Original operating manual
150 000 148 01 en
Round Baler
Bellima F 130
(from machine no. 835 525 )
01.02.2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 835 525 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Krone 835 525

  • Page 1 Original operating manual 150 000 148 01 en Round Baler Bellima F 130 (from machine no. 835 525 ) 01.02.2014...
  • Page 2 (Managing Director, Design and Development) Year of manufacture: Machine No.: Dear customer, You have obtained the operating instructions for your new Krone machine. These operating instructions contain important information concerning the proper use and safe operation of the machine. Should these operating instructions for some reason become...
  • Page 3: Foreword

    Similarly, Mach. No. the machine must only be used under the conditions prescribed by Krone. Year This symbol is intended to draw your attention to safety notes contained in the operating instructions. Follow these notes Ordering Replacement Parts in order to avoid accidents.
  • Page 4: Table Of Contents

    Table of Contents Foreword ........................1 General ........................5 Introduction ....................... 8 Positions of the Warning Signs ..................8 Technical Data......................12 Working Methods and Operating Principles of the machine ........14 Preparing the Round Baler ..................15 Special Notes on Safety ................... 15 Adapting the Swinging Drawbar to the Tractor ............
  • Page 5 Settings ........................39 Special Notes on Safety ................... 39 Adjusting the Tail Gate Lock ..................39 Adjusting the Baling Pressure Gauge ..............39 Setting the Baling Pressure ..................40 Locking Hook Stop ....................41 5.5.1 Adjusting the Cord for the Display "Bale Chamber Closed and Locked" ....42 Double Binding Twine Guide ..................
  • Page 6 Faults - Causes and Elimination ................64 11.1 Special Notes on Safety ................... 64 11.2 Tabular List of Faults, their Causes and Elimination ..........64 Special Equipment ....................68 12.1 Electronic Final Pressure Gauge ................68 12.1.1 Adjusting the Final Pressure Gauge ................. 69 12.2 Round Balers with a Wide Pick Up ................
  • Page 7: General

    General Basic rule: 1. Operation in Accordance with Specifications Before any public roads are used and before the machine is started, The round baler is designed solely for normal agricultural check the round baler and the tractor use (operation in accordance with specifications). for road-worthiness and operational safety.
  • Page 8 5. Power take-off shaft operation 1. Only the P.T.O. shafts prescribed by the manufacturer 15.Operating equipment for remote controls (ropes, may be used! chains, rods etc.) must be laid out in such a way that, whatever the working or transport position, it can not 2.
  • Page 9 9. Replacement parts must conform at least to the technical requirements defined by the manufacturer! The best guarantee is to use only original KRONE parts! 10.Where gases are stored, only refill with nitrogen. Danger of explosion!
  • Page 10: Introduction

    Introduction The KRONE Round Baler is equipped with all safety devices (guards). Not all danger areas in this machine can be rendered completely safe as the machine must remain functional. You will find corresponding danger signs on the machine which refer to the remaining danger.
  • Page 11 Danger - rotating auger. Read and observe the operating instructions. (Only for pick ups with lateral augers) Order No. 939 520-1 (2x) Order No. 939 471-1 (1x) Never reach into the pick up area when the tractor engine is running and the PTO shaft is connected.
  • Page 12 Positions of the Warning Signs KKR0002...
  • Page 13 274 948-0 (1x) 274 947-0 (1x) 939 194-1 (2x) 939 223-2 (1x) (2x) 441 071-2 3,0 bar 441 072-2 3,5 bar 441 073-2 4,0 bar 939 361-1 (2x) 942 111-0 (1x) 942 132-0 (1x) 441 074-2 4,5 bar K ontrolle frei Datum Unterschrift: 273 506-1...
  • Page 14: Technical Data

    1.2 Technical Data Standard wide Pick-up Pick-up Lenght 3700 3700 Width 2250 2290 Height 2090 2050 Track 1950 1950 10.0/75-15.3/8 ply Tyres 11.5/80-15.3/10 ply 11.5/80-15.3/10 ply 15.0/55-17/10 ply 15.0/55-17/10 ply Pick-up 1400 1800 width weight ca. 1730 1920 Bale dimensions ø...
  • Page 15 Storage of Bales Storage Binding material Rwine strength m/kg open air Synthetic twine 400-600 indoors Sisal twine 150-330 Wrapping Material Data Wrapping material Dimensions in mm Width 1250 ± 5 Sleeve length 1250-1270 Inner sleeve diameter 75 bis 80 Roll diameter max.
  • Page 16: Working Methods And Operating Principles Of The Machine

