawbar on the universal shaft bracket (1), refer to page 164. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 51: Mounting The Universal Shaft On The Machine
To reduce the height of the machine for transport, a tensioning device can be mounted ex works on the tensioning arms of the machine. Before starting up the machine, remove the tensioning device from the right and left sides of the machine. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 52 „ Remove the screw connection (5) and the connecting pipe (6). „ Mount bolt (1) on both machine sides at an equal height. „ Dispose of all removed parts properly. Reuse is not permitted. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 53: Commissioning
(e.g. tractor tyres). „ Couple and connect the hoses and cables to the designated connections as described in the operating instructions. Connecting machine to tractor RP000-098 Example image Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 54: Mounting The Universal Shaft On The Tractor
„ In order to avoid damage to the machine, check universal shaft length every time the tractor is changed and correct it, if necessary, refer to page 49. ü The machine is shut down and safeguarded, refer to page 27. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 55: Connecting Hydraulic Hoses
If foreign objects or liquids get into the hydraulic system, the hydraulic system may be severely damaged. „ When connecting the quick couplings, ensure that they are clean and dry. „ Check the hydraulic hoses for abrasion and pinch point and replace if required. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 56: Connecting Hydraulic Brake (Export)
The brake is activated by actuating the brake pedal. ü The machine is shut down and safeguarded, refer to page 27. „ Connect the hydraulic hose of the hydraulic brake to the connection for the hydraulic brake on the tractor. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 57: Coupling The Hydraulic Auxiliary Brake
„ Then connect the supply line (2) (red coupling head). Disconnecting Observe the correct order when disconnecting the compressed air lines. „ Firstly, disconnect the supply line (2) (red coupling head). „ Then disconnect the brake line (1) (yellow coupling head). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 58: Adjusting Drawbar Eye
„ Rotate the drawbar eye into the desired position (I) or (II) and use the screw connection (2) to mount it on the drawbar (1). „ Ensure that the toothed disc connections mesh. Connecting the KRONE ALPHA operation unit For “medium electronics” version NOTICE Short circuit caused by impurities and moisture in the plug connection The machine may be damaged by a short circuit.
Page 59: Connecting Krone Terminal Ds 500
Commissioning Connecting KRONE terminal DS 500 ð The operation unit (1) is fixed to the support (4) by the magnetic plate (5). Connecting the operation unit (1) „ Connect the 12V power supply cable to the 3-pin socket on the tractor and machine.
Page 60 Commissioning Connecting KRONE terminal DS 500 Tractors with integrated ISOBUS system EQ003-251 ü The machine is shut down and safeguarded, refer to page 27. ü The machine is shut down and safeguarded, refer to chapter Safety “Shutting down and safeguarding the machine” in the operating instructions of the machine.
Page 61: Connecting Krone Beta Ii Terminal
ü The machine is shut down and safeguarded, refer to chapter Safety “Shutting down and safeguarding the machine” in the operating instructions of the machine. ü The accessories kit B290 “KRONE tractor retrofitting” is mounted. Connection terminal to tractor „ Connect the 9-pin plug (2) of the cable (1) to the 9-pin socket (3) (In-cab).
Page 62 ü The machine is shut down and safeguarded, see chapter Safety, "Shutting down and safeguarding the machine". ü The accessories kit B290 “KRONE tractor retrofitting” is mounted. Connection terminal to tractor „ Connect the 9-pin plug (1) of the terminal to the 9-pin socket (2) (In-cab).
Page 63: Connecting The Krone Isobus Terminal (Cci 800, Cci 1200)
Commissioning Connecting the KRONE ISOBUS terminal (CCI 800, CCI 1200) 7.11 Tractors with integrated ISOBUS system EQ003-120 ü The machine is shut down and safeguarded, refer to page 27. Connection terminal to tractor „ Connect the 9-pin plug (1) of the terminal to the 9-pin socket (2) (In-cab).
Page 64 Commissioning 7.11 Connecting the KRONE ISOBUS terminal (CCI 800, CCI 1200) Tractors with integrated ISOBUS system CCI 1200 CCI 800 EQ001-173 ü The machine is shut down and safeguarded, refer to page 27. Connection terminal to tractor „ Connect the 12-pin plug (2) of the cable (3) to the 12-pin socket (1) of the terminal.
Page 65: Connecting Foreign Isobus Terminal
ü The machine is shut down and safeguarded, refer to page 27. ü The accessories kit B290 “KRONE tractor retrofitting” is mounted. Connection terminal to tractor „ Connect the 12-pin plug (2) of the cable (3) to the 12-pin socket (1) of the terminal.
Page 66 „ Connect the 11-pole socket (4) of the cable (2) to the 11-pole socket (3) of the machine. Connection terminal to tractor INFORMATION For further details on terminal connection, observe operating instructions of ISOBUS terminal manufacturer. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 67: Connecting The Camera To The Krone Isobus Terminal Cci 800 Or Cci 1200
CCI 800 CCI 1200 EQ000-212 „ Insert the plug (4) on the camera (2) cable (3) into the connection C (1) of the KRONE ISOBUS terminal CCI 800 or CCI 1200 . „ To connect the plug (4) correctly, ensure that it is aligned with the marked points (5). 7.14...
Page 68: Mounting Safety Chain
ü The machine is shut down and safeguarded, refer to page 27. RP000-104 „ Mount the safety chain (1) on the machine. DV000-016 „ Install the safety chain (1) at a suitable position (for example: [I] or [II]) on the tractor. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 69: Operation
„ Press only round bales which do not exceed the set baling pressure and bale diameter. „ Observe the following information on the even filling of the bale chamber. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 70 This can be reduced by taking the following measures: „ Reduce the number of blades in the cutting unit or completely swivel out the blades, refer to page 84. „ Reduce the baling pressure, refer to page 169. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 71: Improving Bale Chamber Filling
„ To largely prevent short, brittle straw from falling out of the bale chamber when driving from one swath to the next swath, switch off the PTO shaft in the meantime. Driving speed KRONE recommends a driving speed of 5-12 km/h The driving speed during the work must be adapted to the following conditions: •...
Page 72: Mounting Additional Deflector Sheets In The Tailgate
If the finished round bales are still not falling out of the bale chamber following installation of the deflector sheets (1): „ Remove the slide sheets (3) from the right and left sides of the machine housing. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 73: Completing The Baling Process, Starting Tying Cycle And Ejecting Round Bales
„ Pull out the securing pin (4), extend the parking support (2) and secure the position using the securing pin (4). „ Turn the support jack (2) anti-clockwise firmly down onto the ground using the crank handle (1) until the drawbar is relieved. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 74 „ Guide the bolt (1) with handle to the right into the opening (6) and turn it by 90° to the left so that the locking pin (3) locks. „ Actuate the double-acting control unit (green, 5-) until the support jack (5) is firmly on the ground and the drawbar eye is relieved. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 75: Using The Stop Cock Of The Tailgate
The tailgate stop cock (1) is located on the left side of the machine near the tailgate. ü The machine is shut down and safeguarded, refer to page 27. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 76: Releasing/Applying The Parking Brake
„ Push in the key (1) and apply the parking brake (2) until the resistance has increased noticeably. Releasing the parking brake (2) „ Push in the key (1) and press parking brake (2) all the way down. Attaching safety cable of the parking brake RP000-399 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 77: Fitting Wheel Chocks
