Page 1 Round baler Fortima F 1250 (MC) Fortima V 1500 (MC) Fortima F 1600 (MC) Fortima V 1800 (MC) (from serial no.: 848 920) Order no.: 150 000 135 05 en 14.05.2014...
Page 2 Pos: 1 /BA/Konformitätserklärungen/Rundballenpressen/Fortima F 1250 (MC), F1600 (MC), V1500 (MC), V1800 (MC) @ 113\mod_1338368042562_78.docx @ 1000614 @ @ 1 EC Declaration of Conformity Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Str. 10, D-48480 Spelle hereby declare as manufacturer of the product named below, on our sole responsibility,...
Page 3: Foreword
Pos: 3.2 /BA/Vorwort/Rundballenpressen/Verehrter Kunde Rundballenpresse @ 27\mod_1246526159413_78.docx @ 267781 @ @ 1 Dear Customer! By purchasing the round baler, you have acquired a quality product from KRONE. We are grateful for the confidence you have invested in us in buying this machine.
Page 4: Table Of Contents
Hose holder assembly ........................54 5.5.1 Net brake ............................. 55 Attaching the Triangle Spotlights ..................... 55 KRONE operation terminal Beta ......................56 Attachment of control unit ........................ 57 6.1.1 Connecting Control Unit .......................
Page 5 Note and messages ....................... 103 6.13.2 Physical messages ........................ 104 6.13.3 General Messages ......................... 105 KRONE ISOBUS Terminal ........................106 Installing the terminal into cabin ....................107 ISOBUS Short Cut Button ......................108 ...
Page 6 Connection Terminal to Tractor ....................163 8.1.2 Connection Tractor to Machine....................163 Differing functions to KRONE ISOBUS terminal CCI ..............164 ISOBUS „Auxiliary“-function (AUX) ....................165 8.3.1 Example of joystick assignment for Fendt (default setting) ............166 Start-up ..............................
Page 7 Table of Contents 10.1 Preparations for road travel ......................178 10.1.1 Raise the pick-up ........................179 10.1.2 Checking the parking support ....................180 10.1.3 Checking the lighting system ....................180 10.2 Parking ............................
Page 8 Table of Contents 12.1.5 Adjusting the sensor ......................239 12.1.6 Selecting the type of tying ...................... 240 12.1.7 Adjusting the net brake ......................240 12.1.8 Adjusting the additional net brake ..................241 ...
Page 9 General malfunctions ........................314 16.3 Malfunctions on the central chain lubrication system ..............317 16.4 Error Messages of KRONE Operation Terminal ................318 Appendix ............................. 319 17.1 Hydraulic System Circuit Diagrams ....................319 ...
Page 10: Introduction
Pick-up as it passes over them. Pos: 8.5 /Überschriften/Überschriften 3/A-E/Ansprechpartner @ 0\mod_1195569394286_78.docx @ 839 @ 3 @ 1 3.1.1 Contact Pos: 8.6 /BA/Adressen/Adresse Maschinenfabrik KRONE Spelle @ 0\mod_1195568531083_78.docx @ 734 @ 3 @ 1 Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Strasse 10 D-48480 Spelle (Germany) Telephone: + 49 (0) 59 77/935-0 (Head Office) Fax.: + 49 (0) 59 77/935-339 (Head Office)
Page 11: Identification Plate
Authentic KRONE spare parts and accessories authorised by the manufacturer help to ensure safety. The use of spare parts, accessories and other devices which are not manufactured, tested or approved by KRONE will result in the revoking of the liability for damages resulting thereof.
Page 12: Intended Use
Introduction Pos: 8.12.1 /Überschriften/Überschriften 2/A-E/Bestimmungsgemäße Verwendung @ 103\mod_1332169199326_78.docx @ 940071 @ 2 @ 1 Intended use Pos: 8.12.2 /BA/Einleitung/Bestimmungsgemäßer Gebrauch/Rundballenpresse/Bestimmungsgemäßer Gebrauch Rundballenpresse @ 32\mod_1253019678915_78.docx @ 308291 @ 2 @ 1 The round baler is built exclusively for customary use in agricultural work (intended use). Pos: 8.12.3 /BA/Einleitung/Bestimmungsgemäßer Gebrauch/Nicht bestimmungs gemäss @ 103\mod_1332171672294_78.docx @ 940272 @ @ 1 Unauthorised modifications to the machine may have a negative effect on the machine characteristics or safe and reliable use of the machine or may interfere with proper operation.
Page 13: Technical Data
We reserve the right to make design changes at any time and without notification of reasons. Pos: 8.15 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Fortima F 1250 (MC) @ 227\mod_1392733434134_78.docx @ 1827618 @ 2 @ 1 Fortima F 1250 / Fortima F 1250 MC Axle Single axle...
Page 14 Introduction Pos: 8.17 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Fortima F 1600 (MC) @ 227\mod_1392733454061_78.docx @ 1827647 @ @ 1 Fortima F 1600 / Fortima F 1600 MC Axle Single axle Tandem axle Pick-up (width) 2050 mm 2050 mm Width approx. 11.5/80-15 2460 mm 2740 mm 15.0/55-17 2535 mm...
Page 15 Introduction Pos: 8.19 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Fortima V 1500 Magnet @ 227\mod_1392733387217_78.docx @ 1827560 @ @ 1 Fortima V 1500 /Fortima V 1500 MC Axle Single axle Tandem axle Pick-up (width) 2050 mm 2050 mm Width approx. 11.5/80-15 2460 mm 2740 mm 15.0/55-17 2535 mm...
Page 16 Introduction Pos: 8.21 /BA/Einleitung/Technische Daten/Rundballenpresse/Technische Daten Fortima V 1800 Magnet @ 227\mod_1392733414401_78.docx @ 1827589 @ @ 1 Fortima V 1800 / Fortima V 1800 MC Axle Single axle Tandem axle Pick-up (width) 2050 mm 2050 mm Width approx. 11.5/80-15 2460 mm 2740 mm 15.0/55-17 2535 mm...
Page 17: Safety
Safety Pos: 10.1 /Überschriften/Überschriften 1/P-T/Sicherheit @ 0\mod_1195566748646_78.docx @ 635 @ 1 @ 1 Safety Pos: 10.2 /BA/Sicherheit/6. Überarbeitete Warnhinweise/Kennzeichnung von Hinweisen in der Betriebsanleitung Einführungstext (2012-07-27 09:59:06) @ 0\mod_1195637804826_78.docx @ 1098 @ 12 @ 1 Identifying Symbols in the Operating Instructions The safety instructions contained in this manual which could result in personal injury if not followed are identified by the general danger sign: Pos: 10.3 /BA/Sicherheit/6.
Page 18: Personnel Qualification And Training
Safety Pos: 10.6.1 /BA/Sicherheit/Personalqualifikation und -schulung @ 0\mod_1195639383185_78.docx @ 1136 @ 2 @ 1 4.2.1 Personnel Qualification and Training The machine may be used, maintained and repaired only by persons who are familiar with it and have been instructed about the dangers connected with it. The operator must define areas of responsibility and monitoring of personnel.
Page 19: Safety Instructions And Accident Prevention Regulations
Safety Pos: 10.6.6 /BA/Sicherheit/Sicherheits- und Unfallverhütungs-VorschriftenRundballenpressen @ 240\mod_1395127554138_78.docx @ 1888942 @ 33 @ 1 Safety Instructions and Accident Prevention Regulations Please follow all generally applicable safety and accident prevention regulations in addition to the safety instructions contained in these operating instructions! The attached warning and safety signs provide important information for safe operation.
Page 20: Hitched Implements
Safety 25 Parts operated by external power (e.g. hydraulically) can cause crushing and shearing injuries! Pos: 10.6.7 /BA/Sicherheit/Sicherheit-Verlassen des Traktors @ 240\mod_1395128143546_78.docx @ 1889191 @ 33 @ 1 26 Before leaving the tractor, actuate the parking brake, switch off the engine, remove the ignition key and carry it with you.
Page 21: Pto Operation
Safety Pos: 10.6.10 /BA/Sicherheit/Zapfwellenbetrieb Traktor RB @ 156\mod_1364225944809_78.docx @ 1383869 @ 22 @ 1 PTO operation Use only universal shafts specified by the manufacturer! The guard tube and guard cone of the universal shaft and the PTO guard must be attached and in good working condition –...
Page 22: Hydraulic System
Safety Pos: 10.6.13 /BA/Sicherheit/Hydraulikanlage @ 2\mod_1203503691986_78.docx @ 66225 @ 2 @ 1 Hydraulic system 1 The hydraulic system is pressurised! 2 When connecting hydraulic cylinders and motors, make sure the hydraulic hoses are connected as specified! 3 When connecting the hydraulic hoses to the tractor hydraulics, make sure that the hydraulics of both the tractor and the implement have been depressurized! 4...
Page 23: Maintenance
Spare parts must at least comply with the technical requirements determined by the manufacturer of the implements! This is ensured by KRONE original spare parts! Pos: 10.6.21 /BA/Sicherheit/Wartung/Wartung Zusatz Bei Gasspeicherung/Schneidwekzeuge @ 2\mod_1203504102830_78.docx @ 66265 @ @ 1 9...
Page 24: Unauthorised Conversion/Modification And Spare Parts Production
Safety Pos: 10.6.26 /BA/Sicherheit/Eigenmächtiger Umbau und Ersatzteilherstellung @ 1\mod_1201937705539_78.docx @ 55745 @ 22 @ 1 4.10 Unauthorised Conversion/Modification and Spare Parts Production Conversions or modifications of the machine are permitted only with prior consultation with the manufacturer. Original spare parts and accessories authorised by the manufacturer help to ensure safety.
Page 25: Introduction
4.13 Introduction The KRONE round baler is equipped with all safety devices (protective devices). However, it is not possible to eliminate all potential hazards on this machine as this would impair its full functional capability. Hazard warnings are attached to the machine in the relevant areas to warn against any dangers.
Page 26: Position Of The Adhesive Safety Stickers On The Machine
Safety Pos: 10.11 /Überschriften/Überschriften 2/K-O/Lage der Sicherheitsaufkleber an der Maschine @ 0\mod_1195634967326_78.docx @ 1020 @ @ 1 4.14 Position of the Adhesive Safety Stickers on the Machine Pos: 10.12 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) /Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 10.13 /BA/Sicherheit/Aufkleber/Rundballenpresse/Sicherheitsaufkleber Fortima F Maschinen_Teil1 @ 113\mod_1338372416537_78.docx @ 1001134 @ @ 1 FOR00046_1...
Page 27 Safety Before starting the machine, read The P.T.O. speeds must not exceed 540 rpm! and observe the operating The operating pressure of the hydraulic system instructions and safety instructions. must not exceed 200 bar! 939 100-4 540/ MAX. MAX. (1x) 939 471 1 (1x) 939 100 4 Never reach into the working area Do not step under the raised...
Page 28 Safety Pos: 10.15 /BA/Sicherheit/Aufkleber/Rundballenpresse/Sicherheitsaufkleber Fortima F Maschinen_Teil2 @ 247\mod_1396369910808_78.docx @ 1924365 @ @ 1 FOR00046_1 10 6 10 7 Fig. 3...
Page 29 Safety The tailgate must The accumulator is under gas and oil only be operated if pressure. the baler is attached Disassembly and repair in strict accordance correctly to the with the instructions in the technical tractor. handbook. (1x) 942 360 3 942 360-3 (2x) 939 529 0 While parts are moving,...
Page 30 Safety Pos: 10.17 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 10.18 /BA/Sicherheit/Aufkleber/Rundballenpresse/Sicherheitsaufkleber Fortima V 1500 MC - NEU @ 211\mod_1389350170467_78.docx @ 1735815 @ @ 1 VP150206_3 Fig.
Page 31 Safety Before starting the machine, read The P.T.O. speeds must not exceed 540 rpm! and observe the operating The operating pressure of the hydraulic system instructions and safety instructions. must not exceed 200 bar! 939 100-4 540/ MAX. MAX. (1x) 939 471 1 (1x) 939 100 4 Never reach into the working area Do not reach into the danger...
Page 32: Re-Ordering The Adhesive Safety And Information Labels
Safety Pos: 10.20 /BA/Sicherheit/Aufkleber/Rundballenpresse/Sicherheitsaufkleber hinten Fortima V 1500 MC @ 54\mod_1291899144906_78.docx @ 517346 @ @ 1 FOR00022 FOR00020 Abb. 5 While parts are moving, never Do not step between tailgate and reach into areas where there is a a fixed obstacle. Before carrying risk of being crushed.
Page 33 Safety Pos: 12 /Layout Module /Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ @ 1 This page has been left blank deliberately!! Pos: 13 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 34: Commissioning
Commissioning Pos: 14.1 /Überschriften/Überschriften 1/A-E/Erstinbetriebnahme @ 0\mod_1196314201498_78.docx @ 5855 @ @ 1 Commissioning Pos: 14.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Inbetriebnahme/Unvorhergesehene Inbetriebnahme Fortima V 1500 MC @ 209\mod_1387357052199_78.docx @ 1724288 @ @ 1 DANGER! - Unintentional starting, moving machine components and / or unexpected machine movement! Effect: Risk of death, injuries or damage to the machine.
Page 35: Before Initial Start-Up
Commissioning Pos: 14.4 /Überschriften/Überschriften 2/U-Z/Vorbereitungen für die Erstinbetriebnahme @ 32\mod_1253109404174_78.docx @ 312138 @ @ 1 Before initial start-up Pos: 14.5 /BA/Erstinbetriebnahme/Rundballenpresse/Vorbereitungen Erstinbetriebnahme @ 226\mod_1392643174796_78.docx @ 1824323 @ @ 1 For reasons related to transport, the machine is delivered without the PTO shaft and bale ejector.
Page 36 Commissioning Pos: 14.7 /BA/Erstinbetriebnahme/Rundballenpresse/Bild Teile Erstinbetriebnahme Fortima F1250 (MC), F1600 (MC), V1500 (MC), V1800 (MC) @ 113\mod_1338381146421_78.docx @ 1001596 @ 2 @ 1 Fortima F 1250 (MC)/Fortima F 1600 (MC) FOR00031 Fig. 6 Fortima V 1500 (MC)/Fortima V 1800 (MC) VP800015_3 Fig.
Page 37 Commissioning Bale ejector (pallet) 12 Safety foil (twine box) Spacer (twine box) 13 Can of spray paint (twine box) Small parts (twine box) 14 Universal shaft (bale chamber) Nuts (twine box) 15 PTO shaft support (twine box) Linkage (twine box) 16 Hose holder and cable holder (bale chamber) Eye screws 17 Guide wheels (bale chamber)
Page 38 Commissioning Pos: 14.9 /BA/Erstinbetriebnahme/Rundballenpresse/Arbeitsschritte Erstinbetriebnahme @ 32\mod_1253176922910_78.docx @ 312501 @ @ 1 KR-1-081 Fig. 8 • Park the machine on firm, level ground. • Place two wheel chocks (1) under the wheels to prevent the machine from rolling away. VP800016 Fig.
Page 39 Commissioning RBV01170 Fig. 10 • Relieve all pressure from the tractor hydraulics. • Connect the hydraulic hoses (1), (2) and (3) to the tractor hydraulics according to colour coding. RBV0116A Fig. 11 • Set the control valve (1) for "Open tailgate (2)" to "Raise". Pos: 14.10 /BA/Sicherheit/Module Achtung/Gefahr - Geöffnete Heckklappe @ 32\mod_1253180791300_78.docx @ 312630 @ @ 1 DANGER! –...
Page 40 Commissioning Pos: 14.12 /BA/Erstinbetriebnahme/Rundballenpresse/Heckklappe sperren Fortima_F1250 (MC), F1600 (MC), V1500 (MC), V1800 (MC) @ 113\mod_1338450362045_78.docx @ 1002190 @ @ 1 Fortima V1500 (MC)/V1800 (MC) Fortima F1250 (MC)/F1600 (MC) FOR00032 VP-1-057 Fig. 12 • Swivel shut-off valve (1) in the return of the left lifting cylinder from position (b) to position (a), the tailgate is locked hydraulically.
Page 41: Assembling The Bale Ejector
Commissioning Pos: 14.15 /Überschriften/Überschriften 2/K-O/Montage Ballenauswerfer @ 32\mod_1253182217691_78.docx @ 312680 @ 2 @ 1 Assembling the bale ejector Pos: 14.16 /BA/Erstinbetriebnahme/Rundballenpresse/Optional für Fortima V1500 (MC)/V1800 (MC) @ 191\mod_1381762367860_78.docx @ 1630563 @ @ 1 Optional for Fortima V1500 (MC)/V1800 (MC) Pos: 14.17.1 /BA/Inbetriebnahme/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/1_Schraubverbindungen der Aufnahmebleche lösen_Bild_Fortima @ 191\mod_1381928836736_78.docx @ 1634130 @ @ 1 Fig.
Page 42 Commissioning Pos: 14.17.6 /BA/Inbetriebnahme/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/3_Leiste am Ballenauswerfer montieren_Bild_Fortima @ 192\mod_1381929230912_78.docx @ 1634227 @ 2 @ 1 VP700026_2 Fig. 16 Pos: 14.17.7 /BA/Inbetriebnahme/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/3_Leiste am Ballenauswerfer montieren_Text @ 191\mod_1381922409479_78.docx @ 1633675 @ 3 @ 1 • Fitting the strip (1) on the right and left of the bale ejector: Secure with a screw (2), washer (3) and locknut (4).
Page 43 Commissioning Pos: 14.17.14 /BA/Inbetriebnahme/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/6_Gestänge montieren_Bild @ 191\mod_1381922644959_78.docx @ 1633824 @ @ 1 FOR00065 Fig. 18 Pos: 14.17.15 /BA/Inbetriebnahme/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/6_Gestänge montieren_Text @ 191\mod_1381922668059_78.docx @ 1633852 @ @ 1 • Push the linkage (1) on the right and left onto the stud bolts (2) on the frame and secure with a washer (3) and clamping sleeve (4).
Page 44 Commissioning Pos: 14.17.19 /BA/Inbetriebnahme/Erstinbetriebnahme/Rundballenpresse/Ballenauswerfer/7_Zugfeder und Augenschraube einhängen @ 191\mod_1381923248446_78.docx @ 1633876 @ @ 1 Fig.20 • Hook the tension spring (1) into the link (5) on the holding plate. • Hook the eye bolt (3) into the tension spring (1) and guide it through the bore hole (2). •...
Page 45 Commissioning Pos: 14.19 /BA/Erstinbetriebnahme/Rundballenpresse/Abstandshalter Fortima V 1800 MC montieren @ 54\mod_1291732248812_78.docx @ 514412 @ @ 1 Assemble spacers (Fortima V 1800 (MC)) VP700017 Fig. 22 11.5/80-15.3; 15.0/55-17 Tyres: 19.0/45-17; 500/50-17 • Install spacers (1) with coach bolts, discs and nuts to the bale ejector (2). VP700022 Fig.
Page 46: Adjusting The Drawbar Height
Commissioning Pos: 14.21 /Überschriften/Überschriften 2/F-J/Höhenanpassung der Deichsel @ 17\mod_1236255816988_78.docx @ 204061 @ @ 1 Adjusting the drawbar height Pos: 14.22 /BA/Erstinbetriebnahme/Rundballenpresse/Anpassen des Reifenluftdrucks Rundballenpressen @ 114\mod_1338881601674_78.docx @ 1006469 @ @ 1 Note Before aligning the machine and adapting the height of the drawbar, the tyre pressure must be checked and adapted to the value for the existing tyre type which is recommended in the tyre air pressure table (refer to chapter entitled “Maintenance”), if necessary.
Page 47 Commissioning Adapting the height of the towing eye to the height of the tractor hitch (perform setting on both sides): Note Before starting the adjustment, set the machine on the parking support and uncouple the tractor. RBV19221 Fig. 25 1. Reset Pick-up transport-fuse •...