    1.3 Working Methods and Operating Principles of the machine The round baler compresses crops such as hay, straw, grass silage etc. into round bales. On completion of the baling procedure the bale is wrapped with twine, net or synthetic foil, depending on the type of wrapping material selected. Due to their form, the round bales have good storage properties, can be transported simply and can be processed further with ease.
  • Page 17: Preparing The Round Baler

    Preparing the Round Baler Special Notes on Safety • Always switch off the PTO shaft when undertaking maintenance, care and repair work. • Switch off the engine and remove the ignition key. • Only use PTO shafts specified by the manufacturer which have an appropriate overload coupling.
  • Page 18 Mounting the Swinging Drawbar for Top Attachment Mount the swinging drawbar (1) in the upper attachment holes in the brackets (2) on the front cross carrier. The height adjustment of the swinging drawbar is made as described below in this chapter. KR-0-001 Mounting the Swinging Drawbar for Bottom Attachment...
  • Page 19: Adapting The Pto Shaft

    Adapting the PTO Shaft • Before working on the PTO shaft, switch off the engine and remove the ignition key. • Secure the tractor together with the round baler from rolling away. • When adapting the PTO shaft there must be nobody between the tractor and the round baler.
  • Page 20: Adjusting The Height Of The Wheel Hubs

    Adjusting the Height of the Wheel Hubs • Park the round baler on firm ground and secure from rolling away with wheel chocks. • To jack up the round baler, use a suitable jack and jack stands. • Risk of crushing from falling components.
  • Page 21 Jack Stand Risk of crushing hands and feet when actuating the jack stand. For operation, bring the jack stand (1) into the top position and twist the support plate tight beneath the front cross carrier. To do this: • Take the load off the jack stand (using the crank) •...
  • Page 22 Universal drive shaft DANGER! Danger of entrainment at P.T.O. shaft. Attaching the guard cup for universal shaft Effect: Risk of injury when drawing in open long hair, jewellery or baggy clothes. • Remove guard cup (1) out of the twine box. •...
  • Page 23: Selection Of Binding Material

    Actuating Cord for the Starter Mechanism Lay the actuating cord for the starter mechanism in such a way that it is not under tension and does not come into contact with the tractor wheels when going round corners and thereby activate a wrapping cycle or damage the starter mechanism.
  • Page 24: Detaching The Round Baler

    2.6.4 Road Journeys • Driving on public highways is only permitted with the bale chamber empty and closed. • The maximum permissable speed is 25 km/h. • Carrying passengers on the round baler is forbidden. • The road safety of the round baler must be checked before driving on public highways, in particular the lighting, tyres, protective plates...
  • Page 25 Secure the baler from rolling away accidentally using wheel chocks (1). The wheel chocks are located behind the side plates on the round baler. KR-0-081 Bring the jack stand (1) from the transport position into the jacking position and wind down. (For handling, see chapter 2.6.1 - "Jack Stand"...
  • Page 26 Undo the hydraulic hoses (1) as well as the actuating cord and the electrical connection cables and place them in the appropriate containers in the twine box. Unlock the three-point linkage or remove the bolt (the same applies for the swinging drawbar) and carefully drive the tractor forward.
  • Page 27: Working With The Round Baler

    Working with the Round Baler Special Notes on Safety Besides the general notes on safety, a number of additional safety notes also apply for working with the round baler. • The following always applies for all maintenance, mounting, repair and adjustment work: Bring the machine to a standstill.
  • Page 28: Baling Process

    Baling Process Drive up to the beginning of a swath with the round baler and observe the points in the following sections. Settings not described in these sections can be found in the "Settings" chapter in these operating instructions. Checking the Tail Gate Lock The tail gate is correctly locked when the baling pressure gauge (1) on the right hand side of the machine indicates a position below "O"...
  • Page 29: Forward Speed And Pto Shaft Speed

    Forward Speed and PTO Shaft Speed The working speed is dependent on the following factors: Type of crop Moisture content of the crop Swath height Swath width Ground conditions Adapt your forward driving speed to the conditions. Avoid overloading the round baler. Take a speed of 5 - 12 km/h as a guide.
  • Page 30: Completing The Baling Process

    If crops other than agricultural ones are baled, these must also be laid out in swathes and collected automatically by the pick up by driving over the swath. Before you process crops other than those defined as being for proper use, please consult your local KRONE dealer.
  • Page 31: Drive Chain For Pick-Up With Shearing Bolt