(1) upwards, and remove them. RPG000-180 „ Park the machine on level and firm ground. „ Place the wheel chocks (1) so close before and behind the same wheel that the machine cannot roll off. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 78: Removing/Mounting The Safety Device Which Prevents Unauthorised Use
The brake force regulator (1) regulates the brake force of the compressed air brake. The brake force may be reduced under certain conditions in use. When driving on public roads, the brake force regulator (1) must be set to full load (I). The following positions are possible: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 79: Operating The Bale Counter
„ To lower the pick-up into the working position, actuate the control unit on the tractor (yellow, 3+). Transport position „ To preselect the pick-up, press the key on the terminal, refer to page 119. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 80: Setting The Pick-Up Working Height
If ground conditions are extreme, the height of the pick-up can also be set via the chain (3). To do this, the pick-up can be set higher or lower by one complete chain link or even more precisely via the chain holder (1). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 81: Adjusting The Bearing Pressure Relief For The Pick-Up
To be able to negotiate uneven ground better, the pick-up is relieved on both sides of the machine with the aid of a spring (3). The spring (3) can be set on the ring screw (2). KRONE recommends the following setting: • Dimension X (left side of machine): 150 mm •...
Page 82: Setting The Crop Press Roller Unit
The height of the baffle sheet (1) on the crop press roller unit can be adjusted to the swath. Position (I) has been set at the factory. If the crops are very moist, it is recommended to move the baffle sheet into position (II). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 83: Removing/Mounting The Baffle Sheet On The Crop Press Roller Unit
Removing crop blockages: refer to page 95 RPG000-152 ü The machine is shut down and safeguarded, refer to page 27. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 84: Cutting Unit
ü The pick-up is fully raised in transport position, refer to page 79. ü The blade cassette has been lowered, refer to page 84. ü The machine is shut down and safeguarded, refer to page 27. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 85 „ After working on the blade cassette, mount the tool (1) in the storage compartment using the fastening screw. For "Tandem axle" version: RP000-478 RP000-146 The icons in the figure and on the label have the following meaning: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 86 NOTICE For version with "Hydraulic blade group control system" During operation of the machine, KRONE recommends occasionally swivelling the utilised blade groups in and out to prevent crop blockages. If individual blades did not swivel in The following steps must be performed if individual blades did not swivel in after the blade groups were mechanically or hydraulically swivelled in.
Page 87: Net Wrapping
INFORMATION For trouble-free use in the field, KRONE recommends one of the "KRONE excellent" nets, see label on the machine with the number 27 016 326 *. Comprima F 155 XC...
Page 88 „ Use a mounting lever (12) to push the net roll (9) in the required direction of the arrow until the net roll (9) is positioned in the centre. „ Push both adjusting rings (8, 11) each with a distance of 2-3 mm onto the sleeve (10) and fix them in this position. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 89: Insert Net
„ Place the net (7) under the deflection tube on the cross tube (9). To set the feed, cutting and tying position, refer to page 159. To set the number of net layers, refer to page 140. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 90: Net And Chamber Film Wrapping
INFORMATION For trouble-free use in the field, KRONE recommends one of the "KRONE excellent" nets or films, see label on the machine with the number 27 018 640 *. ü The machine is shut down and safeguarded, refer to page 27.
Page 91: Inserting The Net Or Film
„ Always wear protective gloves when inserting the wrapping and tying material and when working in the range of the cutting unit. „ When working in the range of the cutting unit, work particularly carefully and prudently. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 92 5 cm between the pressure shaft (2), covered with red foam, and the conical roller (1), refer to page 146. RP000-183 The feed plate (7), which is required to insert the wrapping material, is in the storage compartment on the right side. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 93: Notes On Operation
If possible, for initial operation, use a complete net roll first and tie the round bales with net. This way provides for previous removal of any sharp edges or paint residues. • KRONE recommends not to use chamber film wrapping for straw bales. There is a risk of condensation forming, resulting in mould. •...
Page 94: Checking The Tension Of The Inserted Film
Net and chamber film wrapping 8.16.4 Checking the tension of the inserted film The round bale must be tied with the appropriate film tension. KRONE recommends a pre- tension of 5-15%. You can check whether this pre-tension of 5-15% has been obtained as follows.
Page 95: Using The Bale Ejector
After the round bale has been laid down, the bale chamber is closed and whilst new crops are being taken in, the bale ejector must be positioned again on the axis. „ Have the setting of the bale ejector be checked by a KRONE service partner. 8.18 Removing crop blockages 8.18.1...
Page 96: Crop Blockage Under The Cutting Rotor
CAUTION! Risk of injury due to sharp parts! Always wear appropriate protective gloves when removing crop blockages. „ Manually remove the accumulated crops. When the crop blockage has been removed, put the cutting unit back into operation as follows: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 97: Crop Blockage In The Baling Element
The central chain lubrication system is located on the left side of the machine behind the front side hood. The rails with the dosing units (1) and (4) are located on the right and left sides of the machine. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 98 Pick-up drive Pick-up/auger conveyor Dosing units on left side of machine RP000-405 The dosing units on the rail on the left side of the machine oil the chains of the following machine components: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 99 Bale formation conveyor drive Roller drive feed roller Pick-up/auger conveyor Setting oil quantity „ Loosen the screws (6). „ Turn the eccentric cam (5) until the arrow is on the required oil quantity. „ Tighten the screws (6). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 100: Krone Alpha Operation Unit
Control of the actuators installed on the machine • Sensor/actuator diagnostics The operation unit (2) provides the driver with information and makes settings for the operation of the machine which are received and processed by the job computer. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 101: Overview
Increase set values Set tying version Set twine tying Select automatic mode Select manual mode Not assigned The warning light lights up: Blade cassette setting preselected Warning light does not light up: Pick-up preselected Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 102: Switching The Operation Unit On/Off
Start tying process (in manual mode) Switching on/off Switching the operation unit on/off „ To switch on the KRONE Alpha operation unit, press the key. Æ If the voltage supply is correct, a short self-test of the operation unit is performed: All warning lights light up briefly and an acoustic signal sounds.
Page 103: Setting The Net Layers
It subsequently starts at the end of the last tying cycle. „ Briefly after the operation unit has been switched on with the key, press the and hold down. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 104: Digital Sensor Test
LED is not lit No metal in front of the sensor LED flashes: Broken cable on the sensor The sensors are assigned to the LEDs of the bar graph display as follows: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 105: Analogue Sensor Test
Setting the feed and end position of the feed rocker arm In order to set the feed and end position of the feed rocker arm refer to page 171. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 106: Display Filling