Page 48 Commissioning Pos: 14.26 /BA/Sicherheit/7. Gefahrenhinweise alt/Inbetriebnahme/Gefahr - Unvorhergesehene Inbetriebnahme_2 BiG Pack @ 17\mod_1236255571519_78.docx @ 204032 @ @ 1 DANGER! - Unexpected movements of the machine! Effect: Danger to life, injuries or damage to the machine. • Secure the machine against rolling away with wheel chocks and by applying the parking brake •...
Page 49: Pto Shaft
Commissioning Pos: 14.30 /Überschriften/Überschriften 2/F-J/Gelenkwelle @ 0\mod_1199781879794_78.docx @ 34542 @ 22 @ 1 PTO shaft Pos: 14.31 /Überschriften/Überschriften 3/A-E/Anbau des Schutztopfes für die Gelenkwelle @ 46\mod_1278501178484_78.docx @ 442635 @ 2222 @ 1 5.4.1 Attaching the guard cup for universal shaft Pos: 14.32 /BA/Sicherheit/7.
Page 50: Mounting The Pto Shaft On The Machine Side
Commissioning Pos: 14.36 /Überschriften/Überschriften 3/K-O/Maschinenseitige Montage der Gelenkwelle @ 32\mod_1253532604423_78.docx @ 314180 @ 332 @ 1 5.4.2 Mounting the PTO shaft on the machine side Pos: 14.37 /BA/Sicherheit/Gelenkwelle/Gefahr - Sich drehende Gelenkwelle_2 @ 0\mod_1199781692950_78.docx @ 34523 @ @ 1 Danger! - Rotating PTO shaft Effect: Danger to life or serious injuries •...
Page 51 Commissioning Pos: 14.41 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Bild Anbau Gelenkwellenhalter @ 32\mod_1253533150220_78.docx @ 314206 @ @ 1 RP-99-012 Fig. 30 Pos: 14.42 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Anbau Gelenkwellenhalter @ 32\mod_1253533341376_78.docx @ 314231 @ @ 1 • Switch off the engine and remove the ignition key. • Assemble the PTO shaft bracket (1) and secure the PTO shaft support (2). Pos: 14.43 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Bild Anbau Gelenkwelle @ 32\mod_1253534105814_78.docx @ 314281 @ @ 1 KR-1-080 Fig.
Page 52 Commissioning Pos: 14.46 /BA/Erstinbetriebnahme/Rundballenpresse/Gelenkwelle/Zugöse drehen @ 77\mod_1310047904943_78.docx @ 667353 @ 3 @ 1 COM00321 Fig. 32 Note To achieve greater PTO shaft freedom, the towing ring can be mounted in position (1) or (2) on the drawbar (3). • Use a suitable tool to loosen the screw connection (4). •...
Page 53: Length Adjustment
Commissioning Pos: 14.50 /Überschriften/Überschriften 3/K-O/Längenanpassung @ 1\mod_1201687632810_78.docx @ 53589 @ @ 1 5.4.3 Length adjustment Pos: 14.51 /BA/Sicherheit/Gelenkwelle/Gefahr - Sich drehende Gelenkwelle_3_ohne Schwungradbremse @ 220\mod_1391418612269_78.docx @ 1780514 @ @ 1 DANGER! - Rotating universal shaft! Effect: Risk of death or serious injuries •...
Page 54: Hose Holder Assembly
Commissioning Pos: 14.56 /Überschriften/Überschriften 2/K-O/Montage Schlauchhalter @ 32\mod_1253538064080_78.docx @ 314638 @ 33 @ 1 Hose holder assembly Pos: 14.57 /BA/Erstinbetriebnahme/Rundballenpresse/Bild Befestigungsmaterial @ 32\mod_1253535577392_78.docx @ 314511 @ 2 @ 1 RBV01080 Fig. 35 Pos: 14.58 /BA/Erstinbetriebnahme/Rundballenpresse/Montage Befestigungsmaterial @ 32\mod_1253535783611_78.docx @ 314534 @ @ 1 •...
Page 55: Net Brake
Commissioning Pos: 14.62 /BA/Erstinbetriebnahme/Rundballenpresse/Netzbremse Fortima V 1500 MC @ 32\mod_1253193714019_78.docx @ 313061 @ @ 1 5.5.1 Net brake Fig. 37 Before starting up for the first time, neatly remove the protective tape from the brake surface (1) of the net brake disc (2). Pos: 14.63 /BA/Erstinbetriebnahme/Rundballenpresse/Anbau Beleuchtungsanlage Rundballenpresse Fortima V 1500 @ 116\mod_1341206884138_78.docx @ 1020833 @ @ 1 Attaching the Triangle Spotlights Fortima V 1500 (MC)/Fortima V 1800 (MC)
Page 56: Krone Operation Terminal Beta
KRONE operation terminal Beta Pos: 16.1 /Überschriften/Überschriften 1/K-O/KRONE Bedienterminal Beta @ 54\mod_1291734038125_78.docx @ 514470 @ 2 @ 1 KRONE operation terminal Beta Pos: 16.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Achtung - Bedieneinheit schützen @ 0\mod_1200308247867_78.docx @ 39598 @ @ 1 Caution! - Protect Control Unit.
Page 57: Attachment Of Control Unit
KRONE operation terminal Beta Pos: 16.5 /BA/Info-Center/Ladewagen/Anbau/Anbau Bedieneinheit @ 33\mod_1254829965082_78.docx @ 320172 @ 22 @ 1 Attachment of control unit BPM50390_1 Fig. 40 Mount the control unit with its support (1) where it can be seen by the driver. Direct fastening •...
Page 58: Description Of The Keys
KRONE operation terminal Beta Pos: 16.12 /Überschriften/Überschriften 2/A-E/Beschreibung der Tasten @ 6\mod_1215069821134_78.docx @ 98445 @ @ 1 Description of the keys Pos: 16.13 /BA/Info-Center/Rundballenpresse/Übersicht/Beschreibung der Tasten 1-8_Fortima_Bild @ 252\mod_1397057135677_78.docx @ 1942838 @ @ 1 Fig. 42 Pos: 16.14 /BA/Info-Center/Rundballenpresse/Übersicht/Beschreibung der Tasten 1-8_Fortima_Text @ 252\mod_1397057177662_78.docx @ 1942867 @ @ 1...
Page 59: Operational Readiness
KRONE operation terminal Beta Pos: 16.16 /Überschriften/Überschriften 2/A-E/Betriebsbereitschaft @ 78\mod_1313048474927_78.docx @ 672856 @ @ 1 Operational Readiness Pos: 16.17 /BA/Info-Center/Rundballenpresse/Übersicht/Betriebsbereitschaft_Einschalten Bedieneinheit @ 185\mod_1379424357442_78.docx @ 1595297 @ @ 1 Switching on • Press the key Pos: 16.18 /BA/Info-Center/Rundballenpresse/Übersicht/Betriebsbereitschaft_Verbindung hergestellt_Bild_Fortima V und F @ 185\mod_1379425050153_78.docx @ 1595603 @ @ 1...
Page 60: Basic Screen
KRONE operation terminal Beta Pos: 16.23.1 /Überschriften/Überschriften 2/F-J/Grundbild @ 50\mod_1287483189546_78.docx @ 471279 @ @ 1 Basic Screen Pos: 16.23.2 /BA/Info-Center/Rundballenpresse/Grundbild/Hinweis - Grafiken und Symbole richten sich nach der Ausstattung der Maschine @ 186\mod_1379942599304_78.docx @ 1604995 @ @ 1 Note Graphics and symbols that are available depend on the equipment of the machine. The displayed graphics and symbols are not shown permanently.
Page 61: Selecting Manual Or Automatic Mode
KRONE operation terminal Beta Pos: 16.23.7 /Überschriften/Überschriften 3/F-J/Hand- oder Automatikbetrieb einstellen @ 186\mod_1380002466289_78.docx @ 1606045 @ 2233 @ 1 Selecting manual or automatic mode Pos: 16.23.8 /BA/Info-Center/Rundballenpresse/Grundbild/Hand- oder Automatikbetrieb einstellen @ 250\mod_1396882958015_78.docx @ 1935805 @ 33 @ 1 After switching on control terminal, operating mode “Manual mode” is set by default.
Page 62: Displays In The Main Window
KRONE operation terminal Beta Pos: 16.23.12 /Überschriften/Überschriften 3/A-E/Anzeigen im Hauptfenster @ 69\mod_1305104621940_78.docx @ 633845 @ @ 1 6.5.2 Displays in the Main Window Pos: 16.23.13 /BA/Info-Center/Rundballenpresse/Grundbild/Anzeigen im Hauptfenster_Bild variable und feste Ballenkammer_Fortima @ 186\mod_1379941011359_78.docx @ 1604907 @ @ 1 120/120 cm 48/50 % Fig.
Page 63 KRONE operation terminal Beta Pos: 16.23.15 /BA/Info-Center/Rundballenpresse/Grundbild/Anzeigen im Hauptfenster_Fahrtrichtung @ 186\mod_1379929071082_78.docx @ 1602561 @ @ 1 Symbol Meaning Information Due to uneven filling, the bale is Correcting direction of travel to the thicker on one side. left The size of the arrow and the number...
Page 64: Messages
KRONE operation terminal Beta Pos: 16.23.20 /Überschriften/Überschriften 3/K-O/Meldungen @ 64\mod_1300188087828_78.docx @ 582130 @ 33 @ 1 6.5.3 Messages Pos: 16.23.21 /BA/Info-Center/Rundballenpresse/Meldungen/Infomeldung @ 33\mod_1255007589312_78.docx @ 321443 @ @ 1 Information message The information message will appear only, if the main operation display has been set. The message will disappear automatically, when the cause for the information message has been removed.
Page 65: Setting Bale Firmness
KRONE operation terminal Beta Pos: 16.23.24.1 /Überschriften/Überschriften 3/A-E/Ballenfestigkeit einstellen @ 185\mod_1379568677694_78.docx @ 1597412 @ 3 @ 1 6.5.4 Setting Bale Firmness Pos: 16.23.24.2 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F @ 252\mod_1397144815201_0.docx @ 1946747 @ @ 1 Fortima F Pos: 16.23.24.3 /BA/Info-Center/Rundballenpresse/Grundbild aufrufen @ 185\mod_1379579129420_78.docx @ 1598025 @ @ 1 Pressing the key twice brings up the basic screen.
Page 66: Setting Bale Diameter
KRONE operation terminal Beta Pos: 16.23.24.8 /Überschriften/Überschriften 3/A-E/Ballendurchmesser einstellen @ 185\mod_1379568590086_78.docx @ 1597384 @ 33 @ 1 6.5.5 Setting Bale Diameter Pos: 16.23.24.9 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V @ 252\mod_1397144853712_0.docx @ 1946775 @ 3 @ 1 Fortima V Pos: 16.23.24.10 /BA/Info-Center/Rundballenpresse/Grundbild aufrufen @ 185\mod_1379579129420_78.docx @ 1598025 @ @ 1 Pressing the key twice brings up the basic screen.
Page 67: Menu Level
KRONE operation terminal Beta Pos: 16.25 /Überschriften/Überschriften 2/K-O/Menüebene Kurzüberblick @ 33\mod_1255074316915_78.docx @ 321525 @ 33 @ 1 Menu Level 6.6.1 Short overview Pos: 16.26 /BA/Info-Center/Rundballenpresse/Menuführung/Menüebene Kurzüberblick Fortima V 1500 MC @ 79\mod_1315205008057_78.docx @ 700172 @ 33 @ 1 1-8-1 1-8-3 FOR00028 Fig.
Page 68: Bringing Up A Menu Level
KRONE operation terminal Beta Pos: 16.28 /Überschriften/Überschriften 3/K-O/Menüebene aufrufen @ 33\mod_1255076738228_78.docx @ 321575 @ 33 @ 1 6.6.2 Bringing up a Menu Level Pos: 16.29 /BA/Info-Center/Rundballenpresse/Menuführung/Menüebene aufrufen Fortima Beta @ 252\mod_1397225225893_78.docx @ 1947938 @ @ 1 122/122 cm RPK50013_2 Fig. 51 Press the key (1).
Page 69: Main Menu 1 "Settings
KRONE operation terminal Beta Pos: 16.32.1 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Hauptmenü „Einstellungen“ @ 79\mod_1315210362801_78.docx @ 700483 @ 3333 @ 1 Main menu 1 "Settings" Fig. 52 • to call the menu level. • Use the keys to select main menu 1 . The icon is shown inversed.
Page 70: Menu 1-1 "Contrast
KRONE operation terminal Beta Pos: 16.32.3 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-1 Kontrast @ 186\mod_1380005272970_78.docx @ 1606323 @ 3333 @ 1 6.7.1 Menu 1-1 "Contrast" Fig. 53 The display contrast can be set in the menu. Displaying the menu Main menu 1 "Settings" appears: •...
Page 71: Menu 1-3 "Number Of Net Winds
KRONE operation terminal Beta Pos: 16.32.7 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-3 „Anzahl der Netzwicklungen“ Fortima @ 123\mod_1344933867483_78.docx @ 1125020 @ @ 1 6.7.2 Menu 1-3 "Number of Net Winds" Fig. 54 Displaying the menu Main menu 1 "Settings" appears: • You can select menu 1-3 with the keys.
Page 72: Menu 1-4 „Sensitivity Of Direction Display
KRONE operation terminal Beta Pos: 16.32.11 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-4 „Empfindlichkeit Richtungsanzeige“ Fortima @ 187\mod_1380012604792_78.docx @ 1606664 @ @ 1 6.7.3 Menu 1-4 „Sensitivity of Direction Display“ Fig. 55 Calling the menu Main menu 1 “Settings” is called. • Select menu 1-4 by using keys, the symbol is shown in reverse colours.
Page 73 KRONE operation terminal Beta Pos: 16.32.14 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-4 „Empfindlichkeit-Richtungsanzeige“_Hinweis - Rollboden wird geschont @ 186\mod_1380011213937_78.docx @ 1606640 @ @ 1 Note An even filling of the bale chamber ensures optimally shaped bales and additionally protects the floor conveyor chains of the machine. Therefore it is recommended to set the sensitivity of direction display.
Page 74: Menu 1-5 „Pre-Signalling
KRONE operation terminal Beta Pos: 16.32.18 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-5 „Vorsignalisierung“ Fortima V und F @ 187\mod_1380030804098_78.docx @ 1607968 @ 33 @ 1 6.7.4 Menu 1-5 „Pre-Signalling" Fig. 57 Note Pre-signalling indicates how far in advance it is signaled that the setpoint value –...
Page 75 KRONE operation terminal Beta Setting pre-signalling: Fortima F Fortima V The value is displayed as percentage. The value is displayed in cm. Fig. 58 • key to set the desired deceleration, the symbol in the upper line goes out. •...
Page 76: Menu 1-6 „Correction Filling
KRONE operation terminal Beta Pos: 16.32.22 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-6 „Korrektur Befüllung“ Fortima V und F @ 187\mod_1380031431960_78.docx @ 1608026 @ @ 1 6.7.5 Menu 1-6 „Correction Filling" Fig. 59 If bale diameter or bale firmness is not reached or if it is too high, bale diameter or bale firmness can be corrected in a predefined range via menu 1-6 “Correction Filling”.
Page 77 KRONE operation terminal Beta Correcting filling Fortima F Fortima V Bale firmness: -10 % to +10 % Bale diameter: -10 cm to +10 cm +10cm 100 % -10cm Fig. 60 • Increase or reduce the desired value by using key, the symbol goes out in the upper line.
Page 78: Menu 1-7 "Select Type Of Tying
KRONE operation terminal Beta Pos: 16.32.25 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-7 „Auswahl Bindeart“ @ 79\mod_1315211698534_78.docx @ 700678 @ @ 1 6.7.6 Menu 1-7 "Select type of tying" Fig. 61 Displaying the menu Main menu 1 "Settings" appears: • You can select menu 1-7 with the keys.
Page 79 KRONE operation terminal Beta Setting the type of tying Net Wrapping Twine tying Fig. 62 • You can use the key to adjust the type of tying. The icon in the top line goes out. • Press the key. The set type of tying is saved and the icon appears in the upper line.
Page 80: Menu 1-8 "Number Of Twine Wraps (Only For Twine Tying With Magnetic Transmission)
KRONE operation terminal Beta Pos: 16.32.28 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-8 „Anzahl Garnumwicklungen“ Fortima @ 79\mod_1315212000326_78.docx @ 700706 @ @ 1 6.7.7 Menu 1-8 "Number of twine wraps (only for twine tying with magnetic transmission)" 1-8-1 Fig. 63 Use menu 1-8 "Number of twine wraps" to enter the number of twine wraps (only for twine tying with magnetic transmission).
Page 81: Menu 1-8-1 „Inserting Twine Wraps
KRONE operation terminal Beta Pos: 16.32.30 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-8-1 „Garnumwicklungen einschießen“ Fortima @ 119\mod_1342074253304_78.docx @ 1068520 @ @ 1 6.7.8 Menu 1-8-1 „Inserting Twine Wraps" 1-8-1 1-8-1 Fig. 64 Calling the Menu Main menu 8-1 “Number of Twine Wraps” is active.
Page 82: Menu 1-8-3 „Cutting Off Twine Wraps
KRONE operation terminal Beta Pos: 16.32.34 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-8-3 „Garnumwicklungen abschneiden“ Fortima @ 119\mod_1342074364565_78.docx @ 1068579 @ @ 1 6.7.9 Menu 1-8-3 „Cutting Off Twine Wraps " 1-8-3 1-8-3 Fig. 65 Calling the Menu Main menu 8-1 “Number of Twine Wraps” is active.
Page 83: Menu 1-9 „Tying Start Delay
KRONE operation terminal Beta Pos: 16.32.38 /BA/Info-Center/Rundballenpresse/Hauptmenü 1 Einstellungen/Menü 1-9 „Bindestartverzögerung“_Fortima V und F @ 187\mod_1380026614793_78.docx @ 1607852 @ @ 1 6.7.10 Menu 1-9 „Tying Start Delay" 2,5 s Fig. 66 Calling the menu Main menu 1 “Settings” is called.
Page 84: Main Menu 2 "Counters
KRONE operation terminal Beta Pos: 16.34.1 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Hauptmenü 2 Zähler Bild @ 33\mod_1255332453804_78.docx @ 321931 @ @ 1 Main menu 2 "Counters" Fig. 67 Pos: 16.34.2 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Hauptmenü 2 Zähler @ 33\mod_1255332388835_78.docx @ 321906 @ @ 1 Calling the main menu •...
Page 85: Menu 2-1 "Customer Counters
KRONE operation terminal Beta Pos: 16.34.4 /Überschriften/Überschriften 3/K-O/Menü 2-1 Kundenzähler @ 34\mod_1255338699351_78.docx @ 322235 @ @ 1 6.8.1 Menu 2-1 "Customer counters" Pos: 16.34.5 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Bild Menü 2-1 Kundenzähler @ 33\mod_1255333033288_78.docx @ 322006 @ @ 1 Fig. 68 Pos: 16.34.6 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 ZählerMenü 2-1 Kundenzähler (2014-04-17 16:57:56) @ 187\mod_1380027434808_78.docx @ 1607914 @ @ 1 Opening the menu Main menu 2 "Counter"...
Page 86 KRONE operation terminal Beta Pos: 16.34.8 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Menü 2-1 Kundenzähler aktivieren @ 33\mod_1255334579523_78.docx @ 322031 @ @ 1 Fig. 69 Activating customer counter • You can use the keys to bring up the desired customer counter. It appears in the top line.
Page 87: Menu 2-2 "Total Bale Counter
KRONE operation terminal Beta Pos: 16.34.11 /Überschriften/Überschriften 3/K-O/Menü 2-2 Gesamtballenzähler @ 33\mod_1255337780148_78.docx @ 322135 @ @ 1 6.8.2 Menu 2-2 "Total bale counter" Pos: 16.34.12 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Bild Menü 2-2 Gesamtballenzähler @ 33\mod_1255337554304_78.docx @ 322110 @ @ 1 Fig. 70 Pos: 16.34.13 /BA/Info-Center/Rundballenpresse/Hauptmenü...