    3.11 Drive Chain for Pick-up with Shearing Bolt In order to ensure against overload, the pick-up driving mechanism and the feed auger, which is located behind the protective cover (3), are secured with a shearing bolt to the upper chain wheel. 5 extra bolts (2) are located at the top of the protective cover (3) M 8 x 35 (Order No.
  • Page 32: Basic Setup And Operation

    Basic Setup and Operation 4.1. Pick Up The following applies for all maintenance, mounting, repair and adjustment work: Bring the machine to a standstill. Switch off the engine and remove the ignition key. Secure the tractor and round baler from rolling KR 130 away.
  • Page 33: Adjusting The Feeler Wheels

    4.1.2 Adjusting the Feeler Wheels Risk of crushing when adjusting the feeler wheels. Secure the pick up from accidental lowering. Set the feeler wheels (1) on the left and right hand sides of the pick up in such a way that these just touch the ground at the pre-selected pick up working height.
  • Page 34: Additional Compression Rake

    4.1.4 Additional Compression Rake Risk of crushing when mounting and dismounting the compression rake. Secure the pick up from accidental lowering. An additional compression rake (2) is mounted as standard on the pick up. It rests loose on top of the pick up.
  • Page 35 There are lugs (2) located in the twine box (1) above the rolls of twine, through which the twine must be fed before the individual rolls of twine (I to VI) are tied. Tie the rolls of twine as follows: (see Fig.
  • Page 36 From the twine holders the twine (1) is fed from above through two twine guide lugs (3) and laid into the twine brake (4). Feed the twine between the spring clamps (2) and the screws (5). KR-0-008 From the twine brake the twine (3) is laid around the drive roller (1) and fed further to the starter for the double binding mechanism.
  • Page 37: The Binding Process For Twine Wrapping

    4.2.2 The Binding Process for Twine Wrapping The round balers can be simultaneously equipped with a net wrapping mechanism as well as the twine wrapping mechanism. Note that only one wrapping mechanism is started at any one time. For this reason only the synthetic cord or the steel cord may be attached to the actuating lever. For twine wrapping in standard models there is mechanical actuation for the starter via a synthetic cord (2).
  • Page 38: Dismounting The Starter Mechanism

    During the binding process the twine is fed through twine guides to the right (1) and left (2) from the centre outwards and then back in again. The twine is cut off in the end or starting position. The adjacent diagram shows the twine guides with the starter dismounted.
  • Page 39 Before the starter mechanism can be laid behind the side plates, the twine guide plate (1) must be unscrewed from the starter (2). Lay the twine guide plate in the twine box. KR-0-024 In the machine, the bracket (1) for holding the starter (2) is located on the right hand side of the machine.
  • Page 40: Pre-Selecting The Baling Pressure

    Pre-selecting the Baling Pressure • Bring the machine to a standstill before adjusting the baling pressure. • Switch off the engine and remove the ignition key. • Secure the tractor and the round baler from rolling away. The baling pressure on the right and left hand sides of the bale chamber can be infinitely varied at the indicators (1) on the front side of the round baler.
  • Page 41: Settings

    Settings Special Notes on Safety • The adjustments listed below may only be carried out when the machine is at a standstill. Switch off the engine and remove the ignition key. • Secure the round baler and the tractor from rolling away. •...
  • Page 42: Setting The Baling Pressure

    The adjustment is made at the adjusting screws (2) on bothe sides of the round baler. The adjusting screws are each connected to the baling pressure gauges respectively via steel cords (1). To make the adjustment, undo the self-locking nuts (3) and twist the adjusting screws.
  • Page 43: Locking Hook Stop

    Locking Hook Stop In order to guarantee that the tail gate is correctly locked, it is necessary to check the setting of the locking hook stop (1) for the tail gate lock. When the tail gate is open, the distance (a) between the adjusting screw (3) and the feeler (4) must be 2 - 5 mm.
  • Page 44: Adjusting The Cord For The Display "Bale Chamber Closed And Locked

    5.5.1 Adjusting the Cord for the Display "Bale Chamber Closed and Locked" Via the cord (2), the right hand baling pressure gauge indicates whether the tail gate properly closed. If the locking hook is in the deepest position, but the tailgate still closed, the right-hand baling pressure indicator (3) should be on a level with firgure "3".
  • Page 45 Carriers Particular care is required when adjusting the knife stop. The knives are extremely sharp. Risk of injury. The carriers (1) should have the 2distances shown in the adjacent diagram a = 38 mm and b = 20 mm. KR-0-115 Knife Stop Particular care is required when adjusting the knive stop.
  • Page 46: Twine Brake