„ To show the version number, press and hold the key. Æ The bargraph shows the current software version number. Bargraph LED Software version number LED A LED B LED C LED D LED E LED F LED G LED H Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 107: Krone Beta Ii Terminal
ISOBUS Shortcut Button not available EQG000-022 The KRONE Beta II terminal does not feature an ISOBUS shortcut button. Icon (1) is shown on the display. The ISOBUS shortcut button is not available to switch off machine functions. Comprima F 155 XC...
Page 108: Switching Terminal On/Off
„ For more details on how the terminal functions, follow the terminal operating instructions. INFORMATION When the terminal is switched on for the first time, the machine configuration is loaded into the terminal and saved in the terminal memory. Loading may take a few minutes. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 109: Design Of Display
Main window (3) There are the following main window views: • Road travel screen, refer to page 126 • Working screen/s, refer to page 125 • Menu level, refer to page 136 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 110: Touchable Display
ð If the machine is connected, the display shows the road travel screen after switching on. Æ The terminal is ready to operate. Switching off „ Press and hold down the key (1). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 111: Design Ds 500
Design DS 500 11.3 11.3 Design DS 500 EQG003-110 The KRONE machine application is divided into the following areas: Status line (1) The status line (1) indicates current states of the machine (depending on how it is equipped), refer to page 118.
Page 112 Reduce the value. • Navigate to the previous value in the menu. • Navigate to the previous menu. Press the scroll wheel: • Select the value. • Save the value. • Open the menu. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 113: Krone Isobus Terminal (Cci 800, Cci 1200)
KRONE machines, which have ISOBUS equipment, are coordinated with this system. EQG000-057 The electronic equipment of the machine consists essentially of the job computer (1), the terminal (2) and the control and function elements.
Page 114: Switching Terminal On/Off
KRONE ISOBUS terminal (CCI 800, CCI 1200) 12.2 Switching terminal on/off 12.2 Switching terminal on/off EQ001-174 KRONE ISOBUS terminal CCI 1200 KRONE ISOBUS terminal CCI 800 „ Before switching on the terminal for the first time, check that the connections are correct and tight.
Page 115: Design Of Display
„ For more details on how the terminal functions, follow the terminal operating instructions. 12.4 Design of the KRONE machine application EQG000-059 The KRONE machine application is divided into the following areas: Status line (1) The status line (1) indicates current states of the machine (depending on how it is equipped), refer to page 118.
Page 116: Setting Units On The Terminal
KRONE ISOBUS terminal (CCI 800, CCI 1200) 12.5 Setting units on the terminal Keys (2) The machine is operated by pressing the keys (2) via touch function, refer to page 119. Main window (3) Values (figures) shown in blue in the main window can be selected using the touch function.
Page 117: Foreign Isobus Terminal
KRONE ISOBUS terminal. Before commissioning, refer to the mode of operation of the KRONE ISOBUS terminal in the operating instructions. A major difference to the KRONE ISOBUS terminal is the arrangement and number of keys with functions determined by the selected external ISOBUS terminal.
Page 118: Terminal Machine Functions
„ Remedy the malfunction when the error message is displayed, refer to page 227. „ If the malfunction cannot be remedied, consult a KRONE service partner. 14.1 Status line INFORMATION Using a terminal with a resolution of less than 480x480 pixels.
Page 119: Keys
Switching chamber film ing the key. wrapping to manual mode Pre-select pick-up. The setting previously selected, pick-up or blade adjustment is displayed. Press the key to change the setting. Pre-select blade adjust- ment. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 120 Menu level on the terminal. Press the key to open the menu level on the terminal, refer to page 136. Counters Press the key to open Menu 13 "Counters", refer to page 147. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 121: Displays On The Working Screen
Flashing: 2 TIM functions are currently active, one TIM function of which has been overridden. The connection is restored by pressing the key and then confirming on the tractor. Direction display. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 122 • the positions of the blade cassette (4) • and the bale ejection by means of the opening tailgate (2). The blade cassette (4) can show the following positions: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 123 Net/chamber film wrapping is running. Net/chamber film wrapping has stopped. Net/film is cut off. Net/film was not cut off. Net/chamber film wrapping is complete. Net/film is pulled without a tying cycle having been actu- ated. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 124: Displays On The Information Bar
The direction display (1) shows the driver to which side and to what extent he must correct his direction when driving over the swath in order to ensure the bale chamber is filled evenly. The following displays are possible: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 125: Accessing The Working Screen
„ If the swath is too narrow, pick it up alternately (on left/right). Ensure that you do not move too far to the left or right 14.6 Accessing the working screen Road travel screen Example menu Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 126: Automatic Call Of The Road Travel Screen
The terminal switches automatically to the Road travel screen after roughly five minutes when the following requirements are met: ü The PTO shaft is switched off. ü The tailgate is closed. ü The machine is in field mode. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 127: Adjusting The Baling Pressure
B) or the complete set of blades (blade groups A and B) can be swivelled in and out from the tractor seat. The following functions of the blade group control system can be selected. The set function appears on the status line of the working screen. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 128 The maintenance position serves to swivel out the blades and to lower the blade cassette in one procedure. To enable better removal of the blades, the blades are then lifted up again slightly. „ On the terminal in the working screen, select Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 129: Operating Tim 1.0 (Tractor Implement Management)
To bale the next round bale, the driver only has to approach the tractor. Then the tractor driver must independently drive at a speed adjusted to visibility, weather or ground conditions. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 130: Tim Displays And Keys On The Working Screen
The connection is restored by pressing the key and then confirming on the tractor. The keys can be used to operate the following functions. If the key is greyed out, the function is not available. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 131: Activating Tim Functions
„ To restore the connection, press the key 14.10.4 Pausing TIM functions If TIM is not to be used for the time being, TIM can be paused. In doing so, registration and authentication are retained between tractor and machine. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 132: Operating Machine Via Joystick
Auxiliary assignment of a joystick INFORMATION The examples below represent a recommendation. The assignment of the joystick can be adapted to own desires. For further information, please refer to the operating instructions of the used terminal. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 133 Recommended configuration of a WTK joystick EQG003-040 The keys on the WTK joystick can be assigned on 2 levels. „ Change between the levels using the switch (2). Æ The LED (1) is lit green or red. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 134: Terminal Menus
(for version with "Net wrapping and chamber film wrap- ping"), refer to page 144 Manual operation, refer to page 145 Counter, refer to page 147 13-1 Customer counter, refer to page 148 ∑ 13-2 Total counter, refer to page 150 ∑ Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 135: Recurring Icons