Page 88 KRONE operation terminal Beta Pos: 16.34.15 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Bild Saisonzähler löschen @ 34\mod_1255338614304_78.docx @ 322210 @ 3 @ 1 Fig. 71 Pos: 16.34.16 /BA/Info-Center/Rundballenpresse/Hauptmenü 2 Zähler/Saisonzähler 1 löschen @ 187\mod_1380113706477_78.docx @ 1609802 @ @ 1 Delete season counter 1 •...
Page 89: Main Menu 3 „Manual Operation
KRONE operation terminal Beta Pos: 16.36.1 /Überschriften/Überschriften 2/F-J/Hauptmenü 3 Handbedienung @ 55\mod_1292224852765_78.docx @ 517684 @ @ 1 Main menu 3 „Manual operation“ Pos: 16.36.2 /BA/Info-Center/Rundballenpresse/Hauptmenü 3 Handbedienung/Hinweis - Motor kann manuell ein- und ausgefahren werden @ 187\mod_1380108756889_78.docx @ 1609117 @ @ 1 Note The "Manual operation"...
Page 90 KRONE operation terminal Beta Pos: 16.36.6 /BA/Info-Center/Rundballenpresse/Hauptmenü 3 Handbedienung/Bild Untermenü Handbedienung @ 55\mod_1292225705375_78.docx @ 517738 @ @ 1 Fig. 73 Pos: 16.36.7 /BA/Info-Center/Rundballenpresse/Hauptmenü 3 Handbedienung/aktuelle Zustände @ 58\mod_1296570675596_78.docx @ 552262 @ @ 1 • The display shows menu level 3 "Manual operation".
Page 91: Main Menu 4 "Service
KRONE operation terminal Beta Pos: 16.38.1 /Überschriften/Überschriften 2/F-J/Hauptmenü 4 Service @ 34\mod_1255339497523_78.docx @ 322336 @ @ 1 6.10 Main menu 4 "Service" Pos: 16.38.2 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Hauptmenü 4 Service Bild @ 34\mod_1255339598616_78.docx @ 322361 @ @ 1 Fig. 74 Pos: 16.38.3 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Hauptmenü 4 Service Fortima @ 251\mod_1397042025589_78.docx @ 1941381 @ 33 @ 1 Calling the main menu •...
Page 92: Menu 4-2 "Manual Sensor Test
KRONE operation terminal Beta Pos: 16.38.5 /Überschriften/Überschriften 3/K-O/Menü 4-2 Sensortest Hand @ 34\mod_1255414500878_78.docx @ 322861 @ 33 @ 1 6.10.1 Menu 4-2 "Manual Sensor Test" Pos: 16.38.6 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Menü 4-2 Sensortest Hand @ 187\mod_1380114678068_78.docx @ 1610095 @ 3 @ 1 RPK50508 Fig.
Page 93 KRONE operation terminal Beta Pos: 16.38.11 /BA/Info-Center/Sensoren/Diagnose Namursensoren @ 19\mod_1238072125300_78.docx @ 214095 @ @ 1 Diagnostics – Namur sensors Pos: 16.38.12 /BA/Info-Center/Sensoren/Mögliche Sensoren (je nach Ausstattung der Maschine) @ 19\mod_1238071336628_78.docx @ 214010 @ @ 1 Possible sensors (depending on how the machine is equipped) Pos: 16.38.13 /BA/Info-Center/Rundballenpresse/Hauptmenü...
Page 94 KRONE operation terminal Beta Pos: 16.38.22 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V @ 252\mod_1397144853712_0.docx @ 1946775 @ 2 @ 1 Fortima V Pos: 16.38.23 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Sensor B9/B10 Ballendurchmesser einstellen _ Fortima V Beta @ 102\mod_1331219317475_78.docx @ 904341 @ @ 1 Sensor B9/B10 Adjusting the bale diameter: Fig.
Page 95 KRONE operation terminal Beta Pos: 16.38.25 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F @ 252\mod_1397144815201_0.docx @ 1946747 @ @ 1 Fortima F Pos: 16.38.26 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Sensor B9/B10 Ballenfestigkeit einstellen _ Fortima F Beta @ 251\mod_1397035371028_78.docx @ 1940285 @ @ 1 Setting sensor B9/B10 bale firmness FOR00050_1 Fig.
Page 96 KRONE operation terminal Beta Pos: 16.38.28 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Diagnose Versorgungsspannungen @ 34\mod_1255419287566_78.docx @ 323036 @ @ 1 Diagnostics – power supply voltages Fig. 78 Pos: 16.38.29 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Menü 4-2 „Sensortest Hand“ > Versorgungsspannung aufrufen @ 251\mod_1397036014682_78.docx @ 1940953 @ @ 1 Calling the menu Main menu 4 “Service”...
Page 97: Menu 4-4 "Manual Actuator Test
KRONE operation terminal Beta Pos: 16.38.32 /BA/Sicherheit/7. Gefahrenhinweise alt/Gefahr - Aktortest @ 47\mod_1285134152781_78.docx @ 455729 @ 33 @ 1 Danger! - Unexpected actions on the machine. Effect: Danger to life or serious injuries. • Only persons familiar with the machine are permitted to perform the actuator test •...
Page 98 KRONE operation terminal Beta Pos: 16.38.36 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Bild Diagnose digitale Aktoren @ 34\mod_1255420082081_78.docx @ 323111 @ @ 1 Diagnostics – digital actuators Fig. 80 Pos: 16.38.37 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Diagnose digitale Aktoren @ 34\mod_1255420229050_78.docx @ 323136 @ @ 1 Errors are only displayed if the actuator is turned on and a test is possible for the actuator (see the table called "Possible digital actuators").
Page 99 KRONE operation terminal Beta Pos: 16.38.42 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Mögliche Motoren (je nach Ausstattung der Maschine) @ 34\mod_1255422731331_78.docx @ 323186 @ @ 1 Possible motors (depending on how the machine is equipped) Pos: 16.38.43 /BA/Info-Center/Rundballenpresse/Hauptmenü 4 Service/Mögliche Motoren Fortima, Comprima @ 250\mod_1396970768938_78.docx @ 1938542 @ @ 1 Fig.
Page 100: Main Menu 5 "Info
KRONE operation terminal Beta Pos: 16.40 /BA/Info-Center/Rundballenpresse/Hauptmenü 5 Info/Hauptmenü 5 Info Bild Fortima @ 122\mod_1344432465074_78.docx @ 1115896 @ @ 1 6.11 Main menu 5 "Info" Fig. 82 Pos: 16.41 /BA/Info-Center/Rundballenpresse/Hauptmenü 5 Info/Hauptmenü 5 Info @ 79\mod_1315230506158_78.docx @ 701771 @ 22 @ 1 Calling the main menu •...
Page 101: Main Menu 6 „Technician
KRONE operation terminal Beta Pos: 16.43 /Überschriften/Überschriften 2/F-J/Hauptmenü 6 Monteur @ 78\mod_1313050883963_78.docx @ 675374 @ 22 @ 1 6.12 Main Menu 6 „Technician“ Pos: 16.44 /BA/Info-Center/Rundballenpresse/Hauptmenü 6 Monteur/Hauptmenü 6 Monteur @ 34\mod_1255438908347_78.docx @ 323489 @ @ 1 Calling the main menu •...
Page 102: Alarm Messages
KRONE operation terminal Beta Pos: 16.46.1 /Überschriften/Überschriften 2/A-E/Alarmmeldungen @ 19\mod_1238572457463_78.docx @ 221082 @ @ 1 6.13 Alarm messages Pos: 16.46.2 /BA/Info-Center/Rundballenpresse/Alarmmeldungen/Akustische Signale @ 34\mod_1255441647925_78.docx @ 323611 @ @ 1 Audio signals Continuous tone Short interval Medium interval Long interval Wrapping is triggered...
Page 103: Note And Messages
KRONE operation terminal Beta Pos: 16.46.4 /Überschriften/Überschriften 3/F-J/Hinweise und Meldungen @ 34\mod_1255441383706_78.docx @ 323591 @ 33 @ 1 6.13.1 Note and messages Pos: 16.46.5 /BA/Info-Center/Rundballenpresse/Alarmmeldungen/1) Hinweise und Meldungen @ 57\mod_1296211399812_78.docx @ 549980 @ @ 1 Screen Acoustic signal Description Maximum filling has been reached...
Page 104: Physical Messages
KRONE operation terminal Beta Pos: 16.46.7 /Überschriften/Überschriften 3/P-T/Physikalische Meldungen @ 34\mod_1255442189285_78.docx @ 323664 @ @ 1 6.13.2 Physical messages Pos: 16.46.8 /BA/Info-Center/Rundballenpresse/Alarmmeldungen/2) Physikalische Meldungen_Fortima V und F @ 251\mod_1396972307863_78.docx @ 1938596 @ @ 1 Figure Acoustic signal Description Sensor for “bale diameter left”...
Page 105: General Messages
KRONE operation terminal Beta Pos: 16.46.10 /Überschriften/Überschriften 3/A-E/Allgemeine Meldungen @ 34\mod_1255443656238_78.docx @ 323714 @ @ 1 6.13.3 General Messages Pos: 16.46.11 /BA/Info-Center/Rundballenpresse/Alarmmeldungen/3) Allgemeine Meldungen @ 34\mod_1255443585941_78.docx @ 323685 @ @ 1 Figure Acoustic signal Description – Fuse in job computer is defective.
Page 106: Krone Isobus Terminal
KRONE ISOBUS Terminal Pos: 18.1 /Überschriften/Überschriften 1/K-O/KRONE ISOBUS-Terminal @ 185\mod_1379578612990_78.docx @ 1598079 @ @ 1 KRONE ISOBUS Terminal Pos: 18.2 /BA/Info-Center/CCI-ISOBUS-Terminal/Hinweis Im weiteren Verlauf Terminal auch als Bedieneinheit bezeichnet @ 46\mod_1281680416671_78.docx @ 445465 @ @ 1 Note In the operating instructions which follow, the terminal will also be referred to as the "control unit".
Page 107: Installing The Terminal Into Cabin
KRONE ISOBUS Terminal Pos: 18.6 /Überschriften/Überschriften 2/P-T/Terminal in Kabine einbauen @ 47\mod_1285163419265_78.docx @ 455855 @ 32 @ 1 Installing the terminal into cabin Pos: 18.7 /BA/Info-Center/CCI-ISOBUS-Terminal/Hinweis für den Anbau des Terminals, in die Traktorkabine... @ 47\mod_1285163596984_78.docx @ 455881 @ @ 1...
Page 108: Isobus Short Cut Button
KRONE ISOBUS Terminal Pos: 18.9.1 /Überschriften/Überschriften 2/F-J/ISOBUS Short Cut Button @ 47\mod_1285564773000_78.docx @ 456410 @ @ 1 ISOBUS Short Cut Button Pos: 18.9.2 /BA/Info-Center/CCI-ISOBUS-Terminal/Module für Beipack/ISOBUS Short Cut ButtonISOBUS Short Cut Button_2 Gefahr @ 46\mod_1282643782875_78.docx @ 447376 @ 2 @ 1 DANGER! –...
Page 109: Display / Touchscreen
KRONE ISOBUS Terminal Pos: 18.9.5 /BA/Info-Center/CCI-ISOBUS-Terminal/Module für Beipack/ISOBUS Short Cut ButtonISOBUS Short Cut Button_wird gelöst @ 120\mod_1342516466580_78.docx @ 1088224 @ 33 @ 1 If the ISOBUS short cut button is deactivated again, the following message will appear in the display: CC000071 Fig.
Page 110: Connecting The Terminal (On Tractors With Integrated Isobus System)
Note The terminal is connected to the tractor via a special cable set (5) which can be ordered by stating the KRONE article no. 20 081 223 0. • Connect plug (2) of cable set (5) with socket (1) (CAN1-IN) of the terminal.
Page 111: Connecting The Terminal (On Tractors Without Isobus System)
KRONE ISOBUS Terminal Pos: 18.16 /BA/Info-Center/CCI-ISOBUS-Terminal/Terminal anschließen (ohne ISO Schlepper) @ 43\mod_1274882231640_78.docx @ 387925 @ 3333 @ 1 7.2.3 Connecting the terminal (on tractors without ISOBUS system) Fig. 89 Connection terminal to machine Note The connection of terminal to machine takes place via a provided cable set (5) (article no.
Page 112: Switching The Terminal On / Off When The Machine Is Not Connected
KRONE ISOBUS Terminal Pos: 18.18 /Überschriften/Überschriften 3/A-E/Ein- Ausschalten des Terminals bei nicht angeschlossener Maschine @ 43\mod_1275290766562_78.docx @ 389835 @ 33 @ 1 7.2.4 Switching the terminal on / off when the machine is not connected Pos: 18.19 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Ein- Ausschalten Bild mit nicht angeschlossener Maschine @ 43\mod_1275291241781_78.docx @ 389860 @ @ 1 Fig.
Page 113: Switching The Terminal On / Off When The Machine Is Connected
KRONE ISOBUS Terminal Pos: 18.23 /Überschriften/Überschriften 3/A-E/Ein- Ausschalten des Terminals bei angeschlossener Maschine @ 43\mod_1274866210140_78.docx @ 387724 @ @ 1 7.2.5 Switching the terminal on / off when the machine is connected Pos: 18.24 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Ein- Ausschalten Bild bei angeschlossener Maschine Fortima @ 80\mod_1315316751793_78.docx @ 702854 @ 3 @ 1 CC000464 Fig.
Page 114: Basic Screen
KRONE ISOBUS Terminal Pos: 18.31 /Überschriften/Überschriften 2/F-J/Grundbild @ 50\mod_1287483189546_78.docx @ 471279 @ @ 1 Basic Screen Pos: 18.32 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Grundbild @ 50\mod_1287482211765_78.docx @ 471174 @ 3 @ 1 CC000201 Fig.94 Pos: 18.33 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Statuszeile (I) oberste Zeile @ 50\mod_1287482314484_78.docx @ 471199 @ @ 1...
Page 115 KRONE ISOBUS Terminal Pos: 18.35 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Beschreibung der Grafiken (II) für Funktionstasten(F1 bis F6) @ 50\mod_1287482628656_78.docx @ 471224 @ @ 1 Description of the symbols (II) for the function keys (F1 to F6) Net feeding manual mode Net is fed when actuating the function key...
Page 116 KRONE ISOBUS Terminal Pos: 18.37 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Grundbild @ 50\mod_1287482211765_78.docx @ 471174 @ @ 1 CC000201 Fig.95 Pos: 18.38 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Anzeigen im Hauptfenster (III) je nach Ausstattung Fortima @ 80\mod_1315317530442_78.docx @ 702931 @ @ 1 Displays on the main window (III) (depending on the machine configuration)
Page 117: Setting The Setpoint Bale Firmness
KRONE ISOBUS Terminal Pos: 18.40 /Überschriften/Überschriften 3/A-E/Einstellen der Soll-Ballenfestigkeit @ 117\mod_1341219335997_78.docx @ 1021287 @ @ 1 7.3.1 Setting the Setpoint Bale Firmness Pos: 18.41 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F @ 252\mod_1397144815201_0.docx @ 1946747 @ @ 1 Fortima F Pos: 18.42 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Einstellen der Soll-Ballenfestigkeit Text @ 117\mod_1341217455785_78.docx @ 1021218 @ @ 1...
Page 118: Setting The Target Bale Diameter
KRONE ISOBUS Terminal Pos: 18.45 /Überschriften/Überschriften 3/A-E/Einstellen des Soll_Ballendurchmessers @ 117\mod_1341219444164_78.docx @ 1021315 @ @ 1 7.3.1 Setting the Target Bale Diameter Pos: 18.46 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V @ 252\mod_1397144853712_0.docx @ 1946775 @ @ 1 Fortima V Pos: 18.47 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Grundbild/Einstellen des Soll-Ballendurchmessers Text @ 117\mod_1341219582258_78.docx @ 1021343 @ @ 1 Fig.
Page 119: Messages
KRONE ISOBUS Terminal Pos: 18.50 /Überschriften/Überschriften 2/K-O/Meldungen @ 33\mod_1255007717750_78.docx @ 321468 @ @ 1 Messages Pos: 18.51 /BA/Info-Center/Rundballenpresse/Meldungen/Infomeldung @ 33\mod_1255007589312_78.docx @ 321443 @ @ 1 Information message The information message will appear only, if the main operation display has been set. The message will disappear automatically, when the cause for the information message has been removed.
Page 120: Menu Level
KRONE ISOBUS Terminal Pos: 18.54 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Menüebene Kurzüberblick Maschine Fortima @ 114\mod_1338965821086_78.docx @ 1007685 @ @ 1 Menu Level 7.5.1 Short Overview CC000491 Fig. 99 Settings Manual operation Service Number of net wrappings Sensitivity of direction display Manual sensor test Pre-signalling...
Page 121: Calling Up The Menu Level
KRONE ISOBUS Terminal Pos: 18.56 /Überschriften/Überschriften 2/K-O/Menüebene aufrufen @ 44\mod_1275977054046_78.docx @ 394176 @ @ 1 7.5.2 Calling up the menu level Pos: 18.57 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Menüebene aufrufen Bild @ 50\mod_1287554961625_78.docx @ 472210 @ 3 @ 1 CC000207 Fig.100 Pos: 18.58 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Menüebene aufrufen CCI @ 43\mod_1275299708140_78.docx @ 390706 @ @ 1...
Page 122: Main Menu 1 „Settings
KRONE ISOBUS Terminal Pos: 18.61 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Hauptmenü 1 "Einstellungen" Fortima @ 252\mod_1397066265409_78.docx @ 1943525 @ @ 1 Main Menu 1 „Settings“ CC000463 Fig. 101 • By pressing the function key in the basic screen you get into the menu level of the machine •...
Page 123: Menu 1-3 "Number Of Net Winds
KRONE ISOBUS Terminal Pos: 18.63 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-3 Anzahl Netzwicklungen Fortima @ 79\mod_1315297590539_78.docx @ 702026 @ @ 1 7.6.1 Menu 1-3 "Number of net winds" CC000208 CC000456 Fig. 102 Calling the menu Main menu 1 "Settings" appears. • Press function key to select menu 1-3 .
Page 124: Menu 1-4 "Sensitivity Of Direction Display
KRONE ISOBUS Terminal Pos: 18.65 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-4 Empfindlichkeit Richtungsanzeige Fortima @ 80\mod_1315383492099_78.docx @ 703343 @ @ 1 7.6.2 Menu 1-4 "Sensitivity of direction display" CC000211 Fig. 103 Setting the sensitivity of the direction display Calling the menu Main menu 1 "Settings" appears.
Page 125: Menu 1-5 „Pre-Signalling
KRONE ISOBUS Terminal Pos: 18.68 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-5 Vorsignalisierung Fortima V und F @ 251\mod_1396976481157_78.docx @ 1938688 @ @ 1 7.6.3 Menu 1-5 „Pre-Signalling" CC000212 Fig. 104 Note Pre-signalling indicates how far in advance it is signaled that the setpoint value –...
Page 126 KRONE ISOBUS Terminal Setting pre-signalling: Fortima F Fortima V The value is displayed as percentage. The value is displayed in cm. CC000234 CC000213 Fig. 105 • Set the desired time delay by using function keys , symbol in the upper line goes out •...
Page 127: Menu 1-6 „Filling Correction
KRONE ISOBUS Terminal Pos: 18.71 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-6 Korrektur Befüllung Fortima V und F @ 117\mod_1341221756477_78.docx @ 1021551 @ @ 1 7.6.4 Menu 1-6 „Filling Correction" CC000214 Fig. 106 Note If the bale size or firmness is too great or not great enough, bale size and firmness can be corrected within a predefined range via menu 1-6 "Filling Correction".
Page 128 KRONE ISOBUS Terminal The values can be corrected in the following areas: Fortima F Fortima V Bale firmness: -10 % to +10 % Bale size: -10 cm to +10 cm CC000215 Fig. 107 • Increase or reduce the desired value by using function key...