    Twine Brake The twine brake (4) causes the twine (1) to be fed taughtly. The adjustment is made by twisting the wing nuts (2). The force on the twine is increased and reduced using the compression springs (3). The setting depends on the twine used and of course the quality of the twine.
  • Page 47: Distance From The Compression Rake To The Pick Up

    If the distance from the roller (3) to the roller panel is corrected, the distances from the guide plates (2) to the roller on the left and right hand sides on the inside of the bale chamber must also be reset. To make this adjustment undo the screws (1) on the left and right hand sides on the outside of the round baler.
  • Page 48: Preparing For Road Transport

    Preparing for Road Transport 6.1 Special Notes on Safety • Repair, maintenance, care and cleaning work may only be carried out when the machine is at a standstill. Switch off the engine and remove the ignition key. • Secure the tractor and the round baler from rolling away. •...
  • Page 49: Care And Maintenance

    Care and Maintenance Special Notes on Safety • Repair, maintenance, care and cleaning work may only be carried out when the machine is at a standstill. Switch off the engine and remove the ignition key. • Secure the round baler and the tractor from rolling away. •...
  • Page 50 Definition: Term Lubricant Place/Quantity Notes Greasing Multi-purpose grease Lubricating nipple/ Remove excess grease approx. two squirts from from the lubricating nipple a grease gun Lubricating If not otherwise specified Guide surfaces/apply a thin Remove old and excess use plant based oils layer with a brush grease Oiling...
  • Page 51 Maintenance according to Number of Bales Number of bales Machine part 100 -150 Check chain tension Roller panel drive Pick up drive Distance roller to roller panel chain after the Gearbox first 500 2000 Gearbox Maintenance at ParticularTimes Times Machine part after every Wheels, wheel nuts, height wheel change...
  • Page 52 Checking and Adjusting Machine Part check adjust Guide plates Chain for the binding mechanism Hydraulic starter wrapping mode twine mode Wrapping mechanism drive wheels spring bar adjusting screw for the block blade carrier Tail gate lock Baling pressure gauge Stop for the locking hook Electronic final pressure gauge Straw trap...
  • Page 53: Tyres

    Tyres • Repairs to the tyres may only be carried out by specialists with suitable mounting tools. • Bring the round baler to a standstill before commencing mounting. • Park the round baler on flat firm ground. Secure from rolling away accidentally using wheel chocks.
  • Page 54: Main Drive Gearbox

    Main Drive Gearbox • Change the oil only when the round baler is at a standstill. • Switch off the engine and remove the ignition key. • Secure the tractor and the round baler from rolling away. • When the tail gate is open, secure it with the shut-off tap.
  • Page 55: Drive Chains

    Drive Chains • Only attempt to oil and tighten the chains when the machine is at a standstill. • The drive chains are equipped with guards.Always remount the guards after tightening and oiling. Use biodegradable, plant-based oils when oiling the drive chains if possible. 7.5.1 Roller Panel Drive The roller panel drive is located on the left hand side of the machine.
  • Page 56: Roller Drive

    7.5.3 Roller Drive The drive for the roller is on the right hand side of the machine. Tightening the Drive Chain A continuous tensile force is exerted by the compression spring (2) via the reversing lever (3) and the chain tensioning wheel (4) on the drive chain (5).
  • Page 57: Double Binding Twine Guide

    7.5.5 Double Binding Twine Guide The drive chain (1) for the double binding twine guide is located in the binding mechanism. It can be accessed from the front by opening the flaps. Tightening the Drive Chain The drive chain has an automatic chain tensioner and does not need to be tightened.
  • Page 58: General

    7.7.2 General The round baler is equipped with various hydraulic elements. Element Connection Comment Pick up a single or double standard: switch at the reversing valve action control unit pick up/tail gate special equipment: separate pick up operation Tail gate a single or double switch at the reversing valve action control unit...
  • Page 59: Hydraulic Circuit Diagram For The Round Baler With Hydraulic Starter Mechanism

    7.7.3 Hydraulic Circuit Diagram for the Round Baler with Hydraulic Starter Mechanism I I I KR-0-061 Hydraulic cylinder pick up Hydraulic cylinder tail gate Shut-off tap tail gate Hydraulic cylinder starter mechanism (special equipment) Additional connection hose (special equipment) Tractor Hitch on the Swinging Drawbar If the sleeve in the tractor hitch is excessively worn, it must be replaced.
  • Page 60: Electrics