Move left to select something. Disk Save the setting. Leave the menu without saving. By pressing the key a little longer, the pre- viously viewed working screen is selected. Reset to factory setting. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 136: Selecting A Menu Level
„ To select a menu, press the keys next to until the desired menu is selected. ð The selected menu is highlighted in colour. „ To call up the menu, press the key next to Æ The menu opens. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 137: Changing Value
If a numeric value is tipped, an input mask opens. For further information on entering values in the input mask, refer to the enclosed operating instructions of the terminal. Examples: By means of the scroll wheel „ Choose the desired value by using the scroll wheel. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 138: Changing Mode
Æ An acoustic signal sounds, the set mode is saved and the icon is briefly displayed in the upper line. „ To leave the menu, press 15.7 Tying in the menu level ü For The menu level is active, refer to page 136. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 139 Tying start delay net wrapping (if ‘net’ has been selected as the type of tying under (3)) Tying start delay chamber film wrapping (if ‘film’ has been selected as the type of tying under (3)) Select type of tying (net or film) Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 140: Menu 1 "Number Of Net Layers" (Net Wrapping)
ü Chamber film wrapping is selected in menu 8 “Type of tying”, refer to page 144. „ To open the menu, press Æ The display shows menu "Number of film layers". Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 141: Menu 3 "Advance Signalling
„ To save the value, press INFORMATION KRONE recommends 3.5 – 4 film layers for optimum chamber film wrapping. The minimum required film layers depend on the condition of the crops. With round bales whose diameter measures more than 130 cm and/or very dry or very wet crops, KRONE recommends at least one additional film layer.
Page 142: Menu 4 "Tying Start Delay" (Chamber Film Wrapping)
ü Chamber film wrapping is selected in menu 8 “Type of tying”, refer to page 144. „ To open the menu, press Æ The display shows menu “Tying start delay”. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 143: Menu 5 "Bale Diameter
Menu 5 “Bale diameter” 15.13 Special feature of chamber film wrapping The tying start delay is automatically set to 0.0 s for chamber film wrapping. KRONE recommends this setting. At high driving speeds, the tying start delay can be set to a minimum for chamber film wrapping: „...
Page 144: Menu 8 "Type Of Tying" (For The "Net And Chamber Film Wrapping" Version)
„ To open the menu, press Æ The display shows menu “Type of tying”. Changing mode „ Call up and save mode, refer to page 138. The following modes can be selected: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 145: Menu 10 "Manual Operation" (For The "Net Wrapping" Version)
The keys on the sides can be used to control the following functions: Icon Explanation Move actuator for wrapping process to feed position Move actuator for wrapping process into cutting position Move actuator for wrapping process into tying position Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 146: Menu 10 "Manual Operation" (For The "Net And Chamber Film Wrapping" Version)
The keys on the sides of the terminal can be used to control the following functions: Icon Explanation Move tying actuator (net/film) to feed position Move tying actuator (net/film) to cutting position Move tying actuator (net/film) to tying position Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 147: Menu 13 "Counters
Æ The display shows the "Counter" menu. The "Counter" menu is divided into the following submenus: Menu Sub-menu Designation Counter, refer to page 147 13-1 Customer counter, refer to page 148 ∑ 13-2 Total counter, refer to page 150 ∑ Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 148: Menu 13-1 "Customer Counter
„ To open the detailed view of a customer, navigate to the required customer and press Detailed view of a customer 13-1 ∑ NAME 03 EQG003-106 The icons displayed in the menu have the following meaning: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 149 „ To increase the number of bales, press „ To reduce the number of bales, press Setting customer counters to zero „ To set the customer counter to zero, hold down for at least 2 seconds. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 150: Menu 13-2 "Total Counter
Set season counter 2 to zero Setting season counter 1 or 2 to zero „ To set season counter 1 to zero, press „ To set season counter 2 to zero, press Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 151: Menu 14 "Isobus
14-5 Brand: Model: Function Instance: EQG003-015 ü The menu 14 “ISOBUS” has been selected, refer to page 151. „ Select to open the menu. Æ The display shows the "Configuring TIM Software" menu. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 152 „ To start establishing a connection between tractor and machine, press Æ Registration and authentication of the TIM functions are started. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 153: Menu 14-9 "Switching Between Terminals
(e.g. because it was dismounted), the restart is delayed as the system searches for a new terminal and loads the specific menus into the terminal. The loading process can take a few minutes. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 154: Menu 15 "Settings
The "Settings" menu is divided into the following submenus: Menu Sub-menu Designation Settings, refer to page 154 15-1 Sensor test, refer to page 155 15-2 Actuator test, refer to page 159 15-3 Software information, refer to page 162 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 155: Menu 15-1 "Sensor Test
Then check whether the bar is in unattenuated state in the lower marked area. Possible sensors (depending on the machine configuration) An overview of the sensors, actuators and control units is in the circuit diagram. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 156 Possible status displays of the sensors Icon Designation Sensor ready for operation Sensor attenuated (metal in front of the sensor) Sensor unattenuated (no metal in front of the sensor) Cable break or short circuit Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 157: 15.20.1.1 Adjusting Sensor B08 "Top Blade Cassette
ü The blade cassette (2) is flush with the cutting unit housing (1). „ Remove contamination in the area of the blade cassette (2) and the cutting unit housing (1). „ Adjust sensor B08 “Blade cassette up” (3) in menu 15-1 “Sensor test”, refer to page 155. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 158: 15.20.1.2 Adjusting Sensor B09/B10 "Filling Display Left/Right
„ Tighten the screw connections on the sensor. „ Press Æ The set position is saved. INFORMATION Saving is only possible if the bar (2) is inside the rectangle (1) of the bargraph. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 159: Adjusting Sensor B61 "Tying 1 (Passive)
ð A warning opens which refers to the operating instructions. „ Observe the safety routine "Run actuator test", refer to page 28. „ Confirm with Æ The display shows the "Actuator test" menu. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 160 Lowering the feed rocker arm Lifting the feed rocker arm Possible status displays of the actuators Icon Designation Actuator ON Actuator OFF General actuator error No supply voltage Possible cause: Fuse defective. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 161 The actuator for wrapping process M01 can be tested by moving it into the feed or cutting position. „ To move the actuator for wrapping process into the feed position, press „ To move the actuator for wrapping process into the cutting position, press Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 162: Menu 15-3 "Software Info
ü Menu 15 “Settings” is called, refer to page 154. „ To open the menu, press Æ The display shows the "Software info" menu. Display area Icon Designation Total software version of the machine Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 163: Driving And Transport
If the brake force controller has been incorrectly set, there is a risk of accidents. „ When driving on public roads, ensure that full load (1/1) is set on the brake force regulator. „ When working for example on wet fields, deceleration may be reduced. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 164: Preparing The Machine For Road Travel