Page 129: Menu 1-7 "Select Type Of Tying
KRONE ISOBUS Terminal 7.6.5 Menu 1-7 "Select type of tying" Fig. 108 Calling the menu Main menu 1 "Settings" appears. • Press function key to select menu 1-7 . The icon is colour highlighted • Press function key The display shows menu 1-7 "Type of tying".
Page 130: Menu 1-8 „Number Of Twine Wraps
KRONE ISOBUS Terminal Pos: 18.75 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-8 Anzahl Garnumwicklungen Fortima @ 117\mod_1341223233034_78.docx @ 1021606 @ @ 1 7.6.6 Menu 1-8 „Number of Twine Wraps" CC000459 CC000460 Fig. 110 The number of twine wraps can be entered via menu 1-8 “Number of Twine Wraps”.
Page 131: Menu 1-9 „Tying Start Delay
KRONE ISOBUS Terminal Pos: 18.77 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 1 Einstellungen/Menü 1-9 Bindestartverzögerung Fortima V und F @ 251\mod_1396977096007_78.docx @ 1938746 @ 2222 @ 1 7.6.7 Menu 1-9 „Tying Start Delay" CC000216 CC000754 Fig. 111 Calling the menu Main menu 1 “Settings” is called.
Page 132: Main Menu 2 "Counters
KRONE ISOBUS Terminal Main menu 2 "Counters" CC000219 Fig. 112 Calling the main menu • Press function key to access the menu level via the basic screen • Press function key to select main menu 2 . The symbol is highlighted in grey.
Page 133: Menu 2-1 „Customer Counter
KRONE ISOBUS Terminal Pos: 18.81 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 2 Zähler/Menü 2-1 Kundenzähler Fortima @ 251\mod_1396977879179_78.docx @ 1938833 @ 32 @ 1 7.7.1 Menu 2-1 „Customer Counter“ CC000219 Fig. 113 Calling the menu Main menu 2 “Counters” is called • Select menu 2-1...
Page 134 KRONE ISOBUS Terminal Pos: 18.83 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 2 Zähler/Kundenzähler aktivieren @ 50\mod_1287562757875_78.docx @ 473074 @ @ 1 Activating customer counters Fig.114 • Press function key to select the desired customer counter and activate by pressing the function key . The desired customer counter (in this case customer counter 1) is highlighted in grey.
Page 135: Menu 2-2 „Total Bale Counter
KRONE ISOBUS Terminal Pos: 18.85 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 2 Zähler/Menü 2-2 Gesamtballenzähler Fortima @ 251\mod_1396978147508_78.docx @ 1938862 @ @ 1 7.7.2 Menu 2-2 „Total Bale Counter“ CC000871 Fig. 115 Calling the menu Main menu 2 “Counters” is called • Select menu 2-2...
Page 136: Main Menu 3 "Manual Operation
KRONE ISOBUS Terminal Pos: 18.87 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 3 Handbedienung/Hauptmenü 3 Handbedienung Fortima @ 79\mod_1315303627750_78.docx @ 702483 @ @ 1 Main menu 3 "Manual operation" CC000461 Fig. 116 Calling the menu • Press function key to access the menu level via the basic screen •...
Page 137: Menu 3-2 "Position Of Net Motor
KRONE ISOBUS Terminal Pos: 18.89 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 3 Handbedienung/Menü 3-2 Position Netzmotor Fortima @ 80\mod_1315307400996_78.docx @ 702569 @ @ 1 7.8.1 Menu 3-2 "Position of net motor" CC000462 Fig. 117 Calling the menu Main menu 3 "Manual operation" is called •...
Page 138: Main Menu 4 "Service
KRONE ISOBUS Terminal Pos: 18.92 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Hauptmenü 4 Service Fortima @ 80\mod_1315388711418_78.docx @ 703632 @ 3333 @ 1 Main menu 4 "Service" CC000226 Fig.118 Calling the main menu • Press function key to access the menu level via the basic screen •...
Page 139: Menu 4-2 "Manual Sensor Test
KRONE ISOBUS Terminal Pos: 18.94 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Menü 4-2 Sensortest Hand Fortima @ 251\mod_1397023672182_78.docx @ 1939053 @ 3333 @ 1 7.9.1 Menu 4-2 "Manual sensor test" CC000226 Fig.119 In the manual sensor test, the sensors that are installed on the machine are checked for errors.
Page 140 KRONE ISOBUS Terminal Pos: 18.97 /BA/Info-Center/Sensoren/Diagnose Namursensoren @ 19\mod_1238072125300_78.docx @ 214095 @ 2 @ 1 Diagnostics – Namur sensors Pos: 18.98 /BA/Info-Center/Sensoren/Mögliche Sensoren (je nach Ausstattung der Maschine) @ 19\mod_1238071336628_78.docx @ 214010 @ @ 1 Possible sensors (depending on how the machine is equipped) Pos: 18.99 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü...
Page 141 KRONE ISOBUS Terminal Pos: 18.103 /BA/Info-Center/Sensoren/Diagnose analoge Sensoren @ 19\mod_1238132263369_78.docx @ 214965 @ 3 @ 1 Diagnostics – analogue sensors Pos: 18.104 /BA/Info-Center/Sensoren/Einstellwerte analoge Sensoren Hand @ 19\mod_1238132357119_78.docx @ 214994 @ @ 1 Setting values: The bar must be inside the marked area of the bar display.
Page 142 KRONE ISOBUS Terminal Pos: 18.110 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Sensor B9/Sensor B9/B10 Ballendurchmesser einstellen _ Fortima V CCI @ 252\mod_1397136826159_78.docx @ 1946103 @ @ 1 Sensor B9/B10 Setting Bale Diameter (Fortima V) CC000470_1 Fig. 120 Caution! The bale chamber must be closed and empty.
Page 143 KRONE ISOBUS Terminal Pos: 18.112 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Sensor B9/Sensor B9/B10 Ballenfestigkeit einstellen _ Fortima F CCI @ 251\mod_1397027780718_78.docx @ 1939363 @ @ 1 Setting sensor B9/B10 bale firmness (Fortima F) FOR00050_1 CC000325 Fig. 121 Caution! The bale chamber must be open and empty.
Page 144 KRONE ISOBUS Terminal Pos: 18.114 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Diagnose Versorgungsspannung @ 50\mod_1287568818750_78.docx @ 473600 @ @ 1 Diagnostics – power supply voltage Fig. 122 Sensor icon Description power supply voltage Nominal voltages: 12V Ges: 12 - 14,5 V 12V Ter: 12 - 14,5 V...
Page 145: Menu 4-4 Manual Actuator Test
KRONE ISOBUS Terminal Pos: 18.117 /Überschriften/Überschriften 3/K-O/Menü 4-4 Aktortest Hand @ 44\mod_1275637010843_78.docx @ 393380 @ 2233 @ 1 7.9.2 Menu 4-4 Manual actuator test Pos: 18.118 /BA/Sicherheit/7. Gefahrenhinweise alt/Gefahr - Aktortest @ 47\mod_1285134152781_78.docx @ 455729 @ @ 1 Danger! - Unexpected actions on the machine.
Page 146 KRONE ISOBUS Terminal Pos: 18.123 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Menü 4-4 Aktortest Hand - Menü aufrufen/Aktor wählen @ 50\mod_1287570586750_78.docx @ 473735 @ 2 @ 1 Calling the menu Main menu 4 "Service" is called. • Pressing the function key to select Menu 4-4 .
Page 147 KRONE ISOBUS Terminal Pos: 18.126 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 4 Service/Diagnose digitale Aktoren @ 44\mod_1275889088109_78.docx @ 393610 @ @ 1 Diagnostics – digital actuators Errors are only displayed if the actuator is turned on and a test is possible for the actuator (see the table called "Possible digital actuators").
Page 148 KRONE ISOBUS Terminal Pos: 18.132 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 4 Service/Mögliche Motoren Fortima @ 252\mod_1397069933974_78.docx @ 1943754 @ @ 1 Possible engines (depending on how the machine is equipped) CC000247 Fig. 124 • Extend engine by pressing function key . The function is only momentary-action.
Page 149: Main Menu 5 „Information
KRONE ISOBUS Terminal Pos: 18.136 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 5 Info/Hauptmenü 5 Info Fortima @ 115\mod_1338993074015_78.docx @ 1008393 @ @ 1 7.10 Main Menu 5 „Information“ CC000471 Fig. 125 Calling the Main Menu • By pressing the function key in the basic screen you get into the menu level of the machine •...
Page 150: Main Menu 6 Technician
KRONE ISOBUS Terminal Pos: 18.139 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-BiG Pack/Hauptmenüs/Hauptmenü 6 Monteur/Hauptmenü 6 Monteur @ 135\mod_1351678746690_78.docx @ 1203319 @ 33 @ 1 7.11 Main Menu 6 Technician Calling the Main Menu 15-6 0000 054536 CC000051 CC000052_1 Fig. 126 • By pressing function key in the basic screen you get into the menu level •...
Page 151: Main Menu 7 Isobus
KRONE ISOBUS Terminal Pos: 18.141 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Hauptmenü 7 ISOBUS @ 117\mod_1341411944044_78.docx @ 1023651 @ 33 @ 1 7.12 Main Menu 7 ISOBUS Fig. 127 Calling the Main Menu • By pressing the function key from the basic screen you get into the menu level of the machine •...
Page 152: Menu 7-1 Virtual Terminal (Vt)
KRONE ISOBUS Terminal Pos: 18.143 /BA/Info-Center/CCI-ISOBUS-Terminal/Menü 7-1 Virtual Terminal (Fortima)/Menü 7-1 VT @ 118\mod_1341912242598_78.docx @ 1028326 @ @ 1 7.12.1 Menu 7-1 Virtual Terminal (VT) Fig. 128 Calling the Main Menu Main menu 7 “ISOBUS” is called. • Select menu 7-1 (...
Page 153: Menu 7-1-1 Switching Day-Night Lighting Display
KRONE ISOBUS Terminal Pos: 18.146 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-1-1 „Tag-Nacht Umschaltung“ @ 118\mod_1341913621588_78.docx @ 1028444 @ @ 1 7.12.2 Menu 7-1-1 Switching Day-Night Lighting Display Fig. 129 The brightness of the display can be adjusted in the menu “Switching Day-Night Lighting Display”...
Page 154: Menu 7-1-4 Switch To Different Terminal
KRONE ISOBUS Terminal Pos: 18.148 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-1-4 Umschaltung VT @ 213\mod_1390225768211_78.docx @ 1750372 @ @ 1 7.12.3 Menu 7-1-4 Switch to different terminal Note • Menu 7-1-4 only appears if several ISO terminals are connected. • Menu 7-1-4 can be used to switch to the next connected terminal (depending on how many terminals are connected).
Page 155: Menu 7-4 Isobus Diagnostics
KRONE ISOBUS Terminal Pos: 18.150 /Überschriften/Überschriften 2/K-O/Menü 7-4 ISOBUS Diagnose @ 118\mod_1342010523712_78.docx @ 1066831 @ @ 1 7.13 Menu 7-4 ISOBUS Diagnostics Pos: 18.151 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-4 Isobus Diagnose Bild @ 118\mod_1341989823426_78.docx @ 1029983 @ @ 1 CC000324 Fig. 131 Pos: 18.152 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü...
Page 156: Menu 7-4-2 Diagnostics Auxiliary Functions (Aux)
KRONE ISOBUS Terminal Pos: 18.154 /Überschriften/Überschriften 3/K-O/Menü 7-4-2 Diagnose "Auxiliary"-Funktion (AUX) @ 117\mod_1341410143303_78.docx @ 1023355 @ @ 1 7.13.1 Menu 7-4-2 Diagnostics Auxiliary Functions (AUX) Pos: 18.155 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü 7/Menü 7-4-2 Diagnose Aux-Funktion_Bild @ 117\mod_1341410286990_78.docx @ 1023385 @ @ 1 Fig. 132 Pos: 18.156 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Hauptmenü...
Page 157: Alarm Messages
KRONE ISOBUS Terminal Pos: 18.160 /Überschriften/Überschriften 2/A-E/Alarmmeldungen @ 19\mod_1238572457463_78.docx @ 221082 @ 33 @ 1 7.14 Alarm messages Pos: 18.161 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Alarmmeldungen allgemein @ 213\mod_1390226364462_78.docx @ 1750401 @ @ 1 CC000240_1 Fig. 133 Alarm message If a fault occurs on the machine, an alarm message appears in the display and an acoustic signal sounds at the same time (continuous horn).
Page 158: Acoustic Warnings
KRONE ISOBUS Terminal Pos: 18.163 /Überschriften/Überschriften 3/A-E/Akustische Hinweise @ 50\mod_1287572164250_78.docx @ 473885 @ @ 1 7.14.1 Acoustic warnings Pos: 18.164 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Akustische Hinweise @ 50\mod_1287572618250_78.docx @ 473966 @ @ 1 Wrapping is triggered Filling reached, pre-signal reached, wrapping complete, bale chamber closed...
Page 159: Note And Messages
KRONE ISOBUS Terminal Pos: 18.166 /Überschriften/Überschriften 3/F-J/Hinweise und Meldungen @ 34\mod_1255441383706_78.docx @ 323591 @ @ 1 7.14.2 Note and messages Pos: 18.167 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Hinweise und Meldungen @ 115\mod_1339050336859_78.docx @ 1008455 @ @ 1 Symbol Acoustic signal Description The maximum filling has been reached...
Page 160: Physical Messages
KRONE ISOBUS Terminal Pos: 18.169 /Überschriften/Überschriften 3/P-T/Physikalische Meldungen @ 34\mod_1255442189285_78.docx @ 323664 @ @ 1 7.14.3 Physical messages Pos: 18.170 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Physikalische Meldungen Fortima V und F @ 252\mod_1397142643741_78.docx @ 1946660 @ @ 1 Symbol Acoustic signal Description Sensor for “bale diameter left”...
Page 161: General Messages
KRONE ISOBUS Terminal Pos: 18.172 /Überschriften/Überschriften 3/A-E/Allgemeine Meldungen @ 34\mod_1255443656238_78.docx @ 323714 @ @ 1 7.14.4 General Messages Pos: 18.173 /BA/Info-Center/CCI-ISOBUS-Terminal/CCI-Rundballenpressen/Hauptmenüs/Alarmmeldungen/Allgemeine Meldungen @ 50\mod_1287572766734_78.docx @ 474221 @ @ 1 Icon Acoustic signal Description Fuse 2 defective (job computer) Fuse 3 defective (self-repairing)
Page 162: Isobus Operation
The operation of this machine requires at least implementation level 3 of the ISOBUS system. Pos: 20.3 /BA/Info-Center/Iso-Bedienung/Gefahr durch nicht von KRONE gelieferte Terminals / Bedieneinheiten @ 48\mod_1286197403750_78.docx @ 459766 @ 233 @ 1 DANGER! When using terminals and other control units which have not been delivered by KRONE mind that the user: •...
Page 163: Mounting Isobus Terminal
ISOBUS operation Pos: 20.5 /BA/Info-Center/Iso-Bedienung/BigPack/ISO-Bedienung_Anbau @ 252\mod_1397068204319_78.docx @ 1943554 @ 2233 @ 1 Mounting ISOBUS Terminal Fig. 134 CAUTION! Failure of control unit. When installing, make certain that the connection cables are not tight when cornering and that they do not touch the tractor wheels or any other parts of tractor or machine. 8.1.1 Connection Terminal to Tractor Note...
Page 164: Differing Functions To Krone Isobus Terminal Cci
Pos: 20.8 /BA/Info-Center/Iso-Bedienung/Rundballenpressen/Abweichende Funktionen CCI_Terminal_Ballengröße Fortima @ 80\mod_1315396808185_78.docx @ 704134 @ @ 1 Note The values for the "bale size", which are set via the scroll wheel for the KRONE ISOBUS - terminal CCI, are carried out at the ISO terminal via the selection key specified by the ISO terminal (refer to the operating instructions of the ISO terminal manufacturer).
Page 165: Isobus „Auxiliary"-Function (Aux)
ISOBUS operation Pos: 20.11 /Überschriften/Überschriften 1/A-E/ISOBUS „Auxiliary“-Funktion (AUX) @ 48\mod_1286278825265_78.docx @ 460508 @ 2 @ 1 ISOBUS „Auxiliary“-function (AUX) Pos: 20.12 /BA/Info-Center/Iso-Bedienung/Hinweis Terminal die Auxilliary unterstützen @ 48\mod_1286278420671_78.docx @ 460483 @ 1 @ 1 Note There are terminals which support the additional function “auxiliary” (AUX). With this function, programmable keys of the peripheral equipment (e.g.
Page 166: Example Of Joystick Assignment For Fendt (Default Setting)
ISOBUS operation Pos: 20.15 /BA/Info-Center/Iso-Bedienung/Rundballenpressen/Joystick-Belegung bei Fendt (Default-Einstellung) Fortima @ 80\mod_1315397686698_78.docx @ 704222 @ 23 @ 1 8.3.1 Example of joystick assignment for Fendt (default setting) Note For further guidelines, please refer to the operating instructions of the terminal being used. Fig.
Page 167: Start-Up
Start-up Pos: 22.1 /Überschriften/Überschriften 1/F-J/Inbetriebnahme @ 0\mod_1196327075811_78.docx @ 6375 @ @ 1 Start-up Pos: 22.2 /BA/Sicherheit/7. Gefahrenhinweise alt/Inbetriebnahme/Unvorhergesehene Inbetriebnahme Fortima V 1500 MC @ 209\mod_1387357052199_78.docx @ 1724288 @ 33 @ 1 DANGER! - Unintentional starting, moving machine components and / or unexpected machine movement! Effect: Risk of death, injuries or damage to the machine.
Page 168: Mounting Onto The Tractor
Start-up Pos: 22.4 /Überschriften/Überschriften 2/A-E/Anbau an den Traktor @ 0\mod_1199717845194_78.docx @ 34039 @ 33 @ 1 Mounting onto the Tractor Pos: 22.5 /BA/Sicherheit/7. Gefahrenhinweise alt/Großpackenpresse/Gefahr - An-/ Abau der Maschine BiG Pack @ 17\mod_1236256986675_78.docx @ 204111 @ @ 1 DANGER! - Attaching / removing the machine Effect: Danger to life or serious injuries.
Page 169: Hydraulics
Start-up Pos: 22.10 /Überschriften/Überschriften 2/F-J/Hydraulik @ 0\mod_1199776034950_78.docx @ 34205 @ 223 @ 1 Hydraulics Pos: 22.11 /Überschriften/Überschriften 3/P-T/Spezielle Sicherheitshinweise @ 0\mod_1197301069931_78.docx @ 17662 @ 33 @ 1 9.2.1 Special Safety Instructions Pos: 22.12 /BA/Sicherheit/Hydraulik/Warnung - Anschluss der Hydraulikleitungen @ 0\mod_1199776548685_78.docx @ 34225 @ @ 1 Warning ! - Connection of the hydraulic line Effect: severe injuries due to penetration of hydraulic oil under the skin.
Page 170: Connecting The Hydraulic Lines
Start-up Pos: 22.16 /Überschriften/Überschriften 3/F-JHydraulikleitungen anschließen @ 0\mod_1199777037794_78.docx @ 34244 @ @ 1 9.2.2 Connecting the hydraulic lines Pos: 22.17 /BA/Inbetriebnahme/Hydraulikkupplungen anschließen alle Maschinen/Hinweis Hydraulikaufkleber beachten - nicht mehr verwenden @ 175\mod_1371705374532_78.docx @ 1491925 @ @ 1 Note Connect the hydraulic lines correctly •...