    Electrics Lighting Lay the electric connection cables between the tractor and the round baler in such a way that they do not come into contact with the tyres. The lighting system (2) on the round baler consists of three unit lamps on the tail gate, as well as round, red rear reflectors (1) on the rear side and orange cats eyes on the lateral protective plates.
  • Page 61: Lubrication

    Lubrication 8.1 Special Notes on Safety • Repair, maintenance, care and cleaning work may only be carried out when the machine is at a standstill. Switch off the engine and remove the ignition key. • Secure the round baler and the tractor from rolling away. •...
  • Page 62: Lubrication Points On The Round Baler

    8.3 Lubrication Points on the Round Baler LH = left-hand side of the machine RH = right-hand side of the machine...
  • Page 63: Over The Winter

    Have the necessary repair work carried out in the time directly after the harvest season. Prepare a list of all spare parts required. By doing this it is easier for your KRONE dealer to process your orders and you can be sure that...
  • Page 64: Putting Into Operation Again

    Putting into Operation again 10.1 Special Notes on Safety • Always bring the machine to a standstill before carrying out maintenance, mounting, repair and adjustment work. Switch off the engine and remove the ignition key. • Secure the tractor and the round baler from rolling away. •...
  • Page 65: Checking The Starter Rollers

    10.4 Checking the Starter Rollers The pressure rollers (3,4) must be able to be turned easily. Turn the drive roller (1) to check. If the pressure rollers do not turn with it, or only with difficulty, slide a screw driver between the drive and the pressure rollers and move back and forth gently.
  • Page 66: Faults - Causes And Elimination

    Faults - Causes and Elimination 11.1 Special Notes on Safety • Repair, care, maintenance and cleaning work may only be carried out when the machine is at a standstill. Switch off the engine and remove the ignition key. • Secure the round baler and the tractor from rolling away. •...
  • Page 67 Fault Possible Cause Elimination Roller panel chain is The roller panel chain has lengthened. Move the roller forwards. knocking against the roller. Causes loud noises. Roller panel chain Chain dirty and not oiled. Clean and oil chain. becomes shorter. An electronic final Electrical supply from the tractor to the Check the electrical supply using the pressure gauge does...
  • Page 68 Fault Possible Cause Elimination Replace the O ring. Friction wheel Twine is not fed in at O ring in the starter without an O ring must not press on starting. defective. against the drive shaft. Starter cord on the hydraulic starter Check the cord or spring setting.
  • Page 69 Fault Possible Cause Elimination Wrapping material is Catch is in locked position. Unlock. not being cut off cleanly. Blade carrier does not fall all the way For hydraulic starter mechanisms: check down. the setting of the operating cord. Wrapping material The PTO shaft speed is kept too low Let the wrapping process run with a PTO comes out forward...
  • Page 70: Special Equipment

    Special Equipment 12.1 Electronic Final Pressure Gauge • The final pressure gauge may only be mounted on the tractor when the engine is switched off and the ignition key has been removed. • Secure the tractor and the round baler from rolling away. •...
  • Page 71: Adjusting The Final Pressure Gauge

    12.1.1 Adjusting the Final Pressure Gauge Do not cause any short circuits when carrying out checking, maintenance or repair work! Operational Check To check its operation, connect the final pressure gauge to the round baler and the power supply (12 volt). Both indicator lamps must be illuminated.
  • Page 72 Control Plate To adjust the control plate (1) undo the attaching screws and slide the control plate in the slots (2). Tighten up the attaching screws again after making the adjustment. KR-0-071 Circuit Diagram for the Electronic Final Pressure Gauge: I I I (PE) (PE)
  • Page 73: Round Balers With A Wide Pick Up

    12.2 Round Balers with a Wide Pick Up 12.2.1 Adjusting the Working Height (low limit) of the Pick Up Risk of crushing when adjusting the working height of the pick up. Secure the pick up from lowering unintentionally. To adjust the working height of the pick up, open the front lateral plate.
  • Page 74: Drive Chains

    12.2.3 Drive Chains The pick up drive is on the left hand side of the machine. Tightening the Drive Chain Undo screws (4) on both sides of the pick up (3). The pick up is displaced in the slots (5) by twisting the tensioner (2) supported on the mount (1) and the drive chain is thereby tightened.
  • Page 75: Adjusting The Height Of The Baffle Plate