Securing the universal shaft If the universal shaft is not connected to the tractor, it must be secured on the drawbar with the universal shaft retaining chain or with the universal shaft bracket. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 165: Checking Road Travel Lighting
Checking road travel lighting RPG000-073 „ Connecting road travel lighting to the vehicle electrical system, refer to page 67. „ Check whether the rear lamps (1) are functional. „ Clean the rear lamps (1) and the side reflectors (2). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 166: Preparing The Machine For Shipment
„ Open the side hood (1). „ Guide a cable tie (2) through the openings of the flap lock (3). „ Carefully close the side hood (1). „ Lay the cable tie (2) around the lock holder (4) and tighten it. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 167: Securing The Storage Compartment Flap
„ Mount connecting pipe (6) with the screw connection (5). „ Mount slip-on bushing (4) with screw connection (3). „ Tighten the screw (2) equally on both sides of the machine until the tensioning arms are released. „ Mount the bolt (1). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 168: Lifting The Machine
„ Ensure that the chain hooks have been correctly attached to the suspension points. „ Tension the chains so that the support jack is relieved. „ Move the support jack into transport position, refer to page 73. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 169: Settings
„ Lift the black baling pressure indicator (1) to the desired position. „ Loosen the wing nut (3) and move the screw with wing nut (3) until the KRONE Alpha operation unit warning lights are lit and the horn sounds, refer to page 106.
Page 170: Setting The Bale Diameter
1 Blade group A 2 Blade group B The cutting length is determined by the number of blades used. The blade groups A and B are swivelled in or out for this purpose. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 171: Checking And Setting The Position Of The Feed Rocker Arm
„ To move the feed rocker arm in the direction of the end position, press „ Press Æ The set position is saved. The left indicator lamp of the filling lights up. In addition, the set value can also be read off the bargraph. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 172: Checking And Adjusting The Feed Position
„ To move the feed rocker arm in the direction of the end position, press „ Press Æ The set position is saved. 17.4.1 Checking and adjusting the feed position RP000-029 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 173: Checking And Setting End Position For Chamber Film Wrapping
„ Switch off the tractor, remove the ignition key and take it with you. „ Check whether the conical roller (3) is positioned on the insulation of the pressure shaft (2) and whether the film jams between the insulation of the pressing shaft (2) and the conical roller (3). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 174: Checking And Setting End Position For Net Wrapping
If the dimension Y is not Y=410 mm, set and save the end position again as follows: „ Start the tractor. „ Move the feed rocker arm in the direction of the end position until the dimension is Y=410 mm. „ Save the new position. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 175: Setting Wrapping Material Overhang
260 mm. RP000-878 Net wrapping: Dimension preset by KRONE Z=365 mm Chamber film wrapping: Dimension preset by KRONE Z=370-375 mm If the wrapping material overhang (1) is not X=170–200 mm or Y=230–260 mm, the wire rope (5) must be adjusted as follows. The greater the dimension Z of the wire rope (5), the greater the wrapping material overhang (1).
Page 176: Setting Wrapping Material Brake
If the net was wrapped around the round bale too loosely or too tightly, the brake force can be set with the nut (4) on the eyelet bolt (3). Default dimension set by KRONE: X=40 mm ü The machine is shut down and safeguarded, refer to page 27.
Page 177: Setting The Brake Force Release When Feeding Wrapping Material
Setting the brake force release when feeding wrapping material 17.7 If "KRONE excellent" net or film is not used for the tying, the brake force may have to be adjusted at the eyelet bolt (3). ü The machine is shut down and safeguarded, refer to page 27.
Page 178: Checking And Setting The Axial Play Of The Brake Disc At The Wrapping Material Brake
„ Use shim rings to set the required axial play X. „ Mount the adjusting collar (1) and tighten the threaded pin (2). „ Push the brake disc (4) onto the roll holder (3) and swivel it back into the machine. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 179: Locking/Releasing The Tension Lever
„ To release the locking pin with ball head (3), turn the ball head anti-clockwise and pull the bolt in the direction of the arrow until the roll pin (4) moves through the slot and the bolt has engaged. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 180: Setting The Lock Of The Tapered Roller
„ To lock the conical roller (1) for net wrapping, pull the locking bar (2) and turn it anti- clockwise until it engages in position (I). „ To release the conical roller (1) for chamber film wrapping, pull the locking bar (2) and turn it clockwise until it engages in position (II). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 181: Checking The Retaining Comb For Net Wrapping
Make the following check on the right and left sides of the machine in the same way: „ Check whether the dimension X on the spring (2) is X=15 mm. „ If the dimension is not X=15 mm, set the dimension on the nut (3). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 182: Checking The Retaining Comb For Chamber Film Wrapping
Make the following check on the right and left sides of the machine in the same way: „ Check whether the dimension X on the spring is X=5 mm. „ If the dimension is not X=5 mm, set the dimension on the nut (3). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 183: Setting The Retaining Comb For Chamber Film Wrapping
Position II If the blue strips (1) are taken along by the first net feed roller with a delay or are not taken along, you can reverse the trapezoidal rubbers (4). This provides additional support. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 184: Setting The Working Lights
The working lights are turned on and off using the keys and the terminal, refer to page 119. RPG000-101 „ Turn the light (1) so that the desired area is illuminated. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 185: Maintenance
Chain lubrication unit refer to page 216 Components Adjust drive chains refer to page 209 Tighten screws/nuts on the machine refer to page 192 Retightening wheel nuts refer to page 196 Check tyre pressure refer to page 196 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 186: Maintenance - After The Season
Touch up damaged paint and preserve un- coated areas with rust protection agent Check that all moveable components move freely. If required, dismount, clean, grease and remount. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 187: Maintenance - Once After 10 Hours
Have the slack adjuster of the brake system checked by KRONE service partners Check the hydraulic hoses for leaks and, if ne- refer to page 198 cessary, have them replaced by a KRONE service partner. Cleaning bushing and drawbar eye refer to page 200 Change/replace blades refer to page 205...
Page 188: Maintenance - Every 50 Hours
The information on maintenance intervals is based on average load of the machine. In case of an increased load and under extreme working conditions, the time periods must be reduced. The types of lubrication are marked by means of icons in the lubrication chart, refer to table. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 189 „ Remove old lubricating Lubricating Multi-purpose grease grease. „ Apply a coat of new lubricating grease thinly with a brush. „ Remove excessive lubricating grease. Left side of machine RPG000-029 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 190 Maintenance 18.2 Lubrication chart Every 20 operating hours Every 50 operating hours Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 191 Maintenance Lubrication chart 18.2 Right and rear side of machine RPG000-030 Every 20 operating hours Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 192: Lubricating The Universal Shaft