Page 171: Hydraulic Brake (Export)
Start-up Pos: 22.24 /Überschriften/Überschriften 2/F-J/Hydraulische Bremse (Export) @ 17\mod_1236332990291_78.docx @ 204927 @ 1 @ 1 Hydraulic brake (Export) Pos: 22.25 /BA/Inbetriebnahme/Hydraulische Bremse/Bild Hydraulische Bremse Fortima V 1500 MC @ 32\mod_1253192337285_78.docx @ 313011 @ @ 1 KR200032 Fig. 138 Pos: 22.26 /BA/Inbetriebnahme/Hydraulische Bremse/Hydraulische Bremse (Export) @ 17\mod_1236333662166_78.docx @ 204952 @ @ 1 A hydraulic brake is provided for certain export versions.
Page 172: Install The Pto Shaft
Start-up Pos: 22.29 /Überschriften/Überschriften 3/F-J/Gelenkwelle montieren @ 11\mod_1223358863095_78.docx @ 145571 @ 2 @ 1 9.4.1 Install the PTO shaft Pos: 22.30 /BA/Sicherheit/Gelenkwelle/Gefahr - Sich drehende Gelenkwelle_ohne Schwungradbremse @ 159\mod_1365509506265_78.docx @ 1410539 @ @ 1 DANGER! – Rotating universal shaft! Effect: Risk of death or serious injuries •...
Page 173 Start-up KR-1-080 Fig. 140 CAUTION! Contact with parts of the tractor or the machine may result in damages to the machine or to the universal shaft • Make certain there is sufficient free space in the swivel range of the PTO shaft in all operating states.
Page 174: Compressed Air Connections For The Compressed Air Brake
Start-up Pos: 22.36 /Überschriften/Überschriften 2/A-E/Druckluftanschlüsse bei Druckluftbremse @ 0\mod_1201161304258_78.docx @ 51103 @ @ 1 Compressed Air Connections for the Compressed Air Brake Pos: 22.37 /BA/Sicherheit/Bremsen/Gefahr - Versagen der Druckluftbremsanlage @ 5\mod_1213795576997_78.docx @ 89573 @ @ 1 Danger! - Failure of the brake system Effect: Danger to life, injuries or damage to the machine.
Page 175: Electrical Connections
Start-up Pos: 22.42 /Überschriften/Überschriften 2/A-E/Elektrische Anschlüsse @ 17\mod_1236579932558_78.docx @ 205175 @ @ 1 Electrical connections Pos: 22.43 /BA/Inbetriebnahme/Rundballenpresse/Elektrische Anschlüsse Fortima V 1500 MC @ 131\mod_1347959904107_78.docx @ 1164120 @ @ 1 KR-1-044 Fig. 142 • Connect the connection cable (2) for the lighting to the 7-pin plug-in connector of the tractor electrical system •...
Page 176: Using The Safety Chain
Start-up Pos: 22.45.1 /Überschriften/Überschriften 2/P-T/Sicherungskette verwenden @ 6\mod_1214542336632_78.docx @ 94799 @ @ 1 Using the safety chain Pos: 22.45.2 /BA/Inbetriebnahme/Sicherheitskette USA/WARNUNG - Falsch dimensionierte Sicherungskette verwendet mit Variante @ 180\mod_1376576652355_78.docx @ 1547873 @ @ 1 WARNING! When using a wrongly dimensioned safety chain, the safety chain may tear if the machine loosens unintentionally.
Page 177 Start-up Pos: 22.45.7 /Beipacks/Sonstige/Sicherungskette 89kN/Sicherungskette am Traktor montieren Mäher,Schwader,Wender Bild @ 150\mod_1362048508388_78.docx @ 1343347 @ @ 1 ZBBP0899_1 Fig. 143 Pos: 22.45.8 /Beipacks/Sonstige/Sicherungskette 89kN/Sicherungskette am Traktor montieren Text @ 150\mod_1362048347829_78.docx @ 1343318 @ 2 @ 1 • Install safety chain (1) on an eligible position (for example: a or b) on the tractor. Pos: 22.45.9 /BA/Inbetriebnahme/Sicherheitskette USA/Sicherheitskette Bild Rundballenpressen @ 181\mod_1376899543214_78.docx @ 1549227 @ @ 1 RPN00075 Fig.
Page 178: Driving And Transport
Driving and Transport Pos: 24.1 /Überschriften/Überschriften 1/F-J/Fahren und Transport @ 0\mod_1196330049217_78.docx @ 6553 @ 2 @ 1 Driving and Transport Pos: 24.2 /Überschriften/Überschriften 2/U-Z/Vorbereitungen zur Straßenfahrt @ 25\mod_1244092605963_78.docx @ 254666 @ 233 @ 1 10.1 Preparations for road travel Pos: 24.3 /BA/Sicherheit/Fahren und Transport/Fortima V 1500 MC Gefahr Straßenfahrt,Mitfahren,Fahrverhalten @ 209\mod_1387367868107_78.docx @ 1724901 @ @ 1 DANGER! - Road driving, riding, driving behaviour Effect: Risk of death, injuries or damage to the machine.
Page 179: Raise The Pick-Up
Driving and Transport Pos: 24.5 /BA/Einlagerung/Fahren und Transport/Großpackenpresse/Arbeiten vor der Straßenfahrt an Maschine und Traktor @ 17\mod_1236587828339_78.docx @ 205393 @ @ 1 The following tasks must be performed on the machine and tractor before road travel: Pos: 24.6 /BA/Einstellungen/Pick-up / Rollenniederhalter/Pick-up ausheben Fortima V 1500 MC @ 32\mod_1253612127484_78.docx @ 315312 @ @ 1 10.1.1 Raise the pick-up RBV19220...
Page 180: Checking The Parking Support
Driving and Transport Pos: 24.8 /BA/Einlagerung/Fahren und Transport/Rundballenpresse/Abstellstütze prüfen @ 32\mod_1253612569968_78.docx @ 315337 @ @ 1 10.1.2 Checking the parking support CPB00100 Fig. 146 • Disconnect the electrical power supply to the control unit • Check that the parking support (1) is in transport position Pos: 24.9 /Überschriften/Überschriften 3/A-E/Beleuchtungsanlage prüfen @ 25\mod_1244090937463_78.docx @ 254566 @ @ 1 10.1.3 Checking the lighting system...
Page 181: Parking
Driving and Transport Pos: 24.14 /Überschriften/Überschriften 2/A-E/Abstellen @ 0\mod_1199801980622_78.docx @ 35320 @ 22 @ 1 10.2 Parking Pos: 24.15 /BA/Sicherheit/7. Gefahrenhinweise alt/Gefahr - Maschine abstellen Fortima V 1500 MC @ 211\mod_1389189770743_78.docx @ 1732857 @ @ 1 DANGER! – Unexpected movement of machine Effect: Risk of death, serious injuries •...
Page 182: Lowering The Parking Support
Driving and Transport Pos: 24.19 /BA/Einlagerung/Fahren und Transport/Rundballenpresse/Bild Abstellstütze runter @ 32\mod_1253617125109_78.docx @ 315487 @ @ 1 10.2.2 Lowering the parking support CPB00090 Fig. 149 Pos: 24.20 /BA/Einlagerung/Fahren und Transport/Rundballenpresse/Abstellstütze positionieren @ 32\mod_1253617584078_78.docx @ 315512 @ @ 1 • Remove stake bolt (2), bring the support pipe out of the parking support (1) and then secure again with the stake bolt (2).
Page 183: Disconnecting The Supply Lines
Driving and Transport Pos: 24.26 /BA/Einlagerung/Fahren und Transport/Rundballenpresse/Bild Fortima V 1500 MC Hydraulikschläuche abziehen @ 32\mod_1253618970406_78.docx @ 315587 @ 22 @ 1 10.2.4 Disconnecting the supply lines KR-1-147 Fig. 151 Pos: 24.27 /BA/Einlagerung/Fahren und Transport/Rundballenpresse/Hydraulikschläuche abziehen @ 32\mod_1253618767671_78.docx @ 315566 @ 2 @ 1 •...
Page 184 Driving and Transport Pos: 26 /Layout Module /Diese Seite ist bewusst freigelassen worden. @ 1\mod_1201783680373_78.docx @ 54443 @ 3 @ 1 This page has been left blank deliberately!! Pos: 27 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 185: Operation
Operation Pos: 28.1 /Überschriften/Überschriften 1/A-E/Bedienung @ 0\mod_1199789505403_78.docx @ 34825 @ @ 1 Operation Pos: 28.2 /BA/Sicherheit/Rundballenpresse/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarbeiten VP @ 209\mod_1387358602334_78.docx @ 1724405 @ @ 1 Danger! - Maintenance, installation, repair and adjustment work, troubleshooting and fault resolution Effect: Risk of death, injuries or damage to the machine.
Page 186: Settings Before Starting Work
Operation Pos: 28.5.1 /BA/Bedienung /Rundballenpresse/Einstellungen vor Arbeitsbeginn/Einstellungen vor Arbeitsbeginn Fortima @ 230\mod_1393311445585_78.docx @ 1842011 @ 3 @ 1 11.1 Settings Before Starting Work Before starting work, perform or check the following settings for all machine types: • Working height of the pick-up •...
Page 187: Travelling Speed
Operation Pos: 28.7 /BA/Bedienung /Rundballenpresse/hohe Ballendichte @ 35\mod_1256125227222_78.docx @ 326331 @ 3 @ 1 If the cutting system is switched on during baling, the bale density will increase substantially, which makes it necessary to reduce the baling pressure. Pos: 28.8 /BA/Bedienung /Rundballenpresse/Ballendichte einstellen Fortima @ 114\mod_1338895842145_78.docx @ 1007108 @ @ 1 To do this: Short, crumbly straw: •...
Page 188: Filling The Bale Chamber
Operation Pos: 28.11.1 /BA/Bedienung /Rundballenpresse/Ballenkammer befüllen/Ballenkammer befüllen Fortima_Teil1 @ 103\mod_1331729267336_78.docx @ 937500 @ 3 @ 1 11.3 Filling the Bale Chamber Fig. 153 To attain a consistent bale density inside a round bale, the bale chamber should be filled evenly. The swath width is an important factor here. It is optimal if the swath has exactly the same width as the bale chamber.
Page 189: Wrapping And Depositing Bales
Operation Pos: 28.13 /BA/Bedienung /Rundballenpresse/Ballen binden Fortima @ 114\mod_1338896205640_78.docx @ 1007137 @ @ 1 11.4 Wrapping and Depositing Bales • Start tying or wrapping process (refer to the chapter entitled “Operation”), continue crop collection until tying or wrapping material is transported from crops into the bale chamber and covered from the round bale.
Page 190: Shear Screw For Pick-Up Drive
Operation Pos: 28.18 /BA/Bedienung /Rundballenpresse/Abscherschraube @ 35\mod_1256128089316_78.docx @ 326536 @ @ 1 11.6 Shear screw for pick-up drive KR201201 KR201141 Fig. 155 To protect against overload the pick-up drive and the feed auger drive, which is located behind the guard (3), are secured with a shear screw at the upper chain wheel. •...
Page 191: Splash Guard
Operation Pos: 28.20 /BA/Bedienung /Rundballenpresse/Spritzschutz @ 35\mod_1256129420269_78.docx @ 326561 @ @ 1 11.7 Splash guard KR201180 Fig. 156 For use in straw the splash guard should be removed (2). To do this: • Remove the spring cotter pin (1) from the attachment bolt (3) (on both sides). •...
Page 192: Pick-Up
Operation Pos: 28.22 /Überschriften/Überschriften 2/P-T/Pick up @ 1\mod_1201791975201_0.docx @ 54586 @ @ 1 11.8 Pick-up Pos: 28.23 /Überschriften/Überschriften 2/F-J/Grundeinstellung (einstellen der Arbeitshöhe) @ 19\mod_1238576636385_78.docx @ 221585 @ @ 1 11.9 Default Setting (Working Height Setting) Pos: 28.24 /BA/Einstellungen/Pick-up / Rollenniederhalter/Hinweis Fahren im Vorgewende @ 20\mod_1238578490213_78.docx @ 221874 @ 2 @ 1 Note Lift the Pick-up for driving in the headland or when driving backward! Pos: 28.25 /BA/Einstellungen/Pick-up / Rollenniederhalter/Pick-up Grundeinstellung Bild VarioPack @ 32\mod_1253622927843_78.docx @ 315722 @ @ 1...
Page 193 Operation Pos: 28.28 /BA/Einstellungen/Pick-up / Rollenniederhalter/Pick-up Zusatzeinstellung Bild VarioPack @ 32\mod_1253624154218_78.docx @ 315822 @ @ 1 RBV04180 Fig. 158 Pos: 28.29 /BA/Einstellungen/Pick-up / Rollenniederhalter/Pick-up Zusatzeinstellung VP @ 32\mod_1253624231937_78.docx @ 315851 @ @ 1 Additional setting (the setting must always be the same on both sides): 1.
Page 194: Roller Crop Guide
Operation Pos: 28.33.1 /Überschriften/Überschriften 2/P-T/Rollenniederhalter @ 0\mod_1201163046930_78.docx @ 51122 @ 33 @ 1 11.10 Roller crop guide Pos: 28.33.2 /BA/Sicherheit/Pick-up / Rollenniederhalter/Gefahr - Abbau des Rollenniederhalters @ 20\mod_1238580223182_78.docx @ 222168 @ @ 1 DANGER! - Operation of the machine without roller crop guide! Effect: Danger to life or serious injuries The roller crop guide is used for accident protection and must not be removed during operation.
Page 195: Adjusting The Baffle Plate
Operation Pos: 28.35.1 /Überschriften/Überschriften 2/P-T/Prallblech verstellen @ 195\mod_1383656418894_78.docx @ 1652771 @ @ 1 11.11 Adjusting the baffle plate Pos: 28.35.2 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) /Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 28.35.3 /BA/Bedienung /Rundballenpresse/Prallblech verstellen/Prallblech verstellen_Einleitung @ 196\mod_1383751549469_78.docx @ 1656355 @ @ 1 The height of the baffle plate (1) can be adjusted to the swath.
Page 196: Preselecting Baling Pressure
Operation Pos: 28.37 /BA/Bedienung /Rundballenpresse/Pressdruck vorwählen Fortima @ 113\mod_1338449513532_78.docx @ 1002063 @ @ 1 11.12 Preselecting Baling Pressure Fortima V 1500 (MC) / Fortima V 1800 (MC) VP-1-061 Fig. 162 Relieve the pressure from the clamping cylinders of the floor conveyor after every use. The shut-off valve (2) is moved in the shown position to set the baling pressure.
Page 197: Cutting System
Operation Pos: 28.39.1 /Überschriften/Überschriften 2/P-T/Schneidwerk @ 20\mod_1238593156760_78.docx @ 223560 @ @ 1 11.13 Cutting system Pos: 28.39.2 /BA/Sicherheit/Schneidwerk/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarb Schneidwerk VP @ 244\mod_1395818598014_78.docx @ 1910171 @ @ 1 WARNING! – Maintenance, assembly, repair and adjustment work as well as troubleshooting and fault clearance Effect: Danger to life, injuries or damage to the machine.
Page 198: Chop Length
Operation Pos: 28.39.5 /BA/Einstellungen/Schneidwerk/Schnittlänge VarioPack @ 247\mod_1396445470207_78.docx @ 1927851 @ @ 1 11.13.2 Chop length Chop length is determined by the number of blades used. The number of blades used can be read on the selector disc (1). VP-1-058_1 Fig. 163 Pos: 28.39.6 /BA/Einstellungen/Schneidwerk/Schnittlänge Tabelle durch Messerbestückung VarioPack @ 39\mod_1268808933991_78.docx @ 361836 @ @ 1 Table cutting length depending on blade equipping Cutting length...
Page 199 Operation Pos: 28.39.9 /BA/Einstellungen/Schneidwerk/Einstellung vornehmen VarioPack @ 39\mod_1268809613491_78.docx @ 361886 @ @ 1 Make setting CPB00060 Fig. 165 The setting is performed on the right-hand side of the machine: 1. Turn the locking lever (3) clockwise, unlock blade control shaft. 2.
Page 200 Operation CP101251 Fig. 166 3. Turn blade control shaft with multipurpose key (1) counter-clockwise into the desired position (2). 4. Turn locking lever (3) counter-clockwise until it engages. Note Do not turn locking lever in the other direction (clockwise). In doing so, the possibility exists that the cutters are not located in working position.
Page 201: Zero Position Of The Cutter
Operation Pos: 28.39.11 /Überschriften/Überschriften 3/K-O/Messer-0-Stellung @ 39\mod_1268811608726_78.docx @ 361945 @ @ 1 11.13.3 Zero position of the cutter Pos: 28.39.12 /BA/Einstellungen/Schneidwerk/Überschrift Messer mechanisch ausschalten @ 40\mod_1268820694835_78.docx @ 362223 @ @ 1 Switch off cutters mechanically Pos: 28.39.13 /BA/Einstellungen/Schneidwerk/Messer mechanisch ausschalten @ 39\mod_1268811740054_78.docx @ 361966 @ @ 1 "0"...
Page 202 Operation Pos: 28.39.16 /BA/Einstellungen/Schneidwerk/ Messer hydraulisch ausschalten @ 39\mod_1268814389726_78.docx @ 362048 @ @ 1 Turn off the blades hydraulically VP-1-059 Fig. 168 Note The purpose of the hydraulic knife retraction is to make it possible to eliminate any blockages or foreign objects.
Page 203: Blade Quick-Fit Device Blade
Operation Pos: 28.39.18 /Überschriften/Überschriften 3/K-O/Messersicherung einstellen @ 39\mod_1268815468585_78.docx @ 362102 @ @ 1 11.13.4 Blade Quick-Fit Device Blade Pos: 28.39.19 /BA/Einstellungen/Schneidwerk/Einstellen der Einzelmessersicherung VP @ 39\mod_1268815378070_78.docx @ 362077 @ @ 1 The single blade locking device prevents the blades from being damaged by foreign objects.The locking device for individual blades is optimally adjusted before the unit leaves the factory.
Page 204 Operation Pos: 28.39.21 /BA/Einstellungen/Schneidwerk/Einstellen der Einzelmessersicherung ohne Schraube VP @ 39\mod_1268816727179_78.docx @ 362127 @ @ 1 Adjusting the locking device for blades VP-1-063 Fig. 170 1. Lowering the cutting system 2. Switch off the control unit and remove the ignition key 3.
Page 205: Adjust Blade Control Shaft
Operation Pos: 28.39.23 /BA/Einstellungen/Schneidwerk/Messerschaltwelle einstellen VP @ 39\mod_1268817605023_78.docx @ 362148 @ @ 1 11.13.5 Adjust blade control shaft CP100093-1 Fig. 171 If the blades are worn, the blade control shaft (1) can be adjusted. Note The distance (a) has to be at least 5 mm. FOR00018 Fig.
Page 206 Operation Make the adjustment of the blade control shaft (1) using the oblong holes: CP100094 Fig. 173 1. Release counter nuts (3) on both sides and readjust blade control shaft (1) with the adjusting screws (4) to the cutting rotor. Make the adjustment identical on both sides.
Page 207: Zero Position Of The Cutter
Operation Pos: 28.39.25 /Überschriften/Überschriften 3/K-O/Messer wechseln @ 40\mod_1268820477038_78.docx @ 362202 @ @ 1 11.13.6 Zero position of the cutter Pos: 28.39.26 /BA/Sicherheit/Schneidwerk/Warnung - Messerwechsel Handschuhe tragen @ 20\mod_1238595345166_78.docx @ 223904 @ @ 1 WARNING! - Blade changing Effect: Severe injuries to fingers and hands •...
Page 208 Operation Pos: 28.39.33 /BA/Einstellungen/Schneidwerk/Messerwelle entsichern @ 118\mod_1341997503323_78.docx @ 1048471 @ @ 1 Unlocking the Blade Shaft VP-1-068 Fig. 176 • Pull the locking bolt out of the locking by pulling the button (1) and swivel it in position (b). FOR00052 Fig.
Page 209 Operation Pos: 28.39.35 /BA/Einstellungen/Schneidwerk/Messer wechseln CF/CV @ 231\mod_1393413681197_78.docx @ 1847806 @ @ 1 Changing Blades KRS-1-015_1 Abb. 178 • Remove the blades (1) Note When inserting the blades (1), ensure that they are located correctly on the blade shaft and centred in the slot (2).