    12.2.5 Adjusting the Height of the Baffle Plate Risk of crushing when adjusting the height of the baffle plate on the pickup. Secure the pick up from accidental lowering. KKR00013 The height adjustment of the baffle plate (1) is effected via the chains (2) on the left and the right machine side.
  • Page 76: Net And Foil Wrapping Mechanism

    12.3 Net and Foil Wrapping Mechanism 12.3.1 Special Notes on Safety • Before inserting the wrapping material (net or foil) in the round baler, switch off the PTO shaft and allow the machine to come to a standstill. • Switch off the engine. Remove the ignition key. •...
  • Page 77 Slide the roll of net (2) on to the receiver mechanism in such a way that the net is unrolled downwards from above. Slide on the brake disk (1) while turning it anti- clockwise. Make sure that the springs with the serrated tips on the brake drum grip into the cardboard roll.
  • Page 78: Wrapping Process For The Net Wrapping Mechanism

    After inserting the net in the wrapping mechanism close the locking pawl (1) behind the drive wheel (2) again (see direction of arrow). Pull the spring bar (4) through at lever (3), remove from the adjusting screw (5) and bring to the position shown.
  • Page 79 When the start process is triggered, the lever (1) is pulled into position (2). The spring bar moves to position (4), a few centimeters above the thread (7). At the same time the brake on the roll of net is freed (on the right under the twine supply container), so that the net can be drawn in more easily at the start of the wrapping process.
  • Page 80: Selecting The Number Of Times The Bale Is Wrapped

    12.3.5 Selecting the Number of Times the Bale is Wrapped • Always switch off the PTO shaft when carrying out care, maintenance or repair work on the round baler. Bring the machine to a standstill. • Switch off the engine. Remove the ignition key. •...
  • Page 81: Adjustments To The Wrapping Mechanism

    12.3.7 Adjustments to the Wrapping Mechanism Before making adjustments to the wrapping mechanism, always swing the blade carrier into the upper position and secure by inserting the locking pawl (right hand side of the machine, behind the drive wheel on the net wrapping mechanism).
  • Page 82 Basic Blade Setup • The setting of the blade is checked and corrected when the bale chamber is open. Secure the tail gate from lowering accidentally. To do this bring the hydraulic shut-off tap on the left hand tail gate hydraulic cylinder into the locked position. •...
  • Page 83: Hydraulic Starter Mechanism

    12.4 Hydraulic Starter mechanism 12.4.1 General Notes on Safety • Always switch off the PTO shaft when carrying out care, maintenance or repair work on the round baler. Bring the machine to a standstill. • Switch off the engine. Remove the ignition key.
  • Page 84: Adjusting The Compression Spring On The Hydraulic Start Cylinder

    12.4.3 Adjusting the Compression Spring on the Hydraulic Start Cylinder When the hydraulic cylinder is extended the compression spring (2) on the hydraulic cylinder (1) should compress to a dimension a = 110 - 120 mm. To make the adjustment undo the self-locking nut (3) and twist the adjusting screw.
  • Page 85: Disposal Of The Machine

    Disposal of the machine Disposal of the machine 13.1 Disposal of the machine After the service life of the machine has expired, the individual components of the machine must be disposed of properly. The applicable country-specific, current waste disposal guidelines and the legal laws must be observed.
  • Page 86 Disposal of the machine...
  • Page 87: Removing The Crop Blockages In The Crop Collection Area

    Removing the Crop Blockages in the Crop Collection Area WARNING! – Unexpected movements of the machine! Effect: Injuries or damage to the machine • Eliminate blockages only when the machine is stopped. Switch off the engine and remove the ignition key. •...
  • Page 88 b) In case of a crop blockage of the pick-up • When the PTO shaft is running, drive backward. In doing so, lift/lower the pick-up several times. If the blockage is not removed due to this: Fig. 2 • Raise the pick-up. •...
  • Page 89 c) If there is a crop blockage on the transition from the pick-up input to the bale chamber Fig. 3 1) Transition from the pick-up input to the bale chamber • When the PTO shaft is running, drive backward. In doing so, lift/lower the pick-up several times.
  • Page 90 • Open tailgate. Fig. 4 • Swivel the stop cock (1) in the return of the left-hand lifting cylinder (2) of the tailgate from position (a) to position (b). The tailgate is locked hydraulically. • Remove the bale from the bale chamber (roll it out to the swath, if necessary). –...