50 hours 30 g 20 g 18.4 Tightening torques Deviating tightening torques All screw connections must in general be tightened with the listed tightening torques following. Deviations from the tables are marked accordingly. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 193 The table does not apply to countersunk screws with hexagon socket in case the countersunk screw is tightened via hexagon socket. DV000-001 Thread size Strength class on screw head Strength class 10.9 12.9 Tightening torque (Nm) 1,050 1,220 1,100 1,550 1,800 1,450 2,100 2,450 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 194 Metric thread screws with countersunk head and hexagon socket INFORMATION The table applies only to countersunk screws with hexagon socket and metric thread tightened via hexagon socket. DV000-000 Thread size Strength class on screw head Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 195 Ventilation/breather filter made of brass steel Steel and cast Aluminium Steel and cast Aluminium Maximum tightening torque (Nm) (±10%) M10x1 M12x1.5 G1/4“ M14x1.5 M16x1.5 M18x1.5 M20x1.5 G1/2“ M22x1.5 M24x1.5 G3/4“ M33x2 G1“ M42x1.5 G1 1/4“ Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 196: Checking/Maintaining Tyres
Inspect the tyres visually „ Visually inspect tyres for cuts or breaks. Æ If there are cuts or breaks in the tyres, have the tyres repaired or replaced by a KRONE service partner. Maintenance intervals for visual inspection of the tyres, refer to page 185.
Page 197: Servicing The Main Gearbox
„ Pour in fresh oil via the inspection and filling hole (3) up to the inspection and filling hole (3). „ Screw the locking screw into the inspection and filling hole (3), tightening torque refer to page 195. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 198: Checking Hydraulic Hoses
„ If required, repeat the cleaning several times a day. 18.9 Cleaning deflection pipes or conical tying roller The maintenance intervals can be found in the maintenance table, refer to page 185. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 199 Cleaning deflection pipes or conical tying roller 18.9 For version with "Net wrapping" RP000-467 „ Remove any corrosion from all fixed deflection pipes (1) and from the brake surface of the brake disc (2) in the tying unit. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 200: Clean The Bushing And The Drawbar Eye
(1) in the drawbar eye (2) is X=43 mm. If the dimension X is exceeded, the drawbar eye (1) must be replaced by a KRONE service partner. „ To minimize wear, clean the bushing (1) and the drawbar eye (2) several times a day and coat with grease.
Page 201: Cleaning Drive Chains
„ Tighten the screw connections (1) on the drawbar to the tightening torque 210 Nm. „ Tighten the screw connections (2) on the drawbar eye to the tightening torque 730 Nm. Maintenance interval, refer to page 185. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 202: Setting The Scraper And Stone Deflector
To set the scraper rail (1), loosen the scraper reinforcers (3): „ Loosen the screw connections (2). Æ The scraper reinforcers (3) can be moved in the oblong hole. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 203 Setting and tightening the scraper reinforcer For the "Net and chamber film wrapping" version RP000-302 „ Place the scraper reinforcer (3) on the spiral roller (4). „ Tighten the screw connections (2), tightening torque, refer to page 192. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 204: Adjusting The Scraper On The Deflection Shafts
„ Adjust the scraper on the deflection rolls (1) so that the distance between deflection roll (1) and scraper is 0-0.5 mm. 18.14.4 Setting the stone deflectors All stone deflectors on the deflection shafts must be regularly checked and adjusted. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 205: Releasing The Cam Clutch On The Universal Shaft
„ For version with "Hydraulic blade group control system": Move the blade cassette hydraulically via the terminal into the maintenance position, refer to page 127. „ Unlock the blade retaining shaft, refer to page 206. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 206: Unlocking/Locking Blade Retaining Shaft
If work has to be carried out on the blades of the cutting unit, the blade retaining shaft must be unlocked beforehand. After work, the blade retaining shaft must be locked again. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 207: Checking And Moving The Blade Retaining Shaft
Checking and moving the blade retaining shaft Checking the blade retaining shaft RPG000-160 The area around the groove (1), in which the blades (2) on the blade retaining shaft (3) are located, wears during use. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 208: Grinding The Blades
INFORMATION KRONE recommend the KRONE blade grinding machine for grinding the blades. Contact your KRONE dealer. For further information, please refer to the operating instructions of the blade grinding machine. Correctly ground, sharp blades reduce fuel consumption and the wear on the cutting components.
Page 209: Checking/Lubricating The Safety Rolls Of The Single Blade Locking Device
„ When working on the drive chains, wear protective equipment, refer to page 20. „ Before working on any drive chains, shut down and safeguard the machine, refer to page 27. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 210: Drive Chain Of The Pick-Up
The drive chain is supplied with oil via the central chain lubrication system, refer to page 97. Spring discs of the pick-up drive RP000-472 „ After repairing the pick-up drive (1), ensure that the disc springs (2) are arranged as shown. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 211: Drive Chain Of The Intake
ü The machine is shut down and safeguarded, refer to page 27. ü The left side hood is open. „ To tension the drive chain (1), use the nut on the eyelet bolt (5) to set the dimension =220 mm. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 212: Drive Chain Of The Auger Conveyor
ü The drive chain (2) and the pick-up guard have been cleaned. „ To tension the drive chain (2), use the nut (4) to set the dimension X=60 mm. INFORMATION The drive chain is supplied with oil via the central chain lubrication system, refer to page 97. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 213: Drive Chain Of The Starter Roller And The Lower Compression Roller
RPG000-090 The dimension X=440 mm has been set at the factory and must not be changed. „ Check whether the dimension X=440 mm. „ If the dimension is not X=440 mm, contact the KRONE service partner. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 214: Setting The Baling Pressure Indicators
2 mm to the holder (4). The wire rope (3) must be tensioned slightly. „ Set the wire rope (3) on the screw connection (2) so that it is tensioned slightly and the baling pressure indicators (1.2) are a distance of approx. 2 mm from the holder (4). Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 215: Checking And Setting The Axial Play Of The Brake Disc At The Wrapping Material Brake
Setting the electronics RP000-553 If the filling in the KRONE Alpha operation unit (8) is no longer displayed correctly on the warning lights (7) the baling pressure indicators (1) must be set as follows. „ Lift the baling pressure indicators (1) up to the red label (2) and hold in this position.
Page 216: Servicing Chain Lubrication Unit
Checking oil level and topping up oil „ Read off the oil level on the reservoir (3). „ If the oil level is too low, top up the oil via the opening (4), refer to page 44. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 217: Cleaning The Dosing Units
„ Clean all components with a suitable cleaning agent. In particular, clean the area (4) which is presumably the dirtiest. „ Ensure that the rubber seals (7) are not cleaned with a strong cleaning agent. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 218: Replacing The Hose On The Dosing Unit
„ Insert the new end of the hose (4). Ensure that the hose (4) has been completely inserted into the cap nut (1). 18.26 Servicing compressed air brake (for version with "Compressed air brake") 18.26.1 Cleaning air filter RP000-436 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 219: Drain Condensation Water From The Compressed Air Tank
Damaged or corroded compressed air reservoirs may burst and cause serious injuries. „ Observe the inspection intervals according to maintenance table, refer to page 185. „ Have damaged or corroded compressed air reservoirs replaced immediately by a specialist workshop. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 220: Retighten Tensioning Straps At The Compressed Air Tank