Page 210 Operation Pos: 28.39.38 /BA/Bedienung /Rundballenpresse/Lagerung Ersatzmesser @ 115\mod_1339663777905_78.docx @ 1012059 @ @ 1 Storage of the Replacement Blades FOR00047 Fig. 179 The replacement blades are stored on the right machine side under the side guard. 1. For removing the blades, pull the spring clip (1) and remove the required number of blades from the support (2).
Page 211: Removing The Crop Blockages In The Crop Collection Area
Operation Pos: 28.41.1 /Überschriften/Überschriften 2/A-E/Erntegutblockaden im Bereich der Gutaufnahme entfernen @ 181\mod_1377084620194_78.docx @ 1554595 @ @ 1 11.14 Removing the Crop Blockages in the Crop Collection Area Pos: 28.41.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Warnung - Unkontrollierte Bewegung der Maschine @ 196\mod_1384152827408_78.docx @ 1658910 @ @ 1 WARNING! –...
Page 212 Operation Pos: 28.41.11.1 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Förderrotor @ 194\mod_1383288777404_78.docx @ 1647840 @ @ 1 Feed rotor Pos: 28.41.11.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Erntegutblockade_Schneid-/Förderrotor_1 Zapfwelle aus, Rückwärts, Pick-up hoch @ 194\mod_1383569094775_78.docx @ 1650483 @ @ 1 • Turn off the PTO shaft. • Drive backwards. •...
Page 213 Operation Cutting rotor Pos: 28.41.13.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Erntegutblockade_Schneid-/Förderrotor_1 Zapfwelle aus, Rückwärts, Pick-up hoch @ 194\mod_1383569094775_78.docx @ 1650483 @ @ 1 • Turn off the PTO shaft. • Drive backwards. • Raise the pick-up. Pos: 28.41.13.3 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Zapfwelle anstellen und im Standgas testen, ob sich die Blockade löst. @ 194\mod_1383579178962_78.docx @ 1650659 @ @ 1 •...
Page 214 Operation Pos: 28.41.13.18 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Wenn die Blockade dadurch nicht beseitigt ist: @ 194\mod_1383555273315_78.docx @ 1649635 @ @ 1 If the blockage is not removed due to this: Pos: 28.41.13.19 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Motor starten und Zapfwelle einschalten @ 212\mod_1389783708405_78.docx @ 1742558 @ 3 @ 1 •...
Page 215: Crop Blockage At Pick-Up
Operation Pos: 28.41.15 /Überschriften/Überschriften 3/A-E/Erntegutblockade an der Pick-up @ 193\mod_1383214911049_78.docx @ 1646507 @ @ 1 11.14.2 Crop blockage at pick-up Pos: 28.41.16.1 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Um das angestaute Erntegut zu beseitigen, wie folgt vorgehen: @ 193\mod_1383231662173_78.docx @ 1647045 @ @ 1 Proceed as follows to remove the accumulated crop: Pos: 28.41.16.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/a) Bei Erntegutansammlung an der rechten/linken Ecke der Pick-up @ 194\mod_1383287252016_78.docx @ 1647635 @ @ 1 a) If crop accumulates on the right/left edge of the pick-up...
Page 216: Reversing
Operation Pos: 28.43.1 /Überschriften/Überschriften 2/P-T/Reversieren (Ausführung mit Förderrotor) @ 194\mod_1383557494325_78.docx @ 1649783 @ @ 1 11.15 Reversing Pos: 28.43.2 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Förderrotor ab Baujahr 2013 @ 212\mod_1389717240730_78.docx @ 1740986 @ @ 1 (feed rotor produced from 2013 onwards) Pos: 28.43.3 /BA/Bedienung /Rundballenpresse/Gutflussblockaden entfernen/Warnung - Unkontrollierte Bewegung der Maschine @ 196\mod_1384152827408_78.docx @ 1658910 @ @ 1 WARNING! –...
Page 217 Operation Pos: 28.43.9 /BA/Bedienung /Rundballenpresse/Reversieren/b) Bei Ausführung mit hydraulischer Reversiereinrichtung @ 194\mod_1383558077702_78.docx @ 1649839 @ @ 1 b) For version with hydraulic reversing device Pos: 28.43.10 /BA/Bedienung /Rundballenpresse/Reversieren/Hydraulisch reversieren - Vorgehensweise @ 181\mod_1377095013720_78.docx @ 1555305 @ @ 1 • Turn off the PTO shaft. •...
Page 218: Assembly And Disassembly Of The Bale Ejector
Operation Pos: 28.45.1 /Überschriften/Überschriften 2/K-O/Montage und Demontage Ballenauswerfer @ 32\mod_1253627760593_78.docx @ 316056 @ @ 1 11.16 Assembly and disassembly of the bale ejector Pos: 28.45.2 /BA/Sicherheit/Rundballenpresse/Warnung - Montagearbeiten bei geöffneter Heckklappe @ 234\mod_1394089537987_78.docx @ 1864981 @ @ 1 WARNING! – Maintenance, assembly, repair and adjustment work as well as troubleshooting and fault clearance Effect: Danger to life, injuries or damage to the machine.
Page 219 Operation Pos: 28.45.6 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) /Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 28.45.7 /BA/Sicherheit/Rundballenpresse/Gefahr- Montagearbeiten Ballenauswerfer @ 32\mod_1253627872218_78.docx @ 316077 @ @ 1 DANGER! –...
Page 220: Floor Conveyor Chain
Operation Pos: 28.47 /Überschriften/Überschriften 2/P-T/Rollbodenkette @ 32\mod_1253694727176_78.docx @ 316325 @ @ 1 11.17 Floor conveyor chain Pos: 28.48 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 28.49 /BA/Sicherheit/Rundballenpresse/Warnung - Montagearbeiten bei geöffneter Heckklappe @ 234\mod_1394089537987_78.docx @ 1864981 @ 33 @ 1 WARNING! –...
Page 221: Twine Tying/Twine Tying And Net Wrapping
Pos: 28.55 /Überschriften/Überschriften 3/A-E/Bauteile Garnbindung @ 32\mod_1253697020973_78.docx @ 316470 @ @ 1 11.18.1 Twine tying parts Pos: 28.56 /BA/Einstellungen/Großpackenpresse/Bindegarn einfädeln/Hinweis Verwenden Sie nur KRONE Original Bindegarn_Rundballenpressen @ 234\mod_1394094834500_78.docx @ 1865652 @ 3 @ 1 Note Use only KRONE original tying twine. The tying twine must be ordered via KRONE spare parts department under spare parts number: 00 929 949 0 (750 m/kg) or 00 929 951 0 (1000 m/kg).
Page 222: Twine Tying And Net Wrapping Parts
Operation Pos: 28.59 /Überschriften/Überschriften 3/A-E/Bauteile Garn- und Netzbindung @ 32\mod_1253697078426_78.docx @ 316495 @ @ 1 11.18.2 Twine tying and net wrapping parts Pos: 28.60 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Bild Bauteile Garn- und Netzbindung @ 32\mod_1253697371239_78.docx @ 316541 @ @ 1 RBV00231 Fig. 189 1 Blade bar 2 Twine tying 3 Idler roller...
Page 223: Tying Function
Operation Pos: 28.62 /BA/Bedienung /Rundballenpresse/Funktion der Garnbindung @ 32\mod_1253698253114_78.docx @ 316566 @ 33 @ 1 11.18.3 Tying function The upper twines are guided out of the twine box through the twine eye and twine brake to the stepped pulley (8); the two lower twines are guided by the twine brake directly to the twine tying. From there they are moved through the twine tying (2) between the rubber roller (4) and the idler roller (3) to the area of the blade bar (1).
Page 224: Setting The Tying Twine In Place
Operation Pos: 28.64 /Überschriften/Überschriften 2/A-E/Bindegarn einlegen @ 33\mod_1254403178526_78.docx @ 319620 @ @ 1 11.19 Setting the tying twine in place Pos: 28.65 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Warnung - Bindung eine Person @ 234\mod_1394097677476_78.docx @ 1866325 @ @ 1 DANGER! - Unexpected movement of a machine component. Effect: Danger to life, injuries.
Page 225 Operation Pos: 28.70 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Schema Garn einlegen @ 32\mod_1253775200707_78.docx @ 316836 @ @ 1 • Connect the twine rolls with each other according to the following diagram: FOR00021 Fig. 191 End of the twine with beginning of roll twine roll Twine A Twine B Twine C...
Page 226 Operation Pos: 28.72 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Garn führen @ 32\mod_1253774202848_78.docx @ 316811 @ @ 1 GF000001 VP150202_1 Fig. 192 • Guide the 4 twines through the twine guides (1) vertically downward without crossing in the twine box. Thread one twine into each eye (2). •...
Page 227 Operation Pos: 28.74 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netzbreithalter @ 32\mod_1253775382801_78.docx @ 316861 @ 33 @ 1 RBV04040 Fig. 193 Note If net wrapping is available, the net spreader (2) must be rotated to the upper position if twine tying is being used. The net spreader (2) is held in position by the link in the guide iron (1). CP400002 Fig.
Page 228 Operation CP400003 Fig. 195 • Close the cleaning flaps (1) again. • Turn the stepped pulley in the direction of the arrow until the twine guiding slides (3) move from the outside to the middle. Note The twine guiding slides (3) must move to the middle as the stepped pulley is turned. Otherwise continue turning the stepped pulley in the direction of the arrow until the starting position is reached (see picture).
Page 229 Operation Pos: 28.76 /BA/Bedienung /Rundballenpresse/Überschrift Abstand Garnwicklungen @ 32\mod_1253779237613_78.docx @ 316961 @ 33 @ 1 Distance of the twine wraps on the bale Pos: 28.77 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Tabelle Abstand Garnwicklungen @ 32\mod_1253779470191_78.docx @ 316986 @ @ 1 Length of Ø of the stepped pulley (1) Wrapping crop material distance...
Page 230: Net Wrapping
Operation Pos: 28.80 /Überschriften/Überschriften 2/K-O/Netzbindung @ 33\mod_1254400902338_78.docx @ 319495 @ 33 @ 1 11.20 Net Wrapping Pos: 28.81 /Überschriften/Überschriften 3/A-E/Bauteile Netzbindung @ 33\mod_1254401988166_78.docx @ 319545 @ @ 1 11.20.1 Net wrapping parts Pos: 28.82 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Bild Bauteile Netzbindung @ 234\mod_1394102098116_78.docx @ 1866861 @ 22 @ 1 RBV00212_1 Fig.
Page 231: Inserting The Net Roll
Operation Pos: 28.84 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Gefahr Öl auf Netz @ 211\mod_1389188265860_78.docx @ 1732769 @ @ 1 ATTENTION! – Net and net wrapping contaminated with oil and grease Effect: Machine damage and problems when unrolling the net. • Net and components of the net wrapping must not be contaminated with oil or grease. Pos: 28.85 /BA/Bedienung /Rundballenpresse/Funktion Netzbindung @ 235\mod_1394109991318_78.docx @ 1866973 @ @ 1 The net is guided by the net roll over the deflection shaft (10) to the net spreader (5) and from there between the rubber roller (4) and idler roller (3) into the area of the blade bar (1).
Page 232 Operation Pos: 28.90 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netzrolle auf Halter @ 33\mod_1254404603635_78.docx @ 319691 @ 3 @ 1 VP-2-074 Fig. 199 • Raise the lever (2). • Swing the brake disc (1) and the net roll mounting shaft (3) forward. • Detach the brake disc (1). •...
Page 233 Operation Pos: 28.92 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netzführung @ 33\mod_1254406272557_78.docx @ 319716 @ @ 1 RBV0534A Fig. 201 • Feed the net (2) over the deflection shaft (3) to the net spreader (4). • Swing the net roll mounting shaft back into its support. Pos: 28.93 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netz über Bremse @ 33\mod_1254818678270_78.docx @ 319891 @ @ 1 RBV00111 Fig.
Page 234 Operation Pos: 28.95 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Netz über Umlenkrolle @ 33\mod_1254819094082_78.docx @ 319916 @ @ 1 VP-3-008 Fig. 203 • Insert the net (3) through the deflection shaft (1) under the net spreader (2) between the rubber roller (4) and idler roller (5). The net must extend about 0 - 50 mm over the scraper of the conveyor or cutting roller.
Page 235: Settings
Settings Pos: 30.1 /Überschriften/Überschriften 1/A-E/Einstellungen @ 0\mod_1199868783862_78.docx @ 36141 @ @ 1 Settings Pos: 30.2 /BA/Sicherheit/Rundballenpresse/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarbeiten VP @ 209\mod_1387358602334_78.docx @ 1724405 @ @ 1 Danger! - Maintenance, installation, repair and adjustment work, troubleshooting and fault resolution Effect: Risk of death, injuries or damage to the machine.
Page 236: Tying Unit
Settings Pos: 30.4 /Überschriften/Überschriften 2/A-E/Bindeeinrichtung @ 20\mod_1239003005331_78.docx @ 225610 @ 2 @ 1 12.1 Tying unit Pos: 30.5 /BA/Bedienung /Rundballenpresse/Fadenbegrenzer einstellen @ 33\mod_1253781093098_78.docx @ 317111 @ @ 1 12.1.1 Adjusting the twine limiter The position of the twine limiter determines the distance from the outer wraps to the outside edge of the bale.
Page 237: Adjusting The Twine Brake
Settings Pos: 30.10 /Überschriften/Überschriften 3/F-J/Garnbremse einstellen @ 32\mod_1253780682957_78.docx @ 317040 @ @ 1 12.1.2 Adjusting the twine brake Pos: 30.11 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Bild Garnbremse @ 33\mod_1253781996379_78.docx @ 317186 @ 33 @ 1 CP400004_1 Fig. 206 Pos: 30.12 /BA/Bedienung /Rundballenpresse/Einstellung Garnbremse @ 239\mod_1395061386542_78.docx @ 1885620 @ @ 1 The twine brakes (4) are located in the twine box.
Page 238: Loosening The Twine Brake
Settings Pos: 30.15 /Überschriften/Überschriften 3/F-J/Garnbremse lösen @ 33\mod_1253798186457_78.docx @ 318052 @ 33 @ 1 12.1.3 Loosening the twine brake Pos: 30.16 /BA/Einstellungen/Rundballenpresse/Bild Garnbremse lösen @ 33\mod_1253798290676_78.docx @ 318077 @ 11 @ 1 CP400006 Fig. 207 Pos: 30.17 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Garnbremse lösen @ 33\mod_1253782791316_78.docx @ 317236 @ 2 @ 1 1.
Page 239: Adjusting The Idler Roller
Settings Pos: 30.20 /Überschriften/Überschriften 3/A-E/Andrückrolle einstellen @ 33\mod_1253783433270_78.docx @ 317295 @ 2211112 @ 1 12.1.4 Adjusting the idler roller Pos: 30.21 /BA/Bedienung /Rundballenpresse/Bild Andruckrolle @ 33\mod_1253784658363_78.docx @ 317341 @ 2 @ 1 VP-3-014 Fig. 209 Pos: 30.22 /BA/Bedienung /Rundballenpresse/Andrückrolle einstellen @ 33\mod_1253783906629_78.docx @ 317316 @ @ 1 If the twine is not being drawn in correctly at the start, the pressure of the idler roller can be increased with the spring (2): Right-hand side...
Page 240: Selecting The Type Of Tying
Settings Pos: 30.27 /BA/Einstellungen/Rundballenpresse/Auswahl der Bindung @ 33\mod_1253793476863_78.docx @ 317722 @ 233 @ 1 12.1.6 Selecting the type of tying Fig. 211 In menu 1-7 "Select type of tying" activate the keys to open the "Twine tying" submenu (Fig. RPK50604_2) or "Net wrapping" (Fig. RPK50602) (for additional information see chapter "In-cab Comfort kit").
Page 241: Adjusting The Additional Net Brake
Settings Pos: 30.30.1 /Überschriften/Überschriften 3/K-O/Netzzusatzbremse einstellen @ 33\mod_1253795704348_78.docx @ 317801 @ 224 @ 1 12.1.8 Adjusting the additional net brake Pos: 30.30.2 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 30.30.3 /BA/Einstellungen/Rundballenpresse/Netzzusatzbremse einstellen_Fortima V1500 (MC), V1800 (MC)_Bild @ 235\mod_1394175113223_78.docx @ 1868478 @ 3 @ 1 VP-3-017_1 Fig.
Page 242: Loosening The Net Brake
Settings Pos: 30.32 /Überschriften/Überschriften 3/K-O/Netzbremse lösen @ 33\mod_1253798601910_78.docx @ 318125 @ 22 @ 1 12.1.9 Loosening the net brake Pos: 30.33 /BA/Einstellungen/Rundballenpresse/Bild Netzbremse lösen @ 33\mod_1253797975457_78.docx @ 317897 @ 22 @ 1 VP-3-018 Fig. 214 Pos: 30.34 /BA/Bedienung /Rundballenpresse/Netz-Garnbindung/Garnbremse lösen @ 33\mod_1253782791316_78.docx @ 317236 @ 3 @ 1 1.
Page 243: Adjusting The Magnetic Coupling (In Case Of Twine Wrapping)
Settings Pos: 30.37 /Überschriften/Überschriften 3/K-O/Magnetkupplung einstellen (Garnbindung) @ 116\mod_1341208317705_78.docx @ 1020981 @ 222 @ 1 12.1.11 Adjusting the Magnetic Coupling (in Case of Twine Wrapping) Pos: 30.38 /BA/Einstellungen/Rundballenpresse/Wann Magnetkupplung einstellen @ 80\mod_1315467238092_78.docx @ 704864 @ @ 1 The magnetic transmission must be re-adjusted if: •...
Page 244: Central Chain Lubrication System
Settings Pos: 30.42.1 /Überschriften/Überschriften 2/U-Z/Zentrale Kettenschmierung @ 33\mod_1254819776816_78.docx @ 319945 @ 22 @ 1 12.2 Central chain lubrication system Pos: 30.42.2 /BA/Einstellungen/Rundballenpresse/Zentrale Kettenschmierung @ 33\mod_1254819918129_78.docx @ 319966 @ 2 @ 1 RBV05150 Fig. 217 The central chain lubrication system is attached to the left-hand side of the machine behind the front guard.
Page 245 Settings Pos: 30.42.5 /BA/Einstellungen/Rundballenpresse/Manometer @ 54\mod_1291810709187_78.docx @ 516072 @ @ 1 FOR00019 Fig. 219 A pressure gauge (1) which displays the system pressure is installed on the right-hand side of the machine. This pressure increases or decreases according to the setting of the eccentric disc.
Page 246 Settings Pos: 30.42.7 /BA/Einstellungen/Rundballenpresse/Zentrale Kettenschmierung Öl prüfen @ 234\mod_1394008657190_78.docx @ 1860613 @ @ 1 RP100007_2 Fig. 220 Depending on consumption, check the oil supply in the container and top off if necessary. If the lubricant container is empty, the central chain lubrication system needs to be bled: •...
Page 247: Display Central Chain Lubrication System
Settings Pos: 30.42.9 /Überschriften/Überschriften 3/P-T/Schaubild zentrale Kettenschmierung @ 233\mod_1394001446355_78.docx @ 1860205 @ @ 1 12.2.1 Display Central Chain Lubrication System Pos: 30.42.10 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) / F 1600 (MC) @ 113\mod_1338372324634_78.docx @ 1001105 @ @ 1 Fortima F 1250 (MC) / Fortima F 1600 (MC) Pos: 30.42.11 /BA/Einstellungen/Rundballenpresse/Schaubild zentrale Kettenschmierung Fortima F1250 (MC), F1600 (MC) @ 233\mod_1394001087184_78.docx @ 1860118 @ 3 @ 1 FOR00035 Fig.
Page 248 Settings Pos: 30.42.15 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 30.42.16 /BA/Einstellungen/Rundballenpresse/Schaubild zentrale Kettenschmierung Fortima V1500 (MC), V1800 (MC) @ 233\mod_1394001273265_78.docx @ 1860147 @ 33333333 @ 1 VP700023 Fig.