„ Visually inspect the drain valve (2) to ensure that it is not defective or soiled. Æ If the drain valve (2) is defective and is no longer sealed, immediately have the drain valve (2) replaced by a KRONE service partner. Æ If the drain valve (2) is soiled, clean the drain valve (2).
Page 221: Solenoid Valves
When the Comfort electronics are working properly again: „ Unscrew the knurled head screws (4). The pick-up and the blade cassette can be oeprated via the terminal. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 222: Malfunction, Cause And Remedy
KRONE service partner, refer to page 47. to the tractor. The crop press roller unit has „ Set the crop press roller unit higher, refer to page 81. been set too low. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 223: Disturbances During Or After The Baling Process
Possible cause Remedy The machine is hooked in too „ Check the setting of the drawbar. low at the front. „ If required, have the drawbar height adjusted by the KRONE service partner, refer to page 47. 19.2 Disturbances during or after the baling process Malfunction: The bale formation conveyor is rotating slower than it should.
Page 224 The wrapping material is torn. „ Use only wrapping material of the designated quality. KRONE recommends one of the "KRONE excellent" products, see label on the machine with the number 27 016 326 *. Malfunction: The round bale is barrel-shaped. This causes the wrapping material to tear open in the middle.
Page 225: Disturbances At The Tying Unit Or During The Tying Cycle
„ Remove sharp edges from along the path of the wrapping which damage the wrapping material. material. „ If the malfunction persists, contact the KRONE service partner. Malfunction: The wrapping material (net or film) does not, or not completely, cover one or both of the outer edges.
Page 226: Malfunctions On The Chain Lubrication Unit
Malfunction: The oil pump is not pressed for the complete stroke. Possible cause Remedy The dosing units are blocked. „ Cleaning the dosing units, refer to page 217. The oil is too thick. „ Use recommended oil, refer to page 44. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 227: Faults Of The Electrics/Electronics
„ Remedy the malfunction when the error message is displayed, refer to page 229. „ If the malfunction cannot be remedied, contact KRONE Customer Service. KMC - 521202- 5 EQG000-034 The display shows an error message if a malfunction occurs on the machine. At the same time, an audio signal will be heard (continuous horn sound).
Page 228: Possible Error Types (Fmi)
The lower limit value has been reached. The lower limit value has not been reached. There is a CAN communication failure. The data deviates upwards. The data deviates downwards. The condition has been fulfilled. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 229: Overview Of Fuses
„ If a sensor is defective, run a sensor test to identify the sensor status, refer to page 155. The more information the dealer has, the easier it is to eliminate the cause of the error. 19.5.4 Error list General aspects on error causes Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 230 FMI 19: There is a CAN communication malfunction. The wiring is faulty. „ Check wiring for damage, refer to page 229. The operating terminal is de- „ Note the error number with the FMI and contact the KRONE fective. service partner. 520193- CAN2 CAN2...
Page 231 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521100- Voltage group (UB1) of the KRONE Machine Controller (KMC) Possible cause Remedy FMI 4: An undervoltage or a short circuit to ground has occurred.
Page 232 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521101- Voltage group (UB2) of the KRONE Machine Controller (KMC) High...
Page 233 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521101- Voltage group (UB2) of the KRONE Machine Controller (KMC) Possible cause Remedy FMI 6: There is a short circuit to ground or current intensity is too low.
Page 234 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521102- Voltage group (UB3) of the KRONE Machine Controller (KMC) High...
Page 235 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521103- Voltage group (UB4) of the KRONE Machine Controller (KMC) Possible cause Remedy FMI 4: An undervoltage or a short circuit to ground has occurred.
Page 236 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521104- Voltage group (UB5) of the KRONE Machine Controller (KMC) High...
Page 237 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521104- Voltage group (UB5) of the KRONE Machine Controller (KMC) Possible cause Remedy FMI 6: There is a short circuit to ground or current intensity is too low.
Page 238 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521105- Voltage group (UB6) of the KRONE Machine Controller (KMC) High...
Page 239 „ Replace the control unit KMC. The control unit KMC is de- fective. „ Note the error number with the FMI and contact the KRONE service partner. 521107- Supply voltage for the KRONE Machine Controller (KMC) at connection UE...
Page 240 Possible cause Remedy FMI 4: An undervoltage or a short circuit to ground has occurred. There is a cable break or „ Note the error number with the FMI and contact the KRONE short circuit. service partner. 521112- The voltage group (UB5) has not passed the self-test.
Page 241 Voltage group (UB2) switched off. Possible cause Remedy FMI 11: The error cause is unknown. The supply voltage of the „ Note the error number with the FMI and contact the KRONE sensors could not be activ- service partner. ated. 522005-...
Page 242 „ Check the sensor B61 "Tying 1 (passive)" and set the feed not yet in the feed position. position, refer to page 171. „ Check the rotational speed. It must not be higher than 540 The rotational speed is too high. rpm. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 243 „ Check the spring tension of the retaining comb, refer to ing comb are not correctly fed. page 182. „ Check the feed strips for damage. If required, have new blue strips ordered and mounted by the KRONE service partner. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 244 „ Check whether the cutting unit is engaged/clamped during gaged. the feed process. The cutting unit has been set too deep. „ Check the rotational speed. It must not be higher than 540 The rotational speed is too high. rpm. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 245 „ Set a higher rotational speed via the tractor on the PTO The PTO shaft is rotating too slowly. shaft. The sensor B01 "Speed of „ Check and set the sensor. bale chamber" is defective or has been incorrectly set. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 246 FMI 7: The net is not, or not cleanly, cut. The cutting unit is blunt. „ Remove deposits from the cutting unit. „ If required, have the cutting unit replaced by a KRONE service partner. „ Remove deposits from the cutting unit.
Page 247 • Sensor B11 Lock hook bale chamber left • Sensor B12 Lock hook bale chamber right There is a mechanical fault at „ Contact the KRONE service partner. one of the sensors. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 248 The bale chamber is overfilled „ Manually empty the bale chamber. so that it was opened by the bale. The tailgate is not correctly „ Open and close the tailgate again. locked. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 249 FMI 4: An undervoltage or a short circuit to ground has occurred. FMI 5: A cable break has occurred or the current intensity is too weak. „ Check sensor and wiring for damage, The sensor shows external refer to page 229. damage. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 250 FMI 5: A cable break has occurred or the current intensity is too weak. „ Check sensor and wiring for damage, The sensor shows external refer to page 229. damage. The wiring of the sensor is de- fective. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 251 FMI 5: A cable break has occurred or the current intensity is too weak. „ Check sensor and wiring for damage, The sensor shows external refer to page 229. damage. The wiring of the sensor is de- fective. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 252 FMI 5: A cable break has occurred or the current intensity is too weak. FMI 6: There is a short circuit to ground or current intensity is too low. „ Check actuator and wiring for damage, The actuator is damaged ex- refer to page 229 ternally. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 253 FMI 6: There is a short circuit to ground or current intensity is too low. The actuator is damaged ex- „ Check actuator and wiring for damage, refer to page 229 ternally. The wiring of the actuator is faulty. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 254 Possible cause Remedy FMI 31: The condition has been fulfilled. „ Check the wiring. The wiring is faulty. „ Note the error number with the FMI and contact the KRONE The control unit is defective. service partner. 522531- KMB1 Possible cause Remedy FMI 19: There is a CAN communication malfunction.
Page 255: Setting The Tailgate Lock
FMI 31: The condition has been fulfilled. The wiring is faulty. „ Check wiring for damage, refer to page 229. The control unit is defective. „ Note the error number with the FMI and contact the KRONE service partner. 522533- KMB2 Possible cause Remedy FMI 19: There is a CAN communication malfunction.
Page 256 „ To set the baling pressure indicators, release the screw connection (2) on the rope pulley (1) and push in the oblong hole so that the wire rope (3) is tensioned. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 257: Repairs, Maintenance And Settings By Technicians
„ Only a machine with an intact brake system may be used for work in the field or for travelling on roads. „ Changes to the brake system must not be made without the approval of KRONE. „ KRONE does not accept any warranty claims for natural wear, defects caused by overload or changes made to the brake system.
Page 258: Checking The Pad Thickness Of The Brake Shoes
Checking the pad thickness of the brake shoes The pad thickness of the brake shoes must be at least 2 mm thick. If the pad thickness is less than 2 mm, the brake pads must be replaced by a KRONE service partner.
Page 259: Setting Mechanical Slack Adjuster On The Single Axle
Æ The unbraked wheels must be able to rotate freely without grinding noises. 20.1.4 Setting mechanical slack adjuster on the single axle Due to the naturally occurring wear of brake drums and brake pads, the brakes must be regularly checked and adjusted. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 260: Setting Transmission Linkage And Brake Lever On The Tandem Axle
Brake actuation has been set in the factory. An adjustment is required if • the braking effect decreases (e.g. due to the brake shoes wearing) and/or • the actuating stroke of the brake cylinder W is not within the range of W=25±5 mm. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 261 „ Turn the respective brake linkage (3.1) or (3.2) so that the respective brake linkage (3.1, 3.2) is extended. „ Always ensure to change the length of both brake linkages (3.1, 3.2). The brake linkages (3.1, 3.2) may have to be extended to a varying degree. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 262 „ Ensure that the brake levers are moved the same on both sides. „ Mount the retaining ring (3). „ Mount the brake linkage (3.1, 3.2). „ After moving the brake levers (1.1, 1.2), reset the brake linkages, refer to page 261. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 263: Car Jack Contact Points
1 Car jack contact point at rear left 2 Car jack contact point at rear right Example image of a tandem axle: RP000-869 1 Car jack contact point at rear left 2 Car jack contact point at rear right Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 264: Waste Disposal
All synthetic materials must be brought to a recycling centre for synthetic materials. Rubber • Rubber parts (hoses, tyres, …) must be brought to a rubber recycling centre. Electronic scrap • All electronic parts must be brought to a disposal point for electronic scrap. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 265: Appendix
Blade group A (for the “Hydraulic blade group control system” version) – Tailgate on the bale chamber – Hydraulic support jack Documents about this 2 150102161_00 Comprima F XC (Resources/pdf/3071085707.pdf) Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 266: Index
........102 Analogue sensor test........105 Appendix ............265 Applicable documents .......... 9 Automatic call of the Road travel screen ..126 Auxiliary assignment of a joystick..... 132 Auxiliary functions (AUX)........132 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 267 Checking oil level, topping up oil and changing terminal CCI 800 or CCI 1200 ......67 filter..............216 Connecting the KRONE ALPHA operation unit .. 58 Checking road travel lighting ......165 Connecting the KRONE ISOBUS terminal Checking the bale formation conveyor tension 213 (CCI 800, CCI 1200)...........
Page 268 Data memory ............37 Declaration of conformity........277 Design DS 500 ..........111 Design of display ........109, 115 Design of the KRONE machine application..115 Diagnostics for digital actuators ....... 161 Digital sensor test ..........104 Direction display ..........124 Direction display sensitivity (terminal) ....
Page 269 Keeping universal shaft guard functional ... 20 Function description cutting unit ......41 Keys ..............119 Function description net and chamber film KRONE ALPHA operation unit ......100 wrapping ............. 40 KRONE Beta II terminal ........107 Function description net wrapping...... 39 KRONE ISOBUS terminal (CCI 800, CCI 1200)
Page 270 Tailgate does not close ......223 Wrapping material does not, or not completely, cover one or both of the outer edges ............. 225 Wrapping material not cut cleanly ..225 Wrapping material not transported ..225 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 271 Metric thread screws with fine thread ....194 Number of net layers (net wrapping, terminal) . 140 Mode of operation of TIM 1.0 ......129 Mounting............. 78 Mounting additional deflector sheets in the tailgate ................72 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 272 Overload protections on the machine....38 Preparing the machine for shipment ....166 Overview ............101 Pre-signalling (terminal) ........141 Overview of fuses ..........229 Protecting brake disc of the wrapping material brake from corrosion ........201 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 273 ..............259 Setting the automatic blocking time....103 Setting the baffle sheet on the crop press roller unit ................82 Setting the bale diameter ......... 170 Setting the baling pressure....... 169 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 274 Switching terminal on/off ....108, 110, 114 Switching the operation unit on/off ....102 Keys on the working screen ....130 Swivelling blade groups in/out ......84 Mode of operation ........129 Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 275 Unsuitable consumables ........22 Using the bale ejector......... 95 Using the stop cock of the tailgate ..... 75 Validity ..............9 Varying functions to KRONE ISOBUS terminal 117 Warning signs............. 11 Warnings of property damage/environmental damage .............. 12 Waste disposal ..........264 Working at or on heights of the machine ....
Page 276 This page has been left blank deliberately. Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 277: Declaration Of Conformity
EU Directive 2014/30/EU (EMC) The harmonised standard EN ISO 14982:2009 has been applied in accordance with the directive. The signing Managing Director is authorised to compile the technical documents. Dr.-Ing. Josef Horstmann Spelle, 01/08/2017 (Managing Director, Design & Development) Year of manufacture: Machine no.: Comprima F 155 XC Original Operating Instructions 150001050_01_en...
Page 278 Maschinenfabrik Bernard Krone GmbH & Co. KG * Heinrich-Krone-Straße 10 D-48480 Spelle * Postfach 11 63 D-48478 Spelle ' +49 (0) 59 77 / 935-0 6 +49 (0) 59 77 / 935-339 ü www.landmaschinen.krone.de...

Krone Comprima F 155 XC Original Operating Instructions

1 Information on this Document

2 Safety

3 Data Memory

4 Machine Description

5 Technical Data

6 Initial Operation

7 Commissioning

8 Operation

9 KRONE ALPHA Operation Unit

10 KRONE Beta II Terminal

11 KRONE Terminal DS 500

12 KRONE ISOBUS Terminal (CCI 800, CCI 1200)

13 Foreign ISOBUS Terminal

14 Terminal Machine Functions

15 Terminal Menus

16 Driving and Transport

17 Settings

18 Maintenance

19 Malfunction, Cause and Remedy

20 Repairs, Maintenance and Settings by Technicians

Quick Links

Need help?

Questions and answers

Related Manuals for Krone Comprima F 155 XC

Summary of Contents for Krone Comprima F 155 XC