Page 249: Adjusting The Automatic Floor Conveyor Stop
Settings Pos: 30.44 /Überschriften/Überschriften 2/A-E/Einstellung der automatischen Rollbodenabschaltung @ 116\mod_1341208553537_78.docx @ 1021010 @ 433333333 @ 1 12.3 Adjusting the Automatic Floor Conveyor Stop Pos: 30.45 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ 3 @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 30.46 /BA/Einstellungen/Rundballenpresse/Bild Rollbodenabschaltung einstellen @ 74\mod_1309241717975_78.docx @ 660349 @ 22 @ 1 VP-7-075...
Page 250: Adjusting The Switching Time
Settings Pos: 30.51 /Überschriften/Überschriften 3/A-E/Einstellen des Schaltzeitpunktes @ 74\mod_1309247278903_78.docx @ 660535 @ 33 @ 1 12.3.1 Adjusting the switching time Pos: 30.52 /BA/Einstellungen/Rundballenpresse/Bild Schaltzeitpunkt @ 74\mod_1309247415852_78.docx @ 660557 @ 33 @ 1 VP700018 Fig. 225 Pos: 30.53 /BA/Einstellungen/Rundballenpresse/Schaltzeitpunkt einstellen @ 74\mod_1309245975101_78.docx @ 660501 @ 2332 @ 1 The switching time for floor conveyor shutoff is pre-adjusted in the factory.
Page 251: Maintenance
Effect: Danger to life, serious injuries or loss of warranty claims as well as exclusion of liability • Use only authentic KRONE spare parts and accessories authorised by the manufacturer. The use of spare parts, accessories or additional equipment not manufactured, tested or approved by KRONE will exclude any liability for consequential damage.
Page 252: Overview
Maintenance Pos: 32.8 /Überschriften/Überschriften 2/U-Z/Übersicht @ 53\mod_1289900374656_78.docx @ 506510 @ 33 @ 1 13.3 Overview Pos: 32.9 /BA/Wartung/Rundballenpresse/Tabelle Wartungsarbeiten_Fortima F1250 (MC), F1600 (MC), V1500 (MC), V1800 (MC) @ 114\mod_1338806844070_78.docx @ 1005252 @ 3 @ 1 Maintenance interval Machine part Wheels, wheel nuts after the first 8 operating hours and every time after a wheel is changed...
Page 253: Setting Tailgate Catch
Maintenance Pos: 32.12 /Überschriften/Überschriften 2/A-E/Einstellung Heckklappenverschluss @ 236\mod_1394518601782_78.docx @ 1873133 @ @ 1 13.4 Setting Tailgate Catch Pos: 32.13 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) /Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 32.14 /BA/Wartung/Rundballenpresse/Einstellung Heckklappenverschluss Fortima F @ 114\mod_1338793198814_78.docx @ 1004540 @ 3333 @ 1 FOR00038...
Page 254: Setting Lock Hook Blocker
Maintenance Pos: 32.18 /Überschriften/Überschriften 3/A-E/Einstellung der Verschlusshakensperre @ 236\mod_1394519400468_78.docx @ 1873158 @ 3333 @ 1 13.4.1 Setting Lock Hook Blocker Pos: 32.19 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) /Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ 2 @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 32.20 /BA/Wartung/Rundballenpresse/Einstellung der Verschlusshakensperre Fortima F @ 114\mod_1338791139393_78.docx @ 1004281 @ @ 1 FOR00036...
Page 255: Setting Cutting Blade Net Tying Device
Maintenance Pos: 32.22 /Überschriften/Überschriften 2/A-E/Einstellung der Schneidmesser der Netzwickeleinrichtung @ 236\mod_1394520153957_78.docx @ 1873221 @ 33 @ 1 13.5 Setting Cutting Blade Net Tying Device Pos: 32.23 /WHB/Warnhinweise - Allgemeingültig/GEFAHR - Schnittgefahr durch scharfe Messer @ 29\mod_1251110194290_78.docx @ 279742 @ 33 @ 1 DANGER! –...
Page 256: Setting Of The Scraper Rail To The Upper Spiral Roller
Maintenance Pos: 32.26 /Überschriften/Überschriften 2/A-E/Einstellung der Abstreifschiene zur oberen Spiralwalze @ 75\mod_1309422205904_78.docx @ 662923 @ 33 @ 1 13.6 Setting of the Scraper Rail to the Upper Spiral Roller Pos: 32.27 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Absperrhahn Hydraulikzyl geschlossen @ 34\mod_1256114957331_78.docx @ 325995 @ 33 @ 1 DANGER! –...
Page 257: Grinding Blades
(1). Grind only the ungrooved side. When grinding, make certain no notches are made in area (3). Note If at all possible, use the KRONE grinding mechanism for grinding. The Part No. for the blade holder for the KRONE blade grinding tool is 940 003-0.
Page 258: Sensors
Maintenance Pos: 32.32.1 /Überschriften/Überschriften 2/P-T/Sensoren @ 9\mod_1219743478068_78.docx @ 121498 @ @ 1 13.8 Sensors Pos: 32.32.2 /Überschriften/Überschriften 3/K-O/Lage der Sensoren @ 236\mod_1394523625971_78.docx @ 1873537 @ @ 1 13.8.1 Position of the Sensors Pos: 32.32.3 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) /Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 32.32.4 /Abkürzungen /Abkürzungen Beschreibung/Linke Maschinenseite @ 235\mod_1394183788198_78.docx @ 1869099 @ 2 @ 1 Left Machine Side...
Page 259 Maintenance Pos: 32.32.7 /Abkürzungen /Abkürzungen Beschreibung/Rechte Maschinenseite @ 235\mod_1394183790425_78.docx @ 1869128 @ 44 @ 1 Right Machine Side Pos: 32.32.8 /BA/Wartung/Rundballenpresse/Sensoren/Lage der Sensoren_Fortima F_rechts @ 240\mod_1395124000191_78.docx @ 1888135 @ @ 1 FOR00043_1 Fig. 234 Pos. Sensor designation Distance Sensor type Tightening torque Transmitter/sensor Tying process active...
Page 260 Maintenance Pos: 32.32.10 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) /Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.32.11 /Abkürzungen /Abkürzungen Beschreibung/Linke Maschinenseite @ 235\mod_1394183788198_78.docx @ 1869099 @ 2 @ 1 Left Machine Side Pos: 32.32.12 /BA/Wartung/Rundballenpresse/Sensoren/Lage der Sensoren_Fortima V_links @ 114\mod_1338796211109_78.docx @ 1004741 @ @ 1 FOR00011...
Page 261 Maintenance Pos: 32.32.14 /Abkürzungen /Abkürzungen Beschreibung/Rechte Maschinenseite @ 235\mod_1394183790425_78.docx @ 1869128 @ 2222 @ 1 Right Machine Side Pos: 32.32.15 /BA/Wartung/Rundballenpresse/Sensoren/Lage der Sensoren_Fortima V_rechts @ 114\mod_1338795727025_78.docx @ 1004634 @ 22 @ 1 FOR00010 Fig. 236 Pos. Sensor designation Distance Sensor type Tightening torque Transmitter/sensor Tying process is active...
Page 262: Adjusting The Sensors
Maintenance Pos: 32.32.17 /Überschriften/Überschriften 3/A-E/Einstellung der Sensoren @ 0\mod_1199962173428_78.docx @ 37635 @ @ 1 13.8.2 Adjusting the Sensors Pos: 32.32.18 /BA/Wartung/Sensoren/Namursensor d = 12 mm @ 0\mod_1199962247038_78.docx @ 37654 @ 2222 @ 1 13.8.2.1 Namur sensor d = 12 mm BP-VFS-088-1 Figure 237 The dimension between the encoder (2) and the sensor (1) must be "a"...
Page 263: Central Position Of Engine Sensor
Maintenance 13.8.3 Central Position of Engine Sensor FOR00039 FOR00040 Fig. 239 The sensor “Central Position of Engine” (1) can be found on the right machine side above the V- belt and records the data for the position of the servomotor centre. Setting: 1.
Page 264: Sensor Position Blade Shaft (Machines With Cutting Device)
Maintenance Pos: 32.32.22 /BA/Wartung/Sensoren/Sensor Messerboden Fortima @ 114\mod_1338804171247_78.docx @ 1005228 @ @ 1 13.8.4 Sensor Position Blade Shaft (Machines with Cutting Device) RB-4-004 Fig. 240 The position blade shaft sensor (1) can be found on the right machine side on the blade shaft. Setting: 1.
Page 265: Tightening Torques
Maintenance Pos: 32.34 /Überschriften/Überschriften 2/A-E/Anzugsdrehmomente @ 45\mod_1277103093968_78.docx @ 410970 @ @ 1 13.9 Tightening Torques Pos: 32.35 /BA/Wartung/Drehmomente / Anzugsmomente/Drehmomente @ 45\mod_1277102920578_78.docx @ 410945 @ 3 @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the (unless otherwise indicated).
Page 266: Tightening Torques (Countersunk Screws)
Maintenance Pos: 32.38 /Überschriften/Überschriften 2/A-E/Anzugsdrehmomente über Innensechskant @ 45\mod_1277106415765_78.docx @ 411230 @ @ 1 13.10 Tightening Torques (Countersunk Screws) Pos: 32.39 /BA/Wartung/Drehmomente / Anzugsmomente/Drehmomente über Innensechskant @ 45\mod_1277106232328_78.docx @ 411205 @ 3 @ 1 A = Thread size The tightening torque M is stated in Nm (The stability class can be seen on the head of the (unless otherwise indicated).
Page 267: Drawbar
Maintenance Pos: 32.42 /Überschriften/Überschriften 2/A-E/Deichsel @ 236\mod_1394526379904_78.docx @ 1873562 @ @ 1 13.11 Drawbar Pos: 32.43 /BA/Wartung/Rundballenpresse/Deichsel @ 236\mod_1394527540776_78.docx @ 1873771 @ 33 @ 1 RP-2-002 Fig. 241 • Retighten the screws after 10 operating hours. • Check the screws every 50 operating hours. Pos: 32.44 /Überschriften/Überschriften 3/U-Z/Zugösen an der Deichsel @ 236\mod_1394528187810_78.docx @ 1873833 @ @ 1 13.11.1 Hitches on the Drawbar...
Page 268: Main Gearbox
Maintenance Pos: 32.47 /Überschriften/Überschriften 2/F-J/Hauptgetriebe @ 0\mod_1197005740033_78.docx @ 15416 @ 33 @ 1 13.12 Main gearbox Pos: 32.48 /BA/Wartung/Rundballenpresse/Hauptgetriebe befindet sich im vorderen Querträger der Rundballenpresse. @ 240\mod_1395156439885_78.docx @ 1892049 @ 33 @ 1 The main gearbox is located in the front crossbeam of the round baler. Pos: 32.49 /BA/Wartung/Rundballenpresse/Bild Hauptantrieb VP @ 34\mod_1256042758268_78.docx @ 325491 @ @ 1 RBV05090_1 Fig.
Page 269: Oil Level Check And Oil Change Intervals (Gearboxes)
Maintenance Pos: 32.56 /BA/Wartung/Hinweis Ölsorte nicht mischen. @ 10\mod_1222334992520_78.docx @ 140501 @ @ 1 Note! - Do not mix different types of oil. Effect: Damage to the machine • Never mix different types of oil. • Before changing the type of oil, consult customer service. Never use engine oil. Pos: 32.57 /BA/Wartung/Umwelt/Hinweis Entsorgen / Lagern von Öle und Ölfilter Umwelt @ 32\mod_1253101375171_78.docx @ 311770 @ @ 1 ENVIRONMENT! - Disposal and storage of used lubricants and oil filters Effect: Environmental damage...
Page 270: Drive Chains
Maintenance Pos: 32.61 /Überschriften/Überschriften 2/A-E/Antriebsketten @ 27\mod_1246355234599_78.docx @ 267399 @ 22 @ 1 13.13 Drive chains Pos: 32.62 /BA/Sicherheit/7. Gefahrenhinweise alt/Warnung - Einzugsgefahr der Antriebsketten @ 34\mod_1256045314627_78.docx @ 325616 @ 2 @ 1 WARNING! – Danger of entanglement in the drive chains! Effect: Risk of injury caused by entanglement of loose long hair or loose clothing.
Page 271 Maintenance Pos: 32.67 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.68 /BA/Wartung/Rundballenpresse/Spannen Ketten hinterer Rollbodenantrieb @ 34\mod_1256046927830_78.docx @ 325741 @ @ 1 RBV05050 Fig.
Page 272 Maintenance Pos: 32.70 /BA/Sicherheit/7. Gefahrenhinweise alt/Warnung - Quetschgefahr Pick-up @ 34\mod_1256048391518_78.docx @ 325820 @ 3 @ 1 WARNING! – Crush hazard! Effect: Foot injuries. • Lower pick-up to the ground. Pos: 32.71 /BA/Wartung/Rundballenpresse/Spannen Ketten Pick-up @ 34\mod_1256047612908_78.docx @ 325791 @ @ 1 Pick-up RBV06200 Fig.
Page 273 Maintenance Pos: 32.73 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 32.74 /BA/Wartung/Rundballenpresse/Spannen Ketten Walzenantrieb_F1250 (MC), F1600 (MC) @ 236\mod_1394454284250_78.docx @ 1872271 @ @ 1 Roller drive Fig.
Page 274 Maintenance Pos: 32.78 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ 3 @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.79 /BA/Wartung/Rundballenpresse/Spannen Ketten Walzenantrieb_V1500 (MC), V1800 (MC) @ 34\mod_1256111001113_78.docx @ 325866 @ 3 @ 1 Roller drive RP-A-004 Fig.
Page 275 Maintenance Pos: 32.83 /BA/Wartung/Rundballenpresse/Spannen Ketten Schneidwerkantrieb @ 34\mod_1256111461503_78.docx @ 325891 @ 3 @ 1 Cutting system drive RP-99-014 Fig. 251 The cutting system drive is located on the right side of the machine. To check the chain tension: The length of the spring when tightened must be a = 80 - 90 mm. To correct the chain tension: •...
Page 276 Maintenance Pos: 32.85.1 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) /Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 32.85.2 /BA/Wartung/Rundballenpresse/Rollbodenspannung_Zwischenüberschrift @ 241\mod_1395209479301_78.docx @ 1892321 @ 3 @ 1 Floor Conveyor Tension Pos: 32.85.3 /BA/Wartung/Rundballenpresse/Rollbodenspanner befindet sich_Fortima F1250 (MC), F1600 (MC) @ 241\mod_1395210949606_78.docx @ 1892660 @ @ 1 The floor conveyor tensioner is located right and left on the rear bale chamber housing below...
Page 277: Cleaning The Tensioning Arm Floor Conveyor Rear
Maintenance Pos: 32.87 /Überschriften/Überschriften 2/P-T/Spannarm Rollboden hinten reinigen @ 114\mod_1338811269488_78.docx @ 1005532 @ 233333 @ 1 13.14 Cleaning the Tensioning Arm Floor Conveyor Rear Pos: 32.88 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.89 /BA/Wartung/Rundballenpresse/Spannarm Rollboden fortima @ 114\mod_1338811641231_78.docx @ 1005557 @ @ 1 KRS-1-035...
Page 278: Shortening The Floor Conveyor Chain
Maintenance Pos: 32.91 /Überschriften/Überschriften 2/P-T/Rollbodenkette kürzen @ 34\mod_1256113648035_78.docx @ 325945 @ 22333 @ 1 13.15 Shortening the floor conveyor chain Pos: 32.92 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ 23 @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.93 /BA/Wartung/Rundballenpresse/Rollbodenkette prüfen @ 34\mod_1256113932581_78.docx @ 325966 @ @ 1 Checking the length of the rear floor conveyor chain...
Page 279 Maintenance Pos: 32.95 /BA/Wartung/Rundballenpresse/Rollbodenkette hinten kürzen @ 34\mod_1256115506378_78.docx @ 326016 @ 2222 @ 1 Shortening the rear floor conveyor chain KRS-1-201 Fig. 255 • Remove the wire pins (1) on either side. • Remove the strip (2). • Remove two chain links (3) from the floor conveyor chain (5). •...
Page 280: Tyres
If tyres are not correctly fitted, it could explode when pumped up. This can cause serious injury. If you do not have sufficient experience of fitting tyres, have tyres fitted by the KRONE dealer or a qualified tyre specialist. •...
Page 281: Checking And Maintaining Tyres
Maintenance Pos: 32.98.4 /Überschriften/Überschriften 3/P-T/Reifen prüfen und pflegen @ 0\mod_1197358037214_78.docx @ 18094 @ @ 1 13.16.1 Checking and maintaining tyres Pos: 32.98.5 /BA/Wartung/Reifen/Reihenfolge Bild 6-Loch @ 4\mod_1213086131413_78.docx @ 86197 @ @ 1 KS-0-034 Fig. 257 Pos: 32.98.6 /BA/Wartung/Reifen/Reihenfolge Reifenmontage Text @ 4\mod_1213085759054_78.docx @ 86177 @ 21 @ 1 When loosening and tightening the wheel nuts, observe the order indicated in the illustration.
Page 282: Tyre Air Pressure
Maintenance Pos: 32.98.9 /BA/Wartung/Reifen/Reifen-Luftdruck allgemein @ 0\mod_1199956852616_78.docx @ 37365 @ @ 1 13.16.2 Tyre air pressure Check the tyre pressure at regular intervals and refill if necessary. The tyre pressure depends on the size of the tyres. The values are listed in the table. Pos: 32.98.10 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) / F 1600 (MC) @ 113\mod_1338372324634_78.docx @ 1001105 @ @ 1 Fortima F 1250 (MC) / Fortima F 1600 (MC) Pos: 32.98.11 /BA/Wartung/Reifen/Rundballenpresse/Reifen-Luftdruck Tabelle Fortima F1250 (MC), F1600 (MC) @ 234\mod_1394016167685_78.docx @ 1861813 @ 233 @ 1...
Page 283 Maintenance Pos: 32.98.14 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.98.15 /BA/Wartung/Reifen/Rundballenpresse/Reifen-Luftdruck Tabelle Fortima V1500 (MC), V1800 (MC) @ 234\mod_1394015606485_78.docx @ 1861724 @ 2 @ 1 Single axle Tyre pressure (bar) min.
Page 284: Brakes
Maintenance Pos: 32.100 /Überschriften/Überschriften 2/A-E/Bremsen @ 0\mod_1197278385463_78.docx @ 16886 @ @ 1 13.17 Brakes Pos: 32.101 /BA/Sicherheit/7. Gefahrenhinweise alt/Einstellarbeiten / Einstellungen/Gefahr - Einstellarbeiten Selbsfahrer @ 0\mod_1196327276045_78.docx @ 6432 @ 233 @ 1 Danger! - Unexpected movement of the machine Effect: Danger to life or serious injuries. •...
Page 285: Adjusting The Cam Brake
Maintenance Pos: 32.104 /BA/Wartung/Rundballenpresse/Einstellung der Nockenbremse @ 34\mod_1255606127908_78.docx @ 324956 @ @ 1 13.17.2 Adjusting the cam brake RP-00-001 Fig. 258 Single axle - compressed air system At approx. 6 bar of compressed air the brake lever (1) must be located approx. 55 mm from the plate (2) in brake position.
Page 286 Maintenance Pos: 32.106 /BA/Wartung/Rundballenpresse/Bild Einstellung der Bremsbetätigung @ 34\mod_1255606960518_78.docx @ 324981 @ @ 1 Adjusting the brake activation Fig. 260 Pos: 32.107 /BA/Wartung/Rundballenpresse/Hinweis - Bremsbetätigung werkseitig eingestellt. Nachstellung erforderlich, wenn ... @ 236\mod_1394530000671_78.docx @ 1874012 @ @ 1 Note The brake activation has been adjusted in the factory. The brake must be readjusted: •...
Page 287 Maintenance Pos: 32.109 /BA/Wartung/Rundballenpresse/Einstellung Bremsbetätigung @ 236\mod_1394530686784_78.docx @ 1874037 @ 22 @ 1 Note Each time before you readjust the brake linkage (2a, 2b), the thickness of the lining on the brake shoes must be checked. The thickness of the lining must still be at least 2 mm. 1.
Page 288: Maintenance - Brake System (Special Equipment)
• Irregularities or malfunctions in the brake system must be eliminated immediately. • No changes may be made to the brake system without the approval of KRONE. • Have the brakes checked regularly by a specialist workshop. •...
Page 289: Coupling Heads (Non-Interchangeable)
Maintenance Pos: 32.111.5 /Überschriften/Überschriften 3/K-O/Kupplungsköpfe @ 34\mod_1255596655016_78.docx @ 324497 @ 22 @ 1 13.18.2 Coupling heads (non-interchangeable) Pos: 32.111.6 /BA/Wartung/Bremsanlage/Kupplungsköpfe Bild VP @ 34\mod_1255596792281_78.docx @ 324548 @ @ 1 RP-A-031 RP-A-032 "RESERVOIR" coupling head (colour red) "BRAKE" coupling head (colour yellow) Fig.
Page 290: Air Filter For Pipelines
Maintenance Pos: 32.111.9 /Überschriften/Überschriften 3/K-O/Luftfilter für Rohrleitungen @ 34\mod_1255595485391_78.docx @ 324472 @ 3 @ 1 13.18.3 Air filter for pipelines Pos: 32.111.10 /BA/Wartung/Bremsanlage/Luftfilter/Luftfilter für Rohrleitung Bild CF/Luftfilter für Rohrleitung Bild CF/CV @ 76\mod_1310027669344_78.docx @ 666250 @ @ 1 CP102200 Fig. 262 Pos: 32.111.11 /BA/Wartung/Bremsanlage/Luftfilter/Luftfilter für Rohrleitung Aufzählung @ 6\mod_1214888028238_78.docx @ 96691 @ @ 1 (1) Spring (4) Spring...
Page 291: Compressed-Air Reservoir
Maintenance Pos: 32.111.17 /Überschriften/Überschriften 3/A-E/Druckluftbehälter @ 34\mod_1255593348281_78.docx @ 324372 @ 22 @ 1 13.18.4 Compressed-air reservoir Pos: 32.111.18 /BA/Wartung/Druckluftbehälter/Druckluftbehälter Bild VP1502 @ 34\mod_1255594168750_78.docx @ 324393 @ @ 1 RP-A-030 Fig. 263 Pos: 32.111.19 /BA/Wartung/Druckluftbehälter/Druckluftbehälter_Text 20 Betriebsstunden @ 0\mod_1200293406164_78.docx @ 39343 @ 3323 @ 1 The compressed-air reservoir stores the compressed air that is pumped by the compressor.
Page 292: Hydraulics
Ensure that all line connections are tight before the pressure in the system builds up again. • Repair work on the hydraulic system must only be performed by authorised KRONE professional workshops. Pos: 32.113.4 /BA/Sicherheit/Hydraulik/Gefahr - Hydraulikschlauchleitungen unterliegen einer Alterung @ 256\mod_1397735975770_78.docx @ 1965100 @ @ 1 WARNING! –...
Page 293: Shut-Off Valve For Tailgate
Maintenance Pos: 32.113.6 /BA/Wartung/Großpackenpressen/Hydraulikanlage / Bordhydraulik/Hinweis zu Hydraulikarbeiten @ 24\mod_1241518053726_78.docx @ 245734 @ 123 @ 1 Note • When working on the hydraulic system, absolute cleanliness is essential • Check the hydraulic oil level each time before placing the machine in operation •...
Page 294: Control Block
Maintenance Pos: 32.113.11 /Überschriften/Überschriften 3/P-T/Steuerblock @ 34\mod_1255597822297_78.docx @ 324597 @ 3111212 @ 1 13.19.2 Control block Pos: 32.113.12 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ 22 @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.113.13 /BA/Wartung/Rundballenpresse/Bild Steuerblock VP @ 34\mod_1255598235391_78.docx @ 324643 @ 22 @ 1 VP-1-066 Fig.
Page 295: Emergency Manual Activation Electromagnetic Valves (Mc Cutting System)
Maintenance Pos: 32.113.16 /Überschriften/Überschriften 3/K-O/Not-Hand-Betätigung Elektromagnetventil (MC-Schneidwerk) @ 117\mod_1341209798446_78.docx @ 1021039 @ 22 @ 1 13.19.3 Emergency Manual Activation Electromagnetic Valves (MC Cutting System) Pos: 32.113.17 /BA/Sicherheit/7. Gefahrenhinweise alt/Ladewagen/Gefahr Not-Hand-Betätigung @ 0\mod_1199945455397_78.docx @ 36965 @ @ 1 Danger! - Unexpected actions on the machine. Effect: Danger to life or serious injuries.
Page 296: Replacing The Hydraulic Oil Filter
Maintenance Pos: 32.113.21 /Überschriften/Überschriften 3/F-J/Hydraulikölfilter wechseln @ 34\mod_1255587384500_78.docx @ 324072 @ @ 1 13.19.4 Replacing the Hydraulic Oil Filter Pos: 32.113.22 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.113.23 /BA/Wartung/Umwelt/Hinweis Entsorgen / Lagern von Öle und Ölfilter Umwelt @ 32\mod_1253101375171_78.docx @ 311770 @ 22 @ 1 ENVIRONMENT! - Disposal and storage of used lubricants and oil filters Effect: Environmental damage...
Page 297 Maintenance Replacing the filter element Note Store or dispose used oil and oil filters according to statutory provisions. • Relieve all pressure from the hydraulic system. • Screw the bottom of the filter (4) off the filter head piece (1) and clean it. •...
Page 298: Lifting
Maintenance Pos: 32.115 /Überschriften/Überschriften 2/A-E/Anheben @ 33\mod_1254380091415_78.docx @ 319041 @ 2222 @ 1 13.20 Lifting Pos: 32.116 /BA/Wartung/Rundballenpresse/Anheben der Maschine @ 114\mod_1338467456755_78.docx @ 1003130 @ 2222 @ 1 13.20.1 Lifting Eyes The baler is equipped with three suspension points: • A suspension point is located in the front area of the drawbar.
Page 299: Maintenance - Lubrication
Maintenance – lubrication Pos: 32.118.1 /Überschriften/Überschriften 1/U-Z/Wartung - Schmierung @ 24\mod_1241675457008_78.docx @ 247325 @ 2232 @ 1 Maintenance – lubrication Pos: 32.118.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 33 @ 1 14.1 Special Safety Instructions Pos: 32.118.3 /BA/Sicherheit/Rundballenpresse/Gefahr- Wartungs-, Montage-, Reparatur- und Einstellarbeiten Schmierung @ 240\mod_1395126884169_78.docx @ 1888819 @ @ 1 Danger! - Maintenance, installation, repair and adjustment work, troubleshooting and fault resolution Effect: Risk of death, injuries or damage to the machine.
Page 300: Lubricants
Maintenance – lubrication Pos: 32.118.6 /Überschriften/Überschriften 2/P-T/Schmierfette / Schmieröle @ 24\mod_1241676102945_78.docx @ 247353 @ 33 @ 1 14.2 Lubricants Pos: 32.118.7 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Allgemeines unterschiedliche Schmiersysteme @ 24\mod_1241676457180_78.docx @ 247436 @ @ 1 14.3 General aspects Depending on the design, the machine may be equipped with different lubrication systems. Soft, supple NLGI Class 2 lithium soap greases in accordance with DIN 51825 should be used as lubricating greases.
Page 301: Lubrication Points
Maintenance – lubrication Pos: 32.118.14 /BA/Wartung/Großpackenpressen/Schmierung / Schmierplan/Schmierstellen @ 24\mod_1241705838930_78.docx @ 248021 @ @ 1 14.5 Lubrication points The following tables contain a list of lubrication points on the machine and the number of lubrication nipples. Pos: 32.118.15 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) /Fortima F 1250 (MC) / F 1600 (MC)_sprachneutral @ 235\mod_1394190129453_0.docx @ 1869654 @ @ 1 Fortima F 1250 (MC) / F 1600 (MC) Pos: 32.118.16 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Tabelle Schmierstellen Fortima F @ 115\mod_1339676620578_78.docx @ 1012472 @ @ 1 Lubrication points...
Page 302 Maintenance – lubrication Pos: 32.118.18 /Abkürzungen /Abkürzungen Beschreibung/Linke Maschinenseite @ 235\mod_1394183788198_78.docx @ 1869099 @ @ 1 Left Machine Side Pos: 32.118.19 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Bild Schmierplan links Fortima F @ 114\mod_1338812916132_78.docx @ 1005784 @ @ 1 100h 100h FOR00049_1 Fig. 269 Pos: 32.118.20 /Layout Module ---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ 3 @ 1...
Page 303 Maintenance – lubrication Pos: 32.118.21 /Abkürzungen /Abkürzungen Beschreibung/Rechte Maschinenseite @ 235\mod_1394183790425_78.docx @ 1869128 @ @ 1 Right Machine Side Pos: 32.118.22 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Bild Schmierplan rechts Fortima F @ 114\mod_1338812885213_78.docx @ 1005615 @ @ 1 100h FOR00048_1 Fig. 270 Pos: 32.118.23 /Layout Module ---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 304 Maintenance – lubrication Pos: 32.118.24 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) /Fortima V 1500 (MC) / V 1800 (MC)_sprachneutral @ 226\mod_1392720827776_0.docx @ 1826878 @ @ 1 Fortima V 1500 (MC) / V 1800 (MC) Pos: 32.118.25 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Tabelle Schmierstellen VP @ 35\mod_1256133082003_78.docx @ 326717 @ @ 1 Lubrication points Number of grease nipples Parking jack...
Page 305 Maintenance – lubrication Pos: 32.118.27 /Abkürzungen /Abkürzungen Beschreibung/Linke Maschinenseite @ 235\mod_1394183788198_78.docx @ 1869099 @ @ 1 Left Machine Side Pos: 32.118.28 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Bild Schmierplan links Fortima V @ 35\mod_1256134316035_78.docx @ 326816 @ @ 1 Fig. 271 Pos: 32.118.29 /Layout Module ---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 306 Maintenance – lubrication Pos: 32.118.30 /Abkürzungen /Abkürzungen Beschreibung/Rechte Maschinenseite @ 235\mod_1394183790425_78.docx @ 1869128 @ @ 1 Right Machine Side Pos: 32.118.31 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Bild Schmierplan rechts Fortima V @ 35\mod_1256134074660_78.docx @ 326766 @ @ 1 Fig. 272 Pos: 32.118.32 /Layout Module ---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1...
Page 307: Chain Lubrication System
Maintenance – lubrication Pos: 32.118.33 /Überschriften/Überschriften 3/K-O/Kettenschmierung @ 118\mod_1342006982507_78.docx @ 1066384 @ @ 1 14.5.1 Chain Lubrication System Pos: 32.118.34 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) / F 1600 (MC) @ 113\mod_1338372324634_78.docx @ 1001105 @ @ 1 Fortima F 1250 (MC) / Fortima F 1600 (MC) Pos: 32.118.35 /BA/Wartung/Rundballenpresse/Schmierung/Schmierplan/Kettenschmierung-keine Zentralschmierung vorhanden @ 118\mod_1342007057565_78.docx @ 1066409 @ @ 1 Note The following lubrication points must only be lubricated if there is no central lubrication...
Page 308: Placing In Storage
Placing in Storage Pos: 34.1 /Überschriften/Überschriften 1/A-E/Einlagerung @ 0\mod_1197385459120_78.docx @ 19966 @ @ 1 Placing in Storage Pos: 34.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ 1112 @ 1 15.1 Special Safety Instructions Pos: 34.3 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Gefahr Wartung allgemein Rundballenpresse @ 209\mod_1387362869846_78.docx @ 1724785 @ 12 @ 1 DANGER! - During repair, maintenance, cleaning work or technical interventions on the machine, drive elements can start moving.
Page 309: At The End Of The Harvest Season
Perform the necessary repair tasks during the time immediately after the harvest season. Draw up a list of all replacement parts you will need. This will make it easier for your KRONE dealer to process your orders and you will be certain that your machine will be ready for use at the beginning of the next season.
Page 310: Before The Start Of The New Season
Placing in Storage Pos: 34.8 /Überschriften/Überschriften 2/U-Z/Vor Beginn der neuen Saison @ 0\mod_1197386024448_78.docx @ 20081 @ @ 1 15.3 Before the Start of the New Season Pos: 34.9 /BA/Sicherheit/7. Gefahrenhinweise alt/Rundballenpresse/Gefahr Wartung allgemein Rundballenpresse @ 209\mod_1387362869846_78.docx @ 1724785 @ @ 1 DANGER! - During repair, maintenance, cleaning work or technical interventions on the machine, drive elements can start moving.
Page 311: Maintenance Work Before The Beginning Of The New Season
Placing in Storage Pos: 34.12 /Überschriften/Überschriften 3/U-Z/Wartungsarbeiten vor Beginn der neuen Saison @ 115\mod_1339075746437_78.docx @ 1009040 @ @ 1 15.3.1 Maintenance work before the beginning of the new season Pos: 34.13 /BA/Einlagerung/Rundballenpressen/Bremsscheibe @ 35\mod_1256135763691_78.docx @ 326892 @ @ 1 Fig. 274 •...
Page 312: Venting The Overload Coupling On The Pto Shaft
Placing in Storage Pos: 34.16 /BA/Einlagerung/Rundballenpressen/Überlastkupplung an Gelenkwelle Comprima @ 96\mod_1328790282568_78.docx @ 822224 @ @ 1 15.3.2 Venting the overload coupling on the PTO shaft Friction clutch only COM00337 Fig. 276 Following extended downtimes, overload coupling surfaces (2) may stick to the contact surfaces.
Page 313: Malfunctions - Causes And Remedies
Malfunctions - Causes and Remedies Pos: 36.1 /Überschriften/Überschriften 1/P-T/Störungen - Ursachen und Behebung @ 0\mod_1200296925180_78.docx @ 39459 @ @ 1 Malfunctions - Causes and Remedies Pos: 36.2 /Überschriften/Überschriften 2/P-T/Spezielle Sicherheitshinweise @ 0\mod_1196660495760_78.docx @ 9134 @ @ 1 16.1 Special Safety Instructions Pos: 36.3 /BA/Sicherheit/7.
Page 314: General Malfunctions
Malfunctions - Causes and Remedies Pos: 36.5 /Überschriften/Überschriften 2/A-E/Allgemeine Störungen @ 24\mod_1241775122213_78.docx @ 248807 @ @ 1 16.2 General malfunctions Pos: 36.6 /BA/Störungen - Ursachen und Behebung/Rundballenpressen/Tabellarische Auflistung Allgemein Fortima @ 235\mod_1394192969884_78.docx @ 1870010 @ @ 1 Malfunction Possible cause Remedy Pick-up cannot be Hydraulic hose is not inserted.
Page 315 Malfunctions - Causes and Remedies Malfunction Possible cause Remedy Just use net rollers with prescribed Net is not transported The dimensions of the net are dimensions. during starting process. incorrect. The tension wheel is not pressed Check setting motor or make freewheel against the V-belt or the move smoothly.
Page 316 Malfunctions - Causes and Remedies Malfunction Possible cause Remedy The net does not reach the If the crop is crumbly, the Mount screw (1) M8 x 40 with nuts (2) bale. deflector plate (3) is pressed right and left of the deflector plate upward.
Page 317: Malfunctions On The Central Chain Lubrication System
Malfunctions - Causes and Remedies Pos: 36.8 /Überschriften/Überschriften 2/P-T/Störungen an der zentralen Kettenschmierung @ 35\mod_1256199185431_78.docx @ 327048 @ @ 1 16.3 Malfunctions on the central chain lubrication system Pos: 36.9 /BA/Störungen - Ursachen und Behebung/Rundballenpressen/Tabellarische Auflistung Kettenschmierung @ 240\mod_1395153485543_78.docx @ 1891808 @ @ 1 Malfunction Possible cause Remedy...
Page 318: Error Messages Of Krone Operation Terminal
Malfunctions - Causes and Remedies Pos: 36.11 /Überschriften/Überschriften 2/F-J/Fehlermeldungen der KRONE Bedienterminals @ 77\mod_1310045429649_78.docx @ 667242 @ @ 1 16.4 Error Messages of KRONE Operation Terminal Pos: 36.12 /BA/Störungen - Ursachen und Behebung/Rundballenpressen/Fehlermeldungen Display ISOBUS, Beta @ 235\mod_1394191586324_78.docx @ 1869861 @ @ 1 The error messages in the display are described depending on how the machine is fitted in the Chapters "KRONE ISOBUS-Terminal"...
Page 319: Appendix
Appendix Pos: 38 /Überschriften/Überschriften 1/A-E/Anhang @ 1\mod_1202278612285_78.docx @ 58360 @ @ 1 Appendix Pos: 39 /Überschriften/Überschriften 2/F-J/Hydraulikschaltplan @ 11\mod_1223527787398_78.docx @ 147580 @ @ 1 17.1 Hydraulic System Circuit Diagrams Pos: 40 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima F 1250 (MC) / F 1600 (MC) @ 113\mod_1338372324634_78.docx @ 1001105 @ @ 1 Fortima F 1250 (MC) / Fortima F 1600 (MC) Pos: 41 /BA/Wartung/Rundballenpresse/Hydraulikschaltplan Fortima F1250 @ 114\mod_1338814404296_78.docx @ 1005813 @ @ 1 FOR00041...
Page 320 Appendix Pos: 43 /Abkürzungen /Abkürzungen sprachneutral/Rundballenpressen/Fortima V 1500 (MC) / V 1800 (MC) @ 113\mod_1338372129781_78.docx @ 1000906 @ @ 1 Fortima V 1500 (MC) / Fortima V 1800 (MC) Pos: 44 /BA/Wartung/Rundballenpresse/Hydraulikschaltplan Fortima @ 114\mod_1338876235055_78.docx @ 1006281 @ @ 1 14 bar 15 - 200 bar 20 bar...
Page 321: Electrical Circuit Diagram
Pos: 46 /Überschriften/Überschriften 2/A-E/Elektroschaltplan @ 11\mod_1223544391539_78.docx @ 147914 @ @ 1 17.2 Electrical circuit diagram === Ende der Liste für Textmarke Inhalt ===...
Page 326 Diagnostics - power supply voltages ....96 Alarm messages ........102, 157 Diagnostics Auxiliary Functions (AUX) .... 156 Appendix ............319 Differing functions to KRONE ISOBUS terminal Assemble spacers (Fortima V 1800 (MC)) ..45 CCI ............... 164 Assembly and disassembly of the bale ejector 218 Display .............
Page 327 Note and messages ......... 103, 159 ISOBUS-Terminal ..........106 Number of net winds ........123 K Number of Twine Wraps ........130 KRONE operation terminal Beta ......56 O L Oil Level Check and Oil Change Intervals Lifting ..............298 (Gearboxes) ..........
Page 328 Position of the Adhesive Safety Stickers on the Setting the tying twine in place ......224 Machine ............26 Settings ............235 Position of the Sensors ........258 Settings Before Starting Work ......186 Possible motors (depending on how the machine Shear screw for pick-up drive ......
Page 330 . . konsequent, kompetent Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Straße 10, D-48480 Spelle Postfach 11 63, D-48478 Spelle Phone +49 (0) 59 77/935-0 +49 (0) 59 77/935-339 Internet: http://www.krone.de eMail: info.ldm@krone.de...

This manual is also suitable for:

Fortima f 1600 mc Fortima v 1500 mc Fortima v 1800 mc Fortima f 1250 Fortima f 1600 Fortima v 1500 ... Show all

Krone Fortima F 1250 MC Original Operating Instructions

Quick Links

Related Manuals for Krone Fortima F 1250 MC

Summary of Contents for Krone Fortima F 1250 MC
